HERO Achiever User manual

PREFACE
We, at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve
environment compatibility, comply with all applicable legislation including
environment legislation and strengthen the green supply chain.
This booklet is your guide to the basic operation and maintenance of your new
Hero MotoCorp ACHIEVER. Please take time to read it carefully. As with any fine
machine, proper care and maintenance are essential for trouble-free operation and
optimum performance.
Let us make this world a safer, healthier and more environment friendly place.
Your motorcycle is conforming to latest (Bharat stage-III norms) regulation for emission,
safety & noise levels. We are also using non asbestos brake shoes / pads and engine
gaskets which are environment friendly in nature.
Your Authorised Hero MotoCorp dealer will be glad to provide further information or
assistance and is equipped to handle your future service needs.
Thank you for selecting a Hero MotoCorp ACHIEVER. We wish you many miles of
continued riding pleasure in the years ahead.

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION
AVAILABLE AT THE TIME OF ITS PRINTING APPROVAL, AND THE
ACCURACY OR CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR
GUARANTEED. Hero MotoCorp Limited RESERVES THE RIGHT TO MAKE
CHANGES IN ITS CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR
INCURRING ANY OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO
REPRODUCE ANY PART OF THIS PUBLICATION WITHOUT OBTAINING
PRIOR WRITTEN PERMISSION FROM Hero MotoCorp Limited
NOTE

26
29
30
31
32
34
35
36
40
41
44
44
45
46
46
47
48
48
49
53
28
38
STOP LAMP SWITCH
HEADLAMP ADJUSTMENT
9
11
12
12
12
13
14
15
16
17
19
20
15
15
AIR CLEANER DRAIN TUBE
9
10
SEAT LOCK / HELMET HANGER
FUEL VALVE
HERO GENUINE PARTS
21
22
23
24
25SAFETY PRECAUTION
/ PARKING

Model Code.:
Model Engine
Achiever (Kick - Disc / Cast Wheel)
Achiever (Electric - Disc / Cast Wheel)
VIN
ES
ET
EE
EF
MBLXXXXETYZXYYYYY
MBL
Manufacturer
Code
XXXXET
Vehicle
Description
Y
Year of
Mfg.
Z
Assembly
Plant
X
Month of
Mfg.
YYYYY
Serial
Number
MBLXXXXETYZXYYYYY
XXXXEF
Engine
Description
Y
Year of
Mfg.
Z
Assembly
Plant
X
Month of
Mfg.
YYYYY
Serial
Number
XXXXEFYZXYYYYY
XXXXEFY
ZXYYYYY
Vehicle Identification Number (VIN)
VIN
VIN

134 kg (Kick)/138 kg (Electric Start)
2040 mm
760 mm
1120 mm
1290 mm
160 mm
Overall Length
Overall Width
Overall Height
Wheelbase
Ground Clearance
10 KW (13.4 BHP) @ 8000 r/min
12.80 N-m @ 5000 r/min
57.3 x 57.8 mm
9.1:1
3
149.1 cm
NGK-CPR 8 EA 9, CHAMPION-RG 6 YC
0.8-0.9 mm
IN : 0.08 mm EX : 0.12 mm
1400 + 100 r/min
12.5 litres (Minimum)
1 litre at draining
Castrol Q Stop - DoT 3 / DoT 4
2.3 litres (Usable Reserve)
1.2 litres
150 ml
Maximum Power
Maximum Torque
(cold condition)
PRODUCT SPECIFICATION
ITEM SPECIFICATIONS

Telescopic Hydraulic Shock Absorber
Swingarm with Adjustable Hydraulic
Shock Absorber
O
26
89 mm
2.75 x 18-42P / 4PR
3.00 x 18-52P / 6 PR
Dia 240 mm
Dia 130 mm
3.0769
1.0909
2.8000
0.9375
1.7895
3.3500
1.3043
4th
2nd
5th
3rd
Gear ratio, 1st
Primary reduction
Final reduction
* MFR stands for Multi-focal Reflector
*
*
*
(Electric Start)
Electric Start (Optional)
Front Suspension
Rear Suspension
Front Brake Disc Type
Rear Brake Drum Type
Headlamp
lamp
lamp
ITEM SPECIFICATIONS
10A, 15A / 15A, 20A
Ah Ah
Kick / Electric Start
85 W

