Hilti TE 80-ATC User manual

TE 70 /
TE 70-ATC /
TE 80-ATC
Bedienungsanleitung de
Operating instructions en
Mode d’emploi fr
Manual de instrucciones es
Istruzioni d’uso it
Gebruiksaanwijzing nl
Brugsanvisning da
Bruksanvisning no
Bruksanvisning sv
Käyttöohje fi
Manual de instruções pt
ΟΟδδηηγγιιεεςςχχρρηησσεεωωςς
el
Lietoßanas pamåcîba lv
Instrukcija lt
Kasutusjuhend et

1

2
2
3
4
6
5
4
6
5
3
7
8

ORIGINAL OPERATING INSTRUCTIONS
TE 80‑ATC/ TE 70‑ATC/ TE 70 combihammer
It is essential that the operating instructions
are read before the power tool is operated
for the first time.
Always keep these operating instructions
together with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents Page
1. General information 17
2. Description 18
3. Insert tools, accessories 20
4. Technical data 20
5. Safety instructions 22
6. Before use 25
7. Operation 25
8. Care and maintenance 27
9. Troubleshooting 28
10. Disposal 29
11. Manufacturer’s warranty - tools 30
12. EC declaration of conformity 30
1These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out
cover pages. Keep these pages open while studying
the operating instructions.
In these operating instructions, the designation “the
power tool” always refers to the TE 80-ATC / TE
70-ATC / TE 70 combihammer.
Operating controls and indicators 1
@Function selector switch
;Control switch lock
=Control switch
%Supply cord
&Power reduction button (50% power)
(Side handle
)Chuck
+Insert tool lock
§Theft protection indicator (option)
/Service indicator
:Reduced power indicator
1. General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that could lead
to serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation
that could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation
that could lead to slight personal injury or damage to
the equipment or other property.
NOTE
Draws attention to an instruction or other useful
information.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
Warning:
electricity
Warning: hot
surface
en
17

Obligation signs
Wear eye
protection
Wear a hard
hat
Wear ear
protection
Wear
protective
gloves
Wear
breathing
protection
Symbols
Read the
operating
instructions
before use
Return waste
material for
recycling.
Hammer
drilling
Chiseling
Chisel position
adjustment
Volts Amps Watts
Alternating
current
Hertz Rated speed
under no load
Revolutions
per minute
Diameter Double
insulated
Equipped with
theft
protection
system
Lock symbol
Location of identification data on the power tool
The type designation can be found on the type iden-
tification plate and the serial number on the side of
the motor housing. Make a note of this data in your
operating instructions and always refer to it when
making an enquiry to your Hilti representative or
service department.
Type:
Generation: 01
Serial no.:
2. Description
2.1 Use of the product as directed
The power tool is an electrically-powered combihammer with pneumatic hammering mechanism. The ATC
(Active Torque Control) function of the TE 80-ATC / TE 70‑ATC provides greater operating comfort while
drilling.
The tool is designed for drilling in concrete, masonry, metal and wood and can also be used for chiseling.
Under certain conditions, the power tool is suitable for use for mixing (see “Tools, accessories” and
“Operation”).
Working on materials hazardous to the health (e.g. asbestos) is not permissible.
Nationally applicable industrial safety regulations must be observed.
The power tool is designed for professional use and may be operated, serviced and maintained only by trained,
authorized personnel. This personnel must be informed of any special hazards that may be encountered. The
power tool and its ancillary equipment may present hazards when used incorrectly by untrained personnel or
when used not as directed.
The working environment may be as follows: construction site, workshop, renovation, conversion or new
construction.
The power tool may be used only in a dry environment.
Do not use the power tool where there is a risk of fire or explosion.
The power tool may be operated only when connected to a power supply providing a voltage and frequency in
compliance with the information given on its type identification plate.
en
18

