1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a
prerequisite for safe, trouble-free handling and use of the product.
• Observe the safety instructions and warnings in this documentation and
on the product.
• Always keep the operating instructions with the product and make sure
that the operating instructions are with the product when it is given to
other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the
product. The following signal words are used:
DANGER
DANGER !
▶Draws attention to imminent danger that will lead to serious personal
injury or fatality.
WARNING
WARNING !
▶Draws attention to a potential threat of danger that can lead to serious
injury or fatality.
CAUTION
CAUTION !
▶Draws attention to a potentially dangerous situation that could lead to
slight personal injury or damage to the equipment or other property.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use.
Instructions for use and other useful information
Dealing with recyclable materials
Do not dispose of electric equipment and batteries as household
waste
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

2 English 2063039 *2063039*
These numbers refer to the corresponding illustrations found at the
beginning of these operating instructions
The numbering reflects the sequence of operations shown in the
illustrations and may deviate from the steps described in the text
Item reference numbers are used in the overview illustrations and
refer to the numbers used in the product overview section
This symbol is intended to draw special attention to certain points
when handling the product.
1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols are used on the product:
Drilling with hammering action (hammer drilling)
Chiseling
Chisel positioning
Protection class II (double-insulated)
Rated speed under no load
Revolutions per minute
Revolutions per minute
Diameter
Alternating current
The product supports wireless data transmission compatible with
iOS and Android platforms.
1.4 Product information
products are designed for professional users and only trained,
authorized personnel are permitted to operate, service and maintain the
products. This personnel must be specifically informed about the possible
hazards. The product and its ancillary equipment can present hazards if
used incorrectly by untrained personnel or if used not in accordance with
the intended use.
The type designation and serial number are printed on the rating plate.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

*2063039* 2063039 English 3
▶Write down the serial number in the table below. You will be required to
state the product details when contacting Hilti Service or your local Hilti
organization to inquire about the product.
Product information
Combihammer TE 70AVR |
TE 70ATC/AVR |
TE 80ATC/AVR
Generation 03
Serial no.
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here
complies with the applicable directives and standards. A copy of the
declaration issued by the certification department can be found at the end
of this documentation.
The technical documentation is filed here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistrasse 6 | 86916
Kaufering, Germany
2 Safety
2.1 General power tool safety warnings
WARNING Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow all instruc-
tions listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
Work area safety
▶Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
▶Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
▶Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
▶Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

4 English 2063039 *2063039*
▶Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
▶Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
▶Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
▶When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk
of electric shock.
▶If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
Personal safety
▶Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal
injury.
▶Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard
hat or hearing protection used for appropriate conditions will reduce
personal injuries.
▶Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your finger on the switch
or energising power tools that have the switch on invites accidents.
▶Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
▶Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
▶Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
▶If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
▶Do not let familiarity gained from frequent use of tools allow you
to become complacent and ignore tool safety principles. A careless
action can cause severe injury within a fraction of a second.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

*2063039* 2063039 English 5
Power tool use and care
▶Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
▶Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
▶Disconnect the plug from the power source and/or remove the
battery pack, if detachable, from the power tool before making
any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool
accidentally.
▶Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands of
untrained users.
▶Maintain power tools and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other condition
that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
▶Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
▶Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and
the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
▶Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
Service
▶Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
2.2 Drill safety warnings
Safety instructions for all operations
▶Wear ear protectors when impact drilling. Exposure to noise can cause
hearing loss.
▶Use the auxiliary handle(s). Loss of control can cause personal injury.
▶Hold the power tool by insulated gripping surfaces, when performing
an operation where the cutting accessory or fasteners may contact
hidden wiring or its own cord. Cutting accessory or fasteners contacting
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

