GLO-RAY®
Que Warmer
QW-6 Series
Installation and Operating anual
I&W #07.05.128.00

i
CONTENTS
Form No. QWM-0208
INTRODUCTION
The Hatco Glo-Ray Que Warmer is designed to hold
melted, liquid, or soft food product such as butter,
syrup, gravy, and mashed potatoes at 170°F (77°C).
It will keep the food product at optimum serving
temperatures without affecting quality. An internal,
preset temperature control and uniform heat
distribution along the sides and bottom of the pan
ensure even heating and holding.
The Glo-Ray Que Warmer is a product of extensive
research and field testing. The materials used were
selected for maximum durability, attractive
appearance, and optimum performance. Every unit
is inspected and tested thoroughly prior to shipment.
This manual provides the installation, safety, and
operating instructions for the Glo-Ray Que Warmer.
Hatco recommends all installation, operating, and
safety instructions appearing in this manual be read
prior to installation or operation of the Glo-Ray Que
Warmer.
Safety information that appears in this manual is
identified by the following signal word panels:
WARNING indicates a hazardous situation
which, if not avoided, could result in death or
serious injury.
CAUTION indicates a hazardous situation which,
if not avoided, could result in minor or moderate
injury.
NOTICE is used to address practices not related
to personal injury.
WARNING
NOTICE
CAUTION
Important Owner Information...............................i
Introduction ...........................................................i
Important Safety Information..............................1
odel Description................................................2
odel Designation ...............................................2
Specifications.......................................................3
Plug Configurations .........................................3
Electrical Rating Chart.....................................3
Dimensions......................................................3
Installation ............................................................4
General............................................................4
Operation ..............................................................4
General............................................................4
aintenance .........................................................5
General............................................................5
Cleaning...........................................................5
Troubleshooting Guide........................................6
Hatco Limited Warranty.......................................9
Authorized Parts Distributors ...........Back Cover
I PORTANT OWNER INFOR ATION
Record the model number, serial number, voltage
and purchase date of your Glo-Ray®Que Warmer in
the spaces below. Please have this information
available when contacting Hatco for service
assistance.
Model No. ____________________________________
Serial No. ____________________________________
Voltage ______________________________________
Date of Purchase ______________________________
Business 8:00 a.m. to 5:00 p.m.
Hours: Central Standard Time
(Summer Hours: June to September –
8:00 a.m. to 5:00 p.m. C.S.T.
Monday through Thursday
8:00 a.m. to 2:30 p.m. C.S.T. Friday)
Telephone: [phone]
Fax: [phone] (Parts and Service)
[phone] (International)
24 Hour 7 Day Parts and Service
Assistance available in the
United States and Canada
by calling [phone].
Additional information can be found by visiting our
web site at www.hatcocorp.com.

I PORTANT SAFETY INFOR ATION
Form No. QWM-0208 1
ELECTRIC SHOCK HAZARD:
• Plug unit into a properly grounded electrical
outlet of the correct voltage, size, and plug
configuration. If the plug and receptacle do
not match, contact a qualified electrician to
determine and install the proper voltage and
size electrical outlet.
• Turn the power switch OFF, unplug the power
cord, and allow the unit to cool before
performing any maintenance or cleaning.
• DO NOT submerge or saturate with water.
Unit is not waterproof. Do not operate if unit
has been submerged or saturated with water.
• Unit is not weatherproof. Locate the unit
indoors where the ambient air temperature is
a minimum of 70°F (21°C).
• Do not pull unit by power cord.
• Discontinue use if power cord is frayed or
worn.
• Do not attempt to repair or replace a
damaged power cord. The cord must be
replaced by Hatco, an Authorized Hatco
Service Agent, or a person with similar
qualifications.
• Do not use corrosive cleaning agents to
clean the unit. Corrosive cleaning agents
may eat through the unit, allowing liquids
into the housing.
• Use only Genuine Hatco Replacement Parts
when service is required. Failure to use
Genuine Hatco Replacement Parts may
subject operators of the equipment to
hazardous electrical voltage, resulting in
electrical shock or burn. Genuine Hatco
Replacement Parts are specified to operate
safely in the environments in which they are
used. Some aftermarket or generic
replacement parts do not have the
characteristics that will allow them to operate
safely in Hatco equipment.
WARNING
FIRE HAZARD: Locate the unit a minimum of 1″
(25 mm) from combustible walls and materials. If
safe distances are not maintained, combustion
or discoloration could occur.
ake sure food product has been heated to the
proper food-safe temperature before placing in
the unit. Failure to heat food product properly
may result in serious health risks. This unit is
for holding pre-heated food product only.
This unit has no “user-serviceable” parts. If
service is required on this unit, contact an
Authorized Hatco Service Agent or contact the
Hatco Service Department at 800-558-0607 or
414-671-6350; fax [phone]; or International
fax [phone].
BURN HAZARD:
• Some exterior surfaces on the unit will get
hot. Use caution when touching these areas.
• Do not move or relocate unit while it contains
food product. Remove product pan and allow
unit to cool completely before moving or
cleaning.
Locate the unit at the proper counter height in
an area that is convenient for use. The location
should be level to prevent the unit or its
contents from falling accidentally and strong
enough to support the weight of the unit and its
contents.
Do not lay unit on the side with the control panel
or damage to the unit could occur.
Use non-abrasive cleaners only. Abrasive
cleaners could scratch the finish of the unit,
marring its appearance and making it
susceptible to soil accumulation.
WARNING
NOTICE
CAUTION
Read the following important safety information before using this equipment to avoid
serious injury or death and to avoid damage to equipment or property.

