Haulotte C8 User manual

Operator's manual
E
LECTRIC
SCISSOR
LIFTS
24203 3227 0 E 10 09 EN
Operator's manual
Electric scissor lifts
C8 (COMPACT 2032E) - C8W (COMPACT
2247E) - C10N (COMPACT 2632E) - C10
(COMPACT 2747E) - C12 (COMPACT 3347E) -
OPTIMUM 6 (OPTIMUM 1530E) - OPTIMUM 8
(OPTIMUM 1930E) - COMPACT 10RTE
(COMPACT 2668RTE) - COMPACT 12RTE
(COMPACT 3368RTE) - C14
EN

2 24203 3227 0 E 10 09 EN
Electric scissor lifts

3
CONTENTS
Operator's manual
CONTENTS
1 - Operator's manual . . . . . . . . . . . . . . . . . . . . . . . 7
2 - After Sales Service . . . . . . . . . . . . . . . . . . . . . . . 7
3 - Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
A
SAFETY PRECAUTIONS
1 - Recommendations . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 - Operator's manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.2 - Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 - Label colours . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2 - Pre-operation instructions. . . . . . . . . . . . . . . . 11
2.1 - General instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2 - Specific instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 - Operation instructions . . . . . . . . . . . . . . . . . . . 12
3.1 - General warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2 - Potential risks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.1 - Risk of command system disturbance . . . . . . . . . . . . . . . . . . . . 13
3.2.2 - Risk of falling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.3 - Risk of electrocution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.4 - Risk of uncontrolled movement and overturning . . . . . . . . . . . . 14
3.2.5 - Risk of burns and explosion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.2.6 - Risk of crushing and collision . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
B
INTERVENOR'S RESPONSIBILITY
1 - Owner's (or hirer's) responsibility . . . . . . . . . 17
2 - Employer's responsibility . . . . . . . . . . . . . . . . 17
3 - Trainer's responsibility . . . . . . . . . . . . . . . . . . 17
4 - Operator's responsibility . . . . . . . . . . . . . . . . . 17
5 - Inspection and maintenance . . . . . . . . . . . . . . 18
C
MACHINE LAYOUT
1 - Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2 - Main components . . . . . . . . . . . . . . . . . . . . . . . 20
3 - Safety devices. . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.1 - Slinding (or vertically) hinged intermediate guard-rails. . . . . . . . . . . . . . 22
3.2 - Anchorage pointPlease see machine configuration . . . . . . . . . . . . . . . 23
3.3 - Maintenance support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4 - Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.1 - Classification plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.1.1 - Red labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.1.2 - Orange labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.1.3 - Yellow labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.1.4 - Other labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4
Operator's manual
4.1.5 - Green labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.2 - Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5 - Control boxes . . . . . . . . . . . . . . . . . . . . . . . . . . 58
5.1 - Ground control box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
5.2 - Platform control box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
D
OPERATING PRINCIPLE
1 - Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
2 - Safety devices. . . . . . . . . . . . . . . . . . . . . . . . . . 65
2.1 - Activation of controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
2.2 - Drive speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
2.3 - Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
2.4 - Load in the platform. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
2.5 - Anti-pothole safety system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
2.6 - Battery discharge indicatorHour meter. . . . . . . . . . . . . . . . . . . . . . . . . . . 66
2.6.1 - Hour meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
2.6.2 - Automatic reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
2.7 - On-board charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
2.8 - manual extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
E
DRIVING
1 - Recommendations . . . . . . . . . . . . . . . . . . . . . . 69
2 - Checks before use . . . . . . . . . . . . . . . . . . . . . . 69
2.1 - Visual inspections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
2.1.1 - General mechanical functions . . . . . . . . . . . . . . . . . . . . . . . . . . 69
2.1.2 - Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
2.2 - Functional tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
2.2.1 - Safety features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
2.2.2 - Ground control box controls (emergency station) . . . . . . . . . . . 71
2.2.3 - Platform control box controls (driving station) . . . . . . . . . . . . . . 72
2.3 - Periodical checks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
2.4 - Repairs and adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
2.5 - Checks to be performed when the machine is returned to service . . 72
3 - Usage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
3.1 - Test procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
3.1.1 - Emergency stop switch- push button function (cut out) . . . . . . . 73
3.1.2 - Tilt sensor control box operation . . . . . . . . . . . . . . . . . . . . . . . . 73
3.1.3 - Visual and audio alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
3.1.4 - Weighing system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
3.1.5 - 8 m (26 ft 3 in) drive cut-offFloor height . . . . . . . . . . . . . . . . . 74
3.2 - Ground operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
3.2.1 - Machine start-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
3.2.2 - Machine shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
3.2.3 - Movement control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
3.2.4 - Other controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
3.3 - Operations from the platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
3.3.1 - Machine start-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
3.3.2 - Machine shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
3.3.3 - Movement control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
3.3.4 - Other controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

