Heatscope MHS-SM2200BK.200 User manual

ORIGINAL INSTALLATION
AND INSTRUCTION MANUAL
Electric ambient carbon radiant heater
for indoor and outdoor areas
Made in Germany
US
CN
Art.-Nr.: 19-010-S
EMC IPX4

SAFETY INFORMATION
HEATSCOPE® infrared heaters must be installed and executed only by an authorized expert / trained
professional electrician in accordance with the applicable standards and regula ons for electrical
wiring in electrical trade in the respec ve country / region of installa on.
Have a quali ed electrician install a properly grounded receptacle outlet, acceptable for outdoor use
and protected from snow and rain, immediately adjacent to the loca on where the heater will be
used. Route the supply cord and locate the heater so as to be protected from damage by live stock.
Do not use extension cords. Inspect cord before using. Unplug heater at receptacle outlet when not
in use or before removing, and store heater indoors a er winter season.
All relevant local building and  re safety regula ons must be observed at any  me and under any
circumstances.
WARNING: This unit is not equipped with an applica on to regulate the room temperature. The
heater must not be used in small rooms inhabited by people who cannot leave the room unaided,
unless constant supervision is ensured.
Be careful when opera ng the unit. Children younger than 3 years must be kept away, unless they
are overseen all the  me. Children older than 3 years and younger than 8 years are allowed to
switch on and off the unit, if they are overseen, or if they were instructed how to use the unit safely
and have received instruc ons how to operate/use the unit, assumed the unit is installed properly.
CAUTION: Some parts of the unit get very hot and may cause burns! High cau ousness is impera ve,
if children or persons with reduced physical, sensory or mental abili es or lack of experience and/or
knowledge. are present in the room.
Children older than 3 years and younger than 8 years are not allowed to connect the plug, to control
the unit, to clean the unit and/or to maintain the unit.
Children older than 8 years and persons with reduced physical, sensory or mental abili es or lack
of experience and/or knowledge can use this unit, if they are overseen, or if they were instructed
how to use the unit safely and have received instruc ons how to operate/use the unit and which
en dangerments may result during the use of the unit. Children must not be playing with the unit.
Cleaning and maintenance must not be done by children, unless they are supervised by a person
responsible for their safety.
The unit must never be used una ended. Children must be supervised at all  mes to ensure that
they do not play with the unit, switch it on uninten onally or adjust it.
CAUTION! The device is not intended for use by persons (including children) with reduced physi-
cal, sensory or mental capacity – it has to be kept out of reach from these persons especially from
children.
It is NOT ALLOWED to use the heater in hazardous loca ons listed below; installa on in non-hazar-
dous loca ons only:
· Class I, Division 1 classi ed loca ons (areas where ignitable concentra ons of  ammable gases,
vapors or liquids can exist all of the  me or some of the  me under normal opera ng condi ons);
· Zone 0 classi ed loca ons (areas where ignitable concentra ons of  ammable gases, vapors or
US GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS

liquids are present connuously or for long periods of me under normal operang condions);
· Zone 1 classied locaon (areas where ignitable concentraons of ammable gases, vapors or
liquids are likely to exist under normal operang condions);
· Class I, Division 2 or Zone 2 classied locaons (areas where ignitable concentraons of ammable
gases, vapors or liquids are not likely to exist under normal operang condions);
· Class II, Division 1 classied locaons (areas where ignitable concentraons of combusble dust
can exist all of the me or some of the me under normal operang condions);
· Class II, Division 2 classied locaons (areas where ignitable concentraons of combusble dust are
not likely to exist under normal operang condions);
· Class III, Division 1 classied locaons (areas where easily ignitable bers or materials producing
combusble yings are handled, manufactured or used.
· Class III, Division 2 classied locaons (areas where easily ignitable bers are stored or handled);
· Zone 20 classied locaons (areas where ignitable concentraons of combusble dust or ignitable
bers/yings are present connuously or for long periods of me under normal operang condi-
ons);
· Zone 21 classied locaon (area where ignitable concentraons of combusble dust or ignitable
bers/yings are likely to exist under normal operang condions);
· Zone 22 classied locaons (areas where ignitable concentraons of combusble dust or ignitable
bers/yings are not likely to exist under normal operang condions).
1. Please check that your HEATSCOPE® radiant heater and accessories are complete and not damaged.
In special take care of the glass holders of the model range VISION, which hold and surround the glass
ceramic front screen. Press the holders carefully back in posion, unll they click into place again.
If the housing or reector is deformed/damaged or the heang element is broken, do not use the
HEATSCOPE® unit. Please contact the vendor or the manufacturer.
The cable must not be crushed, squeezed or damaged.
If the unit or accessories show signs of defects, cracking, breakage or other damage or if the industrial
glass ceramics screen is damaged, disconnue use and have them repaired. In this case, disconnect the
unit from the power supply, return it to the manufacturer or dispose of it. The unit should be labelled
accordingly to prevent it being reconnected.
2. For installaon use only the supplied accessories or original accessories approved by the manu
facturer. The power cable or other components of the HEATSCOPE® radiant heater may only be
replaced by a professional servicing company enlisted by the manufacturer. Before starng the
installaon, you must ensure that the operang voltage corresponds to that stated on the nameplate
of the HEATSCOPE® or accessories. Note that depending on the currently available supply voltage
the actual power of the device may change as well as the emied power as a result of environmental
inuences.
3. HEATSCOPE® heaters together with all available accessories feature IP protecon class IPX4 tested
US
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
AMBIENT HEATING SOLUTIONS

