HIK VISION 9 Series User manual

Video Intercom 9 Series Indoor
Staon
Conguraon Guide

Legal Informaon
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product.
Pictures, charts, images and all other informaon hereinaer are for
descripon and explanaon only. The informaon contained in the Manual
is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision
website ( hps://www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals
trained in supporng the Product.
Trademarks
and other Hikvision's trademarks and logos are the
properes of Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their
respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL
AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL FAULTS AND ERRORS”.
HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS
AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR
ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT,
TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN
Video Intercom 9 Series Indoor Staon Conguraon Guide
i

CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR
INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE ANY
RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR
OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION
WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE
LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE
CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE,
FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE
RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND
OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION
OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN
THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR
FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Video Intercom 9 Series Indoor Staon Conguraon Guide
ii

Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger Indicates a hazardous situaon which, if not avoided, will or
could result in death or serious injury.
Cauon Indicates a potenally hazardous situaon which, if not
avoided, could result in equipment damage, data loss,
performance degradaon, or unexpected results.
Note Provides addional informaon to emphasize or
supplement important points of the main text.
Video Intercom 9 Series Indoor Staon Conguraon Guide
iii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC compliance: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not
occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance
20cm between the radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to
the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operaon.
Video Intercom 9 Series Indoor Staon Conguraon Guide
iv

EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the EMC Direcve
2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve 2011/
65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your
local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collecon points. For more informaon
see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery
that cannot be disposed of as unsorted municipal waste in the
European Union. See the product documentaon for specic
baery informaon. The baery is marked with this symbol,
which may include leering to indicate cadmium (Cd), lead (Pb),
or mercury (Hg). For proper recycling, return the baery to your
supplier or to a designated collecon point. For more informaon
see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operaon is subject to the following two condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may
cause undesired operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radioexempts de licence. L'exploitaon est autorisée aux deux
condions suivantes :
Video Intercom 9 Series Indoor Staon Conguraon Guide
v

1. l'appareil ne doit pas produire de brouillage, et
2. l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est suscepble d'en compromere le
fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmier by Industry Canada. To reduce potenal radio interference to
other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur
radio peut fonconner avec une antenne d'un type et d'un gain maximal (ou
inférieur) approuvé pour l'émeeur par Industrie Canada. Dans le but de
réduire les risques de brouillage radioélectrique à l'intenon des autres
ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire à l'établissement d'une communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance
20cm between the radiator and your body.
Cet équipement doit être installé et ulisé à une distance minimale de 20
cm entre le radiateur et votre corps.
Video Intercom 9 Series Indoor Staon Conguraon Guide
vi

Contents
1 About this Manual ...................................................................................... 1
2 Local Operaon .......................................................................................... 2
2.1 Acvate Indoor Staon ..................................................................................... 2
2.2 Conguraon Sengs ....................................................................................... 2
2.2.1 Set Indoor Staon Network Parameters ................................................... 2
2.2.2 Set Linked Device IP .................................................................................. 3
2.2.3 Set Indoor Staon No. .............................................................................. 5
2.2.4 Add Camera .............................................................................................. 5
2.2.5 Zone and Alarm Sengs ........................................................................... 6
2.3 Password Sengs ............................................................................................. 8
2.4 Synchronize Time ............................................................................................ 10
2.5 Sound Sengs ................................................................................................. 10
2.6 Restore Indoor Staon .................................................................................... 11
2.7 System Sengs ............................................................................................... 12
2.8 Link to the Mobile Client ................................................................................. 13
2.9 Shortcut Sengs ............................................................................................. 14
3 Remote Operaon via the client soware ............................................... 15
3.1 Acvate Device Remotely ............................................................................... 15
3.2 Device Management ....................................................................................... 15
3.2.1 Add Video Intercom Devices .................................................................. 16
3.2.2 Modify Network Informaon ................................................................. 18
3.3 System Conguraon ...................................................................................... 19
Video Intercom 9 Series Indoor Staon Conguraon Guide
vii

3.4 Remote Conguraon ..................................................................................... 19
3.4.1 System .................................................................................................... 19
3.4.2 Video Intercom ....................................................................................... 24
3.4.3 Network .................................................................................................. 31
3.5 Person and Card Management ........................................................................ 35
3.5.1 Organizaon Management ..................................................................... 36
3.5.2 Person Management .............................................................................. 37
A. Communicaon Matrix and Device Command ....................................... 41
Video Intercom 9 Series Indoor Staon Conguraon Guide
viii