5
CONTENTS
Operator's manual
F
SPECIAL PROCEDURE
1 - Emergency lowering . . . . . . . . . . . . . . . . . . . . 81
1.1 - Principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
1.2 - Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
2 - Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
2.1 - Brake release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
3 - Loading and unloading . . . . . . . . . . . . . . . . . . 83
3.1 - Principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
3.1.1 - Loading by ramp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
3.1.2 - Unloading by ramps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
3.1.3 - Loading by lifting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
3.2 - Putting in transport position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
3.3 - Unloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
3.4 - Warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
G
TECHNICAL CHARACTERISTICS
1 - Main characteristics . . . . . . . . . . . . . . . . . . . . . 87
2 - Overall dimensions . . . . . . . . . . . . . . . . . . . . 106
3 - Working area. . . . . . . . . . . . . . . . . . . . . . . . . . 110
3.1 - Machine C8 (COMPACT 2032E) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
3.2 - Machine C8W (COMPACT 2247E) . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
3.3 - Machine C10N (COMPACT 2632E) . . . . . . . . . . . . . . . . . . . . . . . . . . 112
3.4 - Machine C10 (COMPACT 2747E). . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
3.5 - Machine C12 (COMPACT 3347E). . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
3.6 - Machine C14 (N / A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
3.7 - Machine OPTIMUM 6 (OPTIMUM 1530E) . . . . . . . . . . . . . . . . . . . . 116
3.8 - Machine OPTIMUM 8 (OPTIMUM 1930E) . . . . . . . . . . . . . . . . . . . . 117
3.9 - Machine COMPACT 10RTE (COMPACT 2668RTE) . . . . . . . . . . 118
3.10 - Machine COMPACT 12RTE (COMPACT 3368RTE) . . . . . . . . . . 119
4 - AS standard specificities . . . . . . . . . . . . . . . 120
4.1 - Overload test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
4.2 - Functional test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
4.3 - Stability test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
H
INTERVENTION LOG
1 - Intervention log. . . . . . . . . . . . . . . . . . . . . . . . 131

6
Operator's manual

724203 3227 0 E 10 09 EN
Electric scissor lifts
You have just purchased a HAULOTTE® product
and we would like to thank you for your trust and
support.
1 - Operator's manual
As stated on the delivery slip, this manual is one of the documents in the on-board document holder
located at the basket control station HAULOTTE® product.
The operator manual is a translation of the original note.
Safe operation of this product can only be assured if you follow the operating instructions contained in
this manual.
We would like to draw your attention to 2 important points :
• Always comply with the safety warnings related to the machine, its operation and the operating
environment in which the machine is being used
• Always use the equipment with the performance limits set out in this manual.
2 - After Sales Service
Our HAULOTTE Services® After Sales Service is at your disposal over the service life of the machine
to ensure optimum use of your HAULOTTE product..
• When contacting our After Sales Service ensure that you provide the machine model and Serial
Number. Refer to the Identification plate on the machine for this information.
• When ordering either consumable or replacement parts, please refer to the HAULOTTE Spare Parts
Manual provided with the product, and ensure that you only use genuine HAULOTTE Spare parts to
guarantee interchangeability and optimum service life for the product.
• If there is an equipment malfunction involving a HAULOTTE® product then contact HAULOTTE
Services® immediately even if the malfunction does not involve material and/or bodily damage..