2. Always wear a helmet (ISI marked)
with chinstrap securely fastened and
insist on a helmet for your pillion rider.
7. During night time, dip headlamps of
your motorcycle for oncoming traffic,
or when following another vehicle.
4. Ride defensively and at a steady speed
(between 40-50 km/hr).
10. Take care of loose / hanging clothes
while solo / pillion riding.
11. Get your motorcycle serviced regularly
by the Authorised Hero MotoCorp.
workshop.
8. Give way to others on the road and sig-
nal before you make a turn.
Do's:
5. For stopping motorcycle, use both
brakes simultaneously, keeping throttle
in the close position.
9. To make yourself more visible, wear
bright reflective clothing that fits well.
6. Respect road signs and obey traffic
rules for your own safety and that of
others on the road (ref. page no.53-54).
3. While riding, sit in a comfortable posi-
tion with your legs close to fuel tank.
1. Always conduct simple pre-ride
inspection (ref. page no 19).
motorcycle.
muffler.

Regular Servicing: Get your motorcycle serviced at an Authorised Hero MotoCorp
workshop, as per the service schedule, for an optimum performance and keep the
emission level under check.
Genuine Engine Oil: Hero 4T Plus SAE 10W 30 SL grade (JASO MA2) engine oil
recommended by Hero MotoCorp and make sure you change it every 6000 kms.
(with top up every 3000 kilometres) to keep the engine fit and environment healthy.
The following tips shall ensure a healthy motorcycle, healthy environment, and a healthy you.
Genuine Spares: Always insist on Hero MotoCorp genuine parts as spurious or
incompatible spares and accessories can upset or deteriorate your motorcycle’s
running condition.
& fuel efficiency.
Noise Pollution : Noise beyond a certain decibel is pollution. Whether it is from
horns or defective mufflers, excessive noise will cause headaches and discomfort.
Emission Pollution : Get emission of your motorcycle checked by Authorised
agencies atleast once every 3 months or as notified by the government from time to
time.
Fuel Saving & Reduce Pollution : Switch "OFF" the engine while waiting at traffic
signal points to save fuel and reduce pollution, if the waiting period is long.

7
1
2
FRONT TOP VIEW
5
13 14
(19) Headlamp switch
(20) Ignition switch with steering lock
(17) Throttle grip
(14) Fuel gauge
(21) Fuel tank cap
(12) Neutral indicator
(15) Turn signal indicator
(16) Front brake lever
(22) Leg guard
(13) Tachometer
(18) Starter switch
(10) Speedometer
(8) Tripmeter knob
(11) High beam indicator
(9) Odometer
(1) Turn signal switch
(2) Horn switch
(3) Headlamp dimmer switch
(4) Clutch lever
(5) Pass lamp switch
(7) Rear view mirror
(6) Choke lever
15
6
12
3
4
*Accessories and features shown may not be part of standard fitment.
8911
10
22
18
21
20
16
17
19

LEFT SIDE VIEW
(2) Starter motor
(3) Gear shift pedal
(4) Rider foot rest
(1) Fuel valve
(5) Side cover left
(7) Side stand
(9) Women pillion step
(10) Saree guard
(6) Main stand
(8) Pillion foot rest
(14) Helmet hanger
(12) Rear turn signal lamp
(15) Air suction valve
(11) Rear reflex reflector
(13) Rear grip
7
*Accessories and features shown may not be part of standard fitment.
11
12
13
14
1 2 3568 9
7104
15

