Haztec 4-1815-X User manual

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
4-1815-X
15-LED Scene Light
M301.1.0 - 1 - January 2021
Thank you for purchasing this Haztec product. Before proceeding with installation, it is essential
to read and understand this instruction booklet.
▪This product must be installed by persons competent in vehicle electrical installations
▪Care should be taken to ensure that water ingress cannot occur through mounting or
wiring holes
▪Regularly inspect the product to confirm correct operation
▪DO NOT stare directly into the light it produces as permanent damage to the eyes
may result
▪Use only a mixture of soap and water to clean this product
▪DO NOT allow solvents and fuels etc. to come into contact with this product
Basic Operating Specifications:
Supply voltage range:
10-30VDC
Maximum current draw:
1.71A @ 12.5VDC
LED power:
15 x 3W
Lumen output:
2025lm
Beam angle:
0-70 degrees asymmetric
Operating temperature range:
-40 to +55OC
IP rating:
IP67
Dimensions (mm):
230.13 (L) x 47.95 (H) x 34.1 (D)
235 (L) x 52.5 (H) x 35.5 (D) with 0Ogasket
235 (L) x 53 (H) x 39.5 (D) with 7Ogasket
Bezel RAL colours:
Black
9017 (Traffic black)
White
9003 (Signal white)
Yellow
1016 (Sulphur yellow)
Red
3000 (Flame red)
▪15-LED Scene light
▪12/24VDC
▪Surface mount
▪Choice of bezel colour
▪IP67 rated

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
4-1815-X
15-LED Scene Light
M301.1.0 - 2 - January 2021
Connection Instructions:
Wire
Connect to
Function
Red
Positive [+] via switch & fuse
Main feed
Black
Permanent negative [-]
Earth / Chassis ground
Installation Instructions:
▪The scene light is supplied with two gaskets –0 degrees for standard installations and
7 degrees which allows the light to be angled further away from the vehicle
▪Typical beam spread

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
4-1815-X
15-LED Scene Light
M301.1.0 - 3 - January 2021
▪Ensure that the mounting surface is flat, clean, and dry before commencing with
installation
▪Always use the fixings provided, however if a different fixing is required, it is essential
that it fits correctly into the housing
▪Ensure that the mounting holes will not cause damage to, or interfere with, any of the
vehicles wiring and always refer to the manufacturer’s manual for the location of any
airbag systems
▪Using the gasket as a template, mark the mounting holes and position of the cable entry
▪Drill the holes adequately to accept the M4 machine screws and power cables
▪If required, use a suitable customer supplied sealant to prevent water ingress
▪Attach the gasket to the lamp, then pass the power cables through the hole and fit the
lamp using the M4 x 20mm machine screws, nuts, and washers
▪Should the power cables need to be extended, always use cables of equal gauge and it is
recommended that joints are made waterproof
Basic Dimensions:
