Model 500KL
Thank you for your purchase of this Health o meter
®
Professional product. Please read this
manual carefully, and keep it for easy reference or training.
TABLE OF CONTENTS
Cautions and Warnings ............................................................................................. 3
Specifications / Definition of Symbols........................................................................ 5
Certifications / Connectivity / Disposal ...................................................................... 6
500KL Assembly Instructions ................................................................................... 7
Set up / Batteries ....................................................................................................... 14
Operating Instructions ............................................................................................... 16
Maintenance .............................................................................................................. 21
Calibration ................................................................................................................. 22
Troubleshooting ........................................................................................................ 23
Warranty .................................................................................................................... 24
Note: This scale has been factory calibrated, and does not
require calibration prior to use.
Please register your scale for warranty coverage at:
www.homscales.com
For User Instructions updates and revisions please go to:
www.homscales.com

3

CAUTIONS AND WARNINGS
When operating this scale:
 To prevent injury and damage to your scale, please follow the enclosed user instructions
to assemble and operate very carefully.
 Exercise caution when assembling the scale column so as to not pinch the load cell
connector cable.
 For accurate weighing, this scale must be placed on a flat, level and stable surface.
 For accurate weighing, verify before each use the proper operation according to the
procedure described in this manual.
 Operating this scale at voltages and frequencies other than specified can damage the
equipment and will void the warranty.
 Do not transport the scale with any weight on the platform.
 Do not exceed recommended weight limit of 500 lb / 220 kg for this scale.
 Do not use in the presence of flammable or explosive materials.
 For accurate weighing, if the “Lo” indicator activates, replace the batteries or switch to
the optional AC adapter as soon as possible.
 If the scale becomes damaged, it should not be operated until properly serviced.
 When replacing / inserting batteries, be sure to use all new batteries.
 To prevent patient injury, the patient must be attended throughout the entire weighing
event.
 This equipment has been tested and found to comply with the EMC limits for the Medical
Device Directive 93/42/EEC (EN 55011 Class A and EN 60601-1-2). These limits are
designed to provide reasonable protection against harmful interference in a typical
medical installation. The equipment generates, uses and may radiate radio frequency
energy and, if not installed and used in accordance with these instructions, may cause
harmful interference to other devices in the vicinity. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference with other devices, which can be determined by turning the
equipment off and on, the user is encouraged to try to eliminate the interference by one
or more of the following measures:
o Reorient or relocate the receiving device.
o Increase the separation between the equipment.
o Connect the equipment into an outlet on a circuit different from that to which the
other device(s) is connected.
o Consult Customer Service or a field service technician for help.

4

CAUTIONS AND WARNINGS
When operating this scale with the AC adapter:
 Operate this scale exclusively with the AC adapter provided by Health o meter
Professional. Use of an unspecified adapter will void the warranty, and can pose a
serious safety hazard.
 For use with AC adapter model ADPT31 (Domestic, USA) or ADPT30WA (International,
plug kit)
 Prior to using this scale, inspect the AC adapter cord for cracking / fraying, or for broken
/ bent plug prongs.
 Prior to using this scale, ensure that the AC adapter is plugged into an outlet with the
rated voltage appropriate for operation.
 Ensure that the AC adapter outlet is wired to a circuit breaker or other protected power
source.
 Ensure that the AC adapter and scale do not come in contact with liquids, excessive
temperature, or excessive humidity.
 Unplug the AC adapter, and carefully store both the adapter and adapter cord before
moving the scale.
 If the scale is being connected to another medical device, the power adapter must not be
used. Disconnect the power adapter from the scale and use only the battery power.


