HERO SPLENDOR PRO User manual

PREFACE
We, at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy.To
achieve this we commit ourselves to continue product innovations to improve
environment compatibility, comply with all applicable legislation including
environment legislation and strengthen the green supply chain.
Your motorcycle is conforming to latest (Bharat Stage-III norms) regulation for
emission, safety & noise levels. We are also using non asbestos brake shoes and engine
gaskets which are environment friendly in nature.
Let us make this world a safer, healthier and more environment friendly place.
Thank you for selecting a Hero MotoCorp Splendor Pro. We wish you many miles of
continued riding pleasure in the years ahead.
This booklet is your guide to the basic operation and maintenance of your new Hero
MotoCorp Splendor Pro. Please take time to read it carefully. As with any fine machine,
proper care and maintenance are essential for trouble-free operation and optimum
performance.
Your Authorised Hero MotoCorp dealer will be glad to provide further information or
assistance and is equipped to handle your future service needs.

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION
AVAILABLE AT THE TIME OF ITS PRINTING APPROVAL, AND THE
ACCURACY OR CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR
GUARANTEED. Hero MotoCorp Limited. RESERVES THE RIGHT TO MAKE
CHANGES IN ITS CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR
INCURRING ANY OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO
REPRODUCE ANY PART OF THIS PUBLICATION WITHOUT OBTAINING
PRIOR WRITTEN PERMISSION FROM Hero MotoCorp Limited.
NOTE

16
17
17
18
19
21
22
23
UTILITY BOX 25
26
28
15
FUEL VALVE
28
30
31
32
34
34
36
36
38
40
41
43
52
55
47
48
49
50
51
AIR SUCTION VALVE
50
CATALYTIC CONVERTER
45STOP LAMP SWITCH
47HEADLAMP ADJUSTMENT
46SIDE STAND
ACCESSORIES AND MODIFICATIONS
7
STEERING LOCK 13
CLUTCH SWITCH 13
STARTER SWITCH 13
SIDE STAND INDICATOR/ SIDE STAND SWITCH 14
HELMET LOCK 14
ANTI THEFT TIPS 25
24
BRAKING / PARKING
SAFETY PRECAUTIONS 27
42BRAKE WEAR INDICATORS
45FUSE REPLACEMENT
MAINTENANCE SCHEDULE

Model Code.:
Model Engine
Splendor Pro (Electric Start / Drum / Cast Wheel)
VIN
A9 EL
MBLXXXXA9YZXYYYYY
MBL
Manufacturer
Code
XXXXA9
Vehicle
Description
Y
Year of
Mfg.
Z
Assembly
Plant
X
Month of
Mfg.
YYYYY
Serial
Number
MBLXXXXA9YZXYYYYY
XXXXEL
Engine
Description
Y
Year of
Mfg.
Z
Assembly
Plant
X
Month of
Mfg.
YYYYY
Serial
Number
XXXXELYZXYYYYY
XXXXELY
ZXYYYYY
MOTORCYCLE IDENTIFICATION
Vehicle Identification Number (VIN)
VIN
VIN

112 kg
11.0 litres (minimum)
1.4 litres (usable)
2000 mm
1040 mm
720 mm
1230 mm
159 mm
785 mmSaddle Height
0.95 litre at disassembly
0.75 litre at draining
9.0 :1
0.6 - 0.7 mm
IN : 0.10 mm EX : 0.10 mm
5.74 kW (7.8 Ps) @ 7500 r/min
NGK-CR7HSA, BOSCH-UR4AC,
Champion-P-RZ9HC (Federal Mogul)
97.2 cc
163 ml
ITEM SPECIFICATIONS
DIMENSIONS
WEIGHT
CAPACITIES
ENGINE
PRODUCT SPECIFICATION
r/min

