ORIGINAL OPERATING INSTRUCTIONS
SD 4500‑A18 drywall screwdriver
It is essential that the operating instructions
are read before the power tool is operated for
the first time.
Always keep these operating instructions to-
gether with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents Page
1 General information 1
2Description 2
3 Insert tools, accessories 4
4 Technical data 4
5 Spare parts 5
6 Safety instructions 5
7Beforeuse 7
8 Operation 8
9 Care and maintenance 10
10 Troubleshooting 10
11 Disposal 11
12 Manufacturer’s warranty - tools 12
1These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the designation “power
tool” always refers to the SD 4500‑A18 drywall screw-
driver.
Parts, operating controls and indicators 1
@Control switch (with electronic speed control)
;Forward / reverse switch
=Lockbutton for sustained operation
%Depth gauge
&Power tool / accessory interface (click connection)
(Chuck (bit holder)
)Bit holder
+Air exit
§Belt hook
/Grip
:Battery release buttons
·Motor cooling air intake
$Universal hook
1 General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
seriousbodilyinjuryorfatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
Warning:
electricity
Warning:
caustic
substances
Obligation signs
Wear eye
protection
Wear
protective
gloves
en
1
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

Symbols
Read the
operating
instructions
before use
Return waste
material for
recycling.
Volts Direct
current
Rated speed
under no
load
Revolutions
per minute
Revolutions
per minute
Diameter
Location of identification data on the power tool
The type designation and serial number can be found
on the type identification plate on the machine or tool.
Makeanoteofthisdatainyouroperatinginstructions
and always refer to it when making an enquiry to your
Hilti representative or service department.
Type:
Generation: 01
Serial no.:
2 Description
2.1 Use of the product as directed
The SD 4500-A18 is a hand-held cordless drywall screwdriver with automaticclutch.
Drywall screws with a length of up to 55 mm and a diameter of up to 4.2 mm can be used.
Do not use other types of screws intended for heavy-duty applications.
For optimum handling, we recommend that the power tool is gripped in line with the motor.
The air required for motor cooling is drawn in through the ventilation slots and blown out of the tool through the air
exit.
The power tool is suitable for use by right or left-handed persons.
An ergonomically designed grip with synthetic rubber covering provides a comfortable, secure hold and makes the
power tool less tiring to use.
The power tool is designed for professional use and may be operated, serviced and maintained only by trained,
authorized personnel. This personnel must be informed of any special hazards that may be encountered. The power
tool and its ancillary equipment may present hazards when used incorrectlybyuntrainedpersonnelorwhenusednot
as directed.
Observe the information printed in the operating instructions concerning operation, care and maintenance.
To avoid the risk of injury, use only genuine Hilti accessories and insert tools.
Do not use the battery as a power source for other unspecified appliances.
Working on materials hazardous to the health (e.g. asbestos) is not permissible.
Nationally applicable industrial safety regulations must be observed.
Do not use the power tool where there is a risk of fire or explosion.
Modification of the power tool or tampering with its parts is not permissible.
The working environment may be as follows: construction site, workshop, renovation, conversion or new construction.
2.2 Main applications
Application Screw type
Drywall board to metal track (framing) ≦ 0.88 mm / 20 ga Drywall screw with needle point,
type S‑DS01
Drywall board to metal track (framing) ≦ 2.25 mm / 16 - 25 ga Drywall screw with drill point, type S‑DD01
Metal track to metal track (max. thickness of part fastened 2.5 mm
/13-12ga)
Drywall screws with drill point, types
S‑DD02, S‑DD03 and S‑DD08
Fastening drywall board to timber Drywall screw with needle point,
type S‑DS03
Gypsum fiber board to metal track (≦0.88 mm / 20 ga) and timber
framing
Drywall screws with needle point, types
S‑DS14 and S‑DS10
en
2
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