SPE
C
Genera
l
The Mo
d
technolo
g
weight
m
make th
e
Weight
c
an AC a
d
500KL
S
Capacit
y
Power
R
Environ
m
Physical
DEFI
Att
e
C
IFICA
T
l
d
el 500KL e
y
g
y. Each pr
e
m
easuremen
t
e
weighing
p
c
an be displ
a
d
apte
r
, mo
d
S
cale Spe
c
y
and Resolu
t
R
equirements
m
ental
Dimensions
N
ITIO
N
e
ntion, Consult Acc
Type B
F
AC to
D
T
IONS
y
e level digit
e
cision scal
e
t
s. In additi
o
p
rocess sim
p
a
yed in pou
n
d
el ADPT31
c
ifications
t
ion 5
0
1
2
O
S
t
M
S
c
(
O
W
D
H
W
N
OF S
Y
ompanying Docu
m
F
Applied Parts
D
C power supply
FOR T
H
t
al beam sc
a
e
is designe
d
o
n, each sc
a
p
le, fast, an
d
n
ds (lb) or in
(not inclu
d
0
0 lb x 0.2 lb
2
0 - 240AC,
5
O
perating tem
p
t
orage temp
e
M
aximum Hu
m
cale
O
verall Dime
W
idth: 14-1/8”
epth: 21-1/8”
eight: 53-5/8
”
W
eight: 21 lb (
Y
MBOL
40C
T
H
A
m
ents
5
H
IS SC
A
a
le uses hig
h
d
to provide
a
le is design
e
d
convenien
t
kilograms (
d
ed), or by
6
(220 kg x 0.
1
5
0 - 60Hz - 9
V
p
eratures: 5
0
e
ratures: 30°
F
m
idity: 95% R
H
nsions)
(36 cm)
(53.8 cm)
”
(136.2 cm)
9.5 kg)
S
T
emperature range
H
umidity range
A
tmospheric pressu
A
LE
h
ly sophistic
accurate, r
e
e
d to provid
e
t
.
kg). This s
c
6
-
A
A batt
e
1
kg)
V
DC adapte
r
°F to 104°F (
F
to 122°F (0
°
H
Pla
t
(St
a
Wid
De
p
Hei
g
re range
ated microp
e
liable and
r
e
the user
w
c
ale can b
e
e
ries (inclu
d
r
or 6 -
A
A ba
10°C to 40°
C
°
C to 50°C)
t
form
a
nding Area)
th: 13-¾” (34
p
th: 16-½” (41
g
ht: 2-3/8” (6
.
AC t
o
rocessor
r
epeatable
w
ith features
e
powered
u
d
ed).
tteries
C
)
.9 cm)
.9 cm)
.
0 cm)
o
DC power suppl
y
DC Connect
o
that
u
sing
y
o
r Polarity


CER
T
Certific
a
500KL
S
To enabl
designe
d
This con
copying
a
This sca
l
other el
e
availabl
e
500KL
S
This He
a
Follow t
h
waste or
T
IFICA
T
a
tion Des
c
S
cale Con
n
e reliable tr
a
d
to connect
nectivity hel
a
nd then re
c
l
e is EMR-E
e
ctronic devi
c
e
during nor
m
S
cale Dis
p
a
lth o mete
r
®
h
e national,
r
batteries.
D
T
IONS
/
c
riptions
n
ectivity I
n
a
nsmission
o
to a compu
t
ps minimize
c
ording pati
e
HR compati
c
es, please
m
al busines
s
p
osal
®
Profession
a
r
egional or l
o
D
o not disp
o
/
CON
N
Pelstar, L
L
meter
®
Pr
o
requireme
n
marketing,
This prod
1. UL606
0
2. CSA C
2
n
formatio
n
o
f weight, h
e
t
er, monitor
,
e
a source o
f
e
nt data.
ble. For mo
r
contact He
a
s
hours at 1
-
al scale mu
s
o
cal regulat
i
o
se of this d
e
6
N
ECTI
V
L
C has been
o
o
fessional m
e
n
ts. The Pels
and distribu
t
uct is teste
d
0
1-1 First E
d
2
2.2 No. 60
n
e
ight, and B
o
or other el
e
f
potential m
r
e informati
o
a
lth o meter
®
-
800-638-3
7
s
t be dispos
e
i
ons which
a
e
vice in the
d
V
ITY / D
o
fficially certi
f
e
dical device
s
t
ar, LLC qual
t
ion of specia
l
d
to and me
e
d
ition: Safet
y
1-1 M90: M
e
o
dy Mass I
n
e
ctronic devi
edical error
s
o
n regarding
®
Profession
a
7
22.
e
d of prope
r
a
pply to you
d
omestic w
a
ISPOS
A
f
ied as a ma
n
s
to be in co
m
ity assuranc
e
l
ized scales f
o
e
ts the requi
r
y
for Medic
a
e
dical Elect
r
n
dex (BMI)
d
ce via a bui
l
s
caused by
how to con
al Scales T
e
r
ly as electr
o
for disposal
a
ste stream.
A
L
n
ufacturer of
H
m
pliance with
s
e
system cov
e
o
r the Health
c
r
ements of:
a
l Electrical
E
r
ical Equipm
d
ata, this sc
a
l
t-in USB p
o
incorrectly
nect this sc
a
e
chnical Su
p
o
nic waste.
of electroni
c
H
ealth o
s
tringent IS
O
e
rs the desig
n
c
are Industr
y
E
quipment
ent
a
le is
o
rt.
a
le to
p
port,
c
O
n
,
y
.

