ORIGINAL OPERATING INSTRUCTIONS
TE 1000‑AVR / TE 1500‑AVR breaker
It is essential that the operating instructions
are read before the power tool is operated for
the first time.
Always keep these operating instructions to-
gether with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents Page
1 General information 15
2Description 16
3 Accessories, consumables 18
4 Technical data 19
5 Safety instructions 20
6Beforeuse 23
7 Operation 23
8 Care and maintenance 25
9 Troubleshooting 26
10 Disposal 27
11 Manufacturer’s warranty - tools 27
12 EC declaration of conformity (original) 27
1These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the designation “the
power tool” always refers to the TE 1000-AVR and /
or TE 1500-AVR breaker.
Components, operating controls and indicators 1
@Grip
;On / off switch
=Supply cord
%Theft protection indicator (optional)
&Service indicator
(Power level indicator (TE 1000‑AVR)
)Power level selector switch (only TE 1000‑AVR)
+Side handle
§Knob
/Chuck and chisel position adjustment
:Ventilation slots
1 General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
seriousbodilyinjuryorfatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning Warning: electricity Warning: hot surface
en
15
Printed: 16.05.2014 | Doc-Nr: PUB / 5070757 / 000 / 03

Obligation signs
Wear eye
protection Wear a hard hat Wear ear protection Wear protective
gloves
Wear
breathing
protection
Symbols
Read the
operating
instructions
before use
Returning
materials for
recycling
Chiseling Chisel
position
adjustment
Volts Amps Alternating
current Hertz
Double
insulated Lock symbol Equipped with theft
protection
system
Location of identification data on the power tool
The type designation can be found on the type identifica-
tion plate and the serial number on the side of the casing.
Makeanoteofthisdatainyouroperatinginstructions
and always refer to it when making an enquiry to your
Hilti representative or service department.
Type:
Serial no.:
2 Description
2.1 Use of the product as directed
The power tool is an electrically-powered breaker with electropneumatic hammering mechanism designed for heavy
chiseling work.
The power tool is designed for breaking / removing and demolishing concrete, masonry, stone or asphalt.
Working on materials hazardous to the health (e.g. asbestos) is not permissible.
Observe national health and safety requirements.
The power tool is designed for professional use and may be operated, serviced and maintained only by trained,
authorized personnel. This personnel must be informed of any special hazards that may be encountered. The power
tool and its ancillary equipment may present hazards when used incorrectlybyuntrainedpersonnelorwhenusednot
as directed.
The working environment may be as follows: construction site, workshop, renovation, conversion or new construction.
Thepowertoolmaybeusedonlyinadryenvironment.
Do not use the power tool where there is a risk of fire or explosion.
The power tool may be operated only when connected to a power supply providing a voltage and frequency in
compliance with the information given on its type identification plate.
en
16
Printed: 16.05.2014 | Doc-Nr: PUB / 5070757 / 000 / 03

To avoid the risk of injury, use only genuine Hilti accessories and insert tools.
Observe the information printed in the operating instructions concerning operation, care and maintenance.
Modification of the power tool or tampering with its parts is not permissible.
2.2 Chuck
TE‑S quick-change chuck
2.3 Switches
On / off switch
Power level selector switch (100%, 70%, only TE 1000‑AVR)
2.4 Grips (with soft synthetic foam rubber covering)
Vibration-absorbing grip
Vibration-absorbing, rotatable and pivotable side handle
2.5 Lubrication
Gearing and hammering mechanism with separate lubrication chambers
An additional lubrication chamber at the front end of the hammering mechanism prevents entry of dust.
2.6 Active vibration reduction
The power tool is equipped with an AVR active vibration reduction system which reduces vibration significantly
compared to power tools without active vibration reduction.
2.7 TPS theft protection system (optional)
The power tool may be equipped with the TPS theft protection system as an option. If the power tool is equipped with
this optional feature, it can be unlocked and made ready for operation only through use of the corresponding TPS key
(see section “Operation / TPS theft protection system (optional)”).
2.8 Protective features
Vibration reduction and high-temperature protection provided by isolation of the grips and plastic casing from internal
parts of the power tool.
Electronic restart interlock to prevent the power tool starting unintentionally after an interruption in the electric supply
(see section “Troubleshooting”).
Electronics with self-acting protective system against overvoltage and overheating.
2.9 LED indicators
Service indicator LED (see section “Care and maintenance / service indicator”)
Theft protection system indicator (optional) (see section “Operation / TPS theft protection system (optional)”)
Power level indicator (only TE 1000‑AVR) (see section “Operation/ adjusting chiseling power”)
2.10 Items supplied as standard
1 Power tool
1Sidehandle
1 Grease
1 Cleaning cloth
1 Operating instructions
1 Hilti toolbox
2.11 Using extension cords
Use only extension cords of a type approved for the application and with conductors of adequate cross section.
The power tool may otherwise lose performance and the extension cord may overheat. Check the extension cord for
damage at regular intervals. Replace damaged extension cords.
en
17
Printed: 16.05.2014 | Doc-Nr: PUB / 5070757 / 000 / 03