6 English 2063039 *2063039*
a "live" wire may make exposed metal parts of the power tool "live" and
could give the operator an electric shock.
Safety instructions when using long drill bits
▶Never operate at higher speed than the maximum speed rating of the
drill bit. At higher speeds, the bit is likely to bend if allowed to rotate
freely without contacting the workpiece, resulting in personal injury.
▶Always start drilling at low speed and with the bit tip in contact with
the workpiece. At higher speeds, the bit is likely to bend if allowed to
rotate freely without contacting the workpiece, resulting in personal injury.
▶Apply pressure only in direct line with the bit and do not apply
excessive pressure. Bits can bend causing breakage or loss of control,
resulting in personal injury.
Safety instructions for using mixing paddles or stirrers
▶Switch the power tool on or off only when the mixing paddle is
immersed in the material for mixing. Failure to do so can cause a loss
of control with resultant risk of injury.
2.3 Additional safety instructions for rotary hammer
Personal safety
▶Use the product only when it is in technically faultless condition.
▶Never tamper with or modify the power tool in any way.
▶Use the auxiliary grips supplied with the tool. Loss of control can cause
personal injury.
▶Apply appropriate safety measures at the opposite side of the workpiece
in work that involves breaking through. Parts breaking away could fall out
and / or fall down causing injury to other persons.
▶Always hold the power tool with both hands on the grips provided. Keep
the grips clean and dry.
▶Hold the power tool by the insulated gripping surfaces when performing
work in which the accessory tool might come into contact with concealed
wiring. If the accessory tool comes into contact with a live wire, metal
parts of the power tool can also become live, resulting in an electric
shock.
▶Avoid touching rotating parts – risk of injury!
▶Wear suitable protective glasses, a hard hat, ear defenders, protective
gloves and light respiratory protection while using the power tool.
▶Wear protective gloves also when changing the accessory tool. Touching
the accessory tool presents a risk of injury (cuts or burns).
▶Wear eye protection. Flying fragments present a risk of injury to the body
and eyes.
▶Before starting work, check the hazard class of the dust that will be pro-
duced when working. Use an industrial vacuum cleaner with an officially
approved protection class in compliance with the locally applicable dust
protection regulations. Dust from materials such as lead-based paint,
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

*2063039* 2063039 English 7
certain types of wood and concrete/masonry/stone containing quartz,
minerals or metal can be harmful to health.
▶Make sure that the workplace is well ventilated and, where necessary,
wear a respirator appropriate for the type of dust generated. Contact with
or inhalation of the dust can cause allergic reactions and/or respiratory
or other diseases to the operator or bystanders. Certain kinds of dust
such as oakwood and beechwood dust are classified as carcinogenic,
especially in conjunction with additives for wood conditioning (chromate,
wood preservative). Only specialists are permitted to handle material
containing asbestos.
▶Take breaks and do physical exercises to improve the blood circulation
in your fingers. Exposure to vibration during long periods of work can
lead to disorders of the blood vessels and nervous system in the fingers,
hands and wrists.
Electrical safety
▶Before beginning work, check the working area for concealed electric
cables, gas pipes and water pipes. External metal parts of the power tool
can become live, presenting a risk of electric shock, if you accidentally
damage an electric cable.
Power tool use and care
▶Immediately switch off the power tool if the accessory tool jams. The
power tool might twist off-line.
▶Wait until the power tool stops completely before you lay it down.
3 Description
3.1 Product overview 1
@Dust shield
;Chuck
=Accessory tool release
%Function selector switch
&Control switch lock
(Control switch
)Grip
+Service indicator
§Indicator for half power (ATC
version only)
/Button for half power (ATC
version only)
:Supply cord
∙Side handle
3.2 Intended use
The product described is an electrically powered combihammer with pneu-
matic hammering mechanism. It is designed for drilling in concrete, masonry,
wood and metal. The product can also be used for light- to medium-duty
chiseling on masonry and surface finishing work on concrete.
Under certain conditions, the product is also suitable for stirring / mixing.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