7

500KL ASSEMBLY INSTRUCTIONS
Before Assembly
Each 500KL eye level digital beam scale is shipped disassembled in one carton. Carefully
inspect the carton for shipping damage before unpacking. If damage is found, contact your
shipper or a Health o meter
®
Professional representative immediately at 1-800-815-6615.
Claims must be filed with the shipper as soon as possible after receipt of the package. The
following information details what you will find inside the main carton as you unpack the parts for
assembly.
To prevent scratching any components, carefully remove each assembly from the carton and
unwrap the packing materials. Set the carton aside for storage. To avoid damaging the scale
parts when unpacking, do not use a box cutter, knife, scissors, or any sharp object to open the
protective inner packaging.
Parts List
Carton
(1) Scale platform - C
(1) Upper column (w / display assembly) - A
(1) Lower column - B
(6) AA batteries
(1) User instructions
(1) Upper height rod (w / head assembly) - D
(1) Lower height rod - E
(4) Column mounting screws (attached to lower column B)
Tools Required
Phillips head screwdriver (not included)


8

500KL ASSEMBLY INSTRUCTIONS (CONTINUED)
Assembling the 500KL Scale
1. Carefully remove the
contents of the carton and
place each part on a flat,
level, and dry surface.



G
A
B
C
F
D
E

9


500KL ASSEMBLY INSTRUCTIONS (CONTINUED)

2. Remove the 4 column
mounting screws and washers
from the bottom of column B
and set aside for assembly
step 8.
3. Remove the black bracket
from scale platform C. Read
the “Attention” label then
remove it from the bracket.
Place the bracket on the
bottom of Column B with the
adaptor jack arrow sticker
pointing towards the bottom of
the column.
Screws and washers
Column B
Column B
Bracket

10

500KL ASSEMBLY INSTRUCTIONS (CONTINUED)
4. Locate the load cell connector
cable inside column A. While
holding column B, slide the
cable through the center
opening at the top of column
B. Push the cable all the way
through Column B until the
plug reaches the bottom of the
column.
5. Align column A and column B.
Notches are located at the
bottom of column A and the
top of column B. Snap the
locking tab into place. Ensure
that the locking tab is locked
securely into place. Note:
When aligning and locking
the columns, use caution
not to pinch the load cell
connector cable.
Column B
(top)
Column B
(top)
Column
A
(bottom)
Load cell
connector
cable
Column B
(bottom)
Load cell
connector
cable
Notches
Column B
(top)
Column A
(bottom)
Locking tab
Locked position

11

500KL ASSEMBLY INSTRUCTIONS (CONTINUED)

6. Place scale platform C on its
side and place Column B on its
side, perpendicular to the
platform. The front of the
display head on Column A
should be facing forward and
above scale platform C.
7. Carefully pull the cable
connector from the bottom of
Column B and plug into the RJ
jack on scale platform C.
Caution: Once connected,
keep a firm grip on the
columns to ensure the load
cell connector cable is not
pulled out from the RJ jack.
This cable connects the load
cells to the display head and
must be entirely plugged in
for the scale to function
properly.

RJ Jack

12

500KL ASSEMBLY INSTRUCTIONS (CONTINUED)

8. Position and secure the
connected columns A and B to
scale platform C. Locate the 4
column mounting screws
previously removed in step 2.
Insert the 4 screws through the
bottom of scale platform C
screw holes and into Column
B. Ensure that washers are
located between the screw
heads and the scale platform
C screw holes. Using a Phillips
head screwdriver, tighten the
screws to secure Column B to
the base of platform C.
9. Height Rod Assembly:
Locate the upper height rod D
and lower height rod E. Align
upper height rod D with lower
height rod E. Snap the locking
tab into place. Ensure locking
tab is securely locked.
Upper Height Rod D
Locking Tab
Lower Height Rod E
Notch

13

500KL ASSEMBLY INSTRUCTIONS (CONTINUED)

10. Position the bottom of the fully
assembled height rod into the
height rod opening G at the
top of column A. Press locking
tab F inward to insert the
height rod into the height rod
opening G. The scale is now
assembled and ready to use.


