Havis-Shields Cupholders C-CUP2 Series User manual

C-CUP2-INST-6-06
Installation Instructions
C-CUP2 SERIES CUPHOLDERS
TOOLS REQUIRED:
Torx TX20 Driver
Adjustable wrench (panel mount only)
Phillips screwdriver
Warning: Please read all instructions and warnings prior to installation. This product must be installed
and used in accordance with FMVSS, vehicle manufacturer, and all applicable laws, codes, and
specifications. These instructions are provided as a guideline for proper installation, and do not
purport to cover every possible installation scenario or configuration. If questions arise, consult the
factory.
INSTALLATION:
There are four standard installation types, as listed below. Please follow the instructions applicable
to your specific installation:
C-CUP2-I Internal mount for enclosed consoles:
1. The internal-mount cupholder requires
4” of mounting space.
2. First, select the optimum location for
installing the cupholder. Carefully
remove any equipment/panels already
installed in that location.
3. Using the hardware supplied, secure the
cupholder bracket only to the console
(without the plastic cupholder insert
being installed.)
4. Install the plastic cupholder insert by
pressing it firmly into the bracket.
Install the two rubber cupholder pads by
pressing them firmly into each cup
location, if they are not already installed.
5. Replace any necessary equipment/panels
to complete installation, ensuring that
they are installed correctly.
C-CUP2-E-AS or C-CUP2-E-C External mount to rear end-of-console extrusion:
1. Most end-of-console mounted
cupholders should be installed using this
method.
2. First, remove any existing cupholders or
other accessories that will interfere with
the installation of the new cupholder.
3. Remove the two screws holding the
endcap onto the extrusion. Remove the
plastic endcap (note that it may be held
with adhesive.)
4. Using the hardware supplied, install the
cupholder bracket only (without the plastic
cupholder insert being installed.)
5. Install the plastic cupholder insert by
pressing it firmly into the bracket.
Install the two rubber cupholder pads by
pressing them firmly into each cup
location, if they are not already installed.

C-CUP2-E-AS or C-CUP2-E-C External mount to rear end-of-console panel:
1. This method should only be used when
the external mount to end-of-console
extrusion method is not possible.
2. First, remove any existing cupholders or
other accessories that will interfere with
the installation of the new cupholder. Be
sure to remove the plastic endcap as
well, if it is present and will interfere.
3. The console will need to be opened in
order to install the cupholder. Remove
enough equipment/panels to gain sufficient
access to install the new cupholder, taking
care not to damage the accessories.
4. Drill any mounting holes necessary in
the console and/or cupholder mounting
bracket, ensuring proper alignment
between the bracket and the console end
panel. Most Havis-Shields consoles will
include suitable mounting slots, so this
step should not be necessary for most
installations.
5. Attach the cupholder bracket only
(without the plastic cupholder insert
installed) using the supplied hardware.
6. Install the plastic cupholder insert by
pressing it firmly into the bracket.
Install the two rubber cupholder pads by
pressing them firmly into each cup
location, if they are not already installed.
7. Replace any panels or accessories
removed, ensuring that they are installed
correctly.
C-CUP2-E-TM External Trak-Mount:
1. This method should be used to attach a
cupholder to Havis-Shields standard
Trak-Mount console track.
2. First, remove any equipment from the
track that will interfere with the
installation of the new cupholder. Note
that at least one end of the track must be
fully accessible in order to complete
installation.
3. Set the cupholder onto the track, and align
the mounting holes in the bottom with
suitable mounting slots. Select the correct
hardware size and slots so that the
cupholder will be secured in at least two
places. Please note that the innermost
holes on the cupholder will accept only
#10 hardware, while the outermost holes
will accept either #10 or 1/4" hardware.
4. Install supplied nuts into the track, sliding
them in from the end. There are different
slots in the track for #10 hardware and 1/4"
hardware, so the installer must place the
correct hardware into the correct slot(s).
Slide the nuts to the approximate location
where they will align with the holes in the
cupholder.
5. Set the cupholder in place on the track,
align the holes correctly with the nuts,
and secure it with the supplied screws.
6. Install the two rubber cupholder pads by
pressing them firmly into each cup
location. Please note that the cupholder
pads will fully hid the screws when they
are installed correctly.
7. Replace any equipment removed,
ensuring it is installed correctly.
CLEANING & MAINTENANCE:
Plastic cupholders that are not Trak-Mount can be easily removed for cleaning. Simply grip the
cupholder firmly, and pull it straight out. The rubber pads can also be removed for cleaning. Use
only mild soap in cleaning; never use harsh chemicals. Once dry, the pads and cupholders can be
reinstalled by simply pressing them back in place.
