Heatstore DYNAMIC HSDR500T Operating instructions

Model Rating A B
HSDR500T0.5kW 503 104
HSDR750T 0.75kW 503 104
HSDR1000T 1.0kW 671 104
HSDR1500T 1.5kW 741 104
HSDR2000T 2.0kW 911 104
Dimensions
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
IMPORTANT SAFETY ADVICE
When using electrical appliances, basic precautions
should always be followed to reduce the risk of fire,
electrical shock, and injury to persons, including the
following:
IMPORTANT – The wall bracket supplied with the appliance
must be used.
WARNING - DO NOT USE THIS HEATER IN THE
IMMEDIATE SURROUNDINGS OF A BATH, A
SHOWER OR A SWIMMING POOL.
IMPORTANT – If the heater is installed in a room
containing a bath or shower, it must be so installed that
switches and other controls cannot be touched by a
person using a bath or shower.
Do not use outdoors.
Do not locate the heater immediately below a fixed
socket outlet or connection box.
Do not cover the heater. Do not place material or
garments on the heater, or obstruct the air circulation
around the heater, for instance by curtains or
furniture, as this could cause overheating and a fire
risk.
NEVER cover or obstruct in any way the heat outlet
slots at the top of the heater or the air inlet slots in the
base of the heater.
The heater carries the Warning symbol
indicating that it must not be covered.
WARNING – THE SURFACES OF THIS HEATER
CAN BE HOT.
Momentary contact with any part of the heater should
not cause injury.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
Note that due care and consideration must be taken
when using this heater in series with a thermal control, a
program controller, a timer or any other device that
switches on the heat automatically, since a fire risk exists
when the heater is accidentally covered or displaced.
If the supply cord is damaged it must be replaced by the
manufacturer or service agent or a similarly qualified
person in order to avoid a hazard.
Electrical
WARNING THIS APPLIANCE MUST BE EARTHED
The electrical installation must be carried out by a
competent electrician, and be in strict accordance with the
current IEE regulations for Electrical Equipment in Buildings.
The wires in this mains lead are coloured in accordance with
the following code :
GREEN AND YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE
BLACK : PILOT WIRE
- see also ‘Pilot Wire Connection’.
The heater is fitted with a length of flexible cable type
H05VVF size 4 x 1.0mm2for connection to the fixed wiring
of the premises through a suitable connection box
positioned adjacent to the heater.
The supply circuit to the heater must incorporate a double
pole isolating switch having a contact separation of at least
3mm.
Pilot Wire Connection
The BLACK control wire is designed to carry a signal from
the slot in programmer. If, however a programmer is not
being used, the pilot wire should be isolated in accordance
with the current IEE Wiring Regulations.
IMPORTANT
- DO NOT connect the BLACK pilot wire to earth.
Care should be taken with the installation of the pilot wire(s)
as when switching to background (set back) they become
energised at 240V although only at a current of less than
100mA. In every case a suitable means of isolation must be
provided for the pilot wire and marked to indicate that two
sources of supply may be present at the heater.
Where pilot wires are installed separately from the heater
final sub-circuit they should be protected, double insulated
and carry their own integral earth continuity conductor.
Supplementary Earth Bonding
Should Equipotential Earth Bonding be required the earthing
conductor in the supply cord is deemed to provide the
supplementary bonding connection (see Regulation 544.2.5,
17th Edition I.E.E. Wiring Regulations).
Figure 1
Installation and Operating Instructions for
HSDR Dynamic Electric Radiators
DYNAMIC

Model C D
HSDR500T 390 300
HSDR750T 390 300
HSDR1000T 560 300
HSDR1500T 630 300
HSDR2000T 800 300
General
The heater is designed for wall mounting on the wall bracket
supplied. It should only be operated when in the upright
position as shown – see figure 1 overleaf .
All models are splashproof to IPX4 standard and may be
used in bathrooms, however not in the immediate vicinity of
baths, showers, water connections, wash basins or
swimming pools.
Before connecting the heater check that the supply voltage is
the same as that stated on the heater.
Wall Mounting
IMPORTANT The wall bracket supplied with the appliance
must be used. The heater should be positioned observing
the minimum clearances stated around the heater – see
figure 1 .
DO NOT locate the heater immediately below a fixed socket
outlet or connection box.
1. Remove wall mounting bracket from the back of the
heater by depressing the spring latch at the top of each
bracket - – see figure 2 .
2. Fix the wall bracket securely to the wall through the four
screw holes provided.
3. Present the heater to the wall bracket, and engage lower
slots in the back with bracket.
4. Raise the heater to upright position and push the heater
onto bracket to engage top latch.
