Heart of House Somersham 412/6502 User manual

Somersham Oak Bathroom Tall Cabinet
412/6502
Issue 1 - 03/16/15
38cm
33cm
172cm
3

Components - Panels
Please check you have all the panels listed below
2
If you have damaged or missing components,
call the Customer Helpline:03456 400800
12 Under left side panel Under right side panel Under back panel
Upper back panel
3
45 Upper left side panel Upper right side panel 6
7
8
11 Middle shelf
12 Adjustable shelf x 2
10 Bottom panel
Door panel
Top panel
9Upper shelf x 3

Components - Fittings
Please check you have all the fittings listed below
Note:The quantities below are the correct amount to complete the assembly .In some cases more
fittings may be supplied than are required.
D
A
G
J
MN
KL
H
E
B C
F
I
3
Wooden handle x 1
Curved hinge x 2
Φ4 x 12mm Screw x 8
Φ4 x 30mm Screw x 2 Φ3 x 12mm Screw x 1
Φ4 x 35mm Screw x 1 Wall plug(for solid wall only) x 1Wall strap x 1
Cam cap x 12 Screw cap x 2
Pin x 4
Metal Support x 8
Locking Pin x 24 Locking Nut x 32
Ruler - Use this ruler to help correctly identify the screws
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
(medium & large)
Phillips screwdriver Small
hammer
Ruler/tape
measure
Flatblade screwdriver
(medium)
6mm Suitable drill bit
(for use with wall plug)
Eye protection
(when using a
hammer or glue)
Hammer Drill
(Only for dril hole on the wall)

Assembly Instructions
4
Step 1
Fitting locking pin
4
4
5
8
8
5
1
1
8
2
2
A
Screw 24 x locking pin into top
panel , under left side ,
under right side ,upper left side
and upper right side .
J
J
A
A
A
I
Fix wall strap onto top panel
with 12mm screw as shown.
I

Assembling under unit
b:
Slide down under back panel
along grooves in bottom panel
and middle shelf .
a:
Attach bottom panel and
middle shelf to under left side
panel as shown.
Attach under right side onto
the under unit as shown,insert
locking nut into bottom panel
and middle shelf, tighten locking
nuts clockwise to secure it.
Continued on next page.
Insert locking nut into bottom
panel and middle shelf .
Use a screwdriver to turn the
locking nut clockwise to lock.
B
a:
b:
Assembly Instructions
Step 2
5
NOTE:It would be useful to ask
someone to help you at this stage.
2
23
3
1
1
10
10
10
10
11
11
11
11
B
1 2 3
B
B
B

c:
Assembling under unit
A
6
Assembly Instructions
Step 8
Step 2 - continued
Assembling upper side panel
Step 8
Step 3
1
2
4
4
5
5
9
9
9
11
B
B
H
c:
Insert pins into the under side
unit and make sure shorter part
facing down, insert locking nut
into it, tighten locking nuts
clockwise to secure it.
B
H
9
Attach upper left side and upper
right side to upper shelves .
Insert locking nut into the upper
shelves, tighten the locking nuts
clockwise to secure the unit.
B

8
1
6
6
6
8
4
b:
a:
A
7
Assembly Instructions
Step 8
NOTE:It would be useful to ask
someone to help you at this stage.
Assembling the upper unit and
under unit
Step 4
J
B
B
a:
Carefully attach the upper unit to
the under unit as shown, insert the
locking nut into the upper unit,
tighten locking nuts clockwise to
secure it.
b:
Slide down upper back panel
along grooves in upper left side
and upper right side.
B
8
Tighten the locking nut to secure
the unit.
Carefully place the top panel
onto the unit.Insert locking nut
into upper left side panel and
upper right side panel.
B
Pls make sure the wall strap
go through the hole of upper back
panel as shown.
J

7
C
D
E
Assembling door panel
7
7
b:
a:
NOTE:It would be useful to ask
someone to help you at this stage.
G
D
a:
Use 12mm screws to fix curved
hinges onto door panel .
b:
Carefully attach door panel
to the unit by fixing curved hinge
onto under right side with 12mm
screws .
Use 30mm screws to fix handle
onto door.
A
8
Assembly Instructions
Step 8
Step 5
7
C
E
G
D
D
C1
C1
C1
C2
C2
Adjust the door up or down, left or
right, in or out if needed as shown:
1. Loosen two screws and adjust
the door up or down, then fix
screws again.
2. Loosen screw and adjust the
door in or out, then fix screw
again(loose screw clockwise
first help to adjust door in or out if
needed).
3. Loosen screw and adjust the
door left or right, then fix screw
again.
D
D
D
C1
C2
12
3

12
12
12
b:
a:
NOTE:If you have damaged or missing components,
call the Customer Helpline:03456 400800
Argos LTD,489-499 Avebury Boulevard,
Central Milton Keynes, MK9 2NW
a:
Insert metal supports into under
left side and under right side panels.
Carefully put the adjustable shelves
on it.
b:
Use 35mm screw and wall plug
to fix the unit on the wall via
strap as shown.
After above assembly, please
double check and make sure all
screws are firmly fixed before use.
Use cam caps to cover the
visible cams as shown.
Use screw caps to cover the
visible screws as shown.
Assembling adjustable shelf
NOTE:It would be useful to ask
someone to help you at this stage.
A
9
Assembly Instructions
Step 8
Step 6
K
F
F
K
L
J
J
L
M
M
M
M
M
N
N
N

A Guide to - Wall Mounting & Fixings
Revision 2 - 7/10/09
Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist tting in this case. For light
loads, general purpose wall plugs can
be used.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
For use when tting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with walls stuck with
plasterboard. The hammer xing allows
it to be xed to the wall rather than the
plasterboard. Always check the xing
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well tted and are a tight t in the
drilled hole.
If plastic wall plugs
are supplied with your
product:
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect xings is the
responsibility of the installer.
