Hatco Flav-R-Shield EP5 User manual

© 2022 Hatco Corporation 1
Model EP5 Standard Sizes
Item Number
Total Width (A)
(post center to
center)
Number
of
Bays
Width per Bay
(post center to
center)
EP5-036 36″
(914 mm) 136″ (914 mm)
EP5-048 48″
(1219 mm) 224″ (610 mm)
EP5-060 60″
(1524 mm) 230″ (762 mm)
EP5-072 72″
(1829 mm) 236″ (914 mm)
EP5-084 84″
(2134 mm) 242″ (1067 mm)
EP5-096 96″
(2438 mm) 332″ (813 mm)
EP5-108 108″
(2743 mm) 336″ (914 mm)
EP5-120 120″
(3048 mm) 340″ (1016 mm)
EP5-132 132″
(3353 mm) 433″ (838 mm)
EP5-144 144″
(3658 mm) 436″ (914 mm)
A
A
18″
25″
30″
EP5-060 (2 Bay)
EP5-036 (1 Bay)
30″
NOTE:18″EndPanelsmeetNSFrequirements.
4. Insert each Post Assembly into its corresponding Mounting
Flange. Make sure the posts are fully seated in the flanges.
5. Tighten the set screw on each Mounting Flange securely.
6. Slide each Flange Cover down onto its corresponding flange.
continued...
P/N 07.14.002.00-0822 [EP5_IG]
INSTALLATION GUIDE
Model EP5 Full Service Sneeze Guards are available in ten
widths ranging from 36″–144″ (914–3658 mm), with a common
height of 25″ (635 mm) and a common depth of 18″ (457 mm).
For additional information regarding Model EP-5 sneeze guards,
scan the QR Code below:
https://www.hatcocorp.com/en/equipment/sneeze-guard-equipment/
full-service/flav-r-shield-full-service-pass-over-sneeze-guard-ep5
Important Safety Information
To avoid serious injury and damage to equipment or property, read
the following safety information before installing this equipment.
Do not attempt to assemble and install sneeze guards alone.
Installation of sneeze guards requires two or more people,
dependent upon unit.
Always wear proper protective eye wear when handling glass
sneeze guards.
Never spray cleaners directly onto sneeze guard surfaces.
Spray cleaner into non-abrasive cloth, and then wipe down
surfaces.
Use non-abrasive cleaners and cloths only. Abrasive cleaners
and cloths could scratch finish of unit, marring its appearance
and making it susceptible to soil accumulation. Use of abrasive
materials will void warranty.
Assembly and Installation
1. Unpack all components. Verify that the appropriate number of
the items below are present.
• Face Panel, 1/4″ Glass
• End Panel, 1/4″ Glass
• Post Assembly, 1″ Stainless Steel
• Hardware Packet (includes hex wrench for set screws)
2. Remove the Mounting Flanges from each Post Assembly.
a. Slide the Flange Cover up and off of the flange.
b. Using the included hex wrench, loosen the set screw on the
flange.
c. Slide the flange off of the Post Assembly.
IMPORTANT NOTE
Sneeze guards that consist of multiple bays require careful
measurement before installation of the Mounting Flanges.
3. Install the Mounting Flanges to the mounting surface.
a. Refer to the “Model EP5 Standard Sizes” chart and illustration
below to determine the location of the flanges. For multiple
bay installations, refer to “Width per Bay” column in the chart.
b. Position the flanges in the appropriate locations, and mark
the screw hole locations. IMPORTANT! Measure carefully,
and make sure the flanges remain square to each other as
well as the installation location.
c. Pre-drill the screw holes in the mounting surface.
d. Install the flanges using the appropriate, #8 countersunk-
style fasteners for the mounting surface.
Flav-R-Shield™
Full Service Sneeze Guards
Model EP5

© 2022 Hatco Corporation2
Cleaning/Maintenance
Clean the unit daily using non-abrasive cloths and cleaners.
• Always spray/apply cleaner to the cloth, then wipe down the
sneeze guard. Do not spray cleaner directly onto the sneeze
guard.
7. IMPORTANT! Refer to the “Securing the Glass” procedure on
this sheet before beginning installation of any glass panels.
8. Install the glass Face Panel by sliding it into the glass clips from
above. Secure the glass.
9. Install each glass End Panel by sliding them into the glass clips
from above. Secure the glass.
10. For NSF compliance, apply NSF-approved silicone sealant to
the screw heads of all set screws and nylon set screws.
NOTE:ForNSFcompliance, thebottomedgeof allEndPanels
cannotbepositionedhigherthan1-1/2″(38mm)abovethe
installationsurface.
Securing the Glass
All glass panels are attached to support posts using the same,
integrated glass clips. A nylon set screw on each glass clip secures
the glass panel in the clip.
Glass
Panel
Scuffed
Area
Nylon
Set Screw
Glass
Clip
Post Assembly
NOTE:Duringinstallationofallvertical
and angled glass panels,
Hatco strongly recommends
that an abraded surface be
created where the nylon set
screw contacts the glass.
Thiswillcreateastrongbond
betweenthesetscrewandthe
glass.Use320-gritsandpaper
toscufftheglasswhereeach
nylon set screw will contact
theglass.
Turn Nylon
set screw
1/4-turn
clockwise
after contact.
Turn Nylon
set screw
1/4-turn
clockwise
after contact.
Post Assembly
1. Abrade the surface of the glass
panel where each nylon set screw
will contact the glass.
2. Insert the glass panel into the
glass clips.
3. Carefully turn the nylon set screw
clockwise just until the screw
contacts the glass. Then, turn the
screw an additional 1/4-turn to
secure the glass.
24 Hour 7 Day Parts and Service
Assistance available in the United States
and Canada by calling 414-671-6350.
HATCO CORPORATION
P.O. Box 340500
Milwaukee, WI 53234-0500 U.S.A.
414-671-6350
[email protected]
www.hatcocorp.com
Custom Units
Scan this QR code or click the link
below to access information regarding
custom units including sizes, glass,
hardware, and lighting.
www.hatcosneezeguards.com