ODEL DESCRIPTION
2Form No. QWM-0208
ODEL DESIGNATION
QW-6 odel
The QW-6 Que Warmer is ideal for holding melted,
liquid, or soft food products such as butter, syrup,
gravy, and mashed potatoes at an even 170°F
(77°C) temperature. The unit comes equipped with
a built-in 1/6 size steam table pan, 6″ (152 mm)
deep and constructed of sturdy stainless steel.
Features include an illuminated power switch and
heavy-duty cord grip. Utilizing an internal, preset
temperature control and heating element, the unit
evenly distributes heat along the sides and bottom
of the pan.
The QW-6 Que Warmer is a portable unit for easy
placement options. All QW-6 models are shipped
from the factory completely assembled and ready
for use.
Figure 1. QW-6 Model
QW-6
Que Warmer Size of Built-In Pan
6 = 1/6 Size Steam Table Pan
Figure 2. Model Designation

SPECIFICATIONS
Form No. QWM-0208 3
Figure 4. QW-6 Model Dimensions
Dimensions
Plug Configurations
Units are supplied from the factory with an electrical
cord and plug installed. Plugs are supplied
according to the applications as shown in Figure 3.
ELECTRIC SHOCK HAZARD: Plug unit into a
properly grounded electrical outlet of the correct
voltage, size, and plug configuration. If the plug
and receptacle do not match, contact a qualified
electrician to determine and install the proper
voltage and size electrical outlet.
WARNING
Footprint Footprint
odel Width (A) Depth (B) Height (C) Width (D) Depth (E)
QW-6 7-1/2″ (191 mm) 7″ (178 mm) 8-3/8″ (213 mm) 7″ (178 mm) 6-1/2″ (165 mm)
RearView Side View
A
DE
B
C
Plug Shipping
odel Voltage Watts Amps Configuration Weight
QW-6 120 110 0.9 NEMA 5-15P 10 lbs. (4.5 kg)
Electrical Rating Chart
Figure 3. Plug Configuration
NEMA 5-15P
NOTE: Receptacle not supplied by Hatco.

INSTALLATION
4Form No. QWM-0208
General
Read all safety messages in the I PORTANT
SAFETY INFOR ATION section before
operating this equipment.
1. Plug the unit into a properly grounded electrical
outlet of the correct voltage, size, and plug
configuration. See the SPECIFICATIONS
section for details.
2. Move the power switch to the ON position (see
Figure 5). The switch will illuminate.
3. Allow the unit 15–20 minutes to reach operating
temperature.
4. Fill a separate, 1/6 size steam table pan or high
temperature amber pan with pre-heated food
product.
Do not put food product directly into unit. A
separate food product pan must be used. Failure
to use a separate pan may result in improper
cleaning and create an electric shock hazard.
ake sure food product has been heated to the
proper food-safe temperature before placing in
the unit. Failure to heat food product properly
may result in serious health risks. This unit is
for holding pre-heated food product only.
5. Place the filled product pan into the unit. For
best results, keep the product pan covered.
WARNING
WARNING
Figure 5. QW-6 Operating Controls
BURN HAZARD:
• Some exterior surfaces on the unit will get
hot. Use caution when touching these areas.
• Do not move or relocate unit while it contains
food product. Remove product pan and allow
unit to cool completely before moving or
cleaning.
Power CordPower Switch
OPERATION
General
The Que Warmer is shipped from the factory with
all components assembled and ready for use.
1. Remove the unit from the box.
2. Remove the information packet.
NOTE: To prevent delay in obtaining warranty
coverage, fill out and mail in the warranty
card to Hatco.
3. Remove tape and protective packaging from all
surfaces of unit.
FIRE HAZARD: Locate the unit a minimum of 1″
(25 mm) from combustible walls and materials. If
safe distances are not maintained, combustion
or discoloration could occur.
WARNING
4. Place the unit in the desired location.
• Make sure the unit is at the proper counter
height in an area convenient for use.
• Make sure the countertop is level and strong
enough to support the weight of the unit filled
with product.
• Make sure all the feet on the bottom of the
unit are positioned securely on the
countertop.

