Quick Installation Guide
IP Phone
V1.1
- 4 -
Call forward
1．Press Menu > Features > Call Forward.
2．Select the line, the type of forward, enter the destination
number and status and OK.
Call Mute
1. Press to Mute the microphone during the call.
2. Press again to un-mute the conversation.
Call list
1. Press key or Menu > CallLog > Local Call Logs
2. Scroll through the list using
3. To dial an entry, press Dial soft key or pickup handset or
press or .
Call transfer
Attended transfer:
Blind transfer:
1. Press key or Xfer soft key during the active conversation,
the call is put on hold.
2. Dial the second telephone number.
1. Press key or Xfer soft key during the active conversation,
the call will be on hold.
2. Then enter the 2nd telephone number and press key
or Xfer soft key.
3. When the call is answered, then press key or Xfer soft
key to complete the operation.
P/N:CJBA100136B0
Programmable keys
1．You can configure shortcuts for the programmable keys.
2．Press Menu > Basic > Keyboard, select among the
configurable items, and select your desired type and value,
press OK key.
Do not disturb
1. Press DND soft key, and enable the device do not disturb
mode.
2．Or press Menu > Features > DND, and select the Mode and
Type, and press Save soft key.
Redial
1. Press key, redial a call number.
Voice mail
1. To access your voice mailbox, press or Menu >
Message > Voice Message, number of messages will be
indicated if provided by your server or pbx.
2．Select the line and press Play to call.
Putting a call on hold
1. Press key or Hold soft key, caller is put on hold.
2. To retrieve the call press key or Resume soft key.
Note: with more than one active call, select desired call with
the navigator keys and use the corresponding soft key to
hold or resume.
3-party conference
1. Once in line with 1st caller, press key or Conf soft key,
1st caller is put on hold.
2. Then call the 2nd number.
3. After, 2nd call is established, press key or Conf soft key to
set up the conference.
Phonebook
Access phonebook:
Add new entry:
1. Press or Contact soft key or Menu > PhoneBook
> Local Contacts.
1. Press Contact soft key, Press All Contacts or other group
> Press Add.
2. Enter name and number and press OK soft key.
2. Select All Contacts or other group.
3. To dial an entry, press Dial soft key or pickup handset or
press or .

Screen icon
In hands-free mode
In headset mode
In handset mode
Mute activated
Silent mode
Packaging list
Soft keys
Message waiting indicator
Left and right navigation keys
Up navigation key, Shortcut
to call log
Down navigation key, Shortcut to
Status OK key, Shortcut to Menu
Hold key, Hold/Resume the call
Keys features
IP Phone Handset
Handset Cord
Stand Power Adapter
(Optional)
Ethernet Cable Quick Installation Guide
- 2 - - 3 -
Wall Stand
(Buy separately)
In idle mode: activate/deactivate
silent mode
In communication mode:
mute/un-mute a call
In idle mode or during ringing:
increase or decrease ringer volume
In communication: increase or
decrease handset, headset or
hands-free volume
Hand-free key, activate/deactivate
hands free
Long press to lock keypad.
Enter PIN to unlock keypad (default 123)
Call is on hold
Internet connected
Internet is disconnected
X
No IP address
!
Auto-answering
activated
Installation the device
Please follow the instructions in below picture to install the
device.
Bracket desktop installation
Wall mounting (wall stand need buy separately)
Connecting to the device
Please connect power adapter, network, PC, handset, and
headset to the corresponding ports as described in below
picture.
① Power port: connect the power adapter.
② Network port: connecting local area network or Internet.
③ PC port: the network port connect to the computer.
④ Headset port: connect headset.
⑤ Handset port: connect IP Phone handset.
5V
Internet PC Headset
Handset
VLAN activated
Disable do not
disturb (Blue)
Call forward activated
SIP Hotspot activated
Do not disturb
activated (Red) Keypad locked
Forward call(s)
New VM messages
Voice quality level
of call
VPN activated
New SMS
SMS
Call transfer key
Conference key
Call logs key
Phonebook key
Voice messages key
Headset key,
activate/deactivate headset
Status key
Redial key, access to redial
the last record
Configuration via web
1. Get the IP address from the phone: Press key, or Menu
> Status > IPv4 / IPv6.
2. Login: Input the IP address in the web browser. The PC and
phone should be in the same IP address segment(The default
username and password are both ‘admin’.)
3. Configure: Select network/account etc, and fill the
relevant content.
4. Save the configuration.
Language setting
1. Press Menu key > Basic > Language.
2. Select the desired language and press OK soft key.
Making a call
Accepting a call
1. Pre-dialing: enter the phone number and pick up the handset.
2. Direct dialing: lift the handset and enter the phone number.
3. Handsfree: enter phone number and press or vice versa.
4. Headset: enter phone number and press or vice versa.
1. Using the handset: pick up the handset.
2. Using the headset: press .
3. Using the handsfree: press .
Configuration
Configuration via LCD menu of phone
1．Press Menu > Advanced (default password 123).
2．Select Network: To configure the Network Settings
(IPv4/IPv6/IPv4&IPv6, DHCP/Static/PPPoE)
3．Select Accounts: To configure enable the account, fill the
SIP server address, port, user name, password etc .
5. Designated line: press line key, enter phone number and
press dial key.
Line keys
Received call(s)
Dialed call(s)
Missed call(s)
Wireless network
connected
Wireless network
disconnected
Wireless network failure
Network connect
Using Ethernet
1．The power on the device and connect the WAN port of the
phone to the RJ45 socket of a hub/switch or a router
(LAN side of the router) using the Ethernet cable.
2．The default is DHCP mode.
Using WiFi
1．The power on the device and make sure the phone is idle.
2．Press Menu > Basic > WLAN, Enabled the WiFi Feature.
3．Press scan to search for currently available wireless network.
4．Enter the available network and select the WiFi you want to
connect.
5．Press connect soft key and enter the appropriate password
to connect to the WiFi. The default is DHCP mode.