US
following IEC, classi ed NEMA type 3R (protected against objects >1mm and splashing water).
Nevertheless, it is mandatory to install the unit on a surface where it is well protected from any
weather in uences like rain and dust from above; so the HEATSCOPE® has to be installed under a roof,
an overhang or in combiona on with the op onal available weather shield. Never install the HEAT
SCOPE® heater on combus ble material like wood, wooden surfaces etc.
4. CAUTION! To provide con nued protec on against risk of electric shock, connect to properly
grounded outlets only. As soon as the unit is connected to a power source and switched on using an
„ON/OFF“ switch or other opera ng component, it takes a maximum of 1530 seconds un l it reaches
its opera ng temperature.
Important! Before  rst use, please clean the heater surface with an alcoholfree customary glass
cleaner. Fingerprints can cause discolour at the surface.
5. CAUTION! Hot surface! Avoid contact! Risk of burns! – The front screen (approx. 572 °F) and
protec ve  n front (approx. 572 °F) gets very hot while the unit is opera ng.
Do not cover either part of the front or the en re front of the radiant heater. Do not touch any part
of the HEATSCOPE® during opera on and up to 30 minutes a er switching it o .
6. For your own safety, never dry tex les or other materials using the HEATSCOPE®. Covering the
radiant heater may result in a  re! Always maintain a distance from the hea ng surface of the
HEATSCOPE® of at least 59.06 inch from tex les, cloth and other easy in ammable so materials.
7. Ensure that cables, furniture,  ammable materials or other objects do not come into contact with
the surface of the radiant heater and never cover the unit. Under no circumstances should the unit be
covered or enclosed with insula ng or similar materials. Adequate ven la on surrounding the heater
must be ensured at any  me. Ledgers, beams and ra ers must not be cut into or grooved to install the
infrared heater.
When installing the HEATSCOPE® radiant heater, ensure that the lower edge of the unit is at least
70.87 inch from the ground and the safety clearances from the wall and ceiling set out in this manual
are maintained. Always maintain a distance from the hea ng surface of the HEATSCOPE® of at least
59.06 inch from tex les, cloth and other easy in ammable so materials.
8. Disconnect the radiant heater from the power supply before cleaning it, adjus ng the angle or
removing it from the wall/ceiling. Wait un l the hea ng elements are not glowing any more and the
housing is no cably cooled down. If buried cables are used, switch o the power using an omnipolar
switch.
9. The HEATSCOPE® features an omnipolar „ON/OFF“ switch. The unit can be controlled manually
either using an IR remote control (supplied, depending on the model) or a selector switch on the
unit itself (depending on the model as well). The unit must be connected to a residual current circuit
breaker and a fuse on the installa on side – a ground fault circuit interrupter (GFCI) must be installed.
10. The unit must only be used with an approved isola ng system, which must be built in the exis ng
electrical installa on acc. to the facility regula ons. The heater comes as standard with a separate
openended cable for connec on purposes.
11. The power cable or buried cable with omnipolar switch may only be replaced by a professional
specialist electrical company enlisted or approved by the manufacturer. Hea ng elements, other
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS

US
components or parts of the housing may only be replaced by a service organisaon enlisted by the
manufacturer.
If you yourself or someone enlisted by you carries out repairs, they will not be covered by the
guarantee. Improper repairs and incorrect installaon or operaon shall invalidate the guarantee
immediately.
12. If the heater was installed inappropriately or was connected unhomogeneously with the local
electrical supply cable, high transfer resistances may occur, which lead to overheang of the device.
For the heang system and many custom applicaons the heaters were equipped with a NTC tempe
rature control and an addional latching temperature limiter.
Ordinarily possible overhaeng due to inappropriate installaon is protected by the NTC temperature
control and the latching temperature limiter. If overheang of a carbon heang element occur due to
interlinkage of mounng and installaon mistakes, the carbon laments inside of the quarz tubes will
fuse and safely disconnect the current ow. Even aer a mechanical break of the quarz tubes, the
carbon heang spirals will not work any longer. Besides the n front screen of the SPOT heaters and
the glass ceramic, high temperature resistant front screen of the VISION heaters provide best pro-
tecon of the installed carbon heang elements.
Funconal descripon of the NTC temperature control: If the system temperature of the electronical
control exceeds 217.4 °F, the upper heang element will shut o temporary by default to avoid over-
haeng of the electronical parts. Aer a short me the heang element will switch on automacally
again. The selfcontrolled shut o of the heater will take place only, if the heat dissipaon inside the
device is inappropriate, if the heat radiaon is interfered or if the ambience temperetaure is way too
high. Apart from that the NTC temperature control supports energy sangs, if the ambient tempe
ratures are too high and the highest heang level of the heang unit is not necessary.
Funconal descripon of the latching temperature limiter: If the NTC temperature control is not
working against expectaons, the latching temperature limiter will shut down the lower heang
element permanently, unl the heater is shut o totally by hand. Aer cooling down (warm to the
touch) and xing the inappropriate heat dissipaon inside the device and/or the interferred heat
radiaon the heater can be switched on again. If the lower heang element shuts down once more,
a system malfuncon or a heat dissipaon inside the device or an interference of the heat radiaon
or an error in the electrical installaon may be the reason. If a system malfuncon inside the device
causes the shut down, the heater must be repaired by a professional technician; please contact your
dealer immediately. If a wrong cable connecon causes the shut down, this has to be checked and
xed through a professional electrician on the spot.
Installaon and connecng regulaons with tested and approved luster terminals are part of the
delivered equipment.
13. The radiant heater must not be installed directly below a power source/socket. The sides of the
unit must be at least 7.87 inch from the nearest power source. Sockets/power sources must be freely
accessible at all mes and comply with the following specicaons: 220–240 V AC ~, 50/60 Hz, 16 A
with 16 A fuse. No other loads may be connected to this power source.
14. The radiant heater must must not be installed in rooms where there is high humidity (bathroom,
spa, pool etc.) in close vicinity to bathtubes, showers or pools. The distance to the bathtub or shower
must be at least 39.37 inch and the distance to the pool at least 78.74 inch. A person standing in the
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
AMBIENT HEATING SOLUTIONS

US
bathtube, shower or pool should never reach the switch or controller of the heater. If the HEATSCOPE®
is installed in such an environment with high humidity, the switches or other opera ng components
must be posi oned in such a way that they cannot be touched by persons who are in direct contact
with water. Bathroom heaters must not be operated with a separate automa c thermostat or  mer.
When a radiant heater is installed in a bathroom, the CE standard requires that at least one hea ng
element visibly „glows“ as soon as the unit is switched on.
15. CAUTION! To provide con nued protec on against the risk of electric shock, disconnect the supply
cord before cleaning., adjus ng the angle or removing it from the wall/ceiling. Wait un l the hea ng
elements are not glowing any more and the housing is no cably cooled down. If buried cables are
used, switch o the power using an omnipolar switch. Wait at least 30 minutes a er the last use
before you start cleaning it. All surfaces should be cleaned using a damp cloth only. Never use cleaning
products containing alkaline substances such as sodium hydroxide or soap, surfactants or solvents such
as alcohol. Use only a very so cloth or a brush for the re ector and the hea ng elements.
16. Make absolutely sure to always switch o the device a er use.
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS

US
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
AMBIENT HEATING SOLUTIONS