8
13
RIGHT SIDE VIEW
(4) Oil level dipstick
(1) Pillion foot rest
(2) Battery compartment (inside)
(5) Rider foot rest
(3) Carburetor
(6) Kick starter pedal
(7) Brake pedal
(10) Front turn signal lamp
(9) Disc
(8) Caliper Assembly
(12) Visor
(13) Master cylinder
(14) Seat
(15) Tail / Stop lamp
(11) Headlamp
12
8
11
*Accessories and features shown may not be part of standard fitment.
1 2 345679
10
14
15

Rotate knob anti-clockwise to set zero
(3) Tripmeter knob
before a trip
Shows the distance travelled during a trip
(2) Tripmeter
(4) Odometer Shows accumulated mileage
(after setting to zero)
(1) Turn signal indicators Flashes when turn signal switch is operated
(6) High beam indicator Indicator glows when H/L is in Hi Beam
(7) Neutral indicator Indicator glows when vehicle is in neutral gear
(5) Speedometer Indicates driving speed
(9) Fuel gauge Indicates approximate fuel quantity
(8) Tachometer Indicates engine r/min
9
1
2
3
4
5678
9
headlamp

10
Steering can be locked Key can be removed
''ON''
''OFF''
The engine can be started. Turn
signal lamps, Horn, Tail / Stop lamp,
Fuel gauge, Pass lamp, Neutral
indicator will be functional.
2
1
3
Engine cannot be started and no
electrical system will be functional.
''LOCK’'
1. Ignition key
2. Lock position
3. “OFF” position
IGNITION SWITCH
“OFF”
Position/Lock Open
“LOCK” Position
“ON”
Position

5
Press the switch upwards for High Beam
and downwards for Low Beam.
3. Horn Switch
Press the switch to operate the horn.
Shift the turn signal switch sideways for
Right/Left indications and leave it to come
back to its normal position on its own.
2. Turn Signal Switch
IMPORTANT : To switch “OFF” the turn
signal after completing the turn, gently
push the switch inside as directed on the
switch.
1. Headlamp Dimmer Switch
11
LEFT HANDLEBAR CONTROLS
1
To apply choke, pull the lever downwards,
towards the rider, as directed on the switch.
4. Choke Lever
NOTE
Do not accelerate during starting when the
choke is on.
5. Pass Lamp Switch
Press the pass switch to operate the pass
lamp. The pass switch will function while
the lamp is in low beam.
2
3
4
6. Clutch Switch (Electric start model)
There is a clutch switch provided for the
safety of the rider. The motorcycle cannot
be started by electric starter switch until the
clutch lever is operated when the vehicle is
engaged in gear.
6

RIGHT HANDLEBAR CONTROLS
1
2
The switch has three positions.
1. Headlamp Switch
12
Never hold starter switch continuously for
more than 5 seconds as continuous
cranking of engine will drain the battery.
CAUTION
Steering lock with the ignition switch, turn the
key (1) to 'OFF' position & turn the handle
bar towards left or right & push the key
downwards & turn towards "Lock"
position. After locking take out the key.
Position Action
"OFF"
"Following is "ON"
2. Starter Switch (Electric start model)
Ensure starter switch (2) is operated when
the vehicle is in neutral gear. If the vehicle
is engaged in gear press the clutch lever
before operating the starter switch. Release
starter switch after the engine has started.
1
1. OFF
Headlamp “ON”
Tail/Stop lamp
FUEL VALVE
The three way fuel valve is on the left side
Fuel gauge lamp
Meter illumination

1. Fuel valve
13
3. RES
At “RES”, fuel will flow from the reserve
fuel supply from the fuel tank to the
carburetor. Use the reserve fuel only when
the main supply has stopped.
Refill the tank as soon as possible after
switching to “RES”. The usable reserve
fuel supply is 2.3 litres.
2. ON
At “ON”, fuel will flow from the main fuel
supply from the fuel tank to the carburetor.
To unlock fuel tank cap slide the
key hole cover, insert key turn it
clockwise and remove the cap.
Fu e l ta n k ca p a city is 1 2 . 5 li t res
(minimum) including usable reserve
supply of 2.3 litres.
To lock fuel tank cap - Position the cap
back on the opening and press gently.
The key springs back to the normal
position and cap gets locked.
Remove the key and slide back the key
hole cover.
4.
Do not overfill the tank. There should
be no fuel in filler neck (4). Fill the
tank with fuel (5).
2
1
3
NOTE

