Hillrom 900 Series User manual

*171051* ENEN
Hillrom™ 900 Bed
Instructions for Use
LI900B2 and LI900B3
171051 Rev. 12

171051(12) - Hillrom™ 900 Bed - Instructions for Use
Hill-Rom S.A.S. 
Z.I. du Talhouët
56330 PLUVIGNER - FRANCE
Tel: + 33 (0)2 97 50 92 12
Fax: + 33 (0)2 97 50 92 03
hillrom.com
Edition 12: September 2020
First printing 2012
The information contained in this manual is confidential and may not be
reproduced or divulged in any form or by any means without the prior written
permission of Hill-Rom.
ClinActiv®  and Navicare® are registered trademarks of Hill-Rom Services,
Inc.
Duo® is aregistered trademark of Hill-Rom Industries SA.
Hillrom™, Hillrom™ 900, Accella™, Primo™ and AutoContour™ are
trademarks of Hill-Rom Services, Inc.
MCM™ is a trademark of Hill-Rom SARL.
Sabina™, Viking™, Golvo™ and LowBase™ are trademarks of Liko R&D AB.
Hill-Rom reserves the right to make changes to the design, characteristics and
models without prior notice. The only warranty Hill-Rom makes is the express
written warranty extended on the sale or rental of its products.
To order copies of this manual, contact your national Hill-Rom representative or
go to hillrom.com and order the article with the part number 171051.
© 2020 by Hill-Rom Services, Inc. ALL RIGHTS RESERVED.

Introduction
Specifications
Installing the patient Mobilizing the patient Securing the patient Help with care Moving the bed Decontamination,
Maintenance
171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page i
Table of Contents
Introduction, specifications
The structure of the Instructions fo Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Symbol definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Bed model and country of use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety and Usage Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Contraindications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Intended Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
First use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Risk prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
General precautions for the place of use . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Precautions for transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Technical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
General Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Function Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Installing the patient
Before placing the patient on the bed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Accessories and peripheral equipments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Mattress** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Recommended accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Recommended additional parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Recommended traction frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Recommended patient lifts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Recommended bed dining tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Endboards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Installing the endboards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Endboard fastening system* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Bed frame extension*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Wall stop AD277A* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Mobilizing the patient
Electrical Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Control pendants* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Caregiver half-siderail* controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Patient half-siderail* controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Bilateral HiLow pedal with caregiver mode*. . . . . . . . . . . . . . . . . . . . . . . 34
Foot control pendant*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Control unit on a flexible arm* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Raising/lowering the sleep surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Page ii 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use
Raising/lowering the head and thigh sections . . . . . . . . . . . . . . . . . . . . . 36
Trendelenburg/Reverse Trendelenburg* . . . . . . . . . . . . . . . . . . . . . . . . . 37
Chair position* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Place sleep surface flat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Bed exit aid*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Mechanical adjustable foot section*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Patient helpers** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Egress handles*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Patient position monitor half-siderail control*. . . . . . . . . . . . . . . . . . . . . . 45
NaviCare® system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Communication cable** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Securing the patient
Siderails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
AD271B* siderails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Removing the long siderails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Installing the the long siderails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Half-siderails*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Siderail safety net (AD312A)**. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Space Filler panel (AD288A)**. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Fittings for the restraining strap handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Electrical function management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Bed not in lowered position indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Night light* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Equipotential terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Equipotential cable (AC968A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Nurse call* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
CPR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Help with care
Fixed IV pole (AD294A)** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Telescopic IV pole (AD298A-AD299A) . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Linen holder* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Drainage bag holder pins. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Oxygen Cylinder Holder (AC959A-AD101A-AD102A). . . . . . . . . . . . . . . 64
Pivoting 3L Bottle Holder (AC962A)** . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Monitor stand (AD244B) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Syringe-driver holder (AC963A). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Line manager & support (AD286A)** . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
X-ray-transparent adjustable head section (AD242A)**. . . . . . . . . . . . . . 68
Chrome-plated IV hook (AC953A)** . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Label holder (AD325A)** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Movement/Transfer
Brake and steer system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Securing the power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Introduction
Specifications
Installing the patient Mobilizing the patient Securing the patient Help with care Moving the bed Decontamination,
Maintenance
171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page iii
Removable frame (AD270B) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Decontamination, Maintenance
Decontamination of the bed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Safety recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Recommendations for cleaning and disinfection . . . . . . . . . . . . . . . . . . . 75
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Safety recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Preventive maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
De-commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Appendix
Warranty and after sales service conditions . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Electromagnetic conformance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Complies with electromagnetic emission standards . . . . . . . . . . . . . . . . 82
Compliance with electromagnetic immunity. . . . . . . . . . . . . . . . . . . . . . . 84
Recommended separation distances. . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Page iv 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use