AINTENANCE
Form No. QWM-0208 5
General
The Hatco Que Warmer is designed for maximum
durability and performance with minimum
maintenance.
ELECTRIC SHOCK HAZARD:
• Turn the power switch OFF, unplug the power
cord, and allow the unit to cool before
performing any maintenance or cleaning.
• DO NOT submerge or saturate with water.
Unit is not waterproof. Do not operate if unit
has been submerged or saturated with water.
• Do not use corrosive cleaning agents to
clean the unit. Corrosive cleaning agents
may eat through the unit, allowing liquids
into the housing.
Use non-abrasive cleaners only. Abrasive
cleaners could scratch the finish of the unit,
marring its appearance and making it
susceptible to soil accumulation.
Submerging or saturating the unit with water
will damage the unit and void the product
warranty.
NOTICE
WARNING
Cleaning
To preserve the finish of the Glo-Ray Que Warmer,
it is recommended that the surfaces be wiped daily
with a moist cloth. The built-in 1/6 size steam table
pan should be washed using a clean damp cloth
with mild soap and wiped clean with a damp cloth.
WARNING! Do not submerge unit in water.
Stubborn stains may be removed with a good
stainless steel cleaner or a non-abrasive cleaner.
Hard to reach areas should be cleaned with a small
brush and mild soap.
This unit has no “user-serviceable” parts. If
service is required on this unit, contact an
Authorized Hatco Service Agent or contact the
Hatco Service Department at 800-558-0607 or
414-671-6350; fax [phone]; or International
fax [phone].
WARNING

Form No. QWM-0208
6
TROUBLESHOOTING GUIDE
Unit too hot.
Unit not hot enough.
Unit not working at all.
Temperature control defective.
Unit not on long enough.
Food product in product pan not
heated to proper temperature before
placing in unit.
Unit not plugged in.
Unit not turned on.
Power ON/OFF switch is not
functioning.
Heating element is burned out.
Thermostat control is defective.
Move power switch to the ON
position.
Contact Authorized Service Agent
or Hatco for assistance.
Contact Authorized Service Agent
or Hatco for assistance.
Contact Authorized Service Agent
or Hatco for assistance.
Plug unit into proper power
supply.
Allow unit to warm up for 15 – 20
minutes before placing product
pan into unit.
Heat food product to proper food-
safe temperature before placing
in unit.
Contact Authorized Service
Agent or Hatco for assistance.
Symptom Probable Cause Corrective Action
This unit must be serviced by qualified
personnel only. Service by unqualified
personnel may lead to electric shock or burn.
WARNING
ELECTRIC SHOCK HAZARD: Turn the power
switch OFF, unplug the power cord, and allow
the unit to cool before performing any
maintenance or cleaning.
WARNING