Front Suspension Telescopic Hydraulic Shock Absorbers
Rear Suspension Swing Arm with 5 step adjustable Hydraulic
Shock Absorber
2.75 x 18 - 42P / 4 PR
2.75 x 18 - 48P / 6 PR
3.722 (67/18)
3.071 (43/14)
3.182 (35/11)
1.706 (29/17)
1.238 (26/21)
0.958 (23/24)
Rear Wheel
Cast Wheel
Cast Wheel
Trail length 80 mm
Front Wheel
Position lamp
Side Stand Indicator
**MF Battery, MF-4:12V 3 Ah
10 A, 15 A
12V 35/35W Halogen Bulb -MFR*
Electric start
12V 5/10W MFR*
12V 3.0W
12V 1.7W
(Amber bulb) with clear lens-MFR*
120 W
* Multi Focal Reflector ** Maintenance Free
Head lamp (High/Low)
Tail/Stop lamp
Turn signal lamps
12V 3.0W x 2
Front Brake/ Rear Brake Drum Type Dia 130 mm/ 110 mm
ITEM SPECIFICATIONS
CHASSIS AND SUSPENSION
POWER TRANSMISSION
ELECTRICAL
FUSE

6. Respect road signs and obey traffic rules
for your own safety and that of others on
the road (ref. page no. 55 & 56).
3. While riding, sit in a comfortable posi-
tion with your legs close to fuel tank.
5. For stopping motorcycle, use both
brakes simultaneously, keeping throttle
in the close position.
9. To make yourself more visible, wear
bright reflective clothing that fits well.
10. Take care of loose / hanging clothes
while solo / pillion riding.
11. Get your motorcycle serviced regularly by
the Authorised Hero MotoCorp workshop.
1. Always conduct simple pre-ride
inspections (ref. page no 21).
8. Give way to others on the road and sig-
nal before you make a turn.
Do's:
2. Always wear a helmet (ISI marked)
with chinstrap securely fastened and
insist on a helmet for your pillion rider.
4. Ride defensively and at a steady speed
(between 40 to 50 km/hr).
7. During night time, dip headlamps of
your motorcycle for oncoming traffic,
or when following another vehicle.
motorcycle.
muffler.
SAFE RIDING TIPS

Modifying your motorcycle or using non-
Hero MotoCorp accessories can make
your motorcycle unsafe. Before you
consider making any modifications or
adding an accessory, be sure to read the
following information.
Improper accessories or modifications
can cause a crash in which you can be
seriously hurt or killed.
Follow all instructions in this owner's
manual regarding accessories and
modifications.
• Be sure electrical equipment does not
exceed the motorcycle's electrical
system capacity (page 3). A blown fuse
can cause a loss of lights.
• Make sure that the accessory does not
obscure any lamps, reduce ground
clearance, limit suspension travel or
steering travel, affect your riding
position or interfere with operating any
controls.
• Do not pull a trailer or sidecar with
your motorcycle. This motorcycle was
not designed for these attachments,
and their use can seriously impair your
motorcycle's handling.
We strongly advise you not to remove
any original equipment or modify your
motorcycle in any way that would
change its design or operation. Such
changes could seriously impair your
motorcycle's handling, stability and
braking, making it unsafe to ride.
Removing or modifying your lamps,
mufflers, emission control system or
other equipment can also make your
motorcycle illegal.
Modifications
Accessories
ACCESSORIES & MODIFICATIONS

Regular Servicing: Get your motorcycle serviced at an Authorised Hero MotoCorp
workshop, as per the service schedule, for an optimum performance and keep the
emission level under check.
Genuine Engine Oil: Hero 4T Plus SAE 10W 30 SL grade (JASO MA2) engine oil
recommended by Hero MotoCorp and make sure you change it every 6000 kms.
(with top up every 3000 kilometres) to keep the engine fit and environment healthy.
The following tips shall ensure a healthy motorcycle, healthy environment, and a healthy you.
Genuine Spares: Always insist on Hero MotoCorp genuine parts as spurious or
incompatible spares and accessories can upset or deteriorate your motorcycle’s
running condition.
& fuel efficiency.
Noise Pollution : Noise beyond a certain decibel is pollution. Whether it is from
horns or defective mufflers., excessive noise will cause headaches and discomfort.
Emission Pollution : Get emission of your motorcycle checked by Authorised
agencies atleast once every 3 months or as notified by the government from time to
time.
Fuel saving & reduce pollution : Switch "OFF" the engine while waiting at traffic
signal points to save fuel and reduce pollution, if the waiting period is long.
TIPS FOR HEALTHY ENVIRONMENT