NOTE
The power tool can also be used together with the SMD 57 magazine and the appropriate collated screws for the
applications listed above. Please observe the operating instructions for the applicable drywall screw magazine.
2.3 Chuck
¼" bit holder
2.4 Switches
Control switch for smooth speed control
Lockbutton for sustained operation
Forward / reverse switch
2.5 Lubrication
Grease lubrication
2.6 Grips
Vibration-absorbing grip (in-line grip)
2.7 The items supplied include (toolbox versions):
1 Power tool
1Depthgauge
1Bit
1 Bit holder
2B18/2.6Li‑ionbattery
1 Charger for Li-ion batteries
2 Operating instructions
2.8 The items supplied include (cardboard box versions):
1 Power tool
1Depthgauge
1Bit
1 Bit holder
1 Operating instructions
2.9 Li‑ion battery charge status
LEDs light constantly LEDs blink Charge status C
LED 1,2,3,4 -C≧75%
LED 1,2,3 -50 % ≦ C < 75 %
LED 1,2 -25 % ≦ C < 50 %
LED 1 -10 % ≦ C < 25 %
-LED 1 C<10%
en
3
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

3 Insert tools, accessories
Designation Short designation Description
Depth gauge S‑DG‑D 11x75 for the 75mm (3") bit
holder
Bit holder S‑BH 75M
Magazine SMD 57
Extension SME extension for working on ceil-
ings
Charger for Li-ion batteries C 4/36
Charger for Li-ion batteries C 4/36‑ACS
Charger for Li-ion batteries C 4/36-ACS TPS
Charger for Li-ion batteries C 4/36‑90
Charger for Li-ion batteries C 4/36‑350
Battery B 18/3.3 Li‑Ion
Battery B 18/2.6 Li‑ion
Battery B 18/1.6 Li‑Ion
Hilti toolbox
Designation Description
Bit S‑B PH2
4 Technical data
Right of technical changes reserved.
Power tool SD 4500‑A18
Rated voltage 21.6 V
Weight 2.1 kg (4.63 lb)
Dimensions (L x W x H) 253 mm (9.96") x 99 mm (3.9") x 235 mm (9.25")
Rated speed under no load 0…4,200/min
Max. torque 9.5 Nm (7 lb/ft)
Chuck Hex. socket ¹⁄₄"
Battery B 18/2.6 Li‑Ion B 18/2.6 Li‑Ion B 18/1.6 Li‑Ion
Rated voltage 21.6 V 21.6 V 21.6 V
Capacity 3.3 Ah 2.6 Ah 1.6 Ah
Energy content 71.28 Wh 56.16 Wh 34.56 Wh
Weight 0.78 kg (1.72 lb) 0.78 kg (1.72 lb) 0.48 kg (1.06 lb)
Temperature monitoring Yes Yes Yes
Type of cell Li‑Ion Li‑Ion Li‑Ion
No. of cells 12 12 6
en
4
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

5 Spare parts
Spare parts
Designation Short designation Item number
Depth gauge S-DG-D 11 x 50 406292
Bit holder S‑BH 50M 257257
SD 4500-A18 belt hook SD-A BH 406293
SD 4500-A18 universal hook SD-A UH 406294
6 Safety instructions
6.1 General power tool safety warnings
a)
WARNING
Read all safety warnings and instructions. Failure
to follow the warnings and instructions may result
in electric shock, fire and/or serious injury. Save all
warnings and instructions for future reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
6.1.1Workareasafety
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operat-
ing a power tool. Distractions can cause you to lose
control.
6.1.2 Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Un-
modified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
theriskofelectricshock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
6.1.3 Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off‐position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch
on invites accidents.
d) Remove any adjusting key or wrench before turn-
ing the power tool on. A wrench or a key left at-
tached to a rotating part of the power tool may result
in personal injury.
e) Do not overreach. Keep proper footing and bal-
ance at all times. This enables better control of the
power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
6.1.4 Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
en
5
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions taking into
account the working conditions and the work to
be performed. Use of the power tool for opera-
tions different from those intended could result in a
hazardous situation.
6.1.5 Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
b) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery, avoid contact. If contact acci-
dentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
6.1.6 Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
6.2 Additional safety rules
6.2.1 Personal safety
a) Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring. Fasteners contacting
a "live" wire may make exposed metal parts of the
power tool "live" and could give the operator an
electric shock.
b) It is recommended that ear protectors are worn.
Exposure to noise can cause hearing loss.
c) Keep the power tool, especially its grip surfaces,
clean and free from oil and grease. Do not use
cleaning agents which contain silicone.
d) Improve the blood circulation in your fingers by
relaxing your hands and exercising your fingers
during breaks between working.
e) Avoid touching rotating parts. Switch the power
tool on only after bringing it into position at the
workpiece. Touching rotating parts, especially rotat-
ing insert tools, may lead to injury.
f) Activate the safety lock (forward / reverse switch
in the middle position) before storing or trans-
porting the power tool.
g) Use the right power tool for the job. Do not use
the power tool for purposes for which it was not
intended. Use it only as directed and when in
faultless condition.
h) Avoid unintentional starting. Never carry the
power tool with your finger on the on/off switch.
Remove the battery from the power tool during
work breaks, before carrying out maintenance,
before changing cutting tools and before
transporting the power tool.
i) Check that the belt hook is fitted securely before
beginning work.
j) Do not carry the tool by the depth gauge.The depth
gauge may pull off unexpectedly.
k) Children must be instructed not to play with the
power tool.
l) The power tool is not intended for use by children,
by debilitated persons or those who have received
no instruction or training.
m) WARNING: Some dust created by grinding, sand-
ing, cutting and drilling contains chemicals known
to cause cancer, birth defects, infertility or other
reproductive harm; or serious and permanent res-
piratory or other injury. Some examples of these
chemicals are: lead from lead-based paints, crys-
talline silica from bricks, concrete and other masonry
products and natural stone, arsenic and chromium
from chemically-treated lumber. Your risk from these
exposures varies, depending on how often you do
this type of work. To reduce exposure to these
chemicals, the operator and bystanders should
work in a well-ventilated area, work with ap-
proved safety equipment, such as respiratory pro-
tection appropriate for the type of dust generated,
and designed to filter out microscopic particles
and direct dust away from the face and body.
Avoid prolonged contact with dust. Wear protec-
tive clothing and wash exposed areas with soap
and water. Allowing dust to get into your mouth,
eyes, or to remain on your skin may promote absorp-
tion of harmful chemicals.
n) Check that the power tool is placed in a secure
position when it is laid down, especially when
used with the magazine and / or extension.
en
6
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