171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page 1
Introduction
Specifications
Introduction, specifications
The structure of the Instructions fo Use
PATIENT
CAREGIVER
EASE OF USE
INDEPENDENCE
WELL BEING
COMFORT
SAFETY
INSTALLATION
MOBILIZATION
HELP WITH
CARE
MOVEMENT
For every type of use, Hillrom™ beds provide patients with optimal comfort and
greater independence for a feeling of well-being that is conducive to a swift
recovery. They are also easy to use for caregivers.

Page 2 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use
Symbol definitions
This manual contains different typefaces and icons designed to improve readability
and increase understanding of its content. Note the following examples:
• standard text - normal character style used for “basic” information.
•Boldface text- emphasizes a word or phrase.
• highlights special information or explains very important instructions,
• The symbols below represent different risks or hazards:
Symbol Description
Warning
• This symbol indicates that the failure to follow the
associated recommendation can put the patient or
the user in danger, or damage the equipment.
Caution
• This symbol indicates that the failure to follow the
associated recommendation can result in damage
to the equipment.
Tip
Risk of falling
Caught hazard warning
Risk of crushing an upper limb
Chemical Hazard Warning
Electric Shock Hazard

171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page 3
Introduction
Specifications
Bed model and country of use
Certain bed features or accessories may be available or not, depending on the
destination country. These features are identified with an asterisk (*) and the
accessories or the additional parts are identified by two asterisks (**).
To identify your bed model, its serial number SN (HRPXXXXXXXXX), its UDI and
its date of manufacture, refer to the identification label (see “Overview” page 14).
Your LI900BX bed is made up of a chassis/sleep surface, with a REF reference
starting with CS900B2 or CS900B3 and two endboards (a headboard and a
footboard).
• REF: CS900B2XXXXXX or CS900B3XXXXXX: CS900 = Hillrom™ 900 ; B =
Version; 2XXXXXX or 3XXXXXX = unique 7-figure numerical code according
to different criteria, such as the voltage, the electrical functions, the language,
etc.
• SN: HRPXXXXXXXXX: HRP = Hill-Rom Pluvigner; XXXXXXXXX =
incremental code.
• UDI; Unique Device Identification.
Safety and Usage Tips
Intended Use
The Hillrom™ 900 medical beds with emergency Trendelenburg / Reverse
Trendelenburg are beds for intensive care for adult patients (the emergency
Trendelenburg function remains operational in the event of a power cut: SHOCK)
(EN60601-2-52 application environment 1). They are designed for use in intensive
care wards and also in general care and surgery care wards and allow the use of
advanced techniques used in specialist units.They are designed with the needs of
the whole medical team in mind and the benefits are to facilitate the use of
monitoring equipment and the transfer of patients to examination wards.
The Hillrom™ 900 beds with electric comfort Trendelenburg / Reverse
Trendelenburg or without Trendelenburg / Reverse Trendelenburg are variable-
height beds designed for acute, general and ambulatory care or care during long
hospital stays for
adult patients ( EN 60601-2-52, application environments 2, 3
and 5). They are designed with the needs of the whole medical team in mind and
the benefits are to facilitate the use of monitoring equipment and the transfer of
patients to examination wards, etc.