8 24203 3227 0 E 10 09 EN
Electric scissor lifts
3 - Conformity
HAULOTTE® comply with the provisions of applicable design standards and directives in the countries
where the products are sold.
Any modifications made to your HAULOTTE product without the in-writing authority of HAULOTTE®
voids the above compliances..
HAULOTTE® cannot be held liable for the technical specifications contained in this manual.
HAULOTTE® reserves the right to alter alter technical specifications and to make product
improvements without prior notice, or necessarily altering this manual..
Certain options can modify the machine's operating characteristics and the safety associated with it. If
your machine was originally delivered with this option, replacing a safety component associated to this
option does not require any particular precautions other than those associated with the installation itself
(static test).
Otherwise, it is essential to follow the manufacturer's recommendations below :
• Installation by authorised HAULOTTE® personnel only.
• Update the manufacturer's plate.
• Have stability tests carried out by a certified agency.
• Ensure label compliance.

A
B
C
D
E
F
G
H
I
924203 3227 0 E 10 09 EN
Electric scissor lifts
A - Safety precautions
Safety precautions
1 - Recommendations
1.1 - OPERATOR'S MANUAL
This operators manual is specific to the * products listed on the cover page of this manual..
1.2 - SYMBOLS USED
Symbols are used to alert the operator of safety precautions or to highlight practical
information.
Symbol meanings
The operator manual does not replace the basic training required for all worksite equipment operators.
HAULOTTE® has compiled this manual to assist in the safe and efficient operation of the products covered
by the manual.
This manual must be kept on the machine in the storage container provided at the platform upper control
station. The manual must be available to all operators and must be kept in good condition at all times.
Additional copies of the manual can be purchased from HAULOTTE Services®.
Symbol Meaning
Danger : Risk of injury or death (worker safety)
Caution : Risk of material damage (worker quality)
Prohibition relating working safety and quality
Reminder : No identified risk, but a reminder of the need for common
sense, good practice or pre-action prerequisites
Cross-reference to another part of the manual (see section or sheet)
Cross-reference to another manual (see manual)
Cross-reference to repairs (contact HAULOTTE Services®)
N.B. : Additional technical information

10 24203 3227 0 E 10 09 EN
Electric scissor lifts
A - Safety precautions
1.3 - LABEL COLOURS
The potential dangers and any specific regulations are indicated around the product by labels
and identification plates.
Familiarize yourself with the labels and their respective color codes.
Label color code-CE - AS
Label color code-ANSI - CSA
The labels must be kept in good condition. Additional labels can be obtained from HAULOTTE Services®.
Labels Color Meaning
Red Potentially fatal danger
Orange Risk of serious injury
Yellow Risk of material damage and/or minor injury
Other Additional technical information
Labels Color Meaning
Red Potentially fatal danger
Orange Risk of serious injury
Yellow Risk of material damage and/or minor injury
Other Additional technical information
Green CSA maintenance operation or information

A
B
C
D
E
F
G
H
I
1124203 3227 0 E 10 09 EN
Electric scissor lifts
A - Safety precautions
2 - Pre-operation instructions
2.1 - GENERAL INSTRUCTIONS
• On soft, unstable or cluttered ground.
• With wind blowing faster than the permissible limit. Check the maximum value (slope, ec..)in the
Technical Characteristics ( Section G 1- Main characteristics). Consult the Beaufort scale
( Section A 3.2.4- Risk of uncontrolled movement and overturning).
• Close to power lines. Respect the safety distance ( Section A 3.2.3- Risk of electrocution).
• At ambient temperatures higher than 45 °C (113 °F) and lower than -15 °C (5 °F) .
Consult HAULOTTE® if it is necessary to work outside this range.
• In an explosive atmosphere.
• During storms (risk of lightning).
• In the presence of strong electromagnetic fields (radar ...).
2.2 - SPECIFIC INSTRUCTIONS
• If the load in the platform exceeds the maximum load authorized. Check the maximum value (slope,
ec..)in the Technical Characteristics ( Section G 1- Main characteristics).
• If the ground slope is greater than the permissible limit. Check the maximum value (slope, ec..)in the
Technical Characteristics ( Section G 1- Main characteristics).
• At night unless the machine is equipped with the optional light or an other external lighting.
• If the number of persons greater than the permissible. Check the maximum value (slope, ec..)in the
Technical Characteristics ( Section G 1- Main characteristics)
• If the side force on the platform is greater than the permissible force. Check the maximum value
(slope, ec..)in the Technical Characteristics ( Section G 1- Main characteristics)
• The employer is obliged to issue a driving permit to the operator.
• The employer is obliged to inform the operator of the local regulations.
Do not operate the product in the following situations :
Do not operate the product in the following situations :