8 English 2063039 *2063039*
▶The tool may be operated only when connected to a power source
providing a voltage and frequency in compliance with the information
given on the type identification plate.
3.3 AVR option
The product may be optionally equipped with an Active Vibration Reduction
(AVR) system, which reduces vibration noticeably.
3.4 ATC
The power tool is equipped with the ATC (Active Torque Control) quick-
acting electronic cut-out.
If the accessory tool sticks or stalls, the power tool will suddenly pivot about
its own axis in the opposite direction. ATC detects this sudden pivoting
movement of the power tool and switches the tool off immediately.
For ATC to function correctly, the power tool must be free to pivot.
After the power tool has cut out due to ATC, switch it back on again by
releasing the control switch for a moment and then pressing the switch
again.
3.5 Service indicator
The product is equipped with a service indicator LED.
3.5.1 Service indicator status
Status Meaning
The service indicator lights red. End of service interval – servicing is
due.
The service indicator blinks red. Have the combihammer repaired by
Hilti Service.
3.6 Items supplied
Combihammer, side handle, operating instructions.
Other system products approved for use with this product can be found at
your local Hilti Store or at: www.hilti.group | USA: www.hilti.com
4 Technical data
For rated voltage, rated current, frequency and/or input power, refer to
the country-specific type identification plate.
If the tool is powered by a generator or transformer, the generator or
transformer’s power output must be at least twice the rated input power
shown on the rating plate of the tool. The operating voltage of the transformer
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

*2063039* 2063039 English 9
or generator must always be within +5 % and -15 % of the rated voltage of
the tool.
TE 70AVR TE 70-ATC/AVR TE 80-ATC/AVR
Weight 18.3 lb
(8.3 kg)
20.9 lb
(9.5 kg)
21.4 lb
(9.7 kg)
Single impact
energy in ac-
cordance with
EPTA procedure
05
11.5 J 11.5 J 11.5 J
Hammer drill
bits, Ø
1/2 in …
2 3/16 in
1/2 in …
2 3/16 in
1/2 in …
2 3/16 in
Hammer drill
bits, Ø
12 mm …
55 mm
12 mm …
55 mm
12 mm …
55 mm
Ø drill bits for
wood
13/32 in …
1 1/4 in
13/32 in …
1 1/4 in
13/32 in …
1 1/4 in
Ø drill bits for
wood
10 mm …
32 mm
10 mm …
32 mm
10 mm …
32 mm
Ø drill bits for
metal
0 in … 23/32 in 0 in … 23/32 in 0 in … 23/32 in
Ø drill bits for
metal
0 mm … 20 mm 0 mm … 20 mm 0 mm … 20 mm
4.1 Using extension cords
WARNING
A damaged supply cord presents a hazard! Do not touch the supply cord
or extension cord if damaged while working. Disconnect the supply cord
plug from the power outlet.
▶Check the appliance’s supply cord at regular intervals and have it replaced
by a qualified specialist if found to be damaged.
• Use only extension cords of a type approved for the application and
with conductors of adequate gauge (cross section). The power tool
may otherwise suffer a drop in performance and the extension cord may
overheat.
• Check the extension cord for damage at regular intervals.
• Replace damaged extension cords.
• When working outdoors, use only extension cords that are approved and
correspondingly marked for this application.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

10 English 2063039 *2063039*
Recommended minimum conductor cross-section and maximum
power-cord length for 120V supply voltage
Cord AWG 16 AWG 14 AWG 12 AWG 10
Conductor cross-section 1,31
mm²
2,08
mm²
3,31
mm²
5,26
mm²
Conductor cross-section 2,58
kcmil
4,11
kcmil
6,53
kcmil
10,4
kcmil
Cord length 25 m 30 m 50 m 100 m
Cord length 75 ft 100 ft 150 ft 250 ft
5 Operation
5.1 Fitting the side handle 2
CAUTION
Risk of injury! Loss of control over the combihammer.
▶Check that the side handle is fitted correctly and tightened securely.
Check that the clamping band is engaged in the groove provided on the
tool.
▶Fit the side handle.
5.2 Fitting / removing the accessory tool 3
The use of unsuitable grease may cause damage to the tool. Use only
genuine Hilti grease.
Always check the accessory tool for damage and uneven wear before
each use; replace if necessary.
▶Fit or remove the accessory tool, as applicable.
5.3 Drilling without hammer action 4
Drilling without hammer action is possible when accessory tools with a
special connection end are used. Tools of this kind are available from
the Hilti tools range.
When the keyless quick-release chuck is fitted, smooth-shank drill bits
for wood or steel, for example, can be used to drill without hammer
action.
▶Set the function selector switch to the “Hammer drilling” position .
5.4 Mixing 4
Use the mixing paddle only with the quick-release chuck.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