Modification of the power tool or tampering with its parts is not permissible.
To avoid the risk of injury, use only genuine Hilti accessories and insert tools.
Observe the information printed in the operating instructions concerning operation, care and maintenance.
2.2 Chuck
TE‑Y (SDS max) quick-change “click” chuck
2.3 Switches
Speed control switch for smooth starting
Function selector switch: Hammer drilling, chiseling, chisel adjustment (24 positions)
Choice of full or reduced (50%) power
Control switch lockable for chiseling
2.4 Grips
Vibration-absorbing, pivotable side handle
Vibration-absorbing grip
2.5 Protective devices
Mechanical safety clutch
Electronic restart interlock to prevent the power tool starting unintentionally after an interruption in the electric
supply (see section 9 “Troubleshooting”).
Additional ATC “Active Torque Control” (TE 80‑ATC/ TE 70‑ATC)
2.6 Lubrication
Gearing and hammering mechanism with separate lubrication chambers
2.7 TPS theft protection system (optional)
The power tool may be equipped with the TPS theft protection system as an option. If the power tool is equipped
with this feature, it can be unlocked and made ready for operation only through use of the corresponding TPS
key.
2.8 Active Vibration Reduction (only TE 80‑ATC)
The power tool is equipped with an AVR Active Vibration Reduction system which reduces vibration significantly
compared to power tools without AVR.
2.9 LED indicators
Service indicator LED (see section “Care and maintenance”)
Theft protection system indicator (optional) (see section “Operation”)
Reduced power indicator (see section “Operation”)
2.10 Items supplied as standard
1 Power tool
1 Side handle
1 Grease
1 Cleaning cloth
1 Operating instructions
1 Hilti toolbox
en
19

2.11 Using extension cords
Recommended minimum conductor cross section and max. cable lengths
Conductor cross section 1.5 mm²2mm²2.5 mm²3.5 mm²
Mains voltage 100V 30 m 50 m
Mains voltage 110-120 V 20 m 30 m 40 m
Mains voltage 220-240 V 30 m 75 m
2.12 Using a generator or transformer
This power tool may be powered by a generator or transformer when the following conditions are fulfilled:
The unit must provide a power output in watts of at least twice the value printed on the type identification
plate on the power tool. The operating voltage must remain within +5% and -15% of the rated voltage at all
times, frequency must be in the 50 – 60 Hz range and never above 65 Hz, and the unit must be equipped with
automatic voltage regulation and starting boost.
Never operate other power tools or appliances from the generator or transformer at the same time. Switching
other power tools or appliances on and off may cause undervoltage and / or overvoltage peaks, resulting in
damage to the power tool.
3. Insert tools, accessories
Hammer drill bits Ø12…45 mm
Breach bits Ø40…80 mm
Percussion core bits Ø45…150 mm
PCM diamond core bits Ø42…132 mm
Chisels Pointed, flat and shaped chisels with TE‑Y connection
end
Wood drill bits Ø10…32 mm
Metal drill bits Up to Ø20 mm
TPS theft protection system with company card,
company remote and TPS‑K key
Option, 206999
Setting tool Setting tool with TE‑Y connection end , 32221
Quick-release chuck Keyless chuck for wood and metal drill bits with
smooth or hex. shank, 60208, Chuck holder 263359
Mixing paddles for non-flammable materials, with
smooth or hex. shank
Ø80…150 mm, 41215 (Ø80mm), 41216
(Ø110mm), For use only with the keyless quick-
release chuck
4. Technical data
Right of technical changes reserved.
Power tool TE 80‑ATC TE 70‑ATC TE 70
Weight in accordance
with EPTA procedure
01/2003
10.2 kg 8.9 kg 7.7 kg
en
20