Ceiling Installa on
2 x2 x 2 x 4 x
1 x
1. 2.
3.
2 x
2 x 4 x2 x
A (inch) B (inch)
MHS-SM1600/MHS-SP1600 ≤ 9.45 ≥ 5.32
MHS-SM2200/MHS-SP2200 ≤ 11.81 ≥ 6.89
MHS-SM2800/MHS-SP2800 ≤ 14.57 ≥ 6.89
A (inch) B (inch)
MHS-VT1600/
MHS-VE1600 ≤ 11.81 ≥ 6.89
MHS-VT2200/
MHS-VE2200 ≤ 25.59 ≥ 6.89
MHS-VT3200/
MHS-VE3200 ≤ 45.28 ≥ 6.89
≤ A
≥ B ≥ B
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS
US

Wall mounng
1. 2.
3.
2 x
1 x
2 x 2 x 4 x2 x 2 x 4 x 4 x2 x
≤ A
≥ B ≥ B
≤ A
≥ B ≥ B
≤ A
≥ B ≥ B
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
AMBIENT HEATING SOLUTIONS
US

O
I
III
Manual control
MHS-SM1600BK.100, MHS-SM2200BK.100, MHS-SM2800BK.100,
MHS-SM1600WT.100, MHS-SM2200WT.100, MHS-SM2800WT.100
MHS-VE1600BK.100, MHS-VE2200BK.100, MHS-VE3200BK.100,
MHS-VE1600WT.100, MHS-VE2200WT.100, MHS-VE3200WT.100
O
I
III
O
I
IIIIII
100 %
50 %
0 %
O
I
III
0 %
LED:
O
I
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMSMUNICH HOME SYSTEMS
US

IR remote control
MHS-SP1600BK.100, MHS-SP2200BK.100, MHS-SP2800BK.100,
MHS-SP1600WT.100, MHS-SP2200WT.100, MHS-SP2800WT.100
MHS-VT1600BK.100, MHS-VT2200BK.100, MHS-VT3200BK.100,
MHS-VT1600WT.100, MHS-VT2200WT.100, MHS-VT3200WT.100
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
AMBIENT HEATING SOLUTIONSAMBIENT HEATING SOLUTIONS
US
O
I
ON
/ OFF
+ 1
– 1




AMBIENT HEATING
MIN.
/ MAX. ·
···
O
I
O
I
0 %
0 %
100 %


O
I


50 %


100 %
O
I
O
I


0 %
0 %
LED:

Electrical connec on
PE
N
L
O
I
HEATSCOPE® SP // HEATSCOPE® VT
MHS-SP1600BK.100, MHS-SP2200BK.100, MHS-SP2800BK.100,
MHS-SP1600WT.100, MHS-SP2200WT.100, MHS-SP2800WT.100
MHS-VT1600BK.100, MHS-VT2200BK.100, MHS-VT3200BK.100,
MHS-VT1600WT.100, MHS-VT2200WT.100, MHS-VT3200WT.100
220240 V AC~
50/60 Hz
PE N L
Circuit breaker / fuse switch
on installa on side
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS
US

L L
PE
N
L
acc. VDE 0293
MHS-SM1600BK.100, MHS-SM2200BK.100, MHS-SM2800BK.100,
MHS-SM1600WT.100, MHS-SM2200WT.100, MHS-SM2800WT.100
MHS-VE1600BK.100, MHS-VE2200BK.100, MHS-VE3200BK.100,
MHS-VE1600WT.100, MHS-VE2200WT.100, MHS-VE3200WT.100
O
I
III
HEATSCOPE® SM // HEATSCOPE® VE
MHS-SP1600BK.100, MHS-SP2200BK.100, MHS-SP2800BK.100,
MHS-SP1600WT.100, MHS-SP2200WT.100, MHS-SP2800WT.100
MHS-VT1600BK.100, MHS-VT2200BK.100, MHS-VT3200BK.100,
MHS-VT1600WT.100, MHS-VT2200WT.100, MHS-VT3200WT.100
220240 V AC~
50/60 Hz
PE N
II: 50% I: 50%
Circuit breaker / fuse switch
on installaon side
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
AMBIENT HEATING SOLUTIONS
US

Minimum distances wall moun ng
The following installa on regula ons ensure that the HEATSCOPE® ambient heater is working e ec vely.
All minimum clearances that must be met regardless of the installa on environment are listed.