1 About this Manual
Get the manual and related soware from or the ocial website (hp://
www.hikvision.com).
Product Model
Network Indoor Staon DS-KH9310-WTE1/DS-KH9510-WTE1
Video Intercom 9 Series Indoor Staon Conguraon Guide
1

2 Local Operaon
2.1 Acvate Indoor Staon
You can only congure and operate the indoor staon aer creang a password for
the device acvaon.
Steps
1. Power on the device. It will enter the acvaon page automacally.
2. Create a password and conrm it.
3. Tap OK to acvate the indoor staon.
Note
We highly recommend you to create a strong password of your own choosing
(using a minimum of 8 characters, including at least three kinds of following
categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we
recommend you change your password regularly, especially in the high security
system, changing the password monthly or weekly can beer protect your
product.
2.2 Conguraon Sengs
Conguraon sengs is required before starng using the indoor staon. It is
necessary to set the indoor staon network, room No., linked devices, device me
display, and so on.
2.2.1 Set Indoor Staon Network Parameters
Network connecon is mandatory for the use of the indoor staon. Set the network
parameters aer acvang the indoor staon. Only when the IP address of the
indoor staon is in the same network segment as other devices, it can work properly
in the same system.
Steps
Note
The default IP address of the indoor staon is 192.0.0.64.
Video Intercom 9 Series Indoor Staon Conguraon Guide
2

Two ways are available for you to set IP address: DHCP, and set IP address manually.
1. Tap Sengs → → Conguraon Sengs → to enter the network sengs
page.
Note
Enter acvate password as the admin password.
Figure 2-2 Network Sengs
2. Enable DHCP, then the indoor staon can search and get an IP address
automacally.
Note
Skip the following steps if you have enabled DHCP.
3. Set the Local IP, Subnet Mask and Gateway manually.
4. Congure the DNS address according to your needs.
2.2.2 Set Linked Device IP
Linked network parameters refers to the network parameters of devices (like door
staon, doorphone, master staon, center, etc.), to which the indoor staon is
linked. Linked devices for the indoor staon refers to door staon, center, master
staon, and doorphone.
Steps
Note
Here take door staon network sengs as example.
Video Intercom 9 Series Indoor Staon Conguraon Guide
3

1. Tap Sengs → → Conguraon → to enter the device management page.
Note
Default admin password is the acvaon password.
Figure 2-3 Device Management
2. Tap Main Door Staon to pop up the device informaon dialog.
Figure 2-4 Device Informaon
Restore the door staon via
indoor staon.
Tap to restore the parameters of the
door staon.
Modify the IP address of the
linked door staon.
Tap to modify the IP address of door
staon.
3. Select the device to link. Edit the network parameters.
Video Intercom 9 Series Indoor Staon Conguraon Guide
4

2.2.3 Set Indoor Staon No.
Indoor staon No. and the indoor extension No. are numbers, which can be dialed
by other devices to call the indoor staon and the indoor extension in an intercom
system. The indoor staon No., is composed of the oor No. and the room No.
The indoor extension No. should be a numeric from 1 to 5.
Up to 5 indoor extensions can be set for 1 indoor staon.
Steps
1. Tap Sengs → → Conguraon → to enter the indoor staon No. sengs
page.
Note
Default admin password is the acvaon password.
Figure 2-5 Set Indoor Staon No.
2. Congure the indoor staon and indoor extension informaons.
-Select Indoor Staon as Indoor Staon Type. Tap Room Informaon to edit
the Room No., Community No., Building No., Unit No., Floor No. and Room
No.
-Select Indoor Extension as Indoor Staon Type. TapRoom Informaon to
edit the Room Name and Extension No.
2.2.4 Add Camera
Steps
1. Tap Sengs → → Conguraon → to enter the device management page.
Video Intercom 9 Series Indoor Staon Conguraon Guide
5

Note
Default admin password is the acvaon password.
2. Tap + to pop up the dialog box.
3. Tap Camera and OK to add.
Figure 2-6 Add Camera
4. Enter the device name and IP address.
5. Enter the port No. and channel No.
6. Enter the user name and password of the camera.
7. Tap √ to add the camera.
2.2.5 Zone and Alarm Sengs
Zone Sengs
You can set the zone type, alarm type and delay me and other parameters of 8
zones.
Before You Start
Tap Sengs → → Shortcut Sengs to enable Zone Alarm Locally funcons.
Steps
Note
Arming status page and zone sengs page are hidden by default. You should enable
alarm funcon rst.
Video Intercom 9 Series Indoor Staon Conguraon Guide
6