NOTES
Form No. QWM-0208 7

Form No. QWM-0208
8
NOTES

HATCO LI ITED WARRANTY
1. PRODUCT WARRANTY
Hatco warrants the products that it manufactures
(the “Products”) to be free from defects in materials
and workmanship, under normal use and service,
for a period of one (1) year from the date of
purchase when installed and maintained in
accordance with Hatco’s written instructions or 18
months from the date of shipment from Hatco. Buyer
must establish the product’s purchase date by
returning Hatco’s Warranty Registration Card or by
other means satisfactory to Hatco in its sole
discretion.
Hatco warrants the following Product components to
be free from defects in materials and workmanship
from the date of purchase (subject to the foregoing
conditions) for the period(s) of time and on the
conditions listed below:
a) One (1) Year Parts and Labor PLUS One
(1) Additional Year Parts-Only Warranty:
Toaster Elements (metal sheathed)
Drawer Warmer Elements (metal sheathed)
Drawer Warmer Drawer Rollers and Slides
Food Warmer Elements (metal sheathed)
Display Warmer Elements (metal sheathed air
heating)
Holding Cabinet Elements (metal sheathed air
heating)
Built-In Heated Well Elements
(metal sheathed)
b) One (1) Year Parts and Labor PLUS Four
(4) Years Parts-Only Warranty on
pro-rated terms that Hatco will explain
at Buyer’s request:
3CS and FR Tanks
c) One (1) Year Parts and Labor PLUS Nine
(9) Years Parts-Only Warranty on:
Electric Booster Heater Tanks
Gas Booster Heater Tanks
THE FOREGOING WARRANTIES ARE
EXCLUSIVE AND IN LIEU OF ANY OTHER
WARRANTY, EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE OR
PATENT OR OTHER INTELLECTUAL PROPERTY
RIGHT INFRINGEMENT. Without limiting the
generality of the foregoing, SUCH WARRANTIES
DO NOT COVER: Coated incandescent light bulbs,
fluorescent lights, lamp warmer heat bulbs, glass
components, Product failure in booster tank, fin tube
heat exchanger, or other water heating equipment,
caused by liming, sediment buildup, chemical attack
or freezing, Product misuse, tampering or
misapplication, improper installation or application of
improper voltage.
2. LI ITATION OF RE EDIES AND DA AGES
Hatco’s liability and Buyer’s exclusive remedy
hereunder will be limited solely, at Hatco’s option, to
repair or replacement by a Hatco-authorized service
agency (other than where Buyer is located outside
of the United States, Canada, United ingdom or
Australia in which case Hatco’s liability and Buyer’s
exclusive remedy hereunder will be limited solely to
replacement of part under warranty) with respect to
any claim made within the applicable warranty
period referred to above. Hatco reserves the right to
accept or reject any such claim in whole or in part.
Hatco will not accept the return of any Product
without prior written approval from Hatco, and all
such approved returns shall be made at Buyer’s
sole expense. HATCO WILL NOT BE LIABLE,
UNDER ANY CIRCUMSTANCES, FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES,
INCLUDING BUT NOT LIMITED TO LABOR
COSTS OR LOST PROFITS RESULTING FROM
THE USE OF OR INABILITY TO USE THE
PRODUCTS OR FROM THE PRODUCTS BEING
INCORPORATED IN OR BECOMING A
COMPONENT OF ANY OTHER PRODUCT OR
GOODS.
9
Form No. QWM-0208

