Hirschmann BXS User manual

Installation BXS
Release 01 04/2022
Technical support
https://hirschmann-support.belden.com
User Manual
Installation
Industrial Ethernet BOBCAT Extended Switch
BXS

2022-04-26 Installation BXS
Release 01 04/2022
The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2022 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at:
https://www.doc.hirschmann.com
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany

Installation BXS
Release 01 04/2022 3
Contents
Important information 5
Safety instructions 7
About this manual 13
Key 14
1 Description 15
1.1 General device description 15
1.2 Device name and product code 16
1.3 Device views 17
1.3.1 Front view 17
1.3.1 View from below 17
1.4 Power supply 19
1.4.1 Supply voltage with the characteristic value BB 19
1.4.2 Supply voltage with the characteristic value QQ 19
1.4.3 Supply voltage with the characteristic value N9 19
1.4.4 Supply voltage with the characteristic value M9 19
1.5 Ethernet ports 20
1.5.1 10/100 Mbit/s twisted pair port 20
1.5.2 10/100/1000 Mbit/s twisted pair port 20
1.5.3 Support of PoE(+) 21
1.6 Pin assignments 22
1.7 Display elements 22
1.7.1 Device status 22
1.7.2 Port status 24
1.8 Management interfaces 25
1.8.1 USB-M12-C interface 25
2 Installation 27
2.1 Checking the package contents 27
2.2 Installing and grounding the device 27
2.2.1 Mounting on a flat surface 27
2.2.2 Grounding the device 28

4Installation BXS
Release 01 04/2022
2.3 Connecting the supply voltage 29
2.4 Operating the device 29
2.5 Connecting data cables 30
3 Making basic settings 31
3.1 First login (Password change) 31
4 Monitoring the ambient air temperature 33
5 Maintenance and service 34
6Disassembly 35
6.1 Removing the device 35
7 Technical data 36
7.1 General data 36
7.2 Supply voltage 36
7.3 Power consumption/power output 39
7.4 Climatic conditions during operation 40
7.5 Climatic conditions during storage 40
7.6 Dimension drawings 41
7.7 Immunity 42
7.8 Electromagnetic compatibility (EMC) 43
7.9 Network range 45
7.9.1 10/100/1000 Mbit/s twisted pair port 45
8 Scope of delivery 46
9 Accessories 47
9.1 General accessories 47
9.2 Order numbers 47
10 Underlying technical standards 48
A Further support 49

Installation BXS
Release 01 04/2022 5
Important information
Note: Read these instructions carefully, and familiarize yourself with the
device before trying to install, operate, or maintain it. The following notes may
appear throughout this documentation or on the device. These notes warn of
potential hazards or call attention to information that clarifies or simplifies a
procedure.
Symbol explanation
This is a general warning symbol. This symbol alerts you to
potential personal injury hazards. Observe all safety notes that
follow this symbol to avoid possible injury or death.
If this symbol is displayed in addition to a safety instruction of the
type “Danger” or “Warning”, it means that there is a danger of
electric shock and failure to observe the instructions will
inevitably result in injury.
This symbol indicates the danger of hot surfaces on the device.
In connection with safety instructions, non-observance of the
instructions will inevitably result in injuries.
DANGER
DANGER draws attention to an immediately dangerous situation, which will
inevitably result in a serious or fatal accident if not observed.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a possible danger which, if not avoided, may result in
minor injuries.

6Installation BXS
Release 01 04/2022
NOTICE
NOTICE provides information about procedures that do not involve the risk
of injury.

Installation BXS
Release 01 04/2022 7
Safety instructions
General safety instructions
You operate this device with electricity. Improper usage of the device
entails the risk of physical injury or significant property damage. The
proper and safe operation of this device depends on proper handling
during transportation, proper storage and installation, and careful
operation and maintenance procedures.
Before connecting any cable, read this document, and the safety
instructions and warnings.
Operate the device with undamaged components exclusively.
The device is free of any service components. In case of a damaged
or malfunctioning device, turn off the supply voltage and return the
device to Hirschmann for inspection.
Certified usage
Use the product only for the application cases described in the
Hirschmann product information, including this manual.
Operate the product only according to the technical specifications.
See “Technical data” on page 36.
Connect to the product only components suitable for the requirements
of the specific application case.
Installation site requirements
Install this device only in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
When you are selecting the installation location, make sure you
observe the climatic threshold values specified in the technical data.
Use the device in an environment with a maximum pollution degree
that complies with the specifications in the technical data.
See “Technical data” on page 36.
WARNING
UNCONTROLLED MACHINE ACTIONS
To avoid uncontrolled machine actions caused by data loss, configure all
the data transmission devices individually.
Before you start any machine which is controlled via data transmission, be
sure to complete the configuration of all data transmission devices.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.

