Heat-n-glo Cfx-zc Assembly instructions

-Do not store or use gasoline or other flam-

mablevaporsandliquidsinthevicinityofthis

orany otherappliance.

-What to do if you smell gas

•Do not try to light any appliance.

•Do not touch any electrical switch.

•Do not use any phone in your building.

•Immediately call your gas supplier from a

neighbor's phone. Follow the gas supplier's

instructions.

•If you cannot reach your gas supplier, call

thefiredepartment.

-Installationandservicemustbeperformedbya

qualified installer, service agency, or the gas

supplier.

Installers Guide

WARNING: IMPROPER INSTALLA-

TION, ADJUSTMENT, ALTERATION,

SERVICE OR MAINTENANCE CAN

CAUSE INJURYOR PROPERTY DAM-

AGE. REFER TO THIS MANUAL. FOR

ASSISTANCE ORADDITIONAL INFOR-

MATION CONSULT AQUALIFIED IN-

STALLER, SERVICEAGENCY, OR THE

GAS SUPPLIER.

Underwriters

Laboratories Listed

567-900E 1/03

READ THIS MANUAL BEFORE INSTALLING OR

OPERATINGTHISAPPLIANCE. THIS INSTALLERS

GUIDE MUST BE LEFT WITH APPLIANCE FOR

FUTUREREFERENCE.

Please contact your Heat-N-Glo dealer for any questions

or concerns. For the number of your nearest Heat-N-Glo

dealer,pleasecall1-888-427-3973.

Heat-N-Glo,a divisionofHearth&HomeTechnologiesInc.

20802KensingtonBoulevard,Lakeville,MN55044

WARNING: IF THE INFORMATION

IN THESE INSTRUCTIONS IS NOT

FOLLOWED EXACTLY, AFIRE OR

EXPLOSION MAYRESULT CAUS-

ING PROPERTY DAMAGE, PER-

SONAL INJURY, OR DEATH.

This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;

4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)

543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.

Model:

CFX-ZC

1. Thisappliancemaybeinstalledinanafter-

market,permanentlylocated,manufactured

(mobile)home,wherenotprohibitedbylo-

calcodes.

2. Thisapplianceisonlyforusewiththetype

of gas indicated on the rating plate. This

appliance is not convertible for use with

othergases,unlessacertifiedkitisused.

These units MUST use one of the vent systems

described in the Installing the Fireplace section of

the Installers Guide. NO OTHER vent systems or

components MAYBE USED.

This gas fireplace and vent assembly MUST be

vented directly to the outside and MUST NEVER be

attached to a chimney serving a separate solid fuel

burning appliance. Each gas appliance MUST USE

a separate vent system. Common vent systems are

PROHIBITED.

INSPECT the external vent cap on a regular basis to

make sure that no debris is interfering with the air

flow.

The glass door assembly MUST be in place and

sealed, and the trim door assembly MUST be in

place on the fireplace before the unit can be placed

into safe operation.

DO NOT OPERATE this appliance with the glass

door removed, cracked, or broken. Replacement of

the glass door should be performed by a licensed

or qualified service person. DO NOT strike or slam

the glass door.

The glass door assembly SHALL ONLYbe

replaced as a complete unit, as supplied by the gas

fireplace manufacturer. NO SUBSTITUTE material

may be used.

DO NOT USE abrasive cleaners on the glass door

assembly. DO NOT ATTEMPT to clean the glass

door when it is hot.

Turn off the gas before servicing this appliance. It is

recommended that a qualified service technician

perform an appliance check-up at the beginning of

each heating season.

Any safety screen or guard removed for servicing

must be replaced before operating this appliance.

DO NOT place furniture or any other combustible

household objects within 36 inches of the fireplace

front.

READ and UNDERSTAND all instructions carefully

before starting the installation. FAILURE TO

FOLLOW these installation instructions may result

in a possible fire hazard and will void the warranty.

Prior to the first firing of the fireplace, READ the

Using Your Fireplace section of the Owners Guide.

DO NOT USE this appliance if any part has been

under water. Immediately CALL a qualified service

technician to inspect the unit and to replace any part

of the control system and any gas control which has

been under water.

THIS UNIT IS NOT FOR USE WITH SOLID FUEL.

Installation and repair should be PERFORMED by a

qualified service person. The appliance and venting

system should be INSPECTED before initial use

and at least annually by a professional service

person. More frequent cleaning may be required

due to excessive lint from carpeting, bedding

material, etc. It is IMPERATIVE that the unit’s

control compartment, burners, and circulating air

passageways BE KEPT CLEAN to provide for

adequate combustion and ventilation air.

Always KEEP the appliance clear and free from

combustible materials, gasoline, and other

flammable vapors and liquids.

NEVER OBSTRUCT the flow of combustion and

ventilation air. Keep the front of the appliance

CLEAR of all obstacles and materials for servicing

and proper operations.

Due to the high temperature, the appliance should

be LOCATED out of traffic areas and away from

furniture and draperies. Clothing or flammable

material SHOULD NOT BE PLACED on or near the

appliance.

Children and adults should be ALERTED to the

hazards of high surface temperature and should

STAYAWAYto avoid burns or clothing ignition.

Young children should be CAREFULLYSUPERVISED

when they are in the same room as the appliance.

SAFETY AND WARNING INFORMATION

TABLE OF CONTENTS

Safety and Warning Information ............................................... 2

Service Parts List...................................................................... 4

Section 1: Approvals and Codes .............................................. 6

Appliance Certification ................................................................. 6

Installation Codes ........................................................................ 6

HighAltitude Installations.............................................................. 6

Section 2: Getting Started ........................................................ 7

Introducingthe Heat-N-GloGasAppliances ................................. 7

Pre-installation Preparation .......................................................... 7

Venting and Installation................................................................. 7

Section 3: Installing the Insert ................................................. 9

Step 1Installing the Vent System ............................................. 9

Step 2Positioning, Leveling, and Securing the Insert............. 13

Step 3The Gas Control Systems .......................................... 13

Step 4The Gas Supply Line .................................................. 13

Step 5Gas Pressure Requirements...................................... 14

Step 6WiringtheAppliance ................................................... 14

Step 7Installing Logs and Ember Material ............................. 15

Positioning the Logs ................................................... 15

Placing the Ember Material ......................................... 15

Step 8InstallingTrimSurround .............................................. 15

Step 9Before Lighting theAppliance...................................... 16

Step 10 LightingtheAppliance ................................................. 16

Afterthe Installation.................................................................... 16

Section 4: Maintaining and Servicing Your Appliance ........ 17

u= Contains updated information.