12 24203 3227 0 E 10 09 EN
Electric scissor lifts
A - Safety precautions
3 - Operation instructions
3.1 - GENERAL WARNINGS
• The LPG bottle must be firmly attached and in the correct position.
• Check the bottle and its connections periodically (every 250 h ) to detect any leaks. Never use
matches. Always use a specially-designed leak detector product.
• The exterior of the LPG bottle must always be kept rust-free by regularly applying a specific paint.
It is preferable to operate the machine on flat, developed ground (tarmac, concrete, ec.).
• Never use a defective machine (hydraulic leaks, worn tyres, malfunction).
• Never operate the machine controls suddenly.
• Never place the machine against a structure.
• Never use the machine to tow other machines or drag materials.
• Never expose the batteries or electrical components to water (pressure cleaner, rain).
• Never disable the safety devices.
• Do not make contact with a fixed or mobile obstacle. The contact can cause premature deterioration of
the structure and lead to the rupture of certain safety elements.
• Do not climb on the covers.
• Never use the machine alone. It must be operated by a pair of operators.
• Never use the machine when the platform is cluttered.
• Never increase the surface area of the platform by using floor extensions or accessories not authorized
by HAULOTTE®.
• Never leave the hydraulic cylinders entirely extended before switching off the machine, or during an
extended stop period.
• Never use the machine with material or objects suspended from the guard-rail.
• Never use the machine with the elements that can increase the wind force (e.g. placards, signs, boards).
• Never increase the working height by using attachments (ladder).
• Never use the guardrail as the means of access to climb in or out of the platform. Steps have been
provided for this purpose where required.
• Never climb on the guardrail.
• Never use the machine without fully lowering the sliding midrail or without closing the platform entry
gate.
• Never use the machine as a crane, goods lift or elevator.
• Never use the machine for any other purpose than to transport people, their tools and material to the
desired place.
• Never drive fast in narrow or badly cleared areas. Reduce speed under control on bends.
• Never tow the machine over extended distances (it must be transported on a trailer).

A
B
C
D
E
F
G
H
I
1324203 3227 0 E 10 09 EN
Electric scissor lifts
A - Safety precautions
3.2 - POTENTIAL RISKS
3.2.1 - Risk of command system disturbance
Risk of disrupted movement. Maintain clearance from high voltage lines or magnetic fields.
3.2.2 - Risk of falling
When in the machine platform, respect the following instructions :
• Carry individual protection equipment adapted to the work conditions and local
rules.
• Avoid hitting fixed or mobile obstacles (other machines).
• Ensure that the adjustable midrail is closed (low position and against the guardrails).
• Ensure that the gate is closed and locked (For HB135JRT).
• Hold on securely to the guardrails during elevation and driving.
• Do not sit, stand, or climb on the guard rails of the platform.
• Always keep the feet firmly on the floor of the platform.
• Remove any trace of oil or grease from the steps, floor, handrail and the guardrails.
• Keep the floor of the platform free of debris.
• Do not leave the platform until it is in the fully in stowed position.
3.2.3 - Risk of electrocution
The machine is not electrically insulated and does not offer any protection.
The risks of electrocution are high in the following situations :
• Close to live power lines, consider the movement of the machine and the swaying
of the electric power lines.
• In the event that you were to make accidental contact with a high voltage line, wait for the power to
the line to be switched off before operating the machine.
• During storms.
Never use the machine as a welding earth.
Maintain a minimum safe distance with regard to power lines and electrical devices.
Respect the local rules and the minimum safety distance.
To climb up or climb down from the platform :
• The machine must be completely stowed.
• Face the machine to access the entry opening to the
platform
• Keep 3 support points between the steps and the guardrail

