Havis Ledco Installation and operation manual

www.havis.com
1-800-524-9900
Compatible with any Panasonic Toughbook CF-30 and CF-29
Improves productivity
By reducing downtime with onboard diagnostics allowing remote troubleshooting.
Smallest Footprint
And lightest weight of any comparable product, taking up less cabin space
than any other dock currently available.
Tested to the highest standards
In the industry, including MIL-STD-810F shock and vibration tests and
a 30 mph crash test (SAE J1455).
The Industry's First Intelligent Dock
The new Havis® Ledco® Docking Station for Panasonic CF-30 and CF-29 is the most
intelligent, lightest, strongest Panasonic compatible dock on the market providing
the safest, most reliable solution for mobile computing applications.
Specifications (Part # DS-PAN-102)
Height: 3.8” (9.5 cm)
Width: 12.4” (31.5 cm)
Depth: 11.9” (29.9 cm)
Weight: 4.5 lbs (2.04 kg)
Construction: Aircraft grade aluminum uni-body with
reinforced nylon impact resistant plastic side rails
Certifications
•Vibration Testing: MIL-STD 810F 514.5
•30 MPH Crash Test (SAE J1455)
•-23° to +60° C Operating Test
•Electro Magnetic Compatibility Compliant
• Cycle Test: Latch Handle & Docking/Connectors Mechanism
tested to 30,000 cycles
Havis Ledco Docking Station
for Panasonic CF-30 and CF-29

Diagnostics Front Facing USB USB LED’s Lightweight Additional USB’s
Front LED blinks green or
red to display error codes,
resulting in increased
uptime through remote
trouble shooting.
Front facing USB port
is conveniently located
so using temporary USB
devices is easy.
Six LED’s on the front of
the dock lets you know the
status of each USB port.
At 4.5 lbs the DS-PAN-102
is the lightest Panasonic
approved CF-30 Docking
Station currently on
the market.
Four rear USB ports let you
expand your connectivity,
so adding a printer or card
reader is no problem.
4 USB 2.0 Ports
Speaker/Mic
Single or Dual Hi-Gain Antenna
On Board Power Supply
(12 VDC input required)
VGA
RJ45
Ethernet DB9 Serial Ports 6 LED's for USB Status
LED Dock Diagnostics Front USB 2.0 Port
Integrated Cable Strain Relief Clips
New Features
Port Replication (Part # DS-PAN-102-2 shown)
Part # USB
2.0
DB9
Serial
RJ45
Ethernet
VGA LED Dock
Diagnostics
LED for
USB Status
Cable
Exiting
Antenna:
Single Hi-Gain
Antenna:
Dual Hi-Gain
DS-PAN-102 6 2 1 1 Yes Yes Rear Optional
(DS-PAN-102-1)
Optional
(DS-PAN-102-2)
DS-PAN-101 4 2 1 1 Limited No Front Optional
(DS-PAN-101-1)
Optional
(DS-PAN-101-1)
DS-PAN-103 - - - - No No -No No
www.havis.com
1-800-524-9900
DS-PAN-102_NPR_9-09
•On-site eet audits and installation training •Standard Three-Year Warranty on all units
• Demo equipment programs and presentations •Extended Plus Warranty available
•Dedicated customer service
Havis Ledco Docking Station
for Panasonic CF-30 and CF-29