19
12
(2) Front turn signal lamp
(7) Dimmer switch
(8) Speedometer
(3) Horn switch
(1) Turn signal indicator
(6) Passing switch
(4) Turn signal switch
(5) Headlamp switch
(10) Neutral indicator
(9) Odometer
(15) Front brake lever
(13) Side stand indicator
(17) Electric starter switch
(16) Throttle grip
(18) Ignition switch with steering lock
(12) High beam indicator
(14) Rear view mirror
(11) Fuel gauge
(19) Leg guard
(20) Fuel tank lid
7
17
18
3
2
1
4
8 13 14
20
DESCRIPTION
5
6
910 11
15
16

2
14
(1) Fuel valve
(4) Rider foot rest
(5) Main stand
(3) Gear shift pedal
(2) Carburetor
(6) Side stand switch
(7) Side stand
(9) Women pillion step
(8) Pillion foot rest
(10) Saree guard
(11) Reflex reflector
(12) Rear number plate
(14) Rear carrier
(13) Tail/Stop lamp
(15) Helmet lock
(16) Left side cover
(17) Air suction valve
(18) Clutch lever
(19) Front number plate
36 7 8 9
11
12
13
151617
19
LEFT SIDE VIEW
4 5
10
1
18

12
(2) Kick start pedal
(1) Pillion foot rest
(5) Rear brake pedal
(3) Rider foot rest
(4) Oil level dipstick
(10) Starter motor
(8) Headlamp
(7) Front suspension
(9) Front visor
(6) Utility box (11) Battery compartment ( inside)
(13) Re ar turn signal lamp
(14) Rear suspension
(12) Seat
(15) Exhaust muffler
5
46
7
1112
14
13
3
10
8
9
15

(3) Gear shifting Maximum operating speed in each gear.
(4) Neutral indicator Light glows when vehicle is in neutral
(5) Fuel gauge Indicates approximate fuel quantity
(6) Side stand indicator Light glows when the vehicle is parked on the side stand
(7) High beam indicator Light glows when headlamp is in Hi Beam
(8) Turn signal indicator Flashes when turn signal switch is operated
Sl. No. Description Function
(2) Odometer Shows accumulated mileage
(1) Speedometer Indicates driving speed
3 5
8
4
headlamp.
6
7
2
1
PARTS FUNCTION
INSTRUMENTS AND INDICATORS

“ON”
“OFF”
The engine can be started, Turn
signal lamps, Horn, Tail/Stop
lamp, Fuel Gauge and Pass Lamp
will be functional
Steering can be locked
“LOCK”
3
1
2
Engine cannot be started and no
electrical system will be functional.
“OFF” Position /
Lock Open
“LOCK” Position
“ON” Position
IGNITION SWITCH

5
4
2
1
white
Shift the turn signal knob sideways for
right/left indications and leave it to come
back to its normal position on its own.
Functions in DC when the passing switch
knob is pressed in the following condition.
2. Headlamp switch is “ON” but on low beam.
1. Headlamp switch is “OFF”.
LEFT HANDLEBAR CONTROLS
P
A
S
I
N
G
S
IMPORTANT : To switch “OFF” the turn
signal lamp after completing the turn,
gently push the knob inside.
Headlamp switch
Dimmer switch
Tail/Stop lamp
Passing switch
Head lamp “ON”
Turn signal lamp switch
Fuel gauge lamp
Speedometer lamp
3
4.
5.