14 24203 3227 0 E 10 09 EN
Electric scissor lifts
A - Safety precautions
Minimum safety distance
N.B.-:-THIS TABLE IS APPLICABLE, EXCEPT WHEN THE LOCAL REGULATIONS ARE MORE STRICT.
3.2.4 - Risk of uncontrolled movement and overturning
When in the machine platform, respect the following instructions :
• Before engaging the machine on any indoor or outdoor surface (premises, bridge,
truck, etc.), check that the surface is capable of supporting the load. Check the
maximum value (slope, ec..)in the Technical Characteristics ( Section G 1-
Main characteristics).
• During movement reversal from the platform or ground control box, the joysticks or switches must be
stopped in neutral position before reversing the direction of motion.
• Taking note of the overall load dimensions, place the loads in the centre of the platform or distribute
them it a uniform manner.
• Remain vigilant of driving direction reversal on platforms, pavements, etc.. Check driving direction.
The front of the machine is located on the opposite side to the step.
• Always ensure that the chassis is never driven any less than 1 m (3 ft 3 in) m from holes, bumps,
tilts, obstructions, debris and ground coverings that may hide holes and other dangers.
• If the tilt alarm sounds when the platform is raised, lower platform completely, then reposition machine
on level ground before raising platform.
N.B.-:-THE BEAUFORT SCALE MEASURES THE WIND FORCE WITH AGRADUATION SYSTEM. A WIND SPEED
RANGE AT 10 M(32 FT 9 IN) ABOVE FLAT, CLEAR LAND IS ASSOCIATED WITH EACH DEGREE.
Electric voltage Minimum safety distance
Mètre Feet
0 - 300 V Avoid contact
300 V - 50 kV 310
50 - 200 kV 515
200 - 350 kV 620
350 - 500 kV 825
500 - 750 kV 11 35
750 - 1000 kV 14 45
• Do not drive the machine on slopes or tilts beyond the design limits. Check the maximum value (slope,
ec..)in the Technical Characteristics( Section G 1- Main characteristics).
• Do not go down slopes at high speed.
• Do not raise the platform or drive with the platform raised on slopes or when the machine is tilted.
• Do not drive in reverse (direction opposite the field of vision).
• Never use the machine in winds exceeding the authorized limit.
• Do not increase the surface area exposed to the wind. The greater the surface area exposed, the more
unstable the machine becomes.

A
B
C
D
E
F
G
H
I
1524203 3227 0 E 10 09 EN
Electric scissor lifts
A - Safety precautions
Beaufort scale
3.2.5 - Risk of burns and explosion
N.B.-:-ACID IS NEUTRALISED WITH SODIUM BICARBONATE AND WATER.
Force Meteorological
description Observed effects m/s km/h mph
0Calm Smoke rises vertically. 0 - 0,2 0 - 1 0 - 0,62
1Very light breeze Smoke indicates the wind
direction. 0,3 - 1,5 1 - 5 0,62 - 3,11
2Light breeze Wind felt on the face. Leaves
rustle. Weathervanes turn. 1,6 - 3,3 6 - 11 3,72 - 6,84
3Slight breeze
Leaves and small branches in
constant movement. Flags move
slightly.
3,4 - 5,4 12 - 19 7,46 - 11,8
4Nice breeze Dust and loose papers fly. Small
branches bend. 5,5 - 7,9 20 - 28 12,43 - 17,4
5Nice breeze Small trees sway. Crested
wavelets form on inland waters. 8,0 - 10,7 29 - 38 18,02 - 23,6
6Cool wind
Large branches shake. Power
lines and chimneys 'sing'. It is
difficult to use an umbrella.
10,8 - 13,8 39 - 49 24,23 -
30,45
7Strong cool wind All trees shake. Walking against
the wind becomes difficult. 13,9 - 17,1 50 - 61 31 - 37,9
8Squall
Some branches break.
Generally we cannot walk
against the wind.
17,2 - 20,7 62 - 74 38,53 -
45,98
9Strong squall
The wind causes slight damage
to buildings. Tiles and chimney
stacks are blown off.
20,8 - 24,4 75 - 88 46,60 -
54,68
For any intervention on the power sources, wear glasses and protective clothes (acid spray).
• Do not work in an explosive or flammable atmosphere (spark, flame, etc.).
• Do not touch the hot parts of the hydraulic power (engine, filters, ec.).
• Do not use a tool to bridge the battery terminals with metallic objects.
• Do not service the battery close to a spark, naked flame, glowing tobacco (emissions of gas).

