Hi-Tec X2-700 User manual

INSTRUCTION MANUAL
WARNING: THE CHARGING AND DISCHARGING OF RC HOBBY BATTERIES CAN BE DANGEROUS. FAILURE TO FOLLOW
THE INSTRUCTIONS AND WARNINGS IN THIS MANUAL MAY RESULT IN PROPERTY DAMAGE AND/OR LOSS OF LIFE.

2
Table of Contents
Introduction................................................................................................. 3
Warnings and Safety Notes......................................................................... 4
Charger Layout ............................................................................................ 8
Specications............................................................................................... 9
Features...................................................................................................... 10
Charger/Battery Connections................................................................... 12
Flowchart ................................................................................................... 13
Lithium Battery Operations...................................................................... 14
NiCd/NiHM Battery Operations ................................................................ 17
Pb (Lead Acid) Operations ........................................................................ 20
Save/Load Data.......................................................................................... 22
Synchronous Mode.................................................................................... 24
Additional Features & Settings................................................................. 25
Warnings and Error Messages .................................................................. 27
Charge Master Software ........................................................................... 29
Recommended Accessories ...................................................................... 29
Commonly Used Terms.............................................................................. 29
Warranty and Service ................................................................................ 35

3
Introduction
Congratulations on your choice of the Hitec X2-700 charger from Hitec RCD,
USA. The Hitec X2 700 is a high-performance, microprocessor-controlled char-
ger/discharger with battery management capabilities that are suitable for use
with most popular battery types. The X2-700 also features integrated balancing
for six-cell, Lithium-Polymer (LiPo), Lithium-Ferrite (LiFe) and Lithium-Ion (Li-
Ion), as well as the latest high voltage Lithium-Polymer (LiHV) batteries.
Please read this entire operating manual before using the X2-700 Charger. If
you are unsure of its proper operation after reading the manual, please seek
advice from an experienced hobbyist or someone familiar with proper battery
charging procedures.
THE CHARGING AND DISCHARGING OF RC HOBBY BATTERIES CAN BE
DANGEROUS. FAILURE TO FOLLOW THESE EXPLICIT WARNINGS CAN
RESULT IN PROPERTY DAMAGE AND/OR LOSS OF LIFE.
ANEVER LEAVE YOUR CHARGER UNATTENDED WHILE IN OPERATION.
ANEVER CHARGE ON OR AROUND COMBUSTIBLE MATERIALS.
ANEVER CHARGE A DAMAGED BATTERY PACK.
ALOW COST, NO-NAME BATTERY PACKS POSE THE MOST DANGER. WE REC-
OMMEND YOU ONLY USE BATTERY PACKS THAT ARE SOLD AND WARRAN-
TIED BY A REPUTABLE COMPANY.
AIT IS HIGHLY RECOMMENDED THAT YOU UTILIZE A SAFETY DEVICE SUCH
AS A STEEL CASE OR LIPO SACK™ WHILE CHARGING LITHIUM CHEMISTRY
BATTERIES.
AIT IS HIGHLY RECOMMENDED THAT YOU KEEP AN OPERABLE “CLASS A” FIRE
EXTINGUISHER IN THE CHARGING AREA.
FAILURE TO FOLLOW THESE WARNINGS CAN BE CONSIDERED NEGLI
GENCE BY THE OPERATOR AND MAY NEGATE ANY CLAIMS FOR DAM
AGES INCURRED.
Hitec RCD USA will not be held responsible for any damages or injuries that
may occur by persons who fail to follow these warnings or who fail to properly
follow the instructions in this manual.
Warning

These warnings and safety notes are of the utmost importance. You must fol-
low these instructions for maximum safety. Failure to do so can damage the
charger and the battery and in the worst cases, may cause a re.
NEVER LEAVE THE CHARGER UNATTENDED WHILE IT IS CONNECTED
TO ITS POWER SOURCE. IF ANY MALFUNCTION IS FOUND, TERMINATE
THE PROCESS AT ONCE AND REFER TO THE OPERATION MANUAL.
AThe allowable DC input voltage is 11-30V DC.
AKeep the charger away from dust, damp, rain, heat, direct sunlight and
excessive vibration.
AIf the charger is dropped or suers any type of impact, it should be inspect-
ed by an authorized service station before using it again.
AThis charger and the battery should be put on a heat-resistant, non-am-
mable and non-conductive surface.
ANever place a charger on a car seat, carpet or similar surface. Keep all am-
mable volatile materials away from the operating area.
AMake sure you know the specications of the battery to be charged or dis-
charged to ensure it meets the requirements of this charger. If the program
is set up incorrectly, the battery and charger can be damaged.
AFire or explosion can occur due to overcharging.
ATo avoid a short circuit between the charge lead, always connect the
charge cable to the charger rst, then connect the battery. Reverse the
sequence when disconnecting.
ANever attempt to charge or discharge the following types of batteries:
Warning: Be sure to read this section for your own safety.
Caution: Be sure to read this section to prevent accidents
and damage to your charger.
Tip: This section will help you maximize the performance of
your charger.
Note: This section will provide more detailed explanations.
Warnings and Safety Notes
Caution
Tip
Warning
Warning
Note