Height rod E
Locking tab F
Height rod
opening G
Column A
Locking tab F

14

SET UP / BATTERIES
Preparing the 500KL Scale for Use / Inserting Batteries
1. Remove the protective plastic film covering the display (the film says “FACTORY
CALIBRATED”).
2. Unplug the optional AC adapter, if connected to a power source.
3. With a Phillips head screwdriver remove the screw from the battery compartment cover
located on the back of the display. Remove the battery cover by pressing downward on the
locking tab.
4. Replace or install 6 new AA batteries. Health o meter
®
Professional recommends using an
alkaline or lithium battery, rated for 130°F (54°C) operation. Do not use zinc-carbon batteries.
5. Re-attach the battery cover to the display assembly.
6. Ensure all objects are removed from the scale’s platform, and then press the ON/OFF button
to turn the scale on. The display will show “Start”, then “0.0” LB or “0.0” KG. Press the LB/KG
button to select the weight mode (LB or KG).
Note: The battery icon on the display does not indicate battery life. The battery icon is displayed
when the scale is using batteries as the power source.
Note: This scale will always default to the settings and units last used (LB or KG).
Note: If the set up procedure fails, refer to the troubleshooting instructions. If the problem is not
corrected, contact Health o meter Professional Scales Customer Service at 1-800-815-6615.
Note: If “Lo” appears on the display, it indicates that the battery power is low. It does NOT
indicate a problem with the weight measurement.
Warning: If the scale will not be used for some time, remove the batteries to avoid a
safety hazard. Disposal of batteries must be performed in accordance with the prevailing
national, regional or local regulations which apply to you.
Locking tab
Battery cover
Display assembly

15

SET UP / BATTERIES (CONTINUED)
Optional AC Adapter
1. Connect the AC adapter (not included) into the adaptor jack on the scale platform C.
Warning: To avoid a safety hazard, use AC adapter model ADPT31 (Domestic, USA) or
ADPT30WA (International, plug kit)
2. Plug the scale’s AC adapter into the power source.
3. When the AC adapter is disconnected from the scale, the scale will switch to battery power if
batteries are installed.
Note: If the set up procedure fails, refer to the troubleshooting instructions. If the problem is not
corrected, refer to qualified service personnel.
Adaptor Jack


OPE
R
Fu
n
O
N
HOLD/
R
L
B
B
U
Z
E
C
L
E
N
DO
W
R
ATIN
G
n
ction
N
/OFF
R
ELEASE
B
/KG
B
MI
U
P▲
E
RO
L
EAR
N
TER
W
N▼
G
INST
R
Turns sca
Holds the
pressed a
g
Toggles b
e
Prompts
e
(BMI).
Increases
Zeroes ou
Clears th
e
Used to a
c
Decrease
s
R
UCTI
O
le on and o
f
weight valu
e
gain to clea
r
etween pou
e
ntry of heig
h
height inpu
t
u
t or tares th
e
e
incorrect h
e
c
cept heigh
t
s
height inp
u
16
O
NS
Keypad






D
e
ff
.
e
of the pati
e
r
the value.
n
ds (LB) an
d
h
t data to c
a
t
(0.5 in / 0.
5
e
scale prio
r
e
ight input
w
t
value in B
M
u
t (0.5 in / 0
.
scription
e
nt on the d
d
kilograms
a
lculate pati
e
5
cm increm
e
r
to a weighi
w
hen in BMI
M
I mode.
.
5 cm incre
m
isplay until t
(KG).
e
nt’s Body
M
e
nts)
ng.
mode.
m
ents)
he button is
M
ass Index

17

OPERATING INSTRUCTIONS (CONT)
Weighing a Patient
Note: When this scale is turned on, it will always default to the settings and units last used (LB
or KG).
1. Make sure there is nothing on the scale platform.
2. Press the ON/OFF button to turn the display assembly on.
3. Wait until the “0.0” LB or “0.0” KG appears on the display.
4. Ask the patient to step on the scale. The scale will begin to display weight information and will
lock on the patient’s weight when the stable weight of the patient is determined. Depending on
the movement of the patient on the scale, it may take several seconds for the scale to lock onto
the weight.
Caution: To prevent patient injury, the patient must be attended throughout the entire
weighing event.
5. The weight may be held on the display by pressing the HOLD/RELEASE button. To release,
press the HOLD/RELEASE button again.
6. After the weight measurement has been taken and is recorded, have the patient step off the
scale.
7. Press the ON/OFF button to turn the scale off.
Height Measurement Instructions
WARNINGS: Use caution when sliding height rod up and down. The rod should move
smoothly; do not move the rod in a jerking motion. Fold headpiece down when not in
use.
Note: Patients must be a minimum of 23-5/8” (600mm) tall for the height to be accurately
measured.
1. With the headpiece in the folded down
position, slide the headpiece up or down to
the estimated height of the patient. Then
raise the headpiece into its horizontal
position.