16 24203 3227 0 E 10 09 EN
Electric scissor lifts
A - Safety precautions
3.2.6 - Risk of crushing and collision
When in the machine platform, respect the following instructions :
• During operation, keep all the parts of the body inside the platform.
• Keep hands and limbs well away from the scissor arms.
• Adjust the movement speed to the ground conditions (traffic, slope, ec.).
• Respect stopping after the controls are released :
• 3 m (9 ft 10 in) at high speed.
• 1 m (3 ft 3 in) at low speed.
• To position the machine close to obstacles, use the raise controls (arm, boom, ec.) instead of the drive
controls.
• Ensure there are no obstacles (structure) in the work area.
• Always have someone to guide machine movements in case of poor visibility.
• All personnel on the machine or on the ground must wear an approved safety helmet.
• When moving the machine, ensure that the machine operating areas is free of persons and obstacles.
Do not operate other machines (crane, platform, etc.) in the work area.
Take account of the distance, reduced visibility and blind spots during use of the machine.

A
B
C
D
E
F
G
H
I
1724203 3227 0 E 10 09 EN
Electric scissor lifts
B - Intervenor's responsibility
Intervenor's responsibility
1 - Owner's (or hirer's) responsibility
The owner (or hirer) has the obligation to inform operators of the operator instructions in the Operator
Manual.
The owner (or hirer) has the obligation to renew all manuals or labels that are either missing or in bad
condition. Additional copies of the manual can be purchased from HAULOTTE Services®.
The owner (or hirer) is responsible for applying the local regulations applicable to the use of the
machine.
2 - Employer's responsibility
The employer is obliged to issue a driving permit to the operator.
N.B.-:-INACCORDANCE WITH THE REGULATION IN THE COUNTRY WHERE THE MACHINE IS OPERATING, THE
USER MUST BE AUTHORIZED TO DRIVE BY THE DOCTOR OF LABOUR MINISTRY.
The employer is obliged to inform the operator of the local regulations.
3 - Trainer's responsibility
The trainer must be qualified to provide training to operators in accordance with applicable local
regulations. The training must be given in an obstacle-free area until the trainee is considered
competent as defined by the training program undertaken.
4 - Operator's responsibility
The operator must read and understanding the contents of this manual and the labels affixed on the
machine.
The operator must inform the owner (or hirer) if the manual or any labels are missing or in poor
condition, and of any malfunction of the machine.
The operator may only operate the machine within the parameters set down in this manual by the
manufacturer.
All operators must become familiar with and fully understand the emergency controls and how to
operate the machine in an emergency as a component of their formal operator training.
The operator must stop using the machine in the event of malfunction or safety problems on the
machine or in the work area and report the problem to hsi supervisor.
Forbid anyone from operating the machine who is :
• Under the influence of drugs, alcohol, ec..
• subject to fits, loss of motor skills, dizziness, ec..
Only authorized and qualified operators may operate HAULOTTE® machines.