Power tool TE 80‑ATC TE 70‑ATC TE 70
Dimensions (L x W x H) 555 mm x 125 mm x
312 mm
524 mm x 123 mm x
294 mm
524 mm x 123 mm x
274 mm
NOTE
The power tool is available in various voltage ratings. Please refer to the type identification plate for details of
the power tool’s voltage and power rating.
Power tool TE 80‑ATC TE 70‑ATC / TE 70
Rated input 1,700 W 1,600 W
Rated current input Rated voltage 100 V: 15 A
Rated voltage 110 V: 16 A
Rated voltage 120 V: 15 A
Rated voltage 220 V: 9.8 A
Rated voltage 230 V: 9.9 A
Rated voltage 240 V: 10 A
Rated voltage 100 V: 15 A
Rated voltage 110 V: 16 A
Rated voltage 120: 15 A
Rated voltage 220 V, Rated
current input 1,600 W: 9.6 A
Rated voltage 230 V, Rated
current input 1,600 W: 9.8 A
Rated voltage 240 V, Rated
current input 1,600 W: 9.8 A
Mains frequency 50…60 Hz 50…60 Hz
Hammer drilling speed 380/min 360/min
Single impact energy (full power) 11.5 J 11 J
Single impact energy (50%
power)
5J 5J
NOTE
Information for users as per EN 61000-3-11: Switching on causes a brief drop in voltage. Other appliances may
be negatively affected when connected to mains supplies where conditions are unfavorable. No malfunctions
are to be expected on mains supplies with an impedance of less than <0.15 ohms.
Other information about the power tool
ATC electronic cut-out TE 80‑ATC/ TE 70‑ATC
Protection class Protection class II (double insulated)
NOTE
The vibration emission level given in this information sheet has been measured in accordance with a
standardised test given in EN 60745 and may be used to compare one tool with another. It may be used for a
preliminary assessment of exposure. The declared vibration emission level represents the main applications of
the tool. However if the tool is used for different applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly increase the exposure level over the total working
period. An estimation of the level of exposure to vibration should also take into account the times when the
tool is switched off or when it is running but not actually doing the job. This may significantly reduce the
exposure level over the total working period. Identify additional safety measures to protect the operator from
the effects of vibration such as: maintain the tool and the accessories, keep the hands warm, organisation of
work patterns.
Noise and vibration information (measured in accordance with EN 60745):
Typical A-weighted sound power level, TE 80-ATC 110.5 dB (A)
Typical A-weighted emission sound pressure level,
TE 80-ATC
99.5 dB (A)
en
21

Typical A‑weighted sound power level for the
TE 70-ATC / TE 70
110.5 dB (A)
Typical A‑weighted sound pressure level for the
TE 70-ATC / TE 70
99.5 dB (A)
Uncertainty for the given sound level 3 dB (A)
Triaxial vibration value for the TE 80-ATC (vibration
vector sum)
Measured in accordance with EN 60745‑2‑6
Hammer drilling in concrete, ah, HD 8.8 m/s²
Chiseling, ah, Cheq 8.5 m/s²
Triaxial vibration value for the TE 70-ATC (vibration
vector sum)
Measured in accordance with EN 60745‑2‑6
Hammer drilling in concrete, ah, HD 22 m/s²
Chiseling, ah, Cheq 18 m/s²
Triaxial vibration value for the TE 70 (vibration vector
sum)
Measured in accordance with EN 60745‑2‑6
Hammer drilling in concrete, ah, HD 22 m/s²
Chiseling, ah, Cheq 18 m/s²
Uncertainty (K) for triaxial vibration value 1.5 m/s²
5. Safety instructions
5.1 General safety warnings
WARNING! Read all instructions! Failure to follow all
instructions listed below may result in electric shock,
fire and/or serious injury. The term “power tool” in
all of the warnings listed below refers to your mains-
operated (corded) power tool or battery-operated
(cordless) power tool. SAVE THESE INSTRUCTIONS.
5.1.1 Work area
a) Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while oper-
ating a power tool. Distractions can cause you to
lose control.
5.1.2 Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
5.1.3 Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
en
22