> 70.78 inch
> 5.91 inch
> 15.75 inch
> 70.78 inch
> 70.78 inch
> 5.91 inch
> 59.06 inch
> 15.75 inch
> 59.06 inch
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS
US

X X
X
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
The clearances given are minimum values and may dier from the local building and re regulaons.
The laer must be observed and complied with in any case.
AMBIENT HEATING SOLUTIONS
US

Minimum distances ceiling moun ng
The following installa on con gura on ensures that the HEATSCOPE™ radiant heater is working e ec vely.
All the minimum clearances that must be met regardless of the installa on environment are listed.



> 78.74 inch
> 6.69 inch
> 15.75 inch
> 78.74 inch
> 78.74 inch
> 5.91 inch
> 59.06 inch
> 6.69 inch
> 3.94 inch
> 15.75 inch
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS
US

X X
X
> 6.69 inch
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
The clearances given are minimum values and may dier from the local building and re regulaons.
The laer must be observed and complied with in any case.
AMBIENT HEATING SOLUTIONS
US


> 70.78 inch
Minimum distances in glasshouses and conservatories
The following installa on con gura on ensures that the HEATSCOPE™ radiant heater is working e ec vely.
All the minimum clearances that must be met regardless of the installa on environment are listed.
> 9.84 inch
> 59.06 inch
X
X
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS
US


> 70.78 inch
> 9.84 inch
> 59.06 inch
X
X
Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net
The clearances given are minimum values and may dier from the local building and re regulaons.
The laer must be observed and complied with in any case.
AMBIENT HEATING SOLUTIONS
US

US
Thank you for choosing a HEATSCOPE® electric ambient heater. This high end quality infrared
ambient heater is manufactured in Germany and complies with UL standards and EU direc ves.
Only tested, environmentally friendly materials and components are used.
HEATSCOPE® infrared heaters are producing high energy effi cient heat based on IR fast midwave
up to effi cient IR long wave technology. Eye, skin and organism harming IR short waves are not pro
duced by HEATSCOPE® carbon hea ng elements in any way.
Designed for private and commercial use for wall and ceiling moun ng in well covered, sheltered
indoor and outdoor areas, HEATSCOPE® carbon radiant heaters produce heat within seconds
wherever it is needed. The infrared radiant heater allows you to transport heat over a distance
of up to 3 metres, ideally in a speci c direc on.
Before installing the unit, please read this instruc on manual carefully. Follow the informa on given
to avoid endangering yourself, your family, your friends and your acquaintances. If you have any
ques ons, contact the vendor or manufacturer.
Please keep this instruc on manual in a safe place. Pass on the manual to any subsequent owner of
the HEATSCOPE® unit and ensure that any supplements received are included along with it (cf. www.
heatscope.com).
Prior to installa on, ensure that the opera ng voltage matches the one speci ed on the name plate
of the HEATSCOPE® unit!
This instruc on manual is intended solely for the below listed standard products. The technical data,
installa on requirements and dimensions of custom made, special versions may di er.
Models
HEATSCOPE® SPOT – manual control, 4 core cable
SPECIFICATIONS: ON/OFF + 2 manually switchable power levels (100% or 50%)
MHS-SM2200BK.200, MHS-SM2800BK.200, MHS-SM2200WT.200, MHS-SM2800WT.200
HEATSCOPE® SPOT – 3 power levels, remote controllable, 3 core cable
SPECIFICATIONS: ON/OFF + 3 remote controllable power levels (100% or 50%), IR remote control
MHS-SP1600BK.250, MHS-SP1600WT.250
MHS-SP2200BK.200, MHS-SP2800BK.200, MHS-SP2200WT.200, MHS-SP2800WT.200
HEATSCOPE® VISION – manual control, 4 core cable
SPECIFICATIONS: ON/OFF + 2 manually switchable power levels (100% or 50%, external)
MHS-VE1600BK.200, MHS-VE2200BK.200, MHS-VE3200BK.200, MHS-VE1600WT.200, MHS-
VE2200WT.200, MHS-VE3200WT.200
HEATSCOPE® VISION – remote controllable, 3 core cable
SPECIFICATIONS: ON/OFF + 3 remote controllable power levels (100% or 50%), IR remote control
MHS-VT1600BK.200, MHS-VT2200BK.200, MHS-VT3200BK.200, MHS-VT1600WT.200, MHS-
VT2200WT.200, MHS-VT3200WT.200
GreenChance Inc. · 11265 Washington Blvd. · USA CA90230
MUNICH HOME SYSTEMS