Recommended minimum conductor cross section and max. cable lengths
Conductor cross section 1.5 mm² 2.5 mm² 3.5 mm²
Mains voltage 100V 30 m
Mains voltage 110-127 V 20 m
Mains voltage 220-240 V 30 m 50 m
Do not use extension cords with 1.25 mm² conductor cross section; 2.0 mm² conductor cross section.
2.12 Using extension cords outdoors
When working outdoors, use only extension cords that are approved and correspondingly marked for this application.
2.13 Using a generator or transformer
This power tool may be powered by a generator or transformer when the following conditions are fulfilled: The unit
must provide a power output in watts of at least twice the value printed on the type identification plate on the power
tool. The operating voltage must remain within +5% and -15% of the rated voltage at all times, frequency must be in
the 50 – 60 Hz range and never above 65 Hz, and the unit must be equipped with automatic voltage regulation and
starting boost.
Never operate other power tools or appliances from the generator or transformer at the same time. Switching other
power tools or appliances on and off may cause undervoltage and / or overvoltage peaks, resulting in damage to the
power tool.
3 Accessories, consumables
Designation Short designation Item number, description
TPS Theft Protection System with
Company Card, Company Remote
and TPS‑K key
206999, optional
Dust removal module TE DRS‑B
Use the Hilti chisels or other tools listed below. With these chisels and tools you will achieve higher
performance and longer lifetime as the power tool and chisels have been optimized as a system.
TE‑S chuck /
tool designa-
tion Width (mm) Length (mm) Width in
inches Length in inches
Pointed chisels TE‑SP SM 36 360 14
TE‑SP SM 50 500 20
TE‑SP SM 70 700 27
Flat chisels TE‑SP FM 36 32 360 1¹⁄₄ 14
TE‑SP FM 50 32 500 1¹⁄₄ 20
TE‑SP FM 70 32 700 1¹⁄₄ 27
Wide-flat chisels TE‑SP
SPM 5/36 50 360 2 14
TE‑SP
SPM 5/50 50 500 2 20
TE‑SP
SPM 8/36 80 360 3 14
TE‑SP
SPM 8/50 80 500 3 20
TE‑SP
SPM 12/36 120 360 4³⁄₄ 14
TE‑SP
SPM 12/50 120 500 4³⁄₄ 20
en
18
Printed: 16.05.2014 | Doc-Nr: PUB / 5070757 / 000 / 03