b) Use safety equipment. Always wear eye pro-
tection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions will reduce
personal injuries.
c) Avoid accidental starting. Ensure the switch is
in the off-position before plugging in. Carrying
power tools with your finger on the switch or
plugging in power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and bal-
ance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of these
devices can reduce dust-related hazards.
5.1.4 Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing ac-
cessories, or storing power tools. Such prevent-
ive safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the
hands of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc., in accordance with these instructions and
in the manner intended for the particular type
of power tool, taking into account the working
conditions and the work to be performed. Use of
the power tool for operations different from those
intended could result in a hazardous situation.
5.1.5 Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
5.2 Additional safety instructions
5.2.1 Personal safety
a) Wear ear protectors. Exposure to noise can cause
hearing loss.
b) Use auxiliary handles supplied with the tool.
Loss of control can cause personal injury.
c) Always hold the power tool securely with both
hands on the grips provided. Keep the grips dry,
clean and free from oil and grease.
d) Hold tool by insulated gripping surfaces when
performing an operation where the cutting tool
may contact hidden wiring or its own cord. Con-
tact with a “live” wire will make exposed metal
parts of the tool “live” and shock the operator.
e) Breathing protection must be worn if the power
tool is used without a dust removal system for
work that creates dust.
f) Improve the blood circulation in your fingers by
relaxing your hands and exercising your fingers
during breaks between working.
g) Avoid touching rotating parts. Switch the power
tool on only after bringing it into position at
the workpiece. Touching rotating parts, especially
rotating insert tools, may lead to injury.
h) Always lead the supply cord and extension cord
away from the power tool to the rear while
working. This helps to avoid tripping over the cord
while working.
en
23

i) When using the power tool for mixing, set the
function selector switch to “Hammer drilling”
and wear protective gloves.
j) Children must be instructed not to play with the
appliance.
k) The appliance is not intended for use by chil-
dren, by debilitated persons or those who have
received no instruction or training.
5.2.2 Power tool use and care
a) Secure the workpiece. Use clamps or a vice
to secure the workpiece. The workpiece is thus
held more securely than by hand and both hands
remain free to operate the power tool.
b) Check that the insert tools used are compatible
with the chuck system and that they are secured
in the chuck correctly.
c) Always work from a secure, safe stance.
5.2.3 Electrical safety
a) Before beginning work, check the working area
(e.g. using a metal detector) to ensure that no
concealed electric cables or gas and water pipes
are present. External metal parts of the power tool
may become live, for example, when an electric
cable is damaged accidentally. This presents a
serious risk of electric shock.
b) Check the power tool’s supply cord at regular
intervals and have it replaced by a qualified
specialist if found to be damaged. Check ex-
tension cords at regular intervals and replace
them if found to be damaged. Do not touch the
supply cord or extension cord if it is damaged
while working. Disconnect the supply cord plug
from the power outlet. Damaged supply cords or
extension cords present a risk of electric shock.
c) Dirty or dusty power tools which have been
used frequently for work on conductive materi-
als should be checked at regular intervals at a
Hilti Service Center. Under unfavorable circum-
stances, dampness or dust adhering to the surface
of the power tool, especially dust from conductive
materials, may present a risk of electric shock.
d) When working outdoors with an electric tool
check to ensure that the tool is connected to the
electric supply by way of a ground fault circuit
interrupter (RCD) with a rating of max. 30 mA
(tripping current). Use of a ground fault circuit
interrupter reduces the risk of electric shock.
e) Use of a ground fault circuit interrupter (RCD
residual current device) with a maximum tripping
current of 30 mA is recommended.
5.2.4 Work area
a) Ensure that the workplace is well lit.
b) Ensure that the workplace is well ventilated.
Exposure to dust at a poorly ventilated workplace
may result in damage to the health.
c) Dust from material such as paint containing lead,
some wood species, minerals and metal may be
harmful. Contact with or inhalation of the dust
may cause allergic reactions and/or respiratory
diseases to the operator or bystanders. Certain
kinds of dust are classified as carcinogenic such
as oak and beech dust especially in conjunction
with additives for wood conditioning (chromate,
wood preservative). Material containing asbestos
must only be treated by specialists. Where the
use of a dust extraction device is possible it
shall be used. To achieve a high level of dust
collection, use a suitable vacuum cleaner of the
type recommended by Hilti for wood dust and/or
mineral dust together with this tool. Ensure that
the workplace is well ventilated. The use of a
dust mask of filter class P2 is recommended.
Follow national requirements for the materials
you want to work with.
d) If the work involves breaking right through, take
the appropriate safety measures at the opposite
side. Parts breaking away could fall out and / or
fall down and injure other persons.
5.2.5 Personal protective equipment
The user and any other persons in the vicinity must
wear suitable eye protection, a hard hat, ear pro-
tection, protective gloves and breathing protection
while the power tool is in use.
en
24