1. Tap Sengs → → Zone Sengs to enter the zone sengs page.
Figure 2-7 Zone Sengs
2. Press a zone to pop up the zone eding dialogue box.
3. Set the zone type, alarm type, status of arming status, entering delay, and exing
delay.
4. Tap OK to save the sengs.
Note
•7 zone types are selectable: Panic Buon, Door Magnec, Smoke Detector,
Acve Infrared, Passive Infrared, Gas Detector, and Doorbell.
•3 alarm types are selectable: 24h Alarm, Instant Alarm, and Delay Alarm.
Set the alarm type as 24h alarm, and the zone will be armed for 24h.
Set the alarm type as instant alarm, and the zone will alarm once it's
triggered.
Set the alarm type as delay alarm, and you should set the entering delay
duraon and exing delay duraon.
•Both the entering delay duraon and the exing delay duraon are from 30s
to 60s.
•For Gas Detector and Smoke Detector, the alarm type is set as default 24h
alarm. The alarm type of them can not be changed.
Arming Mode Sengs
4 arming modes can be congured: stay mode, away mode, sleeping mode and
custom mode.
Video Intercom 9 Series Indoor Staon Conguraon Guide
7

Before You Start
Tap Sengs → → Shortcut Sengs to enable Zone Alarm Locally.
Steps
Note
Arming status page and zone sengs page are hidden by default. You should enable
alarm funcon rst.
1. Tap Sengs → → Scene Sengs to enter the arming mode sengs page.
2. Tap Stay Mode, Away Mode, Sleeping Mode, or Custom to enter the page.
Figure 2-8 Arming Mode Sengs
3. Arm the selected zone.
Note
•Zones are congurable on the arming mode page.
•24H alarm zone including smoke detector zone and gas detector zone will be
triggered even if they are disabled.
•Arming mode sengs should be congured with the sengs of arming
status on the user page of the device.
2.3 Password Sengs
You can edit the duress code, unlock password and arm/disarm password of the
indoor staon.
You can edit the arm/disarm password of the indoor extension.
Video Intercom 9 Series Indoor Staon Conguraon Guide
8

Steps
1. Tap Sengs → → Password to enter the password sengs page.
Figure 2-9 Password Sengs
2. Tap Unlock Password, Arm/Disarm, or Duress Code to pop up the password
sengs dialog box.
Unlock Password
Enter the unlock password and room No. on the door staon to open the
door.
Arm/Disarm
Create an arm/disarm password before conguring alarm parameters.
Arm or disarm the zone for the indoor staon by entering the arm/disarm
password.
Note
Arm/Disarm sengs page is hidden by default. Tap Sengs → →
Shortcut Sengs to enable Zone Alarm Locally, you can edit the alarm
parameters.
Duress Code
When you are hijacked and forced to open the door, you can enter the
duress code. An alarm will be triggered to nofy the management center
secretly.
Note
The duress code and the unlock password cannot be the same.
3. Enter the old password.
Video Intercom 9 Series Indoor Staon Conguraon Guide
9

4. Create a new password and conrm it.
5. Tap OK to save the sengs.
Note
Indoor Extension only supports admin password and arm/disarm password.
6. Enable Switch Scene without Password and enter the arm/disarm password.
There is no need to enter the password during scene mode switching.
2.4 Synchronize Time
Steps
1. Tap Sengs → → Time to enter the me sengs page.
2. Synchronize the system me.
-Congure the Date Format, Time Format, Date Sengs and Time manually.
-Tap Sync Time to enable NTP.
Figure 2-10 Sync Time
Set the synchronizing interval, enter the IP address/domain of NTP server
and port No., and select the me zone.
Note
The default unit of synchronizing interval is minute.
2.5 Sound Sengs
Video Intercom 9 Series Indoor Staon Conguraon Guide
10

You can set the ringtone, ring duraon, call forwarding me, volume of microphone
and loudspeaker and enable/disable touch sound on call sengs page.
Steps
1. Tap Sengs → to enter the call sengs page.
Figure 2-11 Call Sengs
2. Set corresponding parameters.
Ringtone
There are 3 ringtones by default, and you can custom and import at most 4
ringtones via Batch Conguraon Tool or iVMS-4200 Client Soware.
Ringtone Duraon: The maximum duraon of indoor staon when it is called
without being accepted. Ringtone duraon ranges from 30 s to 60 s.
Call Forwarding
The ring duraon limit beyond which the call is automacally forwarded to
the mobile phone designated by the resident. Call forwarding ranges from 0
s to 20 s.
Volume Sengs
Adjust the prompt sound volume, call volume and touch sound.
Note
Indoor Extension does not support the ring duraon sengs, or call forwarding
sengs.
2.6 Restore Indoor Staon
Video Intercom 9 Series Indoor Staon Conguraon Guide
11
