1
Gepäckbrückenverbreiterung/ Enlargement
YAMAHA Ténéré 700
ab Baujahr 2019 / from date of manufacture 2019
Artikel Nr.: / Item-no.:
8004564 00 01 schwarz/black
200120
INHALT
CONTENT
1x 610052 00 01 Gepäckbrückenverbreiterung small
1x 700010462 Rohradapter links
1x 700010463 Rohradapter rechts
1x 700010758 Schraubensatz:
1x 610052 00 01 Enlargement small
1x 700010462 Tube adapter left
1x 700010463 Tube adapter right
1x 700010758 Screw kit:
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
4x Senkschrauben M6x20
4x Senkscheiben M6
2x Zylinderschraube M6x60
2x Zylinderschraube M8x45
4x U-Scheiben Ø6,4
4x Selbstsichernde Mutter M6
2x Karosseriescheibe Ø6,4x18
1x Logo H&B Ø30
2x Aludistanz Ø18xØ7x30
4x Countersunk screw M6x20
4x Countersunk washers M6
2x Allen screw M6x60
2x Allen screw M8x45
4x Washer Ø6,4
4x Self lock nut M6
2x Body washere Ø6,4x18
1x Emblem H&B Ø30
2x Alu spacer Ø18xØ7x30
2
WICHTIG
IMPORTANT
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,wie
man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf
das entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist.
Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
8004564 00 01
VORBEREITUNG
PREPARING
Rechts und links die hinteren Pins sowie die beiden hinteren Schrauben der Kennzeichenhalterung
unter dem Heck entfernen, Teile und Schrauben entfallen.
Dismantle the rear pins right and left and the two rear screws of the license plate holder
under the rear, parts and screws are omitted.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
1
2
2x
2x
2x2x
Montage der Rohradapter rechts/links vorne:
Die Montage erfolgt in den nun freien Gewinde-
bohrungen mit den Zylinderschrauben M8x45.
Montage der Rohradapter rechts/links hinten:
Die Montage erfolgt in den nun freien Gewinde-
bohrungen mit den Zylinderschrauben M6x60
sowie Karosseriescheiben Ø6,4x
Ø
18.
Zwischen Lasche und Rahmen die
Aludistanzen Ø18xØ7x30 fügen.
Fastening of the tube adapters right/left front:
On the free thread with allen screw M8x45.
Fastening of the tube adapters right/left rear:
On the free thread with allen screw M6x60
and body washer
Ø6,4x
Ø
18
.
Between lug and frame add the
alu spacer
Ø18xØ7x30.
Fahrtrichtung/driving direction
Fahrtrichtung/driving direction
3
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
3
4x 4x
4x
4x
Montage der Verbreiterung:
Die Montage erfolgt auf den Rohradaptern mit
den Senkschrauben M6x20, Senkscheiben M6
sowie U-Scheiben Ø6,4 und selbstsichernden
Muttern M6. Das Logo in die Vertiefung ein-
kleben.
Fastening of the enlargement:
On the tube adapters with countersunk
screws M6x20 and countersunk washers M6.
Secure with self lock nuts M6 and washers
Ø6,4.
Stick the logo into the cutout.
8004564 00 01
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
Als weiteres Zubehör lieferbar:/ Also available:
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile wieder montieren.
Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the dismantled parts.
Please notice our enclosed service information.
6514564 00 22 00 40 Cutout Koffer/Träger Set silber/ Cutout Side case/carrier Set silver
6514564 00 22 01 40 Cutout Koffer/Träger Set schwarz/ Cutout Side case/carrier Set black
6534564 00 01 Kofferträger festverschraubt/Side carrier firmly bolted
5014564 00 01 Motorschutzbügel/Engine guard
5024564 00 01 Tankschutzbügel/Tank guard
42124564 00 01 Griffschutz/Handle guard
731106 00 00 LED Flooter
42114564 00 91 Seitenständerplatte/Side stand enlargement
