General Information
The Henny Penny auto lift open
fryer offers high-volume frying with
auto lift capabilities. Auto lift open
fryers automatically raise the load
out of the fry pot when cooking
program is complete. This feature
promotes perfect results without
constant monitoring and can
significantly increase productivity in
lightly staffed operations.
The quiet, dependable auto lift
mechanism is designed into the
high-quality, high-efficiency Henny
Penny 320 Series open fryer without
adding one square inch to the
footprint.
Henny Penny’s unique high-
efficiency heat-exchange design
produces extremely fast temperature
recovery—typically in seconds—
while requiring less than 2kW per
gallon of shortening. Fast recovery
speeds up production, saves energy,
Auto lift open fryer, model OEA-321
Henny Penny Corporation
PO Box 60 Eaton OH 45320 USA
+1 937 456.8400 800 417.8417
+1 937 456.8434 Fax [phone] Fax
www.hennypenny.com
Auto lift open fryers
Standard Features
•Stainless steel construction for
easy-cleaning and long life.
•Heavy-duty stainless steel
rectangular fry pot with 7 year
warranty.
•Computron®8000 control with 10
programmable cook cycles, melt
mode, load compensation,
proportional control, idle mode,
optional filter prompt and
customizable filter tracking, clean-
out mode.
•Fryer can be programmed to
operate half baskets independently
or together at the touch of a button.
•16-character digital display with
multiple language settings.
Accessories shipped with unit
•Fry baskets—please select one
(1) full basket
(2) half baskets
•Basket support
•Max shortening filtration system
and (2) PHT filter envelopes.
Accessories and options available
separately
Shortening shuttle
Filter rinse hose
Fry well cover
APPROVED APPROVED AS NOTED RESUBMIT
AUTHORIZED SIGNATURE DATE
and preserves frying oil quality by
reducing temperature fluctuations.
Built-in filtration system filters hot
frying oil in under 4 minutes, with no
separate pumps or pans required. Hot
filtered oil returns directly to the fry
well. Quick, easy and frequent filtering
extends shortening life and can result
in significant savings in time and
direct shortening costs.
The OEA/OGA-321 auto lift open
fryer features two lifters for half or full-
basket loads. Henny Penny’s heavy-
duty stainless steel rectangular fry pot
promotes fast, even cooking and
comes with a 7-year warranty—the
best in the business.
The standard Computron®8000
controller provides fully automatic,
programmable operation, as well as
energy-saving, filtration and load
management features.
•Fry pot protection system.
•Built-in filtration with stainless steel
Max filtering screen and filter
envelope.
•Rugged direct-drive lift mechanism
powered by quiet, low-voltage
motor.
•Motor and drive built into existing
cabinet—footprint is NOT
increased.
•Easy basket set and release.
•Specially designed cold zone
prevents scorching.
•Four heavy-duty casters, two
locking.

PLAN
17 3/8 in. (441 mm)
© 2006 Henny Penny Corporation, Eaton, OH 45320 USA Revised 11/01/07
Laboratory certifications
Continuing product improvement may subject specifications to change without notice.
PROJECT ITEM NO
www.hennypenny.com
Bidding Specifications
•Provide Henny Penny model OEA-321
electric open fryer or model OGA-321 gas
open fryer, 15 lbs. (6.8 kg) capacity per
load, with auto-lift feature, Computron®
8000 control, and built-in filtration system
standard.
•Materials—cabinet, deck, exhaust stack,
filter drain pan and various fittings are
stainless steel. Fry pot is heavy duty
stainless steel.
•Units shall incorporate high-efficiency heat-
exchange design for extremely fast recovery.
•Units qualify for the ENERGY STAR®mark.
•Heating elements encircle the fry pot part-
way up the side, and are not located at the
bottom or below the pot. This design
produces a “cold zone” that extends oil life.
•Units shall have two auto lift mechanisms
and timers to accommodate half-basket
operation.
•
Unit’s controller provides for programmable or
manual operation with press-key controls and
LED digital display. Control offers idle and melt
modes, load compensation, filtration tracking
and 7-day history.
•Units will include four heavy-duty casters, two
locking.
•Units ship with stainless steel Max filtration
screen and 2 PHT filter envelopes, (1) full
basket or (2) half baskets.
FRONT
Auto lift open fryers
Capacity
Product 15 lbs. (6.8 kg)
Oil 65 lbs. (29.5 kg)
Fryer throughput: fries/hr.
Electric 63 lbs. (28.6 kg)
Gas 72 lbs. (32.7 kg)
Electrical
37 3/8 in. (949 mm)
54 5/8 in.
(1387 mm)
Height includes
casters
Dimensions
Width 17 3/8 in. (441 mm)
Depth 37 3/8 in. (949 mm)
Height 54 5/8 in. (1387 mm)
Required clearances
Sides: 6 in. (152 mm) air flow
Back: 6 in. (152 mm) air flow, connections
Front: 30 in. (762 mm) filter pan removal
Crated dimensions
Length 40 in. (1016 mm)
Depth 25 in. (635 mm)
Height 65 in. (1651 mm)
Volume 37.6 cu. ft. (1.07m³)
Net weight N/A
Crated weight
Electric 312 lbs. (142 kg)
Gas 336 lbs. (152 kg)
Heating
Electric Immersed elements, 14.4 kW
Gas
Natural or liquid petroleum (2) burners, 85,000 BTU/hr (25 kW)
(1) ½ in. connection
Volts Phase Cycle/Hz Watts Amps Wire
208 3 60 14400 39.9 3+G
240 3 60 14400 37.2 3+G
480 3 60 14400 17.5 3+G
Power cord and plug must be installed on site by a qualified electrician.
Gas models
120 1 60 N/A 12.0 2+G
230 1 50 N/A 2.5 1NG
Electrical
connection Gas units:
(1) ½ in. gas connection