6. Before use
6.1 Fitting and adjusting the side handle 2
1. Disconnect the supply cord plug from the power
outlet.
2. Release the side handle clamping band by turning
the handle counterclockwise.
3. Slide the side handle clamping band over the
chuck and onto the cylindrical section at the front
end of the power tool.
4. Pivot the side handle into the desired position.
5. CAUTION Check that the clamping band is en-
gaged in the groove provided on the power tool.
Secure the side handle by turning the grip clock-
wise.
6.2 Use of extension cords and generators or
transformers
Please refer to section 2 “Description”.
7. Operation
CAUTION
In accordance with the applications for which it is
designed, the power tool produces a high torque.
Always use the side handle and hold the power
tool with both hands. The user must be prepared for
sudden sticking and stalling of the insert tool.
CAUTION
Use clamps or a vice to hold the workpiece securely.
CAUTION
The collar at the front end of the gearing section is
not to be used as a gripping surface.
7.1 Preparing for use
CAUTION
Wear protective gloves when changing insert tools
as the insert tools get hot during use.
7.1.1 Fitting the insert tool 3
1. Disconnect the supply cord plug from the power
outlet.
2. Check that the connection end of the insert tool is
clean and lightly greased. Clean it and grease it if
necessary.
3. Check that the sealing lip of the dust shield is
clean and in good condition. Clean the dust shield
if necessary or have it replaced if the sealing lip
is damaged.
4. Push the insert tool into the chuck and rotate it
while applying slight pressure until it engages in
the guide grooves.
5. Push the insert tool further into the chuck until it
is heard to engage.
6. Check that the insert tool has engaged correctly
by pulling it.
7.1.2 Removing the insert tool 4
1. Disconnect the supply cord plug from the power
outlet.
2. Open the chuck by pulling back the insert tool
locking sleeve.
3. Pull the insert tool out of the chuck.
7.2 Operation
CAUTION
Working on the material may cause it to splinter.
Wear eye protection and protective gloves. Wear
breathing protection if no dust removal system is
used. Splintering material presents a risk of injury to
the eyes and body.
CAUTION
The work generates noise. Wear ear protectors.
Exposure to noise can cause hearing loss.
en
25