*2063039* 2063039 English 11
▶Set the function selector switch to the "Hammer drilling" position and
insert the mixing paddle into the quick-release chuck.
5.5 Setting the power level
TE 70-ATC-AVR
TE 80-ATC-AVR
Power can be set only when the tool is switched on and ready for use.
To set the tool to half power, press the "half power" button. The power
indicator lights up to indicate reduced power. Press the "half power"
button again to switch to full power. The power indicator goes out.
Switching the combihammer off and then on again resets the tool to full
power.
▶Set the power level.
5.6 Drilling with hammer action (hammer drilling) 4
▶Set the function selector switch to the “Hammer drilling” position .
5.7 Chisel positioning 4
CAUTION
Risk of injury! Loss of control over the chisel direction.
▶Do not operate the tool when the selector switch is set to “Chisel
positioning”. Turn the function selector switch until it engages in the
“Chiseling” position.
The chisel can be set to 24 different positions (in 15° increments). This
ensures that flat chisels and shaped chisels can always be set to the
optimum working position.
▶Set the function selector switch to the “Chisel positioning” position .
5.8 Chiseling 4
▶Set the function selector switch to the “Chiseling” position .
5.9 Control switch lock
When chiseling, the control switch can be locked in the “on” position.
▶Press the control switch lock.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

12 English 2063039 *2063039*
6 Care and maintenance
WARNING
Electric shock hazard! Attempting care and maintenance with the supply
cord connected to a power outlet can lead to severe injury and burns.
▶Always unplug the supply cord before carrying out care and maintenance
tasks.
Care
• Carefully remove any dirt that may be adhering to parts.
• Clean the air vents carefully with a dry brush.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning
agents containing silicone as these may attack the plastic parts.
Maintenance
WARNING
Danger of electric shock! Improper repairs to electrical components may
lead to serious injuries including burns.
▶Repairs to the electrical section of the tool or appliance may be carried
out only by trained electrical specialists.
• Check all visible parts and controls for signs of damage at regular intervals
and make sure that they all function correctly.
• Do not operate the product if signs of damage are found or if parts
malfunction. Have it repaired immediately by Hilti Service.
• After cleaning and maintenance, fit all guards or protective devices and
check that they function correctly.
To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with the product can be found at your local
Hilti Store or online at: www.hilti.group.
7 Transport and storage
• Do not transport electric tools with accessory tools fitted.
• Always unplug the supply cord before storing an electric tool or appliance.
• Store tools and appliances in a dry place where they cannot be accessed
by children or unauthorized persons.
• Check electric tools or appliances for damage after long periods of
transport or storage.
8 Troubleshooting
If the trouble you are experiencing is not listed in this table or you are unable
to remedy the problem by yourself, please contact Hilti Service.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