18 24203 3227 0 E 10 09 EN
Electric scissor lifts
B - Intervenor's responsibility
5 - Inspection and maintenance
The inspection and maintenance table below, identifies the role and the responsibilities of each party
in the regular maintenance of the machine.
Inspections and maintenance
If the machine is operated in a hostile environment or intensively, increase the frequency of maintenance.
Type of
intervention Frequency Person-in-charge Intervenor Reference document
Pre-delivery
inspection
Before each delivery
of sold, hired or
resold equipment
Owner (or hirer) Qualified HAULOTTE
Services® technician Operator's manual
Pre-operation
inspection
Before operation or
when the operator
changes
Operator Operator Operator's manual
Regular preventive
maintenance
At the specified
intervals (250 h or 1
year)
Owner (or hirer)
On-site technician or
qualified HAULOTTE
Services® technician
Maintenance book
Regular visit
2 times a year or at
the latest 6 months
after the last regular
visit, and according
to the local
regulations
Owner (or hirer)
Organization or
technician approved
by the employer or by
the intermediary
of HAULOTTE
Services® in
accordance with
the HAULOTTE
Services® contract
Maintenance book

A
B
C
D
E
F
G
H
I
1924203 3227 0 E 10 09 EN
C - Machine layout
Electric scissor lifts
Machine layout
1 - Identification
The manufacturers dentification plate fixed on the chassis bears all information allowing machine
identification (Please see machine configuration).
Identification plateCE - AS
Identification plate ANSI
For any request for information, intervention or spare parts, specify the type and serial number of the
machine.
ENGIN /
EQUIPMENT
TYPE /
TYPE
N˚ SERIE /
SERIAL NUMBER
MASSE /
TOTAL WEIGHT
ANNEE DE CONSTRUCTION /
YEAR OF MANUFACTURE
PUISSANCE NOMINALE /
NOMINAL POWER
kg
kW
PENTE GRAVISSABLE MAXI /
GRADEABILITY MAX.
%
7814 618 d
CHARGE MAXI /
MAXIMUM LOAD
NOMBRE PERS. + CHARGE /
NUMBER OF PERSONS + LOAD
FORCE LATERALE MAXI /
LATERAL FORCE MAX.
VITESSE DU VENT MAXI /
WINDSPEED MAX.
DEVERS MAXI (degrés) /
SLOPE OPERATION MAX. (degrees)
USAGE INTERIEUR / INSIDE USE USAGE EXTERIEUR / OUTSIDE USE
kg
P + kg
N
m/s
˚
kg
P + kg
N
m/s
˚
HAULOTTE GROUP, La Péronnière, BP9
42152 L'Horme - France
A3
EQUIPMENT
TYPE
SERIAL N°
TOTAL WEIGHT
YEAR OF MANUFACTURE
POWER SOURCE (fuel/gaz/LPG)
lbs
kW
POWER SOURCE (electric) V / Ah
307P218930 b
MAXIMUM LOAD
NUMBER OF PERSONS + LOAD
MAXIMUM PLATFORM HEIGHT
LATERAL FORCE MAX.
SLOPE OPERATION MAX.
lbs
P + lbs
ft
N lbs
0 degres
MAXIMUM PLATFORM REACH ft
MADE IN FRANCE THIS MACHINE HAS BEEN MANUFACTURED IN COMPLIANCE WITH :
HAULOTTE GROUP, La Péronnière, BP.9
42152 L'HORME
A3

20 24203 3227 0 E 10 09 EN
Electric scissor lifts
C - Machine layout
2 - Main components
COMPACT 8 (COMPACT 2032E) - COMPACT 8W
(COMPACT 2247E) - COMPACT 10N (COMPACT
2632E) - COMPACT 10 (COMPACT 2747E) -COMPACT
12 (COMPACT 3347E) - COMPACT 14 (N / A) - View
of the components
OPTIMUM 6 (OPTIMUM 1530E)- OPTIMUM 8
(OPTIMUM 1930E) - View of the components
C87 C87
C20
C1
C6
C35
C75 C7 C68C76
C2C142
C77
C59
C27
C88
C143 C142 C30 C58 C141
C59
C77
C87
C20
C87
C1
C6
C35
C75 C7 C68C76
C141C27C58C88C2
C143
C30
C143
C142