Page 4 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use
Contraindications
• children (aged less than 12 or under 1.46 m tall),
• persons measuring more than 1.85m in height,
• persons with BMI below 17,
• persons weighing less than 40 kg,
Features
The Hillrom™ 900 LI900B2 beds:
• can be fitted with batteries providing protection against power outages as an
option.
• fitted with Ø 150mm casters can be used to transfer patients.
The Hillrom™ 900 LI900B3 beds:
• are equipped with batteries providing protection against power outages.
• fitted with Ø 125 mm double-band casters or Ø 150 mm casters can be used
to transfer patients.
• are equipped with a patient position detection system.
• can be equipped with a nurse call function*.
Intended Users
The Hillrom™ 900 beds are designed to be used by Qualified Staff. Patients and
Visitors can also use the Hillrom™ 900 medical beds depending on authorization
given by Qualified Staff.
First use
Before using the bed, it is essential to have a thorough understanding of this
manual. This manual contains instructions for general use and maintenance and
guarantees improved safety. Caregivers must have access to this manual.
Training can be provided on demand.
Caregivers must be informed of the risks that may be encountered in the use of
electric beds.
The many sources and types of accessories, hardware, or medical devices that
may be used together with this bed do not enable Hill-Rom to guarantee both the
safety and conformity of all the combinations thus created. The operator who
creates these device combinations must therefore ensure that security and
conformity requirements are met.

171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page 5
Introduction
Specifications
Use of accessories, transducers and cables other than those specified or provided by
Hill-Rom could result in increased electromagnetic emissions or decreased
electromagnetic immunity of this equipment and result in improper operation.
Waste packaging (plastic, cardboard, metal, wood, etc.) must follow suitable
recovery circuits with a view to being recycled.
Before installing the bed for the first time or after bringing the bed and its
accessories out of storage:
• ensure that the bed and its various parts are at room temperature,
• only connect the bed to a mains electric power supply with earth protection
(see “Electrical safety” page 8),
• the power plug must be accessible to disconnect the bed,
• wait 12 hours until the battery is fully charged before using the bed without
the mains power supply,
• make sure that all the moving parts are in good working order,
• make sure that the bed has been cleaned and disinfected (see
“Decontamination of the bed” page 75).
Risk prevention
General recommendations
In general:
• check that nothing (e.g. objects, accessories or power cable) or any persons
(e.g. children, limbs) will interfere with the movement of the mobile parts of
the bed before actuating them. An intermittent beep sounds when one of the
bed’s movements is hindered.
• during a movement or combination of movements of a mobile part of the bed
(eg, backrest, sleep surface, siderail), be vigilant (for oneself, the patient or
any other person) on the risks of pinching or crushing between moving parts
or with a fixed part.
• always check (e.g. to and fro movements) that the various locking
mechanisms are in good working order (e.g. siderails, extensions, grip
handles, brakes).
• sufficiently qualified nursing staff determine the usage condition suitable for
the various functions and the degree of supervision to ensure that the patient
uses the bed safely.

Page 6 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use
When the patient is left unattended:
•apply the brakes to prevent any risks of falling, especially if the patient leans
on the bed when getting in or out,
• leave the sleep surface in the lowest position to avoid serious consequences in
the event of falling,
• use the siderails to secure the patient and reduce the risk of falling
accidentally,
• lock any function that, if misused, could worsen existing injuries or
pathologies, or even result in bodily injury,
• never leave the bed in the Trendelenburg position.
Never modify the bed without Hill-Rom's prior written consent. Alterations could
result in injury to the patient or damage to the bed.
Only use manufacturer's parts and accessories.
Never place objects or equipment on the chassis or use it to support a person.
Do not use of the bed with loads in excess of the safe working load.
Notice to Users and/or Patients:

Any serious incident that has occurred in relation to the device, should be reported
to the manufacturer and the Competent Authority of the Member State in which the
user and/or patient is established.
Recommendations for the siderails
In the case of patients suffering from particular behavioral difficulties (e.g.,
agitation, mental confusion, loss of sense of direction, obsessive behavior, old
patients, weakness, etc.), properly trained medical staff should ascertain how the
siderails should be used (irrespective of the model or type), whether the patient
should be monitored closely or immobilized and whether the patient helpers should
be left in position, in order to ensure that patients use the bed in complete safety.
Certain national health authorities have issued guidelines risks to patients and the
reduction of these hazards, as indicated below.
It is recommended that patients at risk be identified in each establishment or ward
so that the safety measures most appropriate to their particular needs can be
implemented.
One measure which has already proved effective is to draw up a protocol
specifying:
1. situations and conditions for siderail use and authorized mattress type or
model,
2. for all patient monitoring procedures, both for restrained and unrestrained
patients, including during intervals,
3. circumstances under which patients must be restrained according to the
instructions and recommendations of the manufacturer of the said
restraining devices.