Operation
Switching On the
Heater (see Fig. 3)
The controls are located
on the right hand side on
top of the appliance, lift
flap to access the controls
–see figure 3 .
The button marked ‘ ’
controls the electricity
supply to the electronic
thermostat. An indicator beside the ‘ ’ button shows when
the unit is powered ‘ON’.
Setting Desired Temperature (see Fig. 4)
The heater is fitted with an adjustable thermostat enabling
the room temperature to be controlled by adjusting the
slider accordingly. The min setting ‘ ’ represents a room
temperature of approximately 5°C and may be used for
protection against frost. The ‘MAX’ setting represents a room
temperature of approximately 30°C. The ‘ ’ symbol glows
when the elements are actually heating.
Turn on the heater using the ‘ ’ button and move the
thermostat slider to the desired position. When the room
temperature has reached the desired level, the power to the
elements will be reduced, the heater will then maintain the
room temperature at the chosen level.
NOTE - Should your heater fail to come on when the
thermostat slider is at a low setting, this may be due to the
room temperature being higher than the thermostat setting.
Limiting the thermostat
setting
Before wall mounting the
product the installer may
wish to limit the heat
selection slider movement for
the operator. This may be
achieved by removing the
two plastic pins (see ‘x’ in
figure 5 ) from the rear of the
thermostat moulding using
pliers and inserting them in
the preferred holes to limit
the slider movement.
Notes to the Installer
Test Mode
When the heater is connected via a pilot wire system, the
test mode allows the installer to check whether the heater is
responding correctly to the incoming pilot wire signal.
Before switching the heater on at the mains, place the
thermostat slider in the ‘MAX’ position, then press and hold
the ‘ ’ button whilst switching on the mains.
The unit will now enter a test state for 4 mins. During this
test state the ‘ ’ neon will indicate the pilot wire status:
2
Figure 4
Figure 3
Figure 2
Figure 5
Neon Pilot Wire Controller mode
Neon on ON
Neon off OFF
Neon flashing fast approx every 0.1 sec FROST
Neon flashing slow approx 0.5 sec SETBACK
Pilot Wire Status
Safety – overheat protection
For your safety this appliance is fitted with a thermal cut-out.
In the event that the product overheats for some reason, the
cut-out prevents excessive temperatures on the product by
cutting the power to the heater. Once the heater has cooled
down, it will reset automatically, it will continue to cycle on
and off automatically until the reason for overheating is
removed.

Figure 7
Programmer Module
The HSDR Dynamic Electronic Radiator is supplied with a 7-
day programmable controller pre-fitted as standard (see
figure 3 overleaf for location). The instructions for
progamming and operating the controller are to be found
below.
Operating instructions for the 7-day
timer/programmer module
General
The HSDR Dynamic Electronic Radiator is supplied with a 7-
day programmable controller pre-fitted as standard.
The 7 Day Timer programmer offers either individual
programming (each individual heater has a programming
module) or group programming from a master heater
through the pilot wire. Zone programming can drive up to
10 slave heaters.
Two heating positions are
offered: comfort and off, with
temperatures set using the
controls on the heater.
For default Screen – see
figure 6.
Individual radiator
programming
Note: When the heater is
individually controlled, the black pilot wire in the mains
supply cable should be isolated in accordance with the
current IEE wiring regulations.
Programming a Zone with multiple radiators
Where multiple radiators are installed, the radiator
containing the 7-day timer programmer is the Master
radiator and is connected by the black pilot wire to the Slave
radiators. The Master radiator determines the Programme
and heating levels for all the radiators (Comfort and Off),
but the actual comfort temperature should still be set on
each individual heater (see ‘Setting Desired Temperature’).
The master heater will switch between Comfort and Off
according to the programme.
Electrical Connection where Master Slave
radiators are installed
DO NOT connect the BLACK (PILOT) SIGNAL WIRE to
earth.
When the programmer drives other heaters, connect the
pilot wire from the ‘MASTER’ unit to the pilot wire of a
‘SLAVE’ heater and then from one ‘SLAVE’ heater to another
(in series) – see figure 7.
Any 240V insulated cable may be used to link pilot wires
around the ring main. The signal current is low. Suitable
connections would be either an additional single core wire
marked or colour coded appropriately or use a 4 core cable
throughout the heater ring.
3
Operating Instructions
The programmer can be programmed either inserted directly
into the heater or out of the heater. If choosing the latter
option, the cassette must be first left in the heater for 2 days
to charge the battery. Remember that the battery only lasts
for 24 hours.
Problem Solving
In the event that no display
appears on your 7-day timer
do the following:1. Press any
button to reactivate the display.