5
• A battery tted with an integral charge circuit or a protection circuit
• A battery pack which consists of dierent types of cells (including dif-
ferent manufacturer’s cells)
• A battery that is already fully charged or just slightly discharged and
non-rechargeable batteries (these pose an explosion hazard)
• A faulty or damaged battery
• Batteries installed in a device or which are electrically linked to other
components
• Batteries that are not expressly stated by the manufacturer to be suit-
able for the currents the charger delivers during the charge process
PLEASE BEAR IN MIND THE FOLLOWING POINTS BEFORE YOU
COMMENCE CHARGING:
• Did you select the appropriate program suitable for the type of battery you
are charging?
• Did you set up the adequate current for charging or discharging?
• Have you checked the battery voltage? Lithium battery packs can be wired
in parallel and in series, i.e. a 2-cell pack can be 3.7V (in parallel) or 7.4V (in
series).
• Have you checked that all connections are rm and secure?
• Make sure there are no intermittent contacts at any point in the circuit.
Warnings and Safety Notes

Warnings and Safety Notes
LiPo LiPo HV LiIon LiFe NiCd NiMH Pb
Nominal
Voltage
3.7V/cell 3.8V/cell 3.6V/cell 3.3V/cell 1.2V/cell 1.2V/cell 2.0V/cell
Max. Charge
Voltage
4.2V/cell 4.35V/cell 4.1V/cell 3.6V/cell 1.5V/cell 1.5V/cell 2.46V/cell
Storage
Voltage
3.8V/cell 3.85V/cell 3.7V/cell 3.3V/cell n/a n/a n/a
Allowable Fast
Charge
≤ 1C ≤ 1C ≤ 1C ≤ 4C ≤ 1-2C ≤ 1-2C ≤ .04C
Min. Discharge
Voltage
3.0-3.3V/cell 3.1-3.4V/cell 2.9-3.2V/cell 2.6-2.9V/cell 0.1-1.1V/cell 0.1-1.1V/cell 1.8V/cell
Standard Battery Parameters
WHEN ADJUSTING YOUR X1 CHARGING PARAMETERS, BE SURE YOU
SELECT THE PROPER BATTERY TYPE AND CELL VOLTAGE FOR THE
TYPE OF CELL YOU ARE CHARGING. CHARGING BATTERIES WITH THE
WRONG SETTINGS MAY CAUSE THE CELLS TO BURST, CATCH FIRE OR
EXPLODE.
Charging
Before charging your batteries, it is critical that you determine the maximum
allowable charge rate for your batteries. The X2-700 is capable of charging
at high rates that may not be suitable or safe for your particular batteries.
For example, Lithium cells are typically safe to charge at 1C, or the total
mAh÷1000. A 1200mAh battery would have a 1C charge rate of 1.2 amps.
A 4200mAh battery would have a 1C charge rate of 4.2 amps. Some
manufacturers are oering Lithium cells that can be charged at greater than
1C but this should ALWAYS be veried before charging a Lithium battery at
rates higher than 1C. Voltage is just as critical as the charging amperage rate
and this is determined by the number of cells in series, or “S”. For example, a
3S LiPo is rated at 11.1 volts (“S” multiplied by a single LiPo cell with a nominal
voltage of 3.7 volts DC. 3 cells x 3.7 volts each equals 11.1 volts DC).
Connect the battery’s main leads to the charger output: red is positive and
black is negative. Keep in mind that the gauge or thickness of your charging
leads from the X1 to your battery must be of an acceptable current rating
to handle the applied charge current. For maximum safety and charging
eectiveness, always match or exceed the main battery lead rating when
assembling or selecting your charging leads. If you charge a battery at a
Warning

7
high current rate (amperage) with a charging lead not rated for the chosen
amperage, the wire could get hot, catch re, short out and/or potentially
destroy your battery and the charger. When in doubt, always use a higher
gauge wire (lower AWG number). It is common to see charging leads
constructed of 14AWG, 16AWG or 18AWG wire.
Always refer to recommendations from your battery manufacturer for your
specic battery type and size before initiating a charge or discharge process.
Do not attempt to disassemble or modify Lithium or Lead-Acid battery packs.
Discharging
The X2-700 discharging functions are for two specic purposes:
• Refreshing the capacity of a Nickel-based battery that has lost capacity over
time (NiMH or NiCd).
• Reducing the voltage of a Lithium battery for safe storage.
LITHIUM CHEMISTRY BATTERY PACKS SHOULD ONLY BE DISCHARGED
TO THEIR MINIMUM SAFE VOLTAGE, NO LOWER. DEEP DISCHARGING
A LITHIUM CELL WILL DO PERMANENT DAMAGE. REFER TO THE
STANDARD BATTERY PARAMETERS TABLE ON PAGE 6 OF THIS MANUAL
FOR MINIMUM DISCHARGE VOLTAGES.
LiPo & LiHV Charge/Discharge Cycling
Lithium batteries are known to reach full capacity after a break-in period of
about 10 charge/discharge cycles. We do not recommend you use the X2-700
charger to do this; normal use and recharging will achieve the same results.
If you wish to perform a Lithium break-in on the bench with the X2-700
discharging to minimum acceptable voltages and performing a balance charge
at 1C maximum rate is recommended. If you choose to break in your Lithium
batteries under normal use, charging at only 1C for the rst ten cycles will help
ensure full performance and service life from your Lithium cells.
Warnings and Safety Notes
Warning

8
Charger Layout
1. X2-700 Charger
2. Battery Clamps
3. 2 x Universal Balancing Boards
4. XT-60 Charging Cable
5. T-Type Charging Cable
6. 2 x 18AWG Wire Charging Cable
Stop/Battery Type Button Start/Resume/Enter Button
Decrease Value(-)/View Status Button Increase Value(+)/View Status Button
LCD Display
1
2
3
4
6
5

9
Specications
DC Input (11-30V) Balance Port
Temperature
Sensor Port
USB Port
Charge Output
Charger Layout
DC Input Voltage 11 - 30 Volts DC
Total Charge Circuit Power 1400 Watts (700 Watts x 2)
Charge Current Range 0.1 - 30.0 Amps x 2
Discharge Current Power 30 Watts x 2
Discharge Current Range 0.1 - 5.0 Amps
Current Drain for LiPo Balancing Max 800mAh per cell
NiCd/NiMh Battery Cell Count 1 - 20 cells
- Capacity Range 100 - 50,000mAh
LiPo/LiHV/LiFe/LiIon Cell Count 2 - 8 cells
- Capacity Range 100 - 50,000mAh
Pb Battery Voltage 2 - 24 Volts
- Capacity Range 100 - 50,000mAh
New Weight 2.69 lbs. (1220g)
Dimensions 7.9 x 5.5 x 2.2in (200 x 140 x 55mm)

10
Features
Optimized Operating Software
The X2-700 “auto” feature sets the charge and discharge current for you au-
tomatically, preventing overcharging which can damage your battery. In the
event of an error, the X2-700 instantly disconnects the circuit and sounds an
alarm. This feature can be set by the user and controlled through the two-way
link for maximum safety.
Data Store/Load
A maximum of ve setting proles can be stored for your convenience. The
X2-700 will store the data pertaining to a program’s settings and you can recall
data at any time.
Internal Independent Lithium Battery Balancer
The X2-700 features a built-in cell voltage balancer so you don’t need to fuss
with external balancers while charging.
Balancing Individual Cells During Discharging
When used with a balancing board the X2-700 can monitor and balance each
cell in the pack individually while discharging. If the voltage of any single cell
is abnormal, the X2-700 will display an error message and the process will end
automatically.
Adaptable to Various Types of Lithium Batteries
The X2-700 will charge and discharge a variety of Lithium batteries such as Li-
ion, LiPo, LiFe and the new higher voltage LiPo, (LiHV) batteries.
Multiple Lithium Battery Charge Modes
The X2-700 features four methods of charging: Regular charge, Fast charge, Bal-
ance charge and Storage charge modes. We highly recommend using balance
charge as it is the safest and best way to charge lithium chemistry batteries. If
you plan on not using your Lithium chemistry batteries for an extended period
of time, Storage charge mode is recommended to optimize your packs for long
term storage and maximum lifespan.
Syncronous Mode
When charging two identical batteries, both channels can be set using channel
one.

11
Features
Input Power Monitoring
The X2-700’s input voltage is monitored to protect the battery from becoming
damaged. The process ends automatically if it drops below the limit.
Capacity and Temperature Limits
The charge process will terminate if either the charging capacity or battery
temperature exceeds the limit set by the user. The temperature function
requires an optional temperature probe, which is not included with the X2-700.
Processing Time Limit
Protect your battery by setting a maximum time limit for charging and
discharging.
Cyclic Charging/Discharging
A battery can be cycled 1 to 5 times consecutively. This process is good for
refreshing and balancing your battery.
Maximum Safety
Our delta-peak voltage detection program ends the charge cycle whenever a
battery’s voltage exceeds the set threshold.
Automatic Charging Current Limit
Charging current can be set by the user when charging lithium NiCd or NiMH
batteries. The ‘AUTO’charging mode, however, is recommended when charging
NiMH batteries with low impedance and capacity.
LiPo Battery Meter
The user can check the battery’s total voltage, the highest and lowest as well as
each cells voltage.
Battery Internal Resistant Meter
The user can check the internal resistance of each cell of the battery.
PC Control Using Charge Master Software
The free Charge Master software gives you unparralled ability to operate the
charger through the computer. You can monitor pack voltage, cell voltage and
other data during the operation. Additionally, you have the ability to set up the
charger and update the rmware.

12
TO AVOID SHORT CIRCUITS, ALWAYS CONNECT THE CHARGE LEADS
TO THE CHARGER FIRST, AND THEN TO THE BATTERY. REVERSE THE
SEQUENCE WHEN DISCONNECTING THE PACK.
Charger/Battery Connections
Warning
Battery Connection With Balance Adaptor.
Battery Connection
Without Balance Adaptor.
12VDC Battery/DC Power Supply Connection.
*
*12VDC battery or
11~18V DC, 30 amp
power supply
2S 3S 4S 5S
6S
1
2
3
4
5
6
BATTERY
BALANCE ADAPTOR
BALANCE
LEAD
BATTERY
BALANCE
LEAD

13
Flowchart
DECINC
LiPo MICRO STORE
500mA 7.4V (2S)
PROGRAM SELECT
BATT MEMORY
ENTER
START
BATT MEMORY [1]
ENTER SET
ENTER
START
BATT TYPE
LiPo
DEC
INC
BATT VOLTS
7.4V ( 2S )
DEC
INC
CHARGE CURRENT
4.9A
DEC
INC
DSCH CURRENT
2.2A
DSCH VOLTAGE
3.0V/CELL
TVC=YOUR RISK
4.20V
DEC
INC
ENTER
START
ENTER
START
PROGRAM SELECT
SYSTEM SET->
Rest Time
CHG>DCHG 10Min
ENTER
START
DEC INC
SAFETY TIMER
ON 120Min
DEC
INC
Capacity Cut-Off
ON 5000mAH
DEC
INC
Key Beep ON
Buzzer ON
DECINC
Power Source?
DC Power Supply
Ext. Temp 0C
Int. Temp 37C
DEC
INC
LOAD FACTORY SET
ENTER
VERSION
1.00
Stop
Batt Type
DECINC
SAVE PROGRAM
ENTER
DEC
INC
SAVE PROGRAM
SAVE….
BATT MEMORY [1]
LiPo 7.4V (2S )
ENTER
START
BATT MEMORY [1]
C:4.9A D:2.2A
ENTER CHARGER
LOAD……
LiPo BALANCE
4.9A 7.4V(2S)
LiPo CHARGE
4.9A 7.4V(2S)
DEC
INC
LiPo FAST CHG
4.9A 7.4V(2S)
DEC
INC
LiPo STORAGE
4.9A 7.4V(2S)
LiPo DISCHARGE
2.2A 7.4V(2S)
DEC
INC
DEC
INC
BATT MEMORY 2
NiMH 2.4V (2S)
BATT TYPE
MiMH
DEC
INC
BATT VOLTS
2.4V (2S)
ENTER
START
CHARGE CURRENT
3.3A
DEC
INC
DEC
INC
TRICKLE
100mA
DEC
INC
PEAK DELAY
1Min
DECINC
DSCH CURRENT
2.2A
DEC
INC
DSCH VOLTAGE
1.1V/CELL
DEC
INC
DELTA PEAK SENSE
4Mv/C
SAVE PROGRAM
ENTER
DEC
INC
BATT MEMORY 3
Pb 4V (2S)
ENTER
START
BATT TYPE
Pb
BATT VOLTS
4.0V (2S)
DEC
INC
CHARGE CURRENT
3.3A
DEC
INC
DSCH CURRENT
1.5A
DEC
INC
DSCH VOLTAGE
1.7V/CELL
DEC
INC
DEC
INC
SAVE PROGRAM
ENTER
DECINC
PROGRAM SELECT
Pb BATT
ENTER
START
Pb CHARGE
2.0A 2.0V (1P)
DEC
INC
Pb DISCHARGE
0.1A 2.0V (1P)
DECINC
PROGRAM SELECT
NiCD BATT
NiCD CHARGE
CURRENT 2.0A
ENTER
START
DEC
INC
NiCD DISCHARGE
0.1A CUT: 1.0V
DEC
INC
NiCD CYCLE
CHG>DCHG 1
DECINC
PROGRAM SELECT
NiMH BATT
ENTER
START
NiMH CHARGE
CURRENT 2.0A
DEC
INC
NiMH DISCHARGE
0.1A CUT: 1.0V
NiMH CYCLE
CHG>DCHG 1
DEC
INC
PROGRAM SELECT
LiPo BATT
LiPo BALANCE
2.0A 7.4V (2S)
LiPo CHARGE
2.0A 7.4V (2S)
LiPo FAST CHG
2.0A 7.4V (2S)
LiPo STORAGE
2.0A 7.4V (2S)
LiPo DISCHARGE
2.0A 7.4V (2S)
ENTER
START
DEC
INC
DEC
INC
DEC
INC
DEC
INC
DECINC
DECINC
PROGRAM SELECT
Lilo BATT
Lilo BALANCE
2.0A 7.2V (2S)
Lilo CHARGE
2.0A 7.2V (2S)
Lilo FAST CHG
2.0A 7.2V (2S)
Lilo STORAGE
2.0A 7.2V (2S)
Lilo DISCHARGE
2.0A 7.2V (2S)
ENTER
START
DEC
INC
DEC
INC
DEC
INC
DEC
INC
PROGRAM SELECT
LiFe BATT
LiFe BALANCE
2.0A 6.6V (2S)
LiFe CHARGE
2.0A 6.6V (2S)
LiFe FAST CHG
2.0A 6.6V (2S)
LiFe STORAGE
2.0A 6.6V (2S)
LiFe DISCHARGE
2.0A 6.6V (2S)
ENTER
START
DEC
INC
DEC
INC
DEC
INC
DEC
INC
DECINC
ENTER
START
PROGRAM SELECT
BATT METER
4.20 4.19 4.19 V
0.00 0.00 0.00 V
DEC
INC
DEC
INC
DECINC
DECINC
DECINC
DEC
INC
NiCD RE-PEAK
1
DEC
INC
NiMH RE-PEAK
1
DEC
INC
NiMH Auto CHARGE
CURRENT 2.0A
DEC
INC
NiCD Auto CHARGE
CURRENT 2.0A
DEC
INC
TEMPERATURE
CUT-OFF 50C
DEC
INC
TEMPERATURE
CUT-OFF 50C
DEC
INC
DECINC
TEMPERATURE
CUT-OFF 50C
LiPo MICRO CHG
500mA 7.4V (2S)
DEC
INC
LiIo MICRO CHG
500mA 7.4V (2S)
DEC
INC
LiFe MICRO CHG
500mA 7.4V (2S)
DEC
INC
LiPo MICRO STORE
500mA 7.4V (2S)
DEC
INC
LiIo MICRO STORE
500mA 7.4V (2S)
DEC
INC
LiFe MICRO STORE
500mA 7.4V (2S)
DEC
INC
Synchron Enable?
OFF
DEC
INC
PROGRAM SELECT
LiHV BATT
LiHV BALANCE
2.0A 7.6V (2S)
LiHV CHARGE
2.0A 7.6V (2S)
LiHV FAST CHG
2.0A 7.6V (2S)
LiHV STORAGE
2.0A 7.6V (2S)
LiHV DISCHARGE
2.0A 7.6V (2S)
ENTER
START
DEC
INC
DEC
INC
DEC
INC
DEC
INC
DECINC
LiHV MICRO CHG
500mA 7.4V (2S)
DEC
INC
LiHV MICRO STORE
500mA 7.4V (2S)
DEC
INC
DECINC
ENTER
START
BATT/PROGRAM
BATT RESISTANCE
1: 5m
Ω 2: 3 m Ω
3: 4m Ω 4: 3 m Ω
DEC
INC
DEC
INC
START
/
ENTER >3s
DEC
INC
LiPo MICRO CHG
500mA 7.4V (2S)
5: 4m Ω 6: 3 m Ω
MAIN 0.00V
H0.000V L0.000V
DEC
INC
0.00 V 0.00 V
Max Power Set
700W
DEC
INC
DECINC
DEC
INC
A larger version of this ow chart can be found on the web at www.hitecrcd.com

14
The X2-700 oers the following lithium charge modes: Charge, Balance
Charge, Fast Charge, Storage, Discharge Micro Charge and Micro Storage.
BEFORE SELECTING A CHARGE MODE, IT IS CRITICAL THAT YOU
SELECT THE CORRECT TYPE OF LITHIUM BATTERY TO BE CHARGED.
FAILURE TO DO SO CAN RESULT IN DAMAGE TO THE BATTERY AND
POSSIBLE EXPLOSION.
Selecting a Lithium Battery Type: After powering on the charger press the
BATT/PROG button once to go to the “PROGRAM SE-
LECT” screen. Use the INC. >button to advance to the
type of battery you want to charge. Choices of lythium
type batteries are; LiPo, LiIo, LiFe, and LiHV. Once you
have sellected your battery type, press the ENTER but-
ton to continue to the charge mode selection screen.
This program is only suitable for charging/discharging Lithium (LiPo/LiHV/
LiIon/LiFe) batteries from 1 - 8 cells.
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
INFORMATION CONTAINED ON PAGES 47.
LITHIUM BATTERIES CAN BE CHARGED WITHOUT THE USE OF A BAL
ANCE ADAPTOR. A BALANCE ADAPTER CAN BE USED, BUT IT IS NOT
REQUIRED. BALANCE CHARGE MODE IS RECOMMENDED FOR ANY
BATTERY WITH A BALANCE LEAD.
See page 12 for the appropriate charging connection setup for this operation.
Selecting the Charge Mode: First, select the correct battery type by following
the instructions above. Once you have set the correct battery type, press the
ENTER button once to go to the to the chage mode select screen.
Use the < DEC. or INC. >buttons to scroll through
the mode choices. The following modes are available
when working with Lithium chemistry batteries:
Lithium Battery Operations
PROGRAM SELLECT
LiPo BATT->
LiPo BALANCE
2.0A 3.7V
Lithium
Warning
Warning
Note
LiPo CHARGE
0.1A 3.7V(1S)

15
Lithium Battery Operations (cont.)
Lithium
Charge: Basic charge mode used for normal charging
Discharge: Basic discharge mode used for normal discharging
Storage: This mode is for charging or discharging batteries to the optimal stor-
age voltage for the purpose of storing the batteries for a longer period of time.
Fast Charge: Charges faster than regular“Charge” mode although capacity
may be reduced resulting in shorter run times.
Balance Charge: For batteries with a balancing connection, this mode balanc-
es the voltage of each individual cell while charging. This is the safest and most
optimal way to charge Lithium chemistry batteries.
Micro Charge: Charges at a rate from 10~500mAh for smaller batteries
Micro Storage: Charges or discharges at a rate from 10~500mAh
Fast Charge: Charges faster than regular“Charge” mode although capacity will
be slightly reduced.
Setting the Charge/Discharge Current: Once you nd the mode you
wish to use press the ENTER/START button and the current value will begin
ashing. Use the < DEC. or INC. >buttons to Set
the Charge/Discharge current based on the battery
manuafcturer’s recomendations. Once you have set the
Charge/Discharge current, press ENTER/START to move to the battery voltage
setting.
Most manufacturers suggest a 1C charge rate for lithium chemis-
try batteries although some manufacturers are oering Lithium
cells that can be charged at a rate greater than 1C. This should
ALWAYS be veried before charging a Lithium battery at rates
higher than 1C.
Setting the Voltage: The cell count indicator will be ashing, use the < DEC.
or INC. >buttons to adjust the value to the desired
number. Press ENTER to conrm. The voltage and cell
count should match the values listed on the battery label.
Program Start: You are now ready to execute the selected program. Press
and hold the ENTER/START button until you see “BATTERY CHECK WAIT...”
followed by the “CONFIRM/CANCEL“ screen.
Caution
LiPo CHARGE
0.1A 3.7V(1S)
Li
LiPo CHARGE
0.1A 3.7V(1S)
Li

16
This screen displays the number of cells you set up as
”R” and the number of cells detected by the processor
as “S”. If both numbers are identical, you may press the
ENTER/START button to conrm and begin charging. If these numbers do not
match, press the STOP button to return to the previous screen and carefully
check the number of cells of the battery pack before proceeding.
DURING CHARGING, THE BATTERY SHOULD BE PLACED INSIDE A
FIREPROOF/RETARDANT BAG AND ON A FIRE PROOF SURFACE AWAY
FROM OTHER COMBUSTIBLE OBJECTS.
Lithium Battery Operations(cont.)
Lithium
R:3SER S:3SER
CONFIRM(ENTER)
Li3s 1.2A 12.19V
CHG 022:43 00682
Warning
Information Displayed During the Process: A variety of information is avail-
able for viewing as the charger executes the selected program. Use the < DEC.
or INC. > buttons to scroll through this information.
Real-time status: battery type, battery cell, charge
current, battery voltage, elapsed time and charged
capacity.
Voltage of each cell in the battery pack when the bat-
tery is connected with balance lead.
Charged capacity percentage and average cell voltage
of the battery pack.
Input Voltage
End Voltage Setting
Capacity Cut-off Settings
Internal and External* Temperatures
*External temperature requires optional temperature probe part no. 44159
Temperature Cut-Off settings
Safety Timer setting
Once the charger has finished the process, it will chime
and display the end voltage and capacity.
4.09 4.09V 4.09V
0.00 0.00V 0.00V
Fuel= 90%
Cell= 4.10V
End Voltage
12.60V
IN Power Voltage
18.88V
Capacity Cut-Off
ON 5000mAh
[CHARGE FINISH ]
16.75V 01800mAh
Ext. Temp 0C
Int. Temp 36C
Temp Cut-Off
80C
SAFETY TIMER
ON 120Min

17
The X2-700 oers the following NiCd/NiMH charge modes: Charge, Auto
Charge, Discharge Re-Peak and Cycle.
BEFORE SELECTING A CHARGE MODE, IT IS CRITICAL THAT YOU
SELECT THE CORRECT TYPE OF BATTERY TO BE CHARGED. FAILURE TO
DO SO CAN RESULT IN DAMAGE TO THE BATTERY.
Selecting the Battery Type: After powering on the charger, press the
BATT/PROG button once to go to the “PROGRAM SELECT” screen. Use the INC.
>button to advance to the type of battery you want
to charge. Once you have selected your battery type,
press the ENTER button to continue to the charge
mode selection screen.
Selecting the Charge Mode: Use the < DEC. or INC. >buttons to scroll
through the mode choices. The following modes are available when working
with NiCd and NiMh batteries:
Charge: Basic charge mode used for normal charging
Auto Charge: In this mode, the charger will automatically detect the battery
parameters and charge the battery automatically.
You should set the upper limit of the charge current in order to avoid
damage from exessive current.
Discharge: Basic discharge mode used for normal discharging
Re-Peak: This mode is will peak charge the battery up to three times
Cycle: Automatically charges/discharges the battery up to 5 times. This pro-
cess can enhance the performance of NiMh/NiCd batteries.
Setting the Charge Current: In Charge mode, you will be prompted to set
the charge current or the maximum charge current for
Auto Charge mode. Once you nd the mode you wish
to use, press the ENTER/START button twice and the
current value will begin ashing. Use the < DEC. or INC. >buttons to set the
charge current based on the battery manufacturer’s recommendations. Press
ENTER to conrm your settings.
NiCd/NiMH
NiMH Auto CHARGE
CURRENT 1.6A
This program is only suitable for charging/discharging NiCD/NiMH batteries.
NiCD/NiMH Battery Operations
PROGRAM SELECT
NiMH BATT
Warning
NiMH CHARGE
CURRENT 0.1A
Li

18
Setting the Discharge Current: You will need to set a discharge current
when using the Discharge and Cycle modes. After
selecting the Discharge mode, press the ENTER/START
button twice and the current value will begin ashing. Use the < DEC. or INC.
>buttons to set the Discharge current based on the battery manufacturer’s
recommendations. Once you have set the Discharge current, press ENTER/
START to conrm your setting.
The X2-700 uses the settings from the Charge and Discharge
programs when performing the charge/discharge cycles in Cycle
mode.
Setting the Cycle Functions: When choosing the cycle function you will be
prompted to set the number of Discharge/Charge cycles to perform as well as
the Charge/Dischage or Discharge/Charge starting/ending points. After select-
ing the Cycle mode, press the ENTER/START button
twice and the starting and ending cycle will begin to
ash. Use the < DEC. or INC. >buttons to select the starting/ending point of
your choice and press the ENTER/START button to conrm. Now the number
of cycles prompt will be ashing Use the < DEC. or INC. >buttons to select
the number of cycles you wish to perform and press
the ENTER/START button to conrm.
Selecting the Number of Re-Peak Operations: When choosing the Re-
Peak function you will need to set the number of times
you want to Re-Peak the battery. After selecting the
Re-Peak mode, press the ENTER/START button twice
and the number of Re-Peak cycles will ash. Use the < DEC. or INC. >buttons
to select the number of Re-Peak cycles you wish to perform and press the
ENTER/START button to conrm.
BEFORE YOU BEGIN CHARGING OR DISCHARGING YOUR BATTERY,
MAKE SURE YOU HAVE READ AND UNDERSTAND ALL OF THE WARN
INGS AND SAFETY INFORMATION CONTAINED ON PAGES 47.
DURING CHARGING, THE BATTERY SHOULD BE PLACED ON A FIRE
PROOF SURFACE AWAY FROM OTHER COMBUSTIBLE OBJECTS.
NiCD/NiMH Battery Operations (cont.)
LithiumNiCd/NiMH
NiMH CYCLE
CHG>DCHG 1
NiMH DISCHARGE
CURRENT 0.1A
Warning
Li
Note
NiMH CYCLE
CHG>DCHG 1
Li
Li
NiMH CYCLE
CHG>DCHG 1
Li

19
Program Start: Once you have chosen the mode and set the proper
parameters, press and hold the ENTER/START button to execute the program.
You will see “BATTERY CHECK” followed by the operation screen. The X2-700
is now executing the chosen program. When the operation is completed the
X2-700 will chime.
Information Displayed During the Process: A variety of information is avail-
able for viewing as the charger executes the selected program. Use the < DEC.
or INC. > buttons to scroll through this information.
Real-time status: battery type, charge current, battery
voltage, process, elapsed time and charged capacity
Delta Peak Sensitivity
Capacity Cut-Off
ON 5000mAh Capacity Cut-Off settings
Safety Timer setting
Temperature Cut-Off settings
Internal and External* Temperatures
*External temperature requires optional temperature probe part no. 44159
Input Power Voltage.
Once the charger has finished the process, it will chime
and display the end voltage and capacity.
NiCd/NiMH
NiCD/NiMH Battery Operations (cont.)
NiMH 0.1A 5.21V
D>C 015:42 00026
NiMH Sensitivity
D.Peak 4mV/Cell
SAFETY TIMER
ON 120Min
Temp Cut-Off
80C
Ext. Temp 0C
Int. Temp 36C
IN Power Voltage
18.88V
[END:FINISH ]
5.92V 00800mAh

20
Pb (Lead-Acid) Battery Operations
Lithium
Pb (Lead-Acid)
This program is only suitable for charging Pb (lead-acid) batteries with nominal
voltages of 2 to 24V. A Pb (lead-acid) battery is signicantly dierent from
NiCd/NiMH batteries. Pb batteries can only deliver current lower in comparison
to their capacity. The same restriction applies to the charging process.
Consequently, the optimum charge current can only be 1/10 of the capacity.
A Pb battery cannot be used for fast charging. Please follow the instructions
provided by the battery manufacturer.
The X2-700 oers the following Pb charge modes: Charge and Discharge.
BEFORE SELECTING A CHARGE MODE, IT IS CRITICAL THAT YOU SELECT
THE CORRECT TYPE OF BATTERY TO BE CHARGED. FAILURE TO DO SO
CAN RESULT IN DAMAGE TO THE BATTERY.
Selecting the Battery Type: After you power on the X2-700, BATT/PROG
button once to go to the “PROGRAM SELECT” screen.
Use the INC. >button to advance to the “Pb BATT“ pro-
gam. Once you have selected your battery type, press
the ENTER button to continue to the charge mode selection screen.
Selecting the Charge Mode: Use the < DEC. or INC. >buttons to choose
either the charge or discharge mode.
Setting the Charge/Discharge Current: Once you have selected
the mode you wish to use, press the ENTER/START
button and the current value will begin ashing.
Use the < DEC. or INC. >buttons to set the Charge/Discharge current based
on the battery manufacturer’s recommendations. Once you have set the
Charge/Discharge current, press ENTER/START to move to the battery voltage
setting.
Setting the Voltage: The voltage indicator count will
be ashing. Use the < DEC. or INC. >buttons to adjust
the value to the desired voltage. Press ENTER to conrm. The voltage and cell
count should match the values listed on the battery label.
BEFORE YOU BEGIN CHARGING OR DISCHARGING YOUR BATTERY,
MAKE SURE YOU HAVE READ AND UNDERSTAND ALL OF THE WARN
INGS AND SAFETY INFORMATION CONTAINED ON PAGES 47.
PROGRAM SELECT
NiMH BATT
Warning
Pb CHARGE
0.7A 12.0V(6P)
Warning
Pb CHARGE
0.7A 12.0V(6P)
Li
Li