171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page 7
Introduction
Specifications
The siderails are designed to help reduce the risk of patients falling out of bed
accidentally. They are not designed to restrain or immobilize the patient. Restraining
straps or other devices must not be fastened to the half-length siderails (e.g., straps).
Recommendations for the mattresses
Hill-Rom shall not be held liable for any problems occurring if the mattress used is
not included in the list of equipment recommended by Hill-Rom (see “References
of recommended mattresses” page 27).
Despite the protective height above the mattress and the top of the siderail,
patients can still potentially fall or become trapped in the spaces around the
mattress.
Use of a mattress thicker than the thickness recommended in “References of
recommended mattresses” page 27 may reduce the effectiveness of the siderails.
Thicker mattresses can increase the risk of falling and shorter or narrower
mattresses can increase the risk of patients becoming trapped. In such cases, the
patient must be monitored closely.
As assessed by the “Hospital Bed Safety Workgroup” guide and the standard EN
60601-2-52, the mattress label on page 25
lists the mattresses recommended for
use on the Hillrom™ 900 to offer the safest conditions. The therapeutic benefits of
the other therapeutic mattresses listed in page 25 outweigh the residual risk of
entrapment or fall incurred by their use.
Other mattresses may be used, but the manufacturer must always be consulted to
make sure that the bed/mattress/siderail combination does not affect the bed's
performance, its suitability for use or its safety characteristics.
If the bed is fitted with an electrically powered air mattress, the power cord must be
routed so as to prevent it from being cut by the moving parts of the bed (refer to the
instructions of the mattress).
Users must check the compatibility of the patient's weight and the accessories placed
on the bed and the mattress system in view of the specifications of the medical bed and
the mattress system.
If the mattress power cord is unplugged, it is advisable to store it on the support
provided by the mattress supplier.
Recommendations for the function lockouts
The electrical function management control prevents any unintended bed
movements that might cause injury to the patient.
For safety reasons, it is advisable to use the lock-out functions when treating the
patient or working on the bed (e.g., examinations, transfers, maintenance), when
the patient is left unattended and when caregivers believe that the patient is not in
a fit state of health to operate the controls in safety.

Page 8 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use
It is thus the responsibility of the nursing staff to authorize the patient to use certain
bed functions, including the HiLow.
The "Shock"*, Trendelenburg, Reverse Trendelenburg, chair* and return to flat*
functions must only be accessible to caregivers.
Electrical safety
When direct intravascular or intracardiac connections are in use, the electric
potentials of all the unprotected metal parts need to be equalized. The bed must be
connected to a mains electric power supply with earth protection.
In an environment where the electrostatic discharges are prevalent, we recommend
using an antistatic caster.
The mains power supply for the bed must comply with relevant standards:
• NF C 15-100 and NF C 15-211 (France),
• International Electrotechnical Commission (IEC) 364 for other locations.
Check that the bed’s power requirements on the identification label (see “Electrical
characteristics” page 13) correspond to the power supply voltage of the hospital.
The power supply should be equipped with a maximum 30 mA earth
leakage circuit breaker, in compliance with IEC 364-5-53.
All the parts of the bed that are within the patient's reach, even if they are under
the frame, are applied parts.
If the integrity of the protective conductor is in doubt, the beds fitted with batteries
must be used in battery mode.
In compliance with standards relating to electromagnetic interference for medical
equipment, this product does not interfere with other medical devices or is not
susceptible to interference when combined with other medical devices that also
comply with the electromagnetic standards in force.
Some devices, particularly older ones that do not comply with the electromagnetic
compatibility standards, may however undergo interference or may themselves
interfere with the working of this product.
The users of such devices are responsible for ensuring that any malfunctions will
not endanger the patient or any other person.
Use of this equipment adjacent to or stacked with other equipment should be avoided
because it could result in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that they are operating
normally.
Ensure that the power cord is unplugged and hooked to the bed before moving the
bed (see “Securing the power cable” page 74).
Only duly qualified and authorized staff should carry out electrical maintenance.