*2063039* 2063039 English 13
8.1 Troubleshooting
Trouble or fault Possible cause Action to be taken
Combihammer does
not start.
Interruption in the elec-
tric supply.
▶Plug in another electric
tool or appliance
and check whether it
works.
The generator is in sleep
mode.
▶Apply a load to
the generator by
connecting a second
power consumer (e.g.
worklight). Switch the
tool off and then on
again.
The electronic restart
interlock is activated
after an interruption in
the electric supply.
▶Switch the power tool
off and then on again.
The carbon brushes are
worn.
▶Have checked, and if
necessary replaced,
by a trained electrical
specialist.
No hammering ac-
tion.
The power tool is too
cold.
▶Bring the tip of the
accessory tool into
contact with the
working surface,
switch the power
tool on and allow it
to run. If necessary,
repeat the procedure
until the hammering
mechanism begins to
operate.
Combihammer does
not achieve full
power.
The extension cord is
too long or the conduc-
tor cross-section is in-
adequate.
▶Use an extension
cord of an approved
length and / or of
adequate conductor
cross-section.
The control switch is not
fully pressed.
▶Press the control
switch as far as it will
go.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

14 English 2063039 *2063039*
Trouble or fault Possible cause Action to be taken
Combihammer does
not achieve full
power.
The voltage provided by
the electric supply is too
low.
▶Connect the power
tool to a different
power source.
TE 70-ATC-AVR
TE 80-ATC-AVR
The half-power button is
engaged.
▶Press the "half-power"
button.
Drill bit does not
rotate.
The function selector
switch is not engaged or
is in the "Chiseling" po-
sition or the "Chisel
positioning" position .
▶With the motor at
a standstill, set the
function selector
switch to the “Hammer
drilling” position.
Drill bit is not re-
leased.
The chuck is not pulled
back fully.
▶Pull the chuck back
as far as it will go and
remove the accessory
tool.
The side handle is not
fitted correctly.
▶Disengage the side
handle and refit it
correctly so that the
clamping band and
side handle engage in
the recess.
The service indicator
blinks red.
A fault has occurred in
the tool.
▶Have the product
repaired by Hilti
Service.
The service indicator
lights red.
The carbon brushes are
worn.
▶Have checked, and if
necessary replaced,
by a trained electrical
specialist.
9 Disposal
Most of the materials from which Hilti tools and appliances are manu-
factured can be recycled. The materials must be correctly separated before
they can be recycled. In many countries, your old tools, machines or appli-
ances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti
representative for further information.
▶Do not dispose of power tools, electronic equipment or batteries as
household waste!
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

*2063039* 2063039 English 15
10 Manufacturer’s warranty
▶Please contact your local Hilti representative if you have questions about
the warranty conditions.
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02

16 Français 2063039 *2063039*
1 Indications relatives à la documentation
1.1 À propos de cette documentation
• Lire intégralement la présente documentation avant la mise en service.
C'est la condition préalablement requise pour assurer la sécurité du travail
et un maniement sans perturbations.
• Bien respecter les consignes de sécurité et les avertissements de la
présente documentation ainsi que celles figurant sur le produit.
• Toujours conserver le mode d'emploi à proximité du produit et uniquement
le transmettre à des tiers avec ce mode d'emploi.
1.2 Explication des symboles
1.2.1 Avertissements
Les avertissements attirent l'attention sur des dangers liés à l'utilisation du
produit. Les termes de signalisation suivants sont utilisés :
DANGER
DANGER !
▶Pour un danger imminent qui peut entraîner de graves blessures corpo-
relles ou la mort.
AVERTISSEMENT
AVERTISSEMENT !
▶Pour un danger potentiel qui peut entraîner de graves blessures corpo-
relles ou la mort.
ATTENTION
ATTENTION !
▶Pour attirer l'attention sur une situation pouvant présenter des dangers
entraînant des blessures corporelles légères ou des dégâts matériels.
1.2.2 Symboles dans la documentation
Les symboles suivants sont utilisés dans la présente documentation :
Lire le mode d'emploi avant d'utiliser l'appareil
Pour des conseils d'utilisation et autres informations utiles
Maniement des matériaux recyclables
Ne pas jeter les appareils électriques et les accus dans les ordures
ménagères
1.2.3 Symboles dans les illustrations
Les symboles suivants sont utilisés dans les illustrations :
Printed: 30.08.2019 | Doc-Nr: PUB / 5150793 / 000 / 02
