08/18 Model 8605WC Page 1 of 4
1455 Kleppe Lane Sparks, NV 89431-6467 (775) 359-4712 Fax (775) 359-7424
E-mail: haws@hawsco.com  website: www.hawsco.com
Model 8605WC Barrier Free Emergency
Shower & Eye/Face Wash Booth
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
No. 2080194(13)
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing
to Haws within a reasonable period after receipt of the product. Where claims for defects
are made, the defective part or parts shall be delivered to the Company, prepaid, for
inspection. HAWS will not be liable for the cost of repairs, alterations or replacements, or
for any expense connected therewith made by the owner or his agents, except upon
written authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages
caused by defective materials or poor workmanship, except for replacements, as provided
above. Buyer agrees that Haws has made no other warranties either expressed or implied
in addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED
OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297
08/18 Model 8605WC Page 2 of 4
LOCATION OF UNIT: The Model 8605WC Barrier Free Emergency Shower &
Eye/Face Wash Booth should be installed in close proximity to potential accident
areas. It should be clearly identified free from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1” IPS with 30-90 psi (2-6
ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet filter
is recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1” IPS. Waste outlet is 3” IC
(Inside caulk).
TROUBLESHOOTING
PROBLEM REPAIR CHECKLIST
1.
No flow.
1.
Check the main shut-off valve.
2.
Insufficient water flow.
2.
Verify minimum 30 psi (2 ATM)
flowing supply line pressure.
3.
Insufficient water flow. On
eyewash, however, shower is
sufficient.
3.
a.
Probable clogging of flow control
due to inadequate line flushing.
Unscrew eye/face wash head and
remove the four screws to
disassemble the head. Clean flow
control and reassemble head. See
SP65 Installation Drawing for details.
4.
Insufficient water flow at the
showerhead, however,
eyewash is sufficient.
4.
Probable clogging of flow control
inside showerhead. Unscrew
showerhead off of elbow and clean
rubber flow control.
5.
Eyewash stream does not meet
desired eye level.
5.
Possible blocked flow control, see
above solution. Possible non-
leveled eyewash assembly.
6.
Water does not drain properly.
6.
Check the main waste line of your
building to see if it does handle the
capacity required for the entire
drainage system.
For more information on Haws products, see our website: www.hawsco.com
© 2018 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.
PARTS BREAKDOWN
5
3
VALVE ASSEMBLY
TEST TAG
SHOWER/EYEWASH SIGN
PULL ROD
2
4
4
5
3
2
7
6SHOWER HEAD
SHOWER/EYEWASH LABEL
6
7
SHOWER VALVE ASSEMBLY8
8
1
EYE/FACE WASH ASSEMBLY
1
0006575890
SP829
SP178LG
SP170
SP178
SP202
SP229
SP65
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
RTM
8/16/01
13
0002080194
8605WC
EMERGENCY SHOWER
1:1
11
MJ
08/07/18
FV
3 of 4
PARTS BREAKDOWN
5334
2018
NG
40-1/2"
1029mm
514mm
20-1/4"
13"
330mm
26"
660mm
19-1/4"
489mm
22"
559mm
279mm
11"
38-1/2"
978mm
AA
SECTION A-A
MOUNTING DETAIL
Ø 5/8"
4X
Ø 16mm
HOLE THRU
46-1/2"
1181mm
83"
2108mm
12-7/8"
327mm
27" MIN
686mm
914mm
36"
2318mm
91-1/4"
FLOOR LINE
2184mm
86"
3-7/8"
98mm
90-1/8"
2289mm
2-1/4" (57mm)
RECESS FOR
WHEELCHAIR
ACCESS
1" IPS
SUPPLY
OPTIONAL
1" IPS
SUPPLY
3" DRAIN PIPE
4X 1/2" (12.7mm)
ANCHOR
BOLT ASSEMBLY
18"
DRAIN SHOWER
3" INSIDE CAULK
(SUPPLIED)
(NOT SUPPLIED)
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
RTM
8/10/01
13
0002080194.D
8605WC
EMERGENCY SHOWER
NA
11
MJ
08/07/18
FV
4 OF 4
INSTALLATION
5334
2018
NG
36"
NOTES:
1. WHEN INSTALLING THIS UNIT, LOCAL , STATE, OR FEDERAL CODES SHOULD BE ADHERED TO FOR
INSTALLATION DIMENSIONS (LOCATIONS), WASTE AND SUPPLY REQUIREMENTS OTHER THAN SHOWN.
2. TO COMPLY WITH ANSI Z358.1-2014 FOR EMERGENCY EYEWASH OR EYE/FACE WASH:
EYEWASH OR EYE/FACE WASH SHALL BE POSITIONED SUCH THAT FLUSHING FLUID PATTERN IS NOT
LESS THAN 33" (838mm), NO GREATER THAN 53" (1346mm) FROM SURFACE ON WHICH USER STANDS,
AND 6.0" (153mm) MINIMUM FROM WALL OR NEAREST OBSTRUCTION.
3 SHOWER SHALL BE POSITIONED SUCH THAT SHOWER HEAD IS NOT LESS THAN 82" (2083mm) OR
GREATER THAN 96" (2438mm) FROM SURFACE ON WHICH USER STANDS.
4. SHOWER SPRAY PATTERN SHALL HAVE A MINIMUM DIAMETER OF 20" (508mm) AT 60" (1524mm) ABOVE
SURFACE ON WHICH USER STANDS. CENTER OF SPRAY PATTERN SHALL BE LOCATED AT LEAST 16" (406mm)
FROM ANY OBSTRUCTION.
5. DIMENSIONS MAY VARY ±1/2".
33"-53"
838mm-1346mm
FLOW PATTERN
