TRAK-MOUNT ASSEMBLY
(Image Upside down)
INSTALL INSTRUCTIONS C-TM-IMP
2000-2005 CHEVROLET IMPALA TRAK-MOUNT KIT
TOOLS REQUIRED:
Ratcheting Wrench
Metric Socket Set
Torx Bit Set
Standard Socket Set
Tape Measure
HARDWARE:
QTY DESCRIPTION PART#
8 ¼” x ¾” hex head bolt GSM33001
8 ¼” Serrated nut GSM30023
6 ¼” x 1” Hex head lag bolts GSM33060
1 32” Trak mount CM93055-9
SUB ASSEMBLY:
1. MOUNT TRAK TO HUMP BRACKETS.
• Determine location that Trak will land on transmission hump for the specific
application.
• With Trak in necessary location, measure Front and Rear Hump Brackets in relation
to Trak.
• Bolt Trak to Hump Brackets, using measurements taken in previous step
Note: There are 2 different sides to the Trak Plate. It is recommended to mount Hump brackets
to side of Trak Plate that has ¼” hardware slots closer together, to better accept equipment,
(consoles, control heads, etc)
• Slide (6) ¼-20 x ¾” Hex Head Bolts into ¼” Hardware Slots.
• With bolts in Trak, position Hump brackets.
• There is a left and right side to the Rear Hump Brackets. Top of brackets will be
parallel to the transmission hump.
• Attach ¼” serrated nuts and tighten.
Front Hump Bracket C-B17
Rear Hump Bracket C-B27
Trak
¼” Hardware Slots

C-TM-IMP-INST-2-07
2
INSTALLATION:
1. REMOVE SEATS:
• Remove rear seat base torx bolts.
• Slide seat to rear most position.
• Seats do not have to come out of vehicle, they will just need to be tilted out of way to
place Trak-Mount assembly. Be careful of wire plugs if vehicle has power seats.
2. MOUNT ASSEMBLED TRAK-MOUNT:
• Place Trak-Mount assembly so front bracket sets squarely on floor beam straddling
seat bolts – lag bolt to the floor beam. The rear hump brackets are place on floor
between floor of vehicle and seat base and can be mounted using the rear seat bolts.
• Re-mount seats over Trak-Mount assembly and tighten all hardware.
• Mount equipment (consoles, control heads, etc), prior to plastic end caps, for access
to hardware slots.
Rear Hump Bracket
(Driver Side)
Rear Hump Bracket
(Pass. Side)
Front Hump Bracket
Trak
