Havis-Shields Telescoping Computer Base C-TCB-7-IMP Configuration guide

C-TCB-7-IMP-INST-12-04
INSTALL INSTRUCTIONS C-TCB-7-IMP
TELESCOPING COMPUTER BASE
CHEVROLET IMPALA SPECIFIC
C-SERIES-IMP CONSOLIDATOR® CONSOLE MOUNT
(Example: C-1400-IMP)
TOOLS REQUIRED:
3/16” Allen wrench Open-end wrench set
HARDWARE & COMPONENETS:
QTY DESCRIPTION PART #
1 Pole support assembly CM93071-7
1 Telescoping pole assembly CM93072-1
1 Spacer bracket CM93381
4 ¼-20 Hex nut GSM30005
4 ¼”Flat washer GSM31005
2 ¼-20-x ½”Hex head bolt GSM33000
2 ¼-20 x 1”Hex head bolt GSM33002
Always!
 Read all instructions before installing any Havis-Shields Equipment Corp products.
 Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
 Use hardware provided with install kit
Pole support
assembly
Telescoping pole
assembly
¼-20 x ½” Hex
head bolt & ¼” Flat
washer
Spacer Bracket w/
¼-20 x ¾” Hex
head bolt & ¼” Flat
washer

C-TCB-7-IMP-INST-12-04
SUB ASSEMBLY:
1. Confirm receipt of all hardware and components.
2. Install Chevrolet Impala Specific C-Series-IMP Consolidator® into vehicle using hardware
and instructions provided.
3. Determine location on console to mount C-TCB-7-IMP and be sure to leave room on
passenger side of console to mount.
INSTALLATION:
1. Mount C-TCB-7-IMP on side of Chevrolet Impala Specific C-Series-IMP console.
• Position C-TCB-7-IMP on Passenger side of console.
• Attach to lower rail of console first.
• Position spacer bracket between C-TCB-7-IMP and C-Series-IMP console.
• Align nuts in rails to slotted holes on pole support assembly.
• Attach pole support assembly and spacer bracket to console using ¼-20 x ¾” Hex
head bolts, washers and nuts with in the console rail.
• Now attach top of C-TCB-7-IMP using only ¼-20 x ½” Hex head bolts, washers and
nuts with in console rail.
Note: Rails of console have (4) ¼-20 hex nuts on both top and bottom. (Extra nuts are
provided if needed)
• Attach optional C-3090 Computer mounting platform to Telescoping pole assembly.
C-TCB-7-IMP mounted
on a C-1400-IMP console
(sold separately)