8Installation BXS
Release 01 04/2022
Strain relief
Note: If the strain relief is insufficient, there is a potential risk of torsion,
contact problems and creeping interruptions.
Relieve the connection points of cables and lines from mechanical
stress.
Design strain reliefs in such a way that they help prevent any
mechanical damage to cables, wires or conductors caused by external
influences or their own weight.
To help prevent damage to device connections, connectors and
cables, follow the instructions for proper installation in accordance with
DIN VDE 0100-520:2013-06, sections 522.6, 522.7 and 522.13.
Qualification requirements for personnel
Only allow qualified personnel to work on the device.
Qualified personnel have the following characteristics:
Qualified personnel are properly trained. Training as well as practical
knowledge and experience make up their qualifications. This is the
prerequisite for grounding and labeling circuits, devices, and systems
in accordance with current standards in safety technology.
Qualified personnel are aware of the dangers that exist in their work.
Qualified personnel are familiar with appropriate measures against
these hazards in order to reduce the risk for themselves and others.
Qualified personnel receive training on a regular basis.
Device casing
Only technicians authorized by the manufacturer are permitted to open
the casing.
Shielding ground
The shielding ground of the connectable twisted pair cables is connected
to the ground connection as a conductor.
Beware of possible short circuits when connecting a cable section with
conductive shielding braiding.
Grounding the device
The device is grounded via the separate ground screw.
The grounding screw is located on the front left bottom side of the device.
See “Grounding the device” on page 28.
Ground the device before connecting any other cables.
Disconnect the grounding only after disconnecting all other cables.

Installation BXS
Release 01 04/2022 9
Requirements for connecting electrical wires
Before connecting the electrical wires, always verify that the
requirements listed are complied with.
Requirements for connecting the supply voltage
Before connecting the supply voltage, always verify that the requirements
listed are complied with.
The following requirements apply without restrictions:
The electrical wires are voltage-free.
The cables used are permitted for the temperature range of the application case.
Only use power supply cables that are suitable for a temperature 20 °C (36 °F)
higher than the maximum ambient air temperature at which the device is used.
Only use copper wire.
Prerequisites:
All of the following requirements are complied with:
The supply voltage corresponds to the voltage specified on the type plate of the device.
The power supply has an easily accessible disconnecting device (for example a switch or
a plug). This disconnecting device is clearly identified. So in the case of an emergency, it is
clear which disconnecting device belongs to which power supply cable.
Depending on the supply voltage used, the following additional requirements apply:
Device variants
featuring supply
voltage with
characteristic
value BB
All of the following requirements are complied with:
The power supply complies with the requirements for a safety extra-
low voltage (SELV) according to IEC 60950-1 or ES1 according to
IEC/EN 62368-1.
The wire diameter of the power supply cable is at least 0.5 mm²
(North America: AWG20) on the supply voltage input.
Supply with DC voltage:
There are fuses suitable for DC voltage in the positive conductors of
the supply lines, or the voltage sources are appropriately current-
limited. Regarding the properties of this fuse: See “Technical data”
on page 36.
The negative conductors of the voltage inputs are on ground
potential.
Device variants
featuring supply
voltage with
characteristic
value QQ
All of the following requirements are complied with:
The power supply complies with the requirements for a safety extra-
low voltage (SELV) according to IEC 60950-1 or ES1 according to
IEC/EN 62368-1.
The wire diameter of the power supply cable is at least 0.75 mm²
(North America: AWG18) on the supply voltage input.
Supply with DC voltage:
There are fuses suitable for DC voltage in the positive conductors of
the supply lines, or the voltage sources are appropriately current-
limited. Regarding the properties of this fuse: See “Technical data”
on page 36.
The negative conductors of the voltage inputs are on ground
potential.