Failing this – 2. Return to the
heater to charge battery
(internal battery lasts for 24
hours when timer is removed
from heater). Display will
appear immediately but
battery will be fully charged in
2 days.
Mode Selection
There are three different
operating modes. Press MODE
to cycle through these:
MAN OFF - heating is
permanently Off – see
figure 8. This is also the
default screen.
MAN ON – heating is
permanently On – see figure 9.
AUTO – runs the programmed
times – see figure 10.
Figure 6
Figure 8
Figure 9
MASTER SLAVE SLAVE
Set Time
Press the PROG key once
(from default display) to set
time.
The ‘ ’ appears – see fig. 11
– on the screen and the hours
can be set using the  keys.
Press ENTER when finished
setting the hours.
Set minutes using  the keys
and press ENTER.
Then choose the day from
Mon to Sun using the 
keys and press ENTER to exit.
Time and day are now set.
Set Programme
The timer can only be
programmed in 2 blocks i.e.
1st Block - Weekdays:
Mon-Fri Press PROG twice –
see Figure 12).
The Weekday programs
are now ready to be set
(starting with P1 ON, where P1
ON is the first ON time setting)
go to a) below:
2nd Block - Weekends: Sat
& Sun Press PROG twice and
then press MODE once –
see figure 13).
Figure 10
Figure 11
Figure 12
Figure 13

ISSUE 3: 0312
Cleaning
WARNING – ALWAYS DISCONNECT FROM THE
POWER SUPPLY BEFORE CLEANING THE HEATER.
Before commencing cleaning, unplug the heater and allow it
to cool. Disconnect the electricity supply to the appliance.
The outside can be cleaned by wiping it over with a soft
damp cloth and then dried. Do not use abrasive cleaning
powders or furniture polish, as this can damage the surface
finish.
To release heater from the wall bracket for cleaning or
redecoration, depress latch on both brackets (see Fig. 2)
and hinge forward.
After Sales Service
Your product is guaranteed for two years from the date of
purchase. Within this period, we undertake to repair or
exchange this product free of charge provided it has been
installed and operated in accordance with these instructions.
Your rights under this guarantee are additional to your
statutory rights, which in turn are not affected by this
guarantee.
Should you require after sales service you should contact
our customer services help desk on 0117 923 5375. It
would assist us if you can quote the model number, series,
date of purchase, and nature of the fault at the time of your
call. The customer services help desk will also be able to
advise you should you need to purchase any spares.
Please do not return a faulty product to us in the first
instance as this may result in loss or damage and delay in
providing you with a satisfactory service. Please retain your
receipt as proof of purchase.
The Weekend programs are now ready to be set (starting
with P1 ON, where P1 ON is the first ON time setting), go
to a) below:
a) set P1 ON time: Set the hours using and press
ENTER. Then set the minutes using and press
ENTER.
Note: Time in minutes can only be set in 10 minute blocks.
Then set P1 OFF time: Set the hours using and press
ENTER.
Then set the minutes using and press ENTER. If only
one program is required, press PROG now to return to
default display OR
b) set P2 ON and OFF times: repeat procedure as ‘a)’
above.
c) set P3 ON and OFF times: repeat procedure as ‘a)’.
d) set P4 ON and OFF times: repeat procedure as ‘a)’.
After P4 Weekday OFF time has been set, the User will be
prompted to set P1 ON time for Weekends.
After P4 Weekend OFF time has been set the default Screen
is displayed.
At any time while programming the timer, pressing the
PROG button, this will exit to the default display. Timer must
be in AUTO mode to run Set Programs.
NOTE: To cycle quickly from weekdays to weekends press
the MODE button. There are 4 programs for weekdays
and 4 for weekends.
Key Lock
To lock the keypad press
ENTER and release, then
press MODE within 1 second.
The key symbol will appear on
the screen when the keypad is
locked – see figure 14 . To
unlock the keypad repeat the
action above. If any of the
buttons on the keypad are
pressed when it is locked,
the light will automatically
come on.
The Advance Function
When in AUTO mode, if is
pressed for longer than 2
seconds the program will
advance to the next
programmed setting. When
the ADVANCE function is
active ADVANCE will be displayed on the screen – see
figure 16 .
To cancel ADVANCE press for longer than 2 seconds
e.g. If present time is 14:00 and P1 ON is at 17:00 and P1
OFF is 19:00, if is held for 2 seconds then ADVANCE
appears on the screen. The heater comes on and remains
on until 19:00. ADVANCE disappears from the screen at
17:00 as set program is then running.
Figure 14
Figure 15
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check
with your local authority or retailer for recycling advice.
Telephone: [phone] Fax: [phone]
Victoria Road, Avonmouth, Bristol BS11 9DB
www.heatstore.co.uk