6.2.2 Power tool use and care
Checkthattheinserttoolsusedarecompatiblewith
the chuck system and that they are secured in the
chuck correctly.
6.2.3 Electrical safety
Before beginning work, check the working area (e.g.
using a metal detector) to ensure that no concealed
electric cables or gas and water pipes are present.
External metal parts of the power tool may become
live, for example, when an electric cable is damaged
accidentally. This presents a serious risk of electric shock.
6.2.4 Battery tool use and care
a) Do not expose batteries to high temperatures or
fire. This presents a risk of explosion.
b) Do not disassemble, squash or incinerate batter-
ies and do not subject them to temperatures over
80°C. A risk of fire, explosion or injury through con-
tact with caustic substances may otherwise result.
c) Do not use batteries other than those approved
for use with the applicable power tool or appli-
ance. Use of other batteries or use of the battery for
purposes for which it is not intended presents a risk
of fire and explosion.
d) Observe the special instructions applicable to the
transport, storage and use of Li-ion batteries.
e) Avoid short-circuiting the battery. Check that the
terminals on the battery and in the power tool
are free from foreign objects before inserting the
battery in the power tool. Short circuiting the bat-
tery terminals presents a risk of fire, explosion and
chemical burns.
f) Do not charge or continue to use damaged bat-
teries (e.g. batteries with cracks, broken parts,
bent or pushed-in and/or pulled-out contacts).
g) If the battery gets too hot to touch, this may indicate
that it is faulty. Place the tool in a location where
it can be kept under observation, well away from
flammable materials, and allow it to cool down.
Contact Hilti Service after the battery has been
allowedtocool.
6.2.5 Work area
Ensure that the workplace is well ventilated. Exposure
to dust at a poorly ventilated workplace may result in
damage to the health.
6.2.6 Personal protective equipment
The user and any other persons in the vicinity must
wear suitable eye protection, a hard hat, protective
gloves and breathing protection while the power tool
is in use.
7Beforeuse
7.1 Battery use and care
NOTE
Battery performance drops at low temperatures. Never
use the battery until the cells become fully discharged.
Change to the second battery as soon as a drop in per-
formance is noticed. Recharge the battery immediately
so that it is ready for reuse.
Store the battery in a cool, dry place. Never store the
battery where it is exposed to direct sunlight or sources
of heat, e.g. on heaters / radiators or behind a motor
vehicle windscreen. Batteries that have reached the end
of their life must be disposed of safely and correctly to
avoid environmental pollution.
7.2 Charging the battery
DANGER
Use only the Hilti batteries and Hilti chargers listed
under “Accessories”.
7.2.1 Charging a new battery for the first time
A new battery must be charged correctly for the first time
before use. This will ensure that the cells form correctly.
Incorrect initial charging may have a permanent, negative
effect on battery capacity. Please refer to the applicable
battery charger’s operating instructions for information
about initial charging.
en
7
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