CAUTION
Switch the power tool on only after bringing it into
the working position.
CAUTION
Do not operate the function selector switch while
the motor is running.
7.2.1 TPS theft protection system (optional)
NOTE
The power tool may be equipped with the optional
theft protection system. If the power tool is equipped
with this feature, it can be unlocked and made ready
for operation only through use of the corresponding
TPS key.
7.2.1.1 Unlocking the power tool 5
1. Plug the supply cord into the power outlet. The
yellow theft protection indicator LED blinks. The
power tool is now ready to receive the signal from
the TPS key.
2. Hold the TPS key against the lock symbol. The
power tool is unlocked as soon as the yellow theft
protection indicator LED no longer lights.
NOTE If, for example, the electric supply is briefly
interrupted due to a power failure or disconnected
when moving to a different workplace, the power
tool remains ready for operation for approx. 20
minutes. In the event of a longer interruption, the
TPS key must be used again to unlock the power
tool.
7.2.1.2 Activation of the theft protection system
for the power tool
NOTE
Further detailed information on activation and use
of the theft protection system can be found in the
operating instructions for the theft protection system.
7.2.2 Hammer drilling 6
NOTE
Working at low temperatures: The hammering mech-
anism works only when the power tool has reached
a minimum operating temperature. Bring the tip of
the drill bit or chisel into contact with the workpiece
and allow the power tool to run under no load until
it reaches the minimum operating temperature. If ne-
cessary, repeat this procedure until the hammering
mechanism begins to operate.
1. Turn the function selector switch until it engages
in the “Hammer drilling” position.
2. Bring the side handle into the desired position
and check that it is fitted correctly and secured.
3. Plug the supply cord into the power outlet.
4. Set the drilling power.
NOTE After connecting the supply cord to the
electric supply, the power tool is always set to full
drilling power.
NOTE To set the power tool to reduced (50%)
drilling power, press the “reduced power” button.
The drilling power LED then lights. To reselect full
drilling power, press the “reduced power” button
again.
5. Position the power tool and drill bit at the point
where the hole is to be drilled.
6. Press the control switch slowly (drill at a low
speed until the drill bit centers itself in the hole).
7. Press the control switch fully to continue working
at full power.
8. Do not apply excessive pressure. This will not in-
crease the power tool’s hammering performance.
Lower pressure extends the life of the insert tool.
9. Reduce drilling speed shortly before breaking
through in order to avoid damage to the surface
at the rear side.
7.2.3 Active Torque Control (TE 80‑ATC/
TE 70‑ATC)
In addition to the mechanical safety clutch, the power
tool is also equipped with the Active Torque Control
system. This system offers additional comfort while
drilling as it causes rapid shutdown upon sudden
rotation of the power tool about the drill bit axis, e.g.
when the drill bit sticks due to hitting a rebar or when
the drill bit is tilted unintentionally. When the torque
control system has become activated, the power tool
can be restarted by releasing the control switch and
re-engaging it after the motor has stopped rotating
(a “click” indicates that the power tool is again ready
for operation). Always choose a working position in
which the electric tool is free to rotate in a clockwise
direction (as seen by the operator). If this rotation is
not possible, the ATC system will be unable to react.
7.2.4 Chiseling 7
NOTE
The chisel can be adjusted to 24 different positions
(in 15° increments). This ensures that flat chisels and
en
26

shaped chisels can always be set to the optimum
working position.
CAUTION
Do not operate the power tool when the selector
switch is set to “Chisel adjustment”.
1. To adjust the position of the chisel, turn the
function selector switch until it engages in the
“Chisel adjustment” position.
2. Bring the side handle into the desired position
and check that it is fitted correctly and secured.
3. Rotate the chisel to the desired position.
4. To lock the chisel in the desired position, turn
the function selector switch until it engages in the
“Chiseling” position. Do not operate the function
selector switch while the motor is running.
5. To begin chiseling, plug the power tool’s supply
cord into the power outlet.
6. Set the desired chisel position.
NOTE After connecting the supply cord to the
electric supply, the power tool is always set to full
chiseling power.
NOTE To set the power tool to reduced (50%)
chiseling power, press the “reduced power” but-
ton. The chiseling power LED then lights. To
reselect full chiseling power, press the “reduced
power” button again.
7. Position the tip of the chisel at the point where
chiseling is to begin.
8. Press the control switch fully.
7.2.5 Drilling without hammering
Drilling without hammering is possible when drill bits
with a special connection end are used. Drill bits of
this kind are available from Hilti. For example, when
the keyless quick-release chuck is fitted, smooth-
shank drill bits for wood or steel can be used to
drill without hammering. The function selector switch
must be set to the “Hammer drilling” position when
the power tool is used in this way.
7.2.6 Control switch lock 8
When chiseling, the control switch can be locked in
the “on” position.
1. Push the control switch lock above the grip for-
ward.
2. Press the control switch fully.
The power tool then operates in sustained mode.
3. To cancel sustained operating mode, slide the
control switch lock to the rear.
The power tool then switches off.
7.2.7 Mixing
1. Turn the function selector switch until it engages
in the “Hammer drilling” position.
2. Insert the quick-release chuck in the power tool’s
chuck.
3. Insert the mixing paddle.
4. Check that the insert tool has engaged correctly
by pulling it.
5. Bring the side handle into the desired position
and check that it is fitted correctly and secured.
6. Plug the supply cord into the power outlet.
7. Position the mixing paddle in the container hold-
ing the substance to be mixed.
8. To begin mixing, press the control switch slowly.
9. Press the control switch fully to continue working
at full power.
10. Guide the mixing paddle carefully in order to avoid
splashing and spillage.
8. Care and maintenance
CAUTION
Disconnect the supply cord plug from the power
outlet.
8.1 Care of insert tools
Clean off dirt and dust deposits adhering to the insert
tools and protect them from corrosion by wiping the
insert tools from time to time with an oil-soaked rag.
8.2 Care of the power tool
CAUTION
Keep the power tool, especially its grip surfaces,
clean and free from oil and grease. Do not use
cleaning agents which contain silicone.
en
27