14
1
(1) Ignition key (2) Fuel tank cap
(3) Key hole cover.
5
3
(1) Seat lock (2) Helmet hanger (3) Knob
Location : On the rear left side of the seat,
below the rear cowl.
SEAT LOCK
HELMET HANGER
The helmet can be hung and locked on the
hook provided with the seat by rotating the key.
Operation : Insert the key and turn it clock
wise. Pull the knob downwards to release the
seat. To install, engage the hook on the
underside of the seat with the frame and slide
the seat to the front until the lock clicks.
Petrol is extremely flammable and is
explosive under certain conditions. Refill
in a well ventilated area with the engine
stopped. Do not smoke or allow flames or
sparks in the area where the motorcycle is
refilled or where petrol is stored.
1
2
4
5
2
3

15
AIR CLEANER DRAIN TUBE
Remove the drain tube plug (1) from the
tube and drain the deposit into a suitable
container. Reinstall the drain tube plug.
NOTE
Always ensure to reinstall the drain tube
plug after draining the deposit.
Follow the above process more frequently
when riding in rain or at full throttle.
(1) Drain tube plug
OIL CAPACITY : 1.2 litres
UPPER
LOWER
3. Remove the oil level dipstick (1), wipe it
clean and insert the oil level dipstick
without screwing it in.
1. Start the engine & let it idle for 3-5 minutes.
2. Stop the engine & park the motorcycle
on its main stand on level ground.
Check engine oil level each day before
operating the motorcycle.
4. The oil level should be between upper and
lower level mark on the oil level dipstick.
1. Tide Water Oil Co. (India) Ltd.
3. Bharat Petroleum Corporation Limited.
2. Savita Oil Technologies Limited.
Manufactured by :
5. Do top up if oil level reaches towards the
lower level mark or on every 3000 kms
whichever is earlier.
GRADE: SAE 10W 30 SL Grade
(JASO MA2).
BRAND: Hero 4T plus
ENGINE OIL
U s e h e r o g e n u i n e e n g i n e o i l o r
recommended grade oil.
1
1

16
7. Reinstall the oil level dipstick & check for
oil leaks.
6. Fill the crankcase with the recommended
engine oil through the filler hole. Insert
the oil level dipstick and check the oil
level. Do not overfill above the UPPER
level mark.
To drain the oil, remove the oil level
dipstick and drain bolt (1).
Reinstall the oil level dipstick with
new O-ring..
Drain
3. Fill the crankcase through the oil level
dipstick opening with approximately
1 litre (when clutch cover is not removed)
of the recommended grade engine oil.
After the oil has completely drained,
reinstall the drain bolt with new sealing
washer (2).
Make sure that oil level is at the upper
level mark of the oil level dipstick with
the motorcycle in an upright position,
and that there are no oil leaks.
Drain bolt
1
(2) Sealing washer
2

17
1
TYRES
3.00 52P
The imported tyre(s) if fitted without ISI
mark; are in compliance of BIS standard
and Central Motor Vehicle Rules 1989, as
declared by the Tyre manufacturer.
NOTE
To safely operate your motorcycle, the tyres
must be of recommended type and size, in good
condition with adequate tread, and correctly
inflated. The recommended tyres size is :
Properly inflated tyres provide the best
combination of handling, tread life, and
riding comfort. Generally, under inflated
tyres wear unevenly, adversely affect
handling, and are more likely to fail from
being overheated. Under inflated tyres can
also cause wheel damage in rocky terrain.
Over inflated tyres make your motorcycle
ride more harshly, are more prone to damage
from surface hazards and wear unevenly.