Never hold starter switch continuously for
more than 10 seconds as continuous
cranking of engine will drain the battery.
There is a clutch switch provided for the
safety of the rider. The motorcycle cannot
be started by electric starter switch until the
clutch lever is operated when the vehicle is
engaged in gear.
STARTER SWITCH
Ensure starter switch (1) is operated when
the vehicle is in neutral gear. If the vehicle
is engaged in gear press the clutch lever
before operating the starter switch. Release
starter switch after the engine has started.
CLUTCH SWITCH
(2) Ignition key
1
(1) Electric starter switch
2
13
Steering lock with Ignition switch, put the
key (2) to "OFF" position & turn the
handle bar towards left or right & push the
key downwards & turn towards "Lock"
position. After locking take out the key.
STEERING LOCK

(2) Knob
2
1
To open lock (1), insert key and turn it
anti-clockwise. To lock, push knob (2) all
the way inside.
HELMET LOCK
SIDE STAND SWITCH
A side stand switch (2) is provided in the
side stand, when the vehicle is parked on
side stand (Ignition Switch “ON”), the
switch enables the side stand indicator
lamp to glow on the speedometer panel.
SIDE STAND INDICATOR
For the safety of the customer a side stand
indicator (1) is provided.
When the vehicle is parked on side stand
(Ignition Switch “ON”), an indicator lamp
glows in the speedometer panel.
(2) Side stand switch
(1) Side stand indicator
2
14
1

RES
At “RES”, fuel will flow from the reserve
fuel supply to the carburetor. Use the
reserve fuel only when the main supply is
exhausted. Refill the tank as soon as
possible after switching to “RES”. The
reserve fuel supply is 1.4 litres (usable).
3
2
1
15
At “OFF”, fuel cannot flow from the tank
to the carburetor. Turn the valve “OFF”
whenever the motorcycle is not in use.
The three way fuel valve is on the left side
of the carburetor.
OFF
FUEL VALVE
ON
At “ON”, fuel will flow from fuel tank to
the carburetor.
(1) “OFF” Position
(2) “ON” Position
(3) “RES” Position

Do not park the motorcycle under direct
sunlight as it causes evaporation of petrol
due to heat and deterioration of paint gloss
due to ultra violet rays.
16
(1) Fuel tank cap (2) Ignition key
(3) Lid
4. For locking, press the lid gently and turn
the key clockwise.
Fuel tank capacity is 11 litres (minimum)
including reserve supply of 1.4 litres (usable).
3. Do not overfill the tank. There should
be no fuel in the filler neck (4).
1. To remove the fuel tank cap (1), insert
the ignition key (2), turn it anti-
clockwise and lift the lid (3) as shown in
the picture.
2. Remove the cap by turning it anti-
clockwise.
1
2
3
Do not operate the motorcycle with the
fuel valve in the “RES” position after
refilling. You may run out of fuel, with
no reserve.
Do not keep the fuel valve between
“ON” and “OFF” position while
riding, since this may drain reserve fuel
from the Tank.
5
Petrol is extremely flammable and is
explosive under certain conditions.
Refill in a well ventilated area with the
engine stopped. Do not smoke or allow
flames or sparks in the area where the
petrol is refilled or where petrol is stored.
FUEL TANK
NOTE
5

17
2. Stop the engine & park the motorcycle on
its main stand on level ground, remove the
oil level dipstick and wipe it clean.
4. If required, add the specified oil up to the
upper level mark. Do not overfill.
6. Reinstall the oil level dipstick, and check
for oil leaks.
3. Reinsert the oil level dipstick without
screwing it in and check the oil level.
5. Quantity of oil to be filled is 0.75 litre
(approx.) during oil changes.
OIL CAPACITY : 0.95 litre
ENGINE OIL LEVEL CHECK
Check engine oil level each day before
operating the motorcycle.
The oil level dipstick (1) is on the right
crankcase cover for measuring oil level.
Oil level must be maintained between the
upper (2) and lower (3) level marks on the
oil level dipstick.
Do top up if oil level reaches towards the
lower level mark or every 3000 kms.
whichever is earlier.
(1) Oil level dipstick (2) Upper level mark
(3) Lower level mark
1
BRAND: Hero 4T plus
GRADE: SAE 10W 30 SL Grade
(JASO MA2).
ENGINE OIL
Use hero genuine engine oil or
recommended grade oil.
Manufactured by :
1. Tide Water Oil Co. (India) Ltd.
3. Bharat Petroleum Corporation Limited.
2. Savita Oil Technologies Limited. 2
UPPER
ENGINE OIL TOP UP
PROCESS
1. Start the engine & let it idle for 3-5
minutes.
LOWER
3