The outer casing of the power tool is made from
impact-resistant plastic. Sections of the grip are made
from a synthetic rubber material.
Never operate the power tool when the ventilation
slots are blocked. Clean the ventilation slots carefully
using a dry brush. Do not permit foreign objects to
enter the interior of the power tool. Clean the outside
of the power tool at regular intervals with a slightly
damp cloth. Do not use a spray, steam pressure
cleaning equipment or running water for cleaning.
This may negatively affect the electrical safety of the
power tool.
8.3 Service indicator
NOTE
The power tool is equipped with a service indicator.
Indicator Constant red light End of service interval - servicing is due. After the
lamp lights for the first time, the power tool may
continue to be used for several hours before the
automatic cut-out is activated. To ensure that the
power tool is always ready for use, it should be
returned to Hilti for servicing in good time.
Blinking red light See section “Troubleshooting”.
8.4 Maintenance
WARNING
Repairs to the electrical section of the power tool
may be carried out only by trained electrical spe-
cialists.
Check all external parts of the power tool for damage
at regular intervals and check that all controls operate
faultlessly. Do not operate the power tool if parts
are damaged or when the controls do not function
faultlessly. If necessary, the power tool should be
repaired by Hilti Service.
8.5 Checking the power tool after care and
maintenance
After carrying out care and maintenance work on
the power tool, check that all protective and safety
devices are fitted and that they function faultlessly.
9. Troubleshooting
Fault Possible cause Remedy
The power tool doesn’t start. Interruption in the electric supply. Plug in another electric appliance
and check whether it works.
The supply cord or plug is defective. Have it checked by a trained
electrical specialist and replaced if
necessary.
Generator with sleep mode. Apply a load to the generator by
connecting another appliance (e.g.
a lamp). Subsequently switch the
power tool off and on again.
Other electrical fault. Have it checked by a trained
electrical specialist.
The electronic restart interlock is
activated after an interruption in the
electric supply.
Switch the power tool off and on
again.
en
28

