Haztec 7-1211-40-8-S User manual

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
7-1211-40-8-S
Flood Barlight
M386.1.0 - 1 - July 2022
Thank you for purchasing this Haztec product. Before proceeding with installation, it is essential to
read and understand this instruction booklet.
▪This product must be installed by persons competent in vehicle electrical installations
▪Care should be taken to ensure that water ingress cannot occur through mounting or
wiring holes
▪Regularly inspect the product to confirm correct operation
▪Keep the heatsink fins clean and free of debris in order to maintain air flow
▪Use only a mixture of soap and water to clean this product
▪The light becomes hot during continuous operation. DO NOT touch the casing or lens
for at least 30 minutes after switching off
▪DO NOT stare directly into the light it produces as permanent damage to the eyes
may result
▪DO NOT allow solvents, fuels, or acetone-based cleaners etc. to contact this product
Basic Operating Specifications:
Supply voltage range:
10-30VDC
Power output (lumens):
Raw: 3400 / Effective: 2466
Beam spread angle:
15OSpot
Operating temperature range:
-40OC to +60OC
Fuse rating:
8A
Dimensions (mm):
200 (L) x 90 (D) x 70 (H)
Connection Instructions:
Wire
Connect to
Function
Red
Permanent positive [+] via switch & fuse
Main Feed
Black
Permanent negative [-]
Earth/Ground
Note: The main feed fuse must be installed within 12” of the power source
▪Spot beam barlight
▪8”(200mm)
▪40W single row
▪3400lm
▪3W CREE LEDs
▪IP67 rated
▪1 year warranty

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK
T: [phone] ∙ inf[email protected] ∙ www.haztec.uk
7-1211-40-8-S
Flood Barlight
M386.1.0 - 2 - July 2022
Installation Instructions:
▪DO NOT install this product or route any wires in the deployment area any airbag system,
as this will cause damage or reduce the effectiveness of the system, or more seriously
become a projectile that could cause personal injury or death
▪Refer to the vehicle owner’s manual to identify the airbag deployment areas
▪The user/installer assumes full responsibility for determining the correct mounting location
based on providing safety to all passengers inside the vehicle
▪If mounting this product requires drilling holes, the installer must be sure that no vehicle
components or other vital parts could be damaged by the process
▪Check both sides of the mounting surface before drilling commences
▪De-burr holes and remove any metal shards or remnants
▪Install rubber grommets into all wire passage holes or seal with a suitable customer
supplied sealant
▪For this product to operate at optimum efficiency, a good electrical connection to chassis
ground must be made
▪Attach the mounting bracket to the light using the supplied ¾” bolts and tighten using an
Allen key. The brackets can be moved along the channel at the base of the light to the
required position
▪Use the supplied 1 ¼” bolts, washers, and nuts to mount the lamp to the vehicle
▪Connect the red wire to positive [+] of a toggle switch and run the appropriate gauge wire
(min. 18AWG) from the input of the switch to the positive [+] terminal of the vehicle battery
▪Connect the black ground wire to the negative [-] terminal of the vehicle battery or any
good bare metal ground source
▪When extending power wires, it is recommended to solder the connections and then to
apply heatshrink over the connections ensuring that they are waterproof
Basic Dimensions:
