HiB Cyclone 33300 User manual

Quality Bathroom Products
Ver No. 3.0 Sept 2014
Fixing Instructions
Thank you for purchasing this HiB product.
Please read through these instructions carefully and refer back to them during installation to
ensure that your product is tted safely and that it retains its high quality nish.
Please retain this leaet for future reference.
Before drilling, ensure there are no hidden cables or pipes in the wall
Please see Figure 1 on the back page for details
These products are suitable for installation in zones:
2
Cyclone Inline Fan, White - Non Illuminated Art no.33300
Cyclone Inline Fan, White - Cool White LED Art no.32600
Cyclone Inline Fan, White - Warm White LED Art no.33800
Cyclone Inline Fan, Chrome - Cool White LED Art no.32700
Cyclone Inline Fan, Chrome - Warm White LED Art no.33700
Cyclone Inline Fan, Chrome - Non Illuminated Art no.33400

Quality Bathroom Products
2
Quality Bathroom Products
In The Box
Includes:
1. Fascia
2. LED Driver (32600, 33800, 32700 & 33700 only)
3. High powered Inline fan,
4. 3 metre flexible ducting
5. Brown external fixed grille
6. Four galvanized steel hose clamps
7. Screw and dowels
8. Plastic screwdriver (only for modications with timer)
9. Fixing instructions
Warning
The Cyclone Inline Fan 32600, 33800, 32700 & 33700 is supplied with an MR16 3
Watt LED lamp. This is the only lamp suitable for use with this fan. Do not replace
with any other lamp as this will invalidate any warranty. Do not exceed the stated
wattage.
The fan must be connected to power mains through an automatic circuit breaker
integrated into the xed wiring system with the gap between the breaker
contacts on all poles not less than 3 mm. Check the fan for any visible damages of
the impeller and the casing before starting installation. The casing internals must
be free of any foreign objects which can damage the impeller blades. Misuse of
the product or any unauthorized modication is not allowed.
Take steps to prevent ingress of smoke, carbon monoxide and other combustion
products into the room through open chimney ues or other re-protection
devices. Sucient air supply must be provided for proper combustion and
exhaust of gases through the chimney of fuel burning equipment to prevent
back drafting.
Please Note; The fan may operate immediately when connected, this is normal and
due to a residual charge left in the capacitor during testing. Should this occur, switch
o, adjust timer to desired setting then turn back on. (see page 7 for Timer System)

Quality Bathroom Products
3
Quality Bathroom Products
Mounting
1. Ceiling mounted ventilation should be ducted through the roof space, by
ducting to an external sot under the eaves or grille in the slope of your roof.
NB: Ducting installed between a oor and ceiling can only run between joists, not
across them.
2. Mark the position of the vent fascia with a pencil in a suitable position on the
ceiling, making sure that it is between the joists.
3. Drill a 9mm hole through the ceiling anywhere along the edge of the pencil
line. Now cut out the hole with a pad saw.
4. Hold the vent fascia against the ceiling and mark the position of the xing
holes. Fix the unit in place using suitable heavy duty plasterboard xings (not
supplied).
5. Attach exible ducting with the metal hose clamps. Ensure that the ducting
has a smooth ow towards the motor body to minimise air resistance. Follow a
similar procedure for the outside wall grille. Extra ducting may be used to extend
the distance to the external grille but performance will be reduced.
6. Install the Cyclone Inline fan within the loft or ceiling space (ensuring correct
direction of air ow using arrows on the fan). The fan is suitable both for
horizontal on a wall (g. A) or a oor (g. B). When mounting the fan ensure
there is a minimum of 1m straight ducting to the motor body (see g.B). Attach
the exible ducting to the fascia with the metal clamps supplied.
min 1m
g. A horizontal on a wall g. B horizontal on a oor Do not mount vertically

Quality Bathroom Products
4
Quality Bathroom Products
7. Using a screw driver,
remove screws on clips.
9. Place frame in desired
location and mark
xing holes.
10.Fix frame to desired surface, using suitable
wall plugs if necessary. Then replace central
unit and bracing clips.
8. Remove bracing clips & remove central unit.
11.Connect the exible ducting to both sides of the Inline fan with the metal
hose clamps. Ensure there is a minimum of 1m straight ducting between
fascia and fan.
12.Ensure the mains power supply to which the fan is being connected is turned
o. This product is designed to be connected to an on/o switch outside the
bathroom, or to a ceiling mounted pull cord switch.
Electrical Connection

Quality Bathroom Products
5
Quality Bathroom Products
13.Using a screw driver,
remove cover.
14.Using a screw driver,
remove cable grip.
15.Feed cable through
hole & replace grip.
16.Wire the fan as per the diagram below.
17.Replace cover using a suitable screw driver.
18.On Illuminated versions (32600, 33800, 32700 & 33700) the mains supply from
the bathroom tting should be connected to the LED driver as per the wiring
diagram for lamp.
19.Fix the external grille to the sot in the same way as the ceiling fascia with 4
screws.
QF - Circult Breaker
ST - External Switch (e.g. light switch)
Wiring Diagram For Lamp
(32600, 33800, 32700 & 33700 only)
N
LST
QF N
L
LT
LIDo Not Use
~
AC in DC out
Live is RedLive supply is Red or Brown
Neutral
supply is Blue or Black Neutral is Black

Quality Bathroom Products
6
Quality Bathroom Products
Operation
The fan is rated for connection to single-phase AC220-240 V / 50/60 Hz power
mains. The fan is designed for continuous operation always connected to mains
power. Air motion direction in the system must match the pointer on the fan
casing. Ingress protection rating IPX4.
Maintenance
• Fan maintenance is to be performed only after the fan is disconnected from the
mains power suppy. Maintenance means periodic cleaning of the surface of
dust and dirt.
• All surfaces should be cleaned with diluted detergent, i.e. washing up liquid,
and a soft cloth. Scourers and scouring agents should not be used, as these may
cause damage to the surface of the product.
• Avoid water dripping on the electric components. Wipe the surfaces dry after
cleaning.

Quality Bathroom Products
7
Quality Bathroom Products
WEEE compliance
Must not be mixed with general household waste
Timer System
The fan is operational after the control voltage is supplied by the external switch
(e.g., by the light switch) to the input terminal LT. After the fan is switched o
the fan continues to operate within the timer period set by the timer from 2
to 30 minutes. To adjust the run on timer, rotate the control knob clockwise to
increase and anti-clockwise to decrease the o-delay time respectively (see
below diagram). Please note the adjustment should only be done without the fan
running.
Warning! The timer circuit is under mains voltage. Ensure mains power supply is
switched o before making any adjustments.
The set includes a specially designed plastic screwdriver for timer setting
adjustments. Only use the plastic screwdriver to alter the turn-o delay time. Do
not use a screwdriver, knife, etc. for adjustments so as not to damage the circuit
board.
-+
30 min
2 min
Õ

hib.co.uk
[phone] [phone] [e-mail]
HiB Ltd. Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN
©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they
are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specications as necessary. E & OE.
zone
2
zone
2
zone
2
zone
2
zone
2
outside
zone
60cm
60cm
60cm
60cm
75cm
75cm
75cm
75cm
60cm
radius
225cm
225cm
zone
1
zone
2
zone
1
This product is suitable for installation in zones:
All installations must comply with guidelines which are based on a zonal concept. The diagram above illustrates this concept
and must be followed to ensure the safe installation of electrical appliances in the bathroom. These regulations apply to
domestic installations only. Installations must be made in accordance with the current IEE wiring regulations and relevant
building regulations. HiB recommends that all electrical bathroom products should only be tted by a suitably qualied,
Part P registered electrician.
2
hib.co.uk
[phone] [phone] [email protected].uk
HiB Ltd. Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN
Technical Information
Power Input: 220-240V, 50/60Hz
Maximum Ventilation Volume: 210 m/hr (±5%) / 58.333 Litres Per Second
Power Consumption: 25W
Decibel: 32dB
Dimensions: Ø14 x D7.3cm
Electrical Safety Information
HiB recommends that all electrical bathroom products should only be tted by a suitably qualied, Part P registered
electrician in accordance with current IEE reguations. Ensure mains power supply is switched o before starting
installation. Before drilling, ensure there are no hidden cables or pipes in the wall.
Care Instructions
Do not use abrasives or solvents when cleaning this product.
Wipe o all water spillages as soon as possible using a soft, damp cloth.
Aftercare Service
In the unlikely event that this product should fail please contact HiB customer services, contact detail shown below.
Figure 1
