Havis-Shields C-VS-0812-CHGR Configuration guide

INSTALL INSTRUCTIONS
C-VS-0812-CHGR & C-VS-0812-CHGR-1
20” VEHICLE SPECIFIC LOW PROFILE CONSOLE
2006-2007 DODGE CHARGER and AGNU
2008 DODGE CHARGER and AGNU
TOOLS REQUIRED:
Ratcheting wrench
Sockets - 7/16”
Combo wrench set
Screwdriver set
T-20 torx bit
HARDWARE:
ITE # QTY DESCRIPTION PART #
1 1 ” console housing CM000672
2 1 Support bracket for stout console CM001595
3 1 12” Low profile console (housing only) C-SM-1200-H
4 1 Frame support bracket CM001593
5 1 YAW sensor cover panel CM00163
6 1 Rear floor filler panel CM001642
7a 1 Driver side wire panel - 2006 – 07 Charger CM00159 -D
7b 1 Driver side trim panel - 200 Charger CM002165
8a 1 Passenger side wire panel - 2006 – 07 Charger CM00159 -P
8b 1 Passenger side trim panels - 200 Charger CM002164
9 2 “L” bracket mounting leg C-B41
10 1 Extension floor plate CM93712
¼-20 Hex nut GSM30005
¼-20 x ¾” Hex bolt GSM33001
¼-20 Serrated nut GSM30023
6 10-32 x ½” Phillips machine screw GSM3311
4 10-32 Keps nut GSM3002
2 #10 Flat washer GSM31003
2 Torx hardware kits C-HK-1
1 Mounting hardware kit C-HK

C-VS-0 12-CHGR_INST_12-07
2
Always!
 Read all instructions before installing any Havis-Shields Equipment Corp products.
 Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
 Use hardware provided with install kit
 For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html, email [e-mail] or call
1- 00-524-9900.
#4 (not shown)
#2
#5
#8
#7
#6
#3
#1
#9
#10 & #9
(not shown)

C-VS-0 12-CHGR_INST_12-07
3
View of installation to this point
Note: Be sure OEM wiring is not
being crushed by mounting
brackets
Place console assembly and
install extension (#10) for “L”
bracket mounting leg on stout
console, using OEM hardware.
Attach “L” bracket mounting
leg (#9) to rear
floor filler panel
(#6) using ¼-
20 x ¾” hex bolts
and serrated nuts.
Remove OEM supplied trak.
Note: Some hardware is re-
used
in installation of console
View of trak removed Attach frame support bracket
(#4) to vehicle using 10/32 x ½”
phillips machine screws,
washers, and keps nuts
Attach support bracket for stout
console (#2) to vehicle and to frame
support bracket using OEM hardware
and #10 x ½” phillips machine screws
and washers
Tighten hardware
Attach frame support bracket
(#4) to vehicle using 10/32 x ½”
phillips machine screws,
washers, and keps nuts
Note: Due to some slight differences on the OEM floor mount bracket, tabs with mounting hole may
need to be bent sligh
tly to accommodate the console front support bracket Bending these tabs can easily
be done using pliers

C-VS-0 12-CHGR_INST_12-07
4
View of installed C-VS-0 12-CHGR Route wiring and install emergency
controls and accessories
Attach rear floor filler panel (#6)
to vehicle using OEM hardware
Attach YAW sensor cover panel
(#5) to vehicle using front
driver side hardware from rear
floor filler panel (#6)
Attach driver and passenger-
side wire panels (#7 & ) to
frame support bracket using #10
x ½” phillips machine screws
and washers.
