Model 8140
Portable emergency body shower – 9 liters capacity
COMMISSIONING:
•Unscrew the two securing nuts and remove the device head.
•Fill approximately 9 liters of water (± 5%) from a container with a volume scale or a balance.
•Add the antibacterial additive (9086) to the water. The filling should be replaced every 12
months and when the device has not been used for an extended period.
•No special precautions are required when handling the water additive. Avoid contact of
the undiluted solution with the eyes.
•Reinsert the device head and tighten the nuts slowly (10 Nm).
USAGE:
•Place the device on the ground and pull out the safety pin at the blue ring.
•Then fully put up the blue handle. This will open the CO2cartridge and pressurize the
container.
•Press the black trigger lever on the spray lance to activate the shower.
•Keep the spray head at least 50 cm away from the body.
•Avoid any contact between the hose and an electrical conductor.
•It is recommended to refill the container and replace the CO2cartridge after each use.
•Do not use the portable body emergency shower 8140 to rinse eyes.
•The device is not suitable for freezing conditions.

Installation, Operating &
Maintenance Instructions
09/23 Installation, Operating & Maintenance Instructions Model 8140 2 / 2
REPLACEMENT OF CO2CARTRIDGE:
•Ensure that there is no internal pressure in the device before opening it.
•Unscrew the two securing nuts and remove the device head.
•Unscrew the white plastic tube from the device head.
•Remove the CO2cartridge using a 19 mm wrench (DO NOT use your hands).
•Inspect the seal for deformation or cracks and replace it if necessary.
•Press the tip of the firing pin back into the device head. The yellow end should now be
visible outside under the blue handle.
•Reinsert the blue safety pin into its designated position.
•Mount the new cartridge after greasing the threads. This will facilitate disassembly during
future inspections. Screw the cartridge in without excessive force.
•Screw the plastic tube back into the device head.
•Reinsert the device head and tighten the nuts slowly (10 Nm).
MAINTENANCE:
•Check the proper functioning of the safety system (pin).
•Inspect the hose and spray lance.
•Perform a thorough inspection of the entire hose by blowing it out.
•Lubricate the moving parts, especially the firing pin rod.
•Replace any defective or missing parts using original replacement components.
•Rinse the device housing and carefully inspect its internal condition.
•Lubricate the mounting thread of the cover with the device body.
•Fill the device with water and the antibacterial additive (9086), as mentioned during the
initial use.
•Reattach the device head and tighten the nuts slowly (torque of 10 Nm).
•Record the inspection date in the designated table on the outside of the body shower.
