Hatco DL-400 User manual

ITEM#
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A.
[phone] • [phone] • Fax [phone] • Int’l. Fax [phone]
www.hatcocorp.com • E-mail: [e-mail]
Form No. DL Spec Sheet
Printed in U.S.A.
September 2007
DECORATIVE HEAT LAMPS
Models DL-400, -500, -700, -725, -750, -760, -775, -800
DLH-400, -500, -700, -725, -750, -760, -775, -800
Hatco Decorative Heat Lamps hold
food warm at kitchen work areas,
waitress pickup stations, or customer
serving points, while enhancing your
d cor. Compliment your d cor with the
200 watt maximum lighting only option.
Match your heat lamps to your customer
lighting needs.
FLEXIBILITY
The Hatco DL series offers great
flexibility with standard and high watt
bulbs, or lighting only applications,
eight lamp shade styles, eight different
mounting arrangements, four switch
options, and fourteen colors to
customize your operation.
QUALITY
The following features assure the finest
performance for years to come.
• Standard and high watt bulbs available.
• Models available in eight lamp
shade styles.
• Eight different mounting arrangements
to choose from.
• Four switch options.
• Available in six Designer colors: Warm
Red, Black, Gray Granite, White
Granite, Navy Blue, Hunter Green.
• Available in six gloss finishes: Smooth
White, Radiant Red, Gleaming Gold,
Glossy Gray, Brilliant Blue, Bold Black
• Available in two polished finishes:
Bright Brass and Bright Nickel
• Available for food holding and display,
or lighting only applications.
ANSI/NSF 4
Model DL-500-SU
in optional
Designer color
Model DL-400-SU
in optional
Designer color
Model DL-725-SPU
with optional
polished finish
Model DLH-775-RPR
with optional
polished finish
Model DLH-800-STR
high watt, in optional
gloss finish, with
remote switch
Model DL-700-AU
in optional
Designer color
Model DL-750-CL
in optional
gloss finish
Model DL-760-SL
in optional Designer color
See our Decora ive Lamp
Configura or on he Ha co
websi e: www.ha cocorp.com

ITEM#
DECORATIVE HEAT LAMPS
Models DL-400, -500, -700, -725, -750, -760, -775, -800
DLH-400, -500, -700, -725, -750, -760, -775, -800
OPTIONS (NOT FOR RETROFIT)
❑Designer Colors: Warm Red, Black, Gray Granite, White Granite,
Navy Blue, Hunter Green
❑Gloss Finishes: Smooth White, Gleaming Gold, Glossy Gray,
Bold Black (standard), Radiant Red, Brilliant Blue
❑Polished Finishes: Bright Brass, Bright Nickel
(Shade styles -500, -725, -775 only)
❑Clear Coated Brushed Metal Finish (Lamp shade only)
❑White Cord (Black is standard) (C and R mounts only)
❑Luminaire Lighting (200W bulb maximum – not included)
ACCESSORIES
❑Uncoated Clear Bulb, 250W
MOUNTING STYLES
ORDERING INSTRUCTIONS
Luminaire lamps are for lighting only. LUMINAIRE option must be
specifie when lamps are utilize for ecorative purposes only
(no heating). This option is not fiel convertible. Maximum 200 watts.
CLEARANCE REQUIREMENTS
NOTE: Install standard watt (120V bulb, 250W) no closer than 1" from a
sidewall and no closer than 16" above a flammable surface, or no closer
than 5" to a non-combustible surface.
NOTE: Install HIGH WATT (120V, 375W bulb) no closer than 1" from a
sidewall and no closer than 27" above a flammable surface, or no closer
than 5" to a non-combustible surface.
PRODUCT SPECS
Decorative Heat Lamp
The Decorative Heat Lamp shall be a Hatco Model ....as manufactured
by the Hatco Corporation, Milwaukee, WI 53234 U.S.A.
With 24/7 parts and service assistance (U.S. and Canada only), the
Decorative Heat Lamp shall be rated at ....watts, ....volts and be
....inches (millimeters) in overall length. It shall consist of a
powdercoated or gloss vented lamp shade and mounting. Switch
locations can be upper, lower, remote or supplied by installer. Bulb
options are uncoated or coated, clear or red, 250W (DL models) or
375W (DLH models).