7.2.2 Charging a previously used battery
Ensure that the outer surfaces of the battery are clean
and dry before inserting it in the corresponding charger.
Read the operating instructions for the charger for further
information about the charging procedure.
Li-ion batteries are ready for use at any time, even when
only partly charged. Charging progress is indicated by
the LED display (see charger operating instructions).
7.3 Fitting the battery 23
CAUTION
Before fitting the battery, check that the power tool
is switched off and that the safety lock is engaged
(forward/reverse switch in the middle position). Use
only the Hilti batteries approved for use with this
power tool.
CAUTION
Check that the terminals on the battery and in the
power tool are free from foreign objects before in-
serting the battery in the power tool.
1. Push the battery into the power tool from the rear as
far as it will go and until it is heard to engage with a
double click.
2. CAUTION A falling battery may present a risk of
injury to yourself or others.
Check that the battery is seated securely in the
power tool.
7.4 Removing the battery 4
1. Press both battery release buttons.
2. Pull the battery out of the power tool toward the
rear.
7.5 Transport and storage of battery packs
Pull the battery pack out of the locked position (working
position) and move it into the first click-stop position
(transport position).
If you disconnect a battery pack from the power tool
for transport or storage, make sure that the contacts of
the battery pack are not short-circuited. Remove loose
metal parts such as screws, nails, clamps, loose screw
bits, wires or metal swarf from the case, toolbox or
transport container, or prevent these parts from coming
into contact with the battery packs.
Observe national and international transport regulations
when shipping battery packs (transportation by road, rail,
sea or air).
8Operation
CAUTION
Wear protective gloves when changing insert tools as
theinserttoolsgethotduringuse.
CAUTION
Working on the material may cause it to splinter. Wear
eye protection and protective gloves. Wear breathing
protection if no dust removal system is used. Splin-
tering material presents a risk of injury to the eyes and
body.
CAUTION
Check that the accessories used are fitted securely.
8.1 Setting forward or reverse rotation 5
NOTE
The forward / reverse switch is used to select the direction
of rotation of the drive spindle. An interlock prevents
switching while the motor is running. The control switch
is locked when the forward / reverse switch is in the
middle position. Push the forward / reverse switch to the
left(whenthepowertoolisheldintheworkingdirection)
to select forward rotation. Push the forward / reverse
switch to the right (when the power tool is held in the
working direction) to select reverse rotation.
8.2 Changing bits
1. Pull the depth gauge away from the power tool,
releasing the click connection.
2. Pull the bit away from the power tool.
3. Fit the new bit.
4. Refit the depth gauge to the power tool.
8.3 Changing tools (bit holder, magazine bit) 6
NOTE
The chuck features a standardized ¼" hex. socket for
insert tools (bits, bit holder, bits for use with screw
magazines).
1. Pull the depth gauge away from the power tool,
releasing the click connection.
The bit holder is then exposed and can be changed.
2. Push the chuck toward the power tool, turn it slightly
and hold it securely.
3. Use the other hand to remove the bit holder.
en
8
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

