Haztec 4-1809-X User manual

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ [e-mail] ∙ www.haztec.uk
4-1809-X
LED Scene Light
M295 Issue 1.1 Created by: Technical December 2020
Thank you for purchasing this Haztec product. Before proceeding with installation it is essential
to read and understand this instruction booklet.
Warning!
This product must be installed by persons competent in vehicle electrical installations
Care should be taken to ensure that water ingress cannot occur through mounting or
wiring holes
Regularly inspect the product to confirm correct operation
DO NOT stare directly into the light it produces as permanent damage to the eyes
may result
Use only a mixture of soap and water to clean this product
DO NOT allow solvents and fuels, etc. to come into contact with this product
Basic Operating Specifications:
Supply voltage range:
10-30VDC
Maximum current draw:
1.3A @ 12VDC
Lumen output:
1000
Operating temperature range:
-40OC to +65OC
IP rating:
IP67
Dimensions (mm):
250 (L) x 57 (H) x 30 (D)
Connection Instructions:
Wire
Connect to
Function
Grey
Positive [+] via switch & fuse
Main feed
White
Permanent negative [-]
Earth / Chassis ground
9-LED angled scene light
12/24VDC
0-60 degree vertical asymmetric
beam, 80 degree horizontal beam
Surface mount
Available with blue, red or white
cast housing
3 year warranty

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ [e-mail] ∙ www.haztec.uk
4-1809-X
LED Scene Light
M295 Issue 1.1 Created by: Technical December 2020
Sealing Plug Installation:
Ensure that the mounting holes (1) are free from dirt & moisture
Place the plug (2) into the hole with the flat end facing down
Push the plug into the mounting hole making sure that the chamfered edge is in-line with
the profile of the light (3) until it is fully home (4)