10 Installation BXS
Release 01 04/2022
Supply voltage
The supply voltage is connected to the device casing through protective
elements exclusively.
National and international safety regulations
Verify that the electrical installation meets local or nationally applicable
safety regulations.
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):
Device variants
featuring supply
voltage with
characteristic
value M9
All of the following requirements are complied with:
The wire diameter of the power supply cable is at least 0.75 mm²
(North America: AWG18) on the supply voltage input.
Supply with AC voltage:
There are fuses in the supply lines, or the voltage sources are
appropriately current-limited. Regarding the properties of this fuse:
See “Technical data” on page 36.
The power sources are electrically isolated from the ground
potential.
Device variants
featuring supply
voltage with
characteristic
value N9
All of the following requirements are complied with:
The wire diameter of the power supply cable is at least 0.5 mm²
(North America: AWG20) on the supply voltage input.
Supply with DC voltage:
There are fuses suitable for DC voltage in the positive conductors of
the supply lines, or the voltage sources are appropriately current-
limited. Regarding the properties of this fuse: See “Technical data”
on page 36.
The negative conductors of the voltage inputs are on ground
potential.
Device variant Directive
All variants 2011/65/EU and 2015/863/EU (RoHS)
Directive of the European Parliament and of the Council on the
restriction of the use of certain hazardous substances in
electrical and electronic equipment.
2014/30/EU (EMC)
Directive of the European Parliament and of the Council on the
harmonisation of the laws of the Member States relating to
electromagnetic compatibility.
Exclusively for device variants
featuring supply voltage with
characteristic value M9 or N9:
2014/35/EU
Directive of the European Parliament and of the Council on the
harmonisation of the laws of the Member States relating to the
making available on the market of electrical equipment
designed for use within certain voltage limits.
Prerequisites:

Installation BXS
Release 01 04/2022 11
In accordance with the above-named EU directive(s), the EU conformity
declaration will be available to the relevant authorities at the following
address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
You find the EU conformity declaration as PDF file for downloading on the
Internet at: https://www.doc.hirschmann.com/certificates.html
The device can be used in industrial environments.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55032
You find more information on technical standards here:
“Technical data” on page 36
The assembly guidelines provided in these instructions must be strictly
adhered to in order to observe the EMC threshold values.
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take
appropriate measures.
UKCA marking
The labeled devices comply with the following UK regulations:
Device variant Directive
All variants S.I. 2012 No. 3032
Restriction of the Use of Certain Hazardous Substances in
Electrical and Electronical Equipment Regulations
S.I. 2016 No. 1091
Electromagnetic Compatibility Regulations 2016
Exclusively for device variants
featuring supply voltage with
characteristic value M9 or N9:
S.I. 2016 No. 1101
Electrical Equipment (Safety) Regulations 2016

12 Installation BXS
Release 01 04/2022
The UKCA conformity declaration will be available to the relevant
authorities at the following address:
Belden UK Ltd.
1 The Technology Centre, Station Road
Framlingham, IP13 9EZ, United Kingdom
You find the UKCA conformity declaration as PDF file for downloading on
the Internet at: https://www.doc.hirschmann.com/certificates.html
FCC note
Supplier's Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Industrial Ethernet BOBCAT Extended Switch
BXS
U.S. Contact Information
Belden – St. Louis
1 N. Brentwood Blvd. 15th Floor
St. Louis, Missouri 63105, United States
Phone: [phone]
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Recycling note
After usage, this device must be disposed of properly as electronic waste,
in accordance with the current disposal regulations of your county, state,
and country.

Installation BXS
Release 01 04/2022 13
About this manual
The “Installation” user manual contains a device description, safety
instructions, a description of the display, and the other information that you
need to install the device.
Documentation mentioned in the “User Manual Installation” that is not
supplied with your device as a printout can be found as PDF files for
downloading on the Internet at: https://www.doc.hirschmann.com

14 Installation BXS
Release 01 04/2022
Key
The symbols used in this manual have the following meanings:
Listing
Work step
Subheading

Installation BXS
Release 01 04/2022 15
1 Description
1.1 General device description
The device is designed especially robust and thus also meets the special
requirements of railway applications. The device meets the relevant industry
standards, provides very high operational reliability, even under extreme
conditions, and also long-term reliability and flexibility.
The device allows you to set up switched Industrial Ethernet networks
according to standard IEEE 802.3.
The device provides you with a large range of functions, which the manuals
for the operating software inform you about. You can download these
manuals as PDF files from the Internet at: https://www.doc.hirschmann.com