8.4 Safe operation 7
WARNING
Do not grip the power tool by the depth gauge or bit
holder. A screw coming into contact with a concealed
electric cable may result in electric shock.
8.5 Switching on / off
The speed of the power tool can be controlled smoothly
(increased from zero to maximum) by pressing the control
switch gradually.
8.6 Power tool overloading and overheating
indicator
NOTE
The power tool is equipped with an electronic protec-
tion system to prevent overloading and overheating. The
power tool switches itself off automatically in the event
of overloading and overheating. After releasing the con-
trol switch, the power tool may not restart immediately
when the switch is pressed again (while the power tool is
cooling down).
8.7 Lockbutton for sustained operation
NOTE
The lockbutton for sustained operation allows the motor
to run continuously without need for constant pressure
on the control switch.
8.7.1 Switching on in sustained operating mode 8
1. Press the control switch fully.
2. While maintaining pressure on the control switch,
press the lockbutton and then release the control
switch.
8.7.2 Switching off after sustained operation
Press the control switch. The lockbutton returns to its
original position.
8.8 Power tool / depth gauge interface 9
1. Pull the depth gauge away from the power tool,
releasing the click connection.
2. Pull the depth gauge forward, away from the power
tool.
With the drive spindle exposed in this way, the
following operations can be carried out: Removing
a previously-driven screw using reverse rotation,
changing the bit holder, changing to magazine op-
eration with the SMD 57 or redriving a screw. Read
the operating instructions for the magazine for infor-
mation about changing to magazine operation.
8.9 Removing a previously-driven screw
1. Remove the depth gauge or the magazine by pulling
it forward, away from the power tool.
2. Set the forward / reverse switch to the reverse
rotation position.
3. The screw can then be removed.
8.10 Reading the charge status LED display on
Li‑ion batteries 
NOTE
The charge status cannot be indicated while the power
tool is in operation. If LED 1 blinks, this simply indicates
that the battery is either fully discharged or too hot for
use (temperature above 80°C).
The Li-ion battery features a charge status LED display.
The charge status is indicated by the LEDs on the battery
during charging (please refer to the operating instructions
forthecharger).Whenthebatteryisatrest(notinuse),its
charge status is indicated by the four LEDs on the battery
for three seconds after pressing one of the battery release
buttons.
8.11 Belt hook 
CAUTION
Check that the belt hook is fitted securely before
beginning work.
The belt hook allows the power tool to be attached to
a belt worn by the operator. The belt hook can also be
fitted to the other side of the power tool for used by
left-handed persons.
1. Pull the battery out of the tool.
2. Fit the mounting plate into the guides provided.
3. Secure the belt hook with the two screws.
8.12 Universal hook
CAUTION
Check that the universal hook is fitted securely. Use
the universal hook only when required. Lay the power
tool down in a secure place when it is no longer in
use.
The universal hook can be used to attach the power tool
to the operator’s belt or to other objects when not in use.
The universal hook can be removed from the power tool
if not required. To do this, release the two screws that
secure the universal hook to the power tool.
en
9
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

9 Care and maintenance
CAUTION
Before beginning cleaning, remove the battery from
the power tool in order to prevent unintentional start-
ing.
9.1Careofinserttools
Clean off dirt and dust deposits adhering to the insert
tools and protect them from corrosion by wiping the
insert tools from time to time with an oil-soaked rag.
9.2 Care of the power tool
CAUTION
Keep the power tool, especially its grip surfaces,
clean and free from oil and grease. Do not use clean-
ing agents which contain silicone.
The outer casing of the power tool is made from impact-
resistant plastic. Sections of the grip are made from a
synthetic rubber material.
Never operate the power tool when the ventilation slots
are blocked. Clean the ventilation slots carefully using
a dry brush. Do not permit foreign objects to enter the
interior of the power tool. Clean the outside of the power
tool at regular intervals with a slightly damp cloth. Do
not use a spray, steam pressure cleaning equipment or
running water for cleaning. This may negatively affect the
electrical safety of the power tool.
9.3 Care of the Li-ion battery
Avoid entrance of moisture.
Charge the battery fully before using it for the first time.
In order to achieve maximum battery life, stop discharging
the battery as soon as a significant drop in performance
is noticed.
NOTE
If use of the power tool continues, further battery dis-
charge will be stopped automatically before the battery
cells suffer damage.
Charge the battery with the Hilti charger approved for use
with Li-ion batteries.
NOTE
- A conditioning charge (as is required with NiCd or
NiMH batteries) is not necessary.
- Interruption of the charging procedure has no negative
effect on battery life.
- Charging can be started at any time with no negative
effect on battery life. There is no memory effect (as
with NiCd or NiMH batteries).
- For best results, batteries should be stored fully
charged in a cool dry place. Avoid charging the battery
in places subject to high ambient temperatures (e.g. at
a window) as this has an adverse effect on battery life
and increases the rate of self-discharge.
- If the battery no longer reaches full charge, it may
have lost capacity due to aging or overstressing. It
is possible to continue working with a battery in this
condition but it should be replaced in good time.
9.4 Maintenance
WARNING
Repairs to the electrical section of the power tool may
be carried out only by trained electrical specialists.
Check all external parts of the power tool for damage
at regular intervals and check that all controls operate
faultlessly. Do not operate the power tool if parts are
damaged or when the controls do not function faultlessly.
If necessary, the power tool should be repaired by Hilti
Service.
9.5 Checking the power tool after care and
maintenance
After carrying out care and maintenance work on the
power tool, check that all protective and safety devices
are fitted and that they function faultlessly.
10 Troubleshooting
Fault Possible cause Remedy
The power tool doesn’t run. The battery is discharged or fitted
incorrectly.
The battery must be heard to engage
with a double click or, respectively,
needs to be charged.
Electrical fault. Remove the battery from the power
tool and contact Hilti Service.
The power tool switches itself
off and all 4 LEDs on the battery
blink.
The overload cut-out has been acti-
vated.
Release the control switch, reduce
the load on the power tool and then
press the switch again.
en
10
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