Fault Possible cause Remedy
No hammering action. The power tool is too cold. Allow the power tool to warm
up to the minimum operating
temperature.
See section: 7.2.2 Hammer
drilling 6
The power tool doesn’t start
and the LED blinks red.
A fault has occurred in the power
tool.
If necessary, the power tool should
be repaired by Hilti Service.
The power tool doesn’t start
and the LED lights red.
The carbon brushes are worn. Have it checked by a trained
electrical specialist and replaced if
necessary.
The power tool doesn’t start
and the indicator lamp blinks
yellow.
The power tool has not been
unlocked (power tools with optional
theft protection system).
Use the TPS key to unlock the power
tool.
The power tool doesn’t achieve
full power.
The extension cord is too long or its
gauge is inadequate.
Use an extension cord of an
approved length and / or of
adequate gauge.
The control switch is not pressed
fully.
Press the control switch as far as it
will go.
The “Reduced power” (50% power)
button is engaged.
Press the “Reduced power” button.
The voltage provided by the electric
supply is too low.
Connect the power tool to a different
power source.
The drill bit doesn’t rotate. The function selector switch is not
engaged or is in the “Chiseling” or
“Chisel adjustment” position.
Move the function selector switch
to the “Hammer drilling” position
when the motor has stopped.
The drill bit / chisel can’t be
released from the chuck.
The chuck is not pulled back fully. Pull the chuck back as far as it will
go and remove the insert tool.
The side handle is not fitted
correctly.
Release the side handle and refit
it correctly so that the clamping
band and side handle engage in the
groove.
10. Disposal
Most of the materials from which Hilti power tools or appliances are manufactured can be recycled. The
materials must be correctly separated before they can be recycled. In many countries, Hilti has already made
arrangements for taking back your old power tools or appliances for recycling. Please ask your Hilti customer
service department or Hilti representative for further information.
en
29

For EC countries only
Disposal of electric tools together with household waste is not permissible.
In observance of European Directive 2002/96/EC on waste electrical and electronic equipment
and its implementation in accordance with national law, electric tools that have reached the end
of their life must be collected separately and returned to an environmentally compatible recycling
facility.
11. Manufacturer’s warranty - tools
Hilti warrants that the tool supplied is free of defects
in material and workmanship. This warranty is valid
so long as the tool is operated and handled correctly,
cleaned and serviced properly and in accordance with
the Hilti Operating Instructions, and the technical
system is maintained. This means that only original
Hilti consumables, components and spare parts may
be used in the tool.
This warranty provides the free-of-charge repair or
replacement of defective parts only over the entire
lifespan of the tool. Parts requiring repair or replace-
ment as a result of normal wear and tear are not
covered by this warranty.
Additional claims are excluded, unless stringent na-
tional rules prohibit such exclusion. In particular,
Hilti is not obligated for direct, indirect, incidental
or consequential damages, losses or expenses in
connection with, or by reason of, the use of, or
inability to use the tool for any purpose. Implied
warranties of merchantability or fitness for a par-
ticular purpose are specifically excluded.
For repair or replacement, send the tool or related
parts immediately upon discovery of the defect to
the address of the local Hilti marketing organization
provided.
This constitutes Hilti’s entire obligation with regard
to warranty and supersedes all prior or contempor-
aneous comments and oral or written agreements
concerning warranties.
12. EC declaration of conformity
Designation: Combihammer
Type: TE 80‑ATC/ TE 70‑ATC/
TE 70
Year of design: 2007
We declare, on our sole responsibility, that this
product complies with the following directives
and standards: as of 28.12.2009 98/37/EC, as of
29.12.2009 2006/42/EC, 2004/108/EC, EN 55014‑1,
EN 55014‑2, EN 60745‑1, EN 60745‑2‑6,
EN 61000‑3‑2, EN 61000‑3‑11.
Hilti Corporation
Peter Cavada Jan Doongaji
Head of BA Quality and Process
Management
Senior Vice President
Business Area Electric Tools & Ac-
cessories
Business Unit Drilling
and Demolition
11 2007 11 2007
en
30

*236490*
236490
Hilti Corporation
LI-9494 Schaan
Tel.: +423 / 234 21 11
Fax: +423 / 234 29 65
www.hilti.com
Hilti = registered trademark of Hilti Corp., Schaan W 3255 1207 00-Pos. 1 1 Printed in Liechtenstein © 2007
Right of technical and programme changes reserved S. E. & O. 236490 / D