❑Coated Clear Bulb, 250W
❑Uncoated Red Bulb, 250W
❑Coated Red Bulb, 250W
❑Uncoated Clear Bulb, 375W (120V DLH models only)
❑Coated Clear Bulb, 375W (120V DLH models only)
❑Uncoated Red Bulb, 375W (120V DLH models only)
❑Coated Red Bulb, 375W (120V DLH models only)
❑Track Mount Bar (Specify 4', 8', or 12' (1219, 2438, or 3658 mm)
track length and color option of black or white for track and
adapter) (120V only) (Maximum 1920 watts per any length track)
❑Additional Track Installation and Modification Kit (Specify color
option of black or white)
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [e-mail]
Printed in U.S.A.
Form No. DL Spec Sheet September 2007
11" (279 mm)
-800
81⁄2"
(216 mm)
81⁄2"
(216 mm)
-700
61⁄2"
(165 mm)
-500
61⁄8"
(156 mm)
-400
61⁄8"
(156 mm)
91⁄2"
(241 mm)
-725
-750
11" (279 mm)
-760
121⁄2" (318 mm)
-775
101⁄2"(267 mm)
SPECIFICATIONS
Specify the following information with your order.
RT Mount
Adjustable Cord Mount
to track adapter.
Adjusts from 333/8" to
717/8" (848-1826 mm).
Mo el▲Maximum Watt Bulb Volts•Shipping Weight
(Not Inclu e )
DL (Luminaire) 200 120 6-10 lbs. (3-6 kg)▼
DL (Standard) 250 120 or 240 6-10 lbs. (3-6 kg)▼
DLH (High Watt) 375 120 6-10 lbs. (3-6 kg)▼
▲
Not field convertible. •Single phase.
▼
Depending on components.
SWITCH LOCATIONS
U– Upper^†, L – Lower^■, R – Remote•,
N – None (supplied by installer)
^Not available on high watt models.
†Not available on track mounts or R mounting style.
■Not available on A mounting style.
•Up to four 250W lamps, or two 375W lamps
maximum per remote switch.
R Mount
Adjustable Cord
Mount. Adjusts
from 31" to 691/2"
(787-1765 mm).
C Mount
Cord Mount to canopy.
Specify overall lengt
from 17" (432 mm)
to any lengt .
CT Mount
Cord Mount to track
adapter. Specify
overall lengt from 17"
(432 mm) to any lengt .
ST Mount
Rigid Mount to track
adapter. Specify overall
lengt from 17" to 71"
(432-1803 mm).
S Mount
Rigid Mount to canopy.
Specify overall lengt
from 14" to 71"
(356-1803 mm).
23⁄8"
(
60 mm )
P Mount
Rigid Mount to canopy
wit pivot. Specify
overall lengt *from 17"
to 71" (432-1803 mm).
A Mount
Rigid Mount to canopy
wit pivot. Specify
orizontal stem lengt
from 7" to 20"
(178-508 mm).
101⁄4"
(260 mm)
7"-20"
(178-508 mm)
SHADE STYLES & DIMENSIONS
Decorative
Lamp
High
Wattage
Switch Location
Mounting Style
Shade Style
Also specify when ordering:
Bulb Style
Shade Color
Track Color/Length
Cord Color
Overall Length
Example
DLH-400-CR
Upper Switch Lower Switch Remote Switch
(Accommodates 10 amps)
* Overall lengt from pivot to bottom of lamp s ade.
1. Voltage: 120V
2. Bulb Code: 200W = Luminaire, 250W
= DL, 375W (UL Listed) = DLH
Bulb Color/Coating:
250W- Clear Uncoated, Clear Coated,
Red Uncoated, or Red Coated;
375W- Clear Uncoated, Clear Coated,
Red Uncoated, or Red Coated
3. Shade Style Code: -400, -500, -700, -
725, -750, -760, -775, -800
Unit Color: Warm Red, Blac , Gray
Granite, White Granite, Navy Blue,
Hunter Green, Smooth White,
Gleaming Gold, Glossy Gray, Bold
Blac , Radiant Red✱
, Brilliant Blue✱ ,
Clear Coat Brushed Metal✱
(lampshade only), Bright Brass▲,
Bright Nic el▲
4. Mounting Style Code: R, RT, C, CT, S, ST, P, A
5. Cord/Trac Color: Blac (standard), White (optional)
6. Switch Location Code: Upper (U), Lower (L), Remote (R), or
None (N)
7. Clearance: from bulb to surface (see NOTE above)
8. Overall Unit Length: from ceiling to bottom of warmer lamp
shade or from center of shade to wall
✱Special process required, see price list for additional pricing.
▲Bright Brass and Bright Nic el finishes are only available in shade styles
-500, -725, and -775.