171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page 9
Introduction
Specifications
Never clean or service the bed without unplugging it from the mains power supply
and disconnecting the battery.
The battery backup must never be left in direct contact with fire, placed in liquid, or
discarded in a refuse bin. In the event of the battery being damaged, see “De-
commissioning” page 80.
This label indicates that the bed must never be used with an
oxygen tent or in explosive atmospheres (presence of
inflammable gases or vapors)
. Use only nasal tubes and oxygen
masks. For reasons of safety, masks and tubes should always be
kept at a higher level than the sleep surface.
Always lock out the HiLow function before any cleaning or
maintenance operations.
If the bed is equipped with a battery, and the bed is stored for long periods of time, the
battery must be charged every 3 months. Failure to do so could result in damage to the
battery.
If a continuous alarm sounds when activating a movement, the battery needs to
be recharged.
General precautions for the place of use
It is advisable not to use the bed under the following conditions:
- in hospital wards other than the intended ward (see “Intended Use” page
3),
- climatic conditions outside the corresponding ranges recommended by
Hill-Rom,
- in hyperbaric chambers,
- in explosive atmospheres,
- in the presence of flammable gases or vapors,
- with oxygen tent type respiration devices or devices that extend below
the sleep surface,
- outdoors or to transport a patient in a vehicle,
- moving the bed over soft ground or inappropriate surfaces,
- moving the bed along slopes of over 10° (with or without a patient).
Service temperature 10° and +40°
Service humidity 30% - 85%
Working atmospheric pressure 700 hPa to 1,060 hPa
Climatic restrictions

Page 10 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use
Precautions for transport and storage
The following conditions must be met to ensure that the bed and its accessories
are shipped and stored in complete safety.
During shipmenta, the bed must be:
a. Transport does not include the transfer of the bed between wards with or without patients.
Climatic restrictions on transport and storage
When stored, the bed must be:
- in the lowered position
- all functions locked out
- covered, brakes applied and all
moving parts secured
- protected from fluid ingress
- in the lowered position
- all functions locked out
- covered, brakes applied
- protected from fluid ingress
Transport/storage temperature -30° and +50°
Transport/storage hygrometry 20% - 85%
Transport/storage atmospheric pressure 700 hPa to 1,060 hPa
During shipment or storage, beds should not be stacked one on top the other.

171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page 11
Introduction
Specifications
Technical specifications
Hill-Rom has an ongoing continuous improvement policy. Therefore
specifications are liable to be altered without notice.
LI900B2 with long siderails
Features Value
Maximum width (W) 995 mma/1010 mmc
Maximum length (without extension) (L) 2158 mma
Maximum length (with extension closed) (L) 2158 mma
Maximum length (with extension open) (L+) 2358 mma
Length of long siderail protection (B) 1421 mmb/1397 mmc
Long siderail protection height (without mattress) (S) 385 mmab/380 mmc
Length of the head half-siderail protection (B1) 499 mma
Length of the foot half-siderail protection (B2) 631 mma
Long siderail protection height (without mattress) (S1) 393 mma
Low position (double-band 125d diameter casterse) (h) 386 mmaf
Low position (125 diameter castersdg) (h) 377 mmah/419 mmaf
Low position (double band 150d diameter casterse) (h) 389 mmah/431 mmaf
L
L+
B
W
65° 28°
S
H
hC
B1 B2
S1
LI900B2/LI900B3/LI900B2 with half-siderails