Fault Possible cause Remedy
The control switch can’t be
pressed, i.e. the switch is
locked.
The forward / reverse switch is in the
middle position (safety lock engaged).
Push the forward / reverse switch to
the left or right.
The power tool runs but the
screw cannot be driven.
The forward / reverse switch is set to
the wrong direction of rotation.
Push the forward / reverse switch to
the left.
Running speed suddenly drops
considerably.
The battery is discharged. Change the battery and recharge the
discharged battery.
Speed cannot be controlled by
the switch, it simply switches on
/off.
The control switch is defective. Contact Hilti Service.
The battery doesn’t engage with
an audible double click.
The retaining lugs on the battery are
dirty.
Clean the retaining lugs and check
that the battery engages securely.
Contact Hilti Service if the problem
persists.
The power tool or the battery
gets very warm.
Electrical fault. Switch the power tool off immedi-
ately, remove the battery and contact
Hilti Service.
The power tool has been overloaded
(application limits exceeded).
Use the right power tool for the job
(don’t use a low-powered tool for
heavy work).
11 Disposal
CAUTION
Improper disposal of the equipment may have serious consequences: the burning of plastic components generates
toxic fumes which may present a health hazard. Batteries may explode if damaged or exposed to very high
temperatures, causing poisoning, burns, acid burns or environmental pollution. Careless disposal may permit
unauthorized and improper use of the equipment. This may result in serious personal injury, injury to third parties and
pollution of the environment.
CAUTION
Dispose of defective batteries without delay. Keep them out of reach of children. Do not attempt to open or dismantle
batteries and do not dispose of them by incineration.
CAUTION
Dispose of the batteries in accordance with national regulations or return them to Hilti.
Most of the materials from which Hilti power tools or appliances are manufactured can be recycled. The materials
must be correctly separated before they can be recycled. In many countries, Hilti has already made arrangements for
taking back your old power tools or appliances for recycling. Please ask your Hilti customer service department or
Hilti representative for further information.
en
11
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

12 Manufacturer’s warranty - tools
Hilti warrants that the tool supplied is free of defects in
materialandworkmanship.Thiswarrantyisvalidsolong
as the tool is operated and handled correctly, cleaned
and serviced properly and in accordance with the Hilti
Operating Instructions, and the technical system is main-
tained. This means that only original Hilti consumables,
components and spare parts may be used in the tool.
This warranty provides the free-of-charge repair or re-
placement of defective parts only over the entire lifespan
of the tool. Parts requiring repair or replacement as a
result of normal wear and tear are not covered by this
warranty.
Additional claims are excluded, unless stringent na-
tional rules prohibit such exclusion. In particular, Hilti
is not obligated for direct, indirect, incidental or con-
sequential damages, losses or expenses in connec-
tion with, or by reason of, the use of, or inability to
use the tool for any purpose. Implied warranties of
merchantability or fitness for a particular purpose are
specifically excluded.
For repair or replacement, send the tool or related parts
immediately upon discovery of the defect to the address
of the local Hilti marketing organization provided.
This constitutes Hilti’s entire obligation with regard to
warranty and supersedes all prior or contemporaneous
comments and oral or written agreements concerning
warranties.
en
12
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02

*400172*
400172
Hilti Corporation
LI-9494 Schaan
Tel.: +423 / 234 21 11
Fax:+423 / 234 29 65
www.hilti.com
Hilti = registered trademark of Hilti Corp., Schaan
W 3656 | 0613 | 00-Pos. 3 | 1
Printed in China © 2013
Right of technical and programme changes reserved S. E. & O.400172 / A4
Printed: 08.07.2013 | Doc-Nr: PUB / 5070549 / 000 / 02