HATCO CORPORATION
P.O. Box 340500
Milwaukee, WI 53234-0500 U.S.A.
[phone] [phone]
Parts and Service Fax [phone]
International Fax [phone]
www.hatcocorp.com
Printed in U.S.A. February 2008 Part No. 07.04.358.00 Form No. QWM-0208
HATCO AUTHORIZED PARTS DISTRIBUTORS
ALABA A
Jones McLeod Appl. Svc.
Birmingham 205-251-0159
ARIZONA
Auth. Comm. Food Equip.
Phoenix 602-234-2443
Byassee Equipment Co.
Phoenix 602-252-0402
CALIFORNIA
Industrial Electric
Commercial Parts & Service, Inc.
Huntington Beach 714-379-7100
Chapman Appl. Service
San Diego 619-298-7106
P & D Appliance
Commercial Parts & Service, Inc.
S. San Francisco 650-635-1900
COLORADO
Hawkins Commercial Appliance
Englewood 303-781-5548
FLORIDA
Whaley Foodservice Repair
Jacksonville 904-725-7800
Nass Service Co., Inc.
Orlando 407-425-2681
B.G.S.I.
Pompano Beach 954-971-0456
Comm. Appliance Service
Tampa 813-663-0313
GEORGIA
TWC Services
Smyrna 770-438-9797
Heritage Service Group
Norcross 866-388-9837
Southeastern Rest. Svc.
Norcross 770-446-6177
HAWAII
Burney’s Comm. Service, Inc.
Honolulu 808-848-1466
Food Equip Parts & Service
Honolulu 808-847-4871
ILLINOIS
Parts Town
Lombard 708-865-7278
Eichenauer Elec. Service
Decatur 217-429-4229
Midwest Elec. Appl. Service
Elmhurst 630-279-8000
Cone’s Repair Service
Moline 309-797-5323
INDIANA
GCS Service
Indianapolis 317-545-9655
IOWA
Electric Motor Service Co.
Davenport 319-323-1823
Goodwin Tucker Group
Des Moines 515-262-9308
KENTUCKY
Certified Service Center
Lexington 859-254-8854
Certified Service Center
Louisville 502-964-7007
LOUISIANA
Chandlers Parts & Service
Baton Rouge 225-272-6620
ARYLAND
Electric Motor Service
Baltimore 410-467-8080
GCS Service
Silver Spring 301-585-7550
ASSACHUSETTS
Ace Service Co., Inc.
Needham 781-449-4220
ICHIGAN
Commercial itchen Service
Bay City 517-893-4561
Bildons Appliance Service
Detroit 248-478-3320
Midwest Food Equip. Service
Grandville 616-261-2000
INNESOTA
GCS Service
Minneapolis 612-546-4221
ISSOURI
General Parts
ansas City 816-421-5400
Commercial itchen Services
St. Louis 314-890-0700
aemmerlen Parts & Service
St. Louis 314-535-2222
NEBRASKA
Anderson Electric
Omaha 402-341-1414
NEVADA
Burney’s Commercial
Las Vegas 702-736-0006
Hi. Tech Commercial Service
N. Las Vegas 702-649-4616
NEW JERSEY
Jay Hill Repair
Fairfield 973-575-9145
Service Plus
Flanders 973-691-6300
NEW YORK
Acme American Repairs, Inc.
Brooklyn 718-456-6544
Alpro Service Co.
Brooklyn 718-386-2515
Appliance Installation
Buffalo 716-884-7425
Northern Parts Dist.
Plattsburgh 518-563-3200
J.B. Brady, Inc.
Syracuse 315-422-9271
NORTH CAROLINA
Authorized Appliance
Charlotte 704-377-4501
OHIO
Akron/Canton Comm. Svc. Inc.
Akron 330-753-6635
Certified Service Center
Cincinnati 513-772-6600
Commercial Parts and Service
Columbus 614-221-0057
Electrical Appl. Repair Service
Independence 216-459-8700
E. A. Wichman Co.
Toledo 419-385-9121
OKLAHO A
Hagar Rest. Service, Inc.
Oklahoma City 405-235-2184
rueger, Inc.
Oklahoma City 405-528-8883
OREGON
Ron’s Service, Inc.
Portland 503-624-0890
PENNSYLVANIA
Elmer Schultz Services
Philadelphia 215-627-5401
FAST Comm. Appl. Service
Philadelphia 215-288-4800
Appliance Installation & Service
Pittsburgh 412-809-0244
& D Service Co.
Harrisburg 717-236-9039
Electric Repair Co.
Reading 610-376-5444
RHODE ISLAND
Marshall Electric Co.
Providence 401-331-1163
SOUTH CAROLINA
Whaley Foodservice Repair
W. Columbia 803-791-4420
TENNESSEE
Camp Electric
Memphis 901-527-7543
TEXAS
GCS Service
Fort Worth 817-831-0381
Armstrong Repair Service
Houston 713-666-7100
Commercial itchen Repair Co.
San Antonio 210-735-2811
UTAH
La Monica’s Rest. Equip. Service
Murray 801-263-3221
VIRGINIA
Daubers
Norfolk 757-855-4097
Daubers
Springfield 703-866-3600
WASHINGTON
Restaurant Appl. Service
Seattle 206-524-8200
WISCONSIN
A.S.C., Inc.
Madison 608-246-3160
A.S.C., Inc.
Milwaukee 414-543-6460
CANADA
ALBERTA
ey Food Equipment Service
Edmonton 780-438-1690
BRITISH COLU BIA
ey Food Equipment Service
Vancouver 604-433-4484
ANITOBA
Air Rite, Inc.
Winnepeg 204-895-2300
NEW BRUNSWICK
EMR Services, Ltd.
Moncton 506-855-4228
ONTARIO
R.G. Henderson Ltd.
Toronto 416-422-5580
Choquette C S
Ottawa 613-739-8458
QUEBEC
Choquette C S
Montreal 514-722-2000
Choquette C S
Québec City 418-681-3944