TE‑S chuck /
tool designa-
tion Width (mm) Length (mm) Width in
inches Length in inches
Flexible chisel TE‑S‑BSPM 150 650 6 25¹⁄₂
Scraper / flexible chisel TE‑SP‑SPMK
12/50 120 500 4³⁄₄ 20
Pointed flat chisel TE‑S‑SPI 50 115 485 4¹⁄₂ 19¹⁄₈
Ballast bed chisel TE‑S‑TT 60 600 24
Shank TE‑S‑SS 300 11³⁄₄
Tamping plate TP‑STP
150/150 150 x 150 6 x 6
Bushing head TP‑SKHM 40 40 x 40 1¹⁄₂ x 1¹⁄₂
TP‑SKHM 60 60 x 60 2¹⁄₃ x 2¹⁄₃
Earth rod rammer TP‑TKS 15 Inside ∅ 15
TP‑TKS 20 Inside ∅ 20
TP‑TKS 25 Inside ∅ 25
TE‑S‑RD ⁵⁄₈" Inside ∅ ⁵⁄₈
TE‑S‑RD ³⁄₄" Inside ∅ ³⁄₄
TE‑S‑RD ⁷⁄₈" Inside ∅ ⁷⁄₈
4 Technical data
Right of technical changes reserved.
NOTE
The power tool is available in various voltage ratings. Please refer to the power tool’s type identification plate for
details of its voltage, current and input power ratings.
Rated
voltage,
TE 1000-
AVR
100 V 110 V 110 V 127 V 220 V 230 V 240 V
Rated
power
input
1,450 W 1,600 W 1,600 W 1,600 W 1,600 W 1,600 W 1,500 W
Rated cur-
rent input 14.6 A 14.6 A 14.6 A 12.7 A 7.3 A 7 A 6.3 A
Mains fre-
quency 50…60 Hz 50 Hz 60 Hz 60 Hz 50…60 Hz 50…60 Hz 50 Hz
Rated
voltage,
TE 1500-
AVR
100 V 110 V 110 V 220 V 230 V 240 V
Rated power
input 1,490 W 1,750 W 1,640 W 1,800 W 1,800 W 1,800 W
Rated current
input 15 A 16 A 15 A 8.5 A 7.9 A 7.6 A
Mains fre-
quency 50…60 Hz 50 Hz 60 Hz 50…60 Hz 50…60 A 50 Hz
en
19
Printed: 16.05.2014 | Doc-Nr: PUB / 5070757 / 000 / 03

Power tool TE 1000‑AVR TE 1500‑AVR
Weight in accordance with EPTA
procedure 01/2003 11.8 kg 14.2 kg
Dimensions (L x W x H) 700 mm x 138 mm x 230 mm 760 mm x 138 mm x 230 mm
Single impact energy in accordance
with EPTA procedure 05/2009 22 J 30 J
Chuck TE‑S TE‑S
Hammering frequency under load 32.5 Hz 27 Hz
Information about the power tool and its applications
Protection class Protection class II (double insulated)
NOTE
The vibration emission level given in this information sheet has been measured in accordance with a standardised test
giveninEN60745andmaybeusedtocompareonetoolwithanother.Itmaybeused for a preliminary assessment
of exposure. The declared vibration emission level represents the main applications of the tool. However if the tool is
used for different applications, with different accessories or poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total working period. An estimation of the level of exposure to
vibration should also take into account the times when the tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure level over the total working period. Identify additional safety
measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.
Noise and vibration information (measured in accordance with EN 60745‑1):
Typical A-weighted sound power level, TE 1000-AVR 98 dB (A)
Typical A-weighted emission sound pressure level, TE
1000-AVR 87 dB (A)
Typical A-weighted sound power level, TE 1500-AVR 100 dB (A)
Typical A-weighted emission sound pressure level, TE
1500-AVR 89 dB (A)
Uncertainty for the sound levels given for the
TE 1000‑AVR / TE 1500‑AVR 3dB(A)
Triaxial vibration value for the TE 1000‑AVR (vibration
vector sum) Measured in accordance with EN 60745‑2‑6
Chiseling, ah, Cheq 6.5 m/s²
Triaxial vibration value for the TE 1500‑AVR (vibration
vector sum) Measured in accordance with EN 60745‑2‑6
Chiseling, ah, Cheq 12 m/s²
Uncertainty (K) 1.5 m/s²
5 Safety instructions
5.1 General Power Tool Safety Warnings
a) WARNING
Read all safety warnings and all instructions. Fail-
ure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury. Save all
warnings and instructions for future reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
5.1.1 Work area safety
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operat-
ing a power tool. Distractions can cause you to lose
control.
en
20
Printed: 16.05.2014 | Doc-Nr: PUB / 5070757 / 000 / 03