Page 12 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use
Low position (150 diameter castersde) (h) 397 mmah/439 mmaf
High position (double-band 125 diameter castersde) (h) 755 mmaf
High position (125 diameter castersdg) (H) 748 mmah/788 mmaf
High position (double band 150 diameter castersde) (H) 760 mmah/800 mmaf
High position (150 diameter castersde) (H) 768 mmah/808 mmaf
Chassis clearance (double-band 125 diameter castersde) (C) 150 mma
Chassis clearance (125 diameter castersdg) (C) 183 mma
Chassis clearance (double band 150 diameter castersde) (C) 195 mma
Chassis clearance (150 diameter castersde) (C) 203 mma
Head sectioni incline + 65°
Thigh sectioni incline* + 28 °
Foot sectioni incline* - 3° to -22°
Trendelenburg/Reverse Trendelenburg + 17°/- 17°
Emergency Trendelenburg (“Shock”)hi - 12 °/30 sec
Maximum patient weight for the SWL version: 220 kg 155-185 kgj
Maximum patient weight for the SWL version: 250 kg* 185-215 kgk
Bed weight LI900B2l (no mattress or accessories) 144 kg
Bed weight LI900B2 (no mattress or accessories) 120 kg
Bed weight LI900B3 (no mattress or accessories) 170 kg
Maximum temperature of applied parts at 40° C 56,5° C
Unweighted peak acoustic pressure levels <120 dB
Maximum measured level of weighted acoustic pressure 42 dBA
a. These are average values, which may vary according to manufacturing tolerances..
b. Bed fitted with AD271B siderails
c. Bed fitted with AD272B siderails
d. Dimensions in mm.
e. An antistatic version is also available.
f. LI900B3 model
g. Incompatible with the CFS 250 kg version, LI900B2 with half-siderail.
h. LI900B2 model
i. Maximum incline in relation to the sleep surface
j. SWL 220 kg / the maximum patient weight varies according to the mattress and accessories
used
- 155 kg as per EN60601-2-52 (acute care or intensive care)
- 185 kg as per EN60601-2-52 (other environments).
k. SWL 250 kg / the maximum patient weight varies according to the mattress and accessories
used
- 185 kg as per EN60601-2-52 (acute care)
- 215 kg as per EN60601-2-52 (other environments).
l. LI900B2 models with half-siderails
Features Value

171051(12) - Hillrom™ 900 Electric Bed Instructions for Use Page 13
Introduction
Specifications
Electrical characteristics
Characteristic 100V* 120V* 230V*
Voltage 100V AC 120V AC 230V AC
Frequency 50/60 Hz 50/60 Hz 50/60 Hz
Power supply unit maximum power load 300 VA 300 VA 300 VA
Power supply unit fuse rating 2 x 2.5 A T 2 x 2.0 A T 2 x 1.25 A T
Electric shock protection Class I
Class according to IEC 60601-1 Type B
Protection against harmful ingress of
water (according to IEC 60529)
IPX4
Duty cycle 10% (2min/18min)a
a. Do not operate electrical functions continuously for more than 2 minutes in any 18 minute
period when the bed is loaded at the safe working load value as this may damage electrical
components. The power supply of the actuator is temporarily cut off if the load factor is
exceeded when using the HiLow.
Conditions required to connect the nurse call system
For more information about the connections required to use the nurse call
function, please refer to the SideCom® Communication System Design and
Application Manual (DS059).

Page 14 171051(12) - Hillrom™ 900 Electric Bed Instructions for Use
Overview
LI900B2 long siderails
Item Name Item Name
AEgress handlea
a. Equipment varies depending on bed model
LElectric emergency
Trendelenburg (Shock)ab
b. Incompatible with the 250 kg SWL version
BRemovable metal siderailsaM150 mm diameter single band
castersa
CHeadboard NFootboard
D Control pendantaOBumper (4)
E 2 sockets for I.V. pole and
patient helper
PExtension + linen holdera
FHRP and identification label QBilateral HiLow pedal with
caregiver modea
GHead section “CPR” control RCentral brake and steer bar
control
HHead section angle indicator SFoot control pendanta
JNight lightaTControl unit on a flexible arma
KLateral caregiver unitaUMaintenance indicatora
A
BC
E
M
R
O
N
JK
L
D
P
T
F
U
Q
S
G
H