18

OPERATING INSTRUCTIONS (CONT)
2. Position the patient facing the display head.
Ensure that the patient’s posture is upright,
and that the patient’s head is straight and
level. Slide the headpiece down until it rests
on the patient’s head.
3. Determine the patient’s height by reading
the value on the measuring strip nearest to
the line on the indicator, as shown below.
Read measurement here
for heights less than
48.5” / 123 cm
Read measurement here
for heights greater than
48.5” / 123 cm

19

OPERATING INSTRUCTIONS (CONT)
BMI Function
Body Mass Index (BMI) is a ratio between a person’s weight and height and interpreted as a BMI
score. This BMI score is then used as a tool to categorize a patient as underweight, normal,
overweight, obese or morbidly obese.
Note: The scale will not calculate BMI for a patient that is 24 pounds (12 kg) or less.
Note: If a height is not entered for the patient within 30 seconds of pressing the BMI button, the
scale will return to the normal weighing mode.
1. Make sure there is no object on the weighing platform.
2. Press the ON/OFF button to turn the scale on.
3. Wait until the “0.0” LB or “0.0” KG appears on the display.
4.Ask the patient to step on the scale. The scale will begin to display weight information and will
lock on the patient’s weight when the stable weight of the patient is determined. Depending on
the movement of the patient on the scale, it may take several seconds for the scale to lock onto
the weight.
5. After obtaining the patient’s weight on the scale, press the BMI button while the scale is on.
6. The display will show 65” (in LB mode) or 150cm (in KG mode). Use the keypad ▲ and ▼
buttons to enter the patient’s height. To determine the patient’s height, follow the height
measuring instructions on pages 17 and 18.
Note: When weighing in pounds, the height is displayed in inches. When weighing in kilograms,
the height is displayed in centimeters.
7. Once height is keyed in, press the ENTER button.
8. The display will show the patient’s BMI.
9. Press the CLEAR button to return to the normal weighing mode of the scale.

Auto-Off Function
As an energy saving feature, the scale will automatically turn off after 2 minutes of inactivity. By
default, this function is enabled.
Disable Auto-Off
1. While the scale is turned off, press and hold the HOLD/RELEASE button.
2. While holding the HOLD/RELEASE button, press the ON/OFF button to turn the scale on.
3. “START” will briefly appear on the display followed by “AOF=0”.
4. Auto-off is now disabled and the scale will remain on until the scale is manually turned off.
Enable Auto-Off
1. While the scale is turned off, press and hold the HOLD/RELEASE button.
2. While holding the HOLD/RELEASE button, press the ON/OFF button to turn the scale on.
3. “START” will briefly appear on the display followed by “AOF=1”.
4. Auto-off is now enabled.

20

OPERATING INSTRUCTIONS (CONT)
KG and LB Lock Out
Note: The default weighing mode for this scale can be changed from LB/KG to KG only or LB
only.
To Change Weighing Mode:
1. Press the ON/OFF button to turn the scale on.
2. Wait for “0.0” LB or “0.0” KG to appear on the display.
3. Press and hold the LB/KG button until the desired unit of measure begins to flash.
4. Release the LB/KG button and the scale will operate in the selected mode.
5. Repeat steps 3-4 to change the weighing mode to a different unit of measure as the default
for use.
Zero Function
Zeroes the scale prior to a weight measurement. The ZERO button is also used in the Tare
function as outlined below.
Tare Function
When using this scale, the weight of an object, such as a cane, can be subtracted from the total
weight in order to determine the weight of the patient alone.
1. With all weight off the scale, press the ON/OFF button to turn on the scale.
2. Wait until the “0.0” LB or “0.0” KG appears on the display.
3. Set the unit (LB or KG).
3. Place the object on the scale. The display will show a value for the object’s weight.
4. Press the ZERO button. The word “TARE” will appear on the display, followed by “0.0” LB or
“0.0” KG.
5. Keep the object on the platform, then ask the patient to step onto the scale as well. The scale
will automatically deduct the weight of the object and only display the patient’s weight.
6. When you remove the item from the platform, “under” will be temporally displayed and then
the display will return to “0.0” LB or KG.
