hernest H200056 User manual

USER MANUAL
1
Caution
Please consu lt the professionals before installation or repairing. The company takes no liabilities for any damage or
injuries that occur during the installation of the pipes, floor, wall and tub.
Thank you for shopping with Hernest, please read this user manual thoroughly for your full under-
standing, installing, and application of the product. Please have this user manual well-reserved
for future reference.
Before Installation
Check the package and ensure that all parts are included. If any part is missing or damaged, please contact us.
Do not disassemble the main body, as it has been installed & commissioned correctly & precisely before leaving
the factory.
Shut off the main water supply before the installation.
Do flush the water supply lines to remove any dirt and debris before installation(IMPORTANT).
Make sure to connect the hot/cold inlet pipe correctly. If standing in front, usually the hot water pipe connects to
the left and the cold water pipe to the right.
Check for leaks and make sure every joint is safely sealed after the installation,
Turn on the water supply and flush the water pipes for 3 minutes to make sure it works well before putting it
into use.
SKU:H200056
Wall Mounted Bathtub Shower Set

NOTE:THIS FAUCET IS DESIGNED FOR WALL MOUNTED ROUGH-IN INSTALLATION
2
Specifications
20mm(0.8")
223mm(9.1")
170mm(Φ7")
121mm(4.9")
65mm(Φ2.7")
16mm(Φ0.6")
55mm(2.2”)
85mm(3.5")
1/2NPT
150mm(6")
25mm(1")
Hot Cold

The recommended distance
is 55mm(2.2”)
3
Adjustable Wrench Hexagon Wrench
Philips Screwdriver Teflon Tape
Tools You will need
A
1Fix the shower valve(A)into the wall, Use
a level to ensure that the valve is straight
and level. The distance between the
bottom of the body and the surface of
the tile is 55mm.
2Wrap Teflon tape around the pipe
threads and connect hot and cold water
supply lines and in-wall pipes(not
included) as desired to the valve. Turn
on the water supply and open the
cartridge to check for leakage. Then, put
on the protective cover.
Installation Steps
Adjustable Outlet1
Outlet2
Hot water inlet
Cold water inlet

4
For more detail information, please check out www.hernest.com
It will be our pleasure to have your visit.
www.hernest.com
After-Sale Service
If you have any issues with the product, please feel free to contact us online or by phone for customer service.
Phone No.: [phone]
Service E-mail: [email protected]
3 4 Turn the water on for 1 minute to flush
any debris. Apply Teflon tape (H) to the
threaded tail pipe and install the shower
hose (I) into the outlet on the wall, Then
connect the top shower (P) to the spout.
5Turn the water on for 1 minute to flush
any debris. Install the tub spout (O) into
the outlet on the wall, Tighten set screws
(E) with Allen key (F).
6Finish.
Remove the protective cover when the
finished wall is completed and install the
escutcheon (B) to the valve (A) and press
it against the finished wall. Then, install
the handle (C) tighten set screws (E) with
Allen key (F), and put on the indication
buttons (D).
A
B
D
H
I
P
C
E
F
E
F
O