16 Installation BXS
Release 01 04/2022
1.2 Device name and product code
The device name corresponds to a product code. The product code
represents specific product properties.
The product code is made up of characteristics with defined positions. The
characteristic values stand for specific product properties.
Order number Device name Product code
942 302-001 BXS30-12TX-EECC-LV-2A BXS30-000804-EBB...
942 302-002 BXS30-12TX-EECC-HV-2A BXS30-000804-EN9...
942 302-003 BXS32-12TX-EECC-LV-2A BXS32-000804-EQQ...
942 302-004 BXS32-12TX-EECC-HV-2A BXS32-000804-EN9...
942 302-005 BXS40-12TX-EECC-LV-2A BXS40-000012-EBB...
942 302-006 BXS40-12TX-EECC-HV-2A BXS40-000012-EN9...
942 302-007 BXS42-12TX-EECC-LV-2A BXS42-000012-EQQ...
942 302-008 BXS42-12TX-EECC-HV-2A BXS42-000012-EN9...
Table 1: Order number, device name and product code
Item Characteristic Characteri
stic value
Description
1 ... 3 Product BXS Industrial Ethernet BOBCAT Extended Switch
4 Data rate 3 Fast Ethernet ports and Gigabit Ethernet ports
4 Gigabit Ethernet ports
5 Hardware type 0 Standard
2 Standard with PoE(+)
6 (hyphen) –
7 ... 8 Reserved 00 Reserved
9 ... 10 Number
Fast Ethernet ports
00 0 × Fast Ethernet ports
08 8 × Fast Ethernet ports
11 ... 12 Number
Gigabit Ethernet ports
04 4 × Gigabit Ethernet ports
12 12 × Gigabit Ethernet ports
13 (hyphen) –
14 Temperature range S Standard 0 °C ... +60 °C
(+32 °F ... +140 °F)
T Extended -40 °C ... +70 °C
(-40 °F ... +158 °F)
E Extended
with
Conformal
Coating
-40 °C ... +70 °C
(-40 °F ... +158 °F)
15 ... 16 Supply voltage BB Rated voltage 24 V DC
QQ Rated voltage range 24 V DC ... 48 V DC
N9 Rated voltage range 72 V DC ... 110 V DC
M9 Rated voltage range 110 V AC ... 230 V AC
Table 2: Product code

Installation BXS
Release 01 04/2022 17
1.3 Device views
1.3.1 Front view
1 Supply voltage connection 5-pin, “K”- or “L”-coded M12 plug
2 4 × 10/100/1000 Mbit/s twisted pair port
These ports support full duplex only.
For PoE device variants: The ports 2,
3, 4 support PoE (PoE+).
8-pin, “X”-coded M12 socket
3 depending on the device variants
BXS3...
8 × 10/100 Mbit/s twisted pair port
For PoE device variants: These ports
support PoE (PoE+).
4-pin, “D”-coded M12 socket
BXS4...
8 × 10/100/1000 Mbit/s twisted pair
port
For PoE device variants: These ports
support PoE (PoE+).
8-pin, “X”-coded M12 socket
4 LED display elements for port status
5 Grounding screw
6 LED display elements for device status
7 USB-M12-C interface 5-pin, “A”-coded M12 socket
Table 3: Front view
2
1
3
4
5
6
7
1
2
3
4
5
6
7
8
9
10
11
12

18 Installation BXS
Release 01 04/2022
1.3.2 View from below
1 ... 2 Slot hole for mounting on a flat surface
Table 4: View from below
1
2

Installation BXS
Release 01 04/2022 19
1.4 Power supply
1.4.1 Supply voltage with the characteristic value BB
The following options for power supply are available:
5-pin, “L”-coded M12 plug
You will find information on connecting the supply voltage here:
See “Connecting the supply voltage” on page 29.
1.4.2 Supply voltage with the characteristic value QQ
The following options for power supply are available:
5-pin, “L”-coded M12 plug
You will find information on connecting the supply voltage here:
See “Connecting the supply voltage” on page 29.
1.4.3 Supply voltage with the characteristic value N9
The following options for power supply are available:
5-pin, “K”-coded M12 plug
You will find information on connecting the supply voltage here:
See “Connecting the supply voltage” on page 29.
1.4.4 Supply voltage with the characteristic value M9
The following options for power supply are available:
5-pin, “K”-coded M12 plug
You will find information on connecting the supply voltage here:
See “Connecting the supply voltage” on page 29.

20 Installation BXS
Release 01 04/2022
1.5 Ethernet ports
You can connect end devices and other segments to the device ports using
twisted pair cables.
1.5.1 10/100 Mbit/s twisted pair port
This port is a 4-pin, “D”-coded M12 socket.
The 10/100 Mbit/s twisted pair port allows you to connect network
components according to the IEEE 802.3 10BASE-T/100BASE-TX standard.
This port supports:
Autonegotiation
Autopolarity
Autocrossing
10 Mbit/s half-duplex mode, 10 Mbit/s full duplex mode
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
Delivery state: Autonegotiation activated
The port casing is electrically connected to the front panel.
The pin assignment corresponds to MDI-X.
1.5.2 10/100/1000 Mbit/s twisted pair port
This port is an 8-pin, “X”-coded M12 socket.
The 10/100/1000 Mbit/s twisted pair port allows you to connect network
components according to the IEEE 802.3 10BASE-T/100BASE-TX/
1000BASE-T standard.
This port supports:
Autonegotiation
Autopolarity
Autocrossing
10 Mbit/s half-duplex mode, 10 Mbit/s full duplex mode
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
1000 Mbit/s full duplex
Delivery state: Autonegotiation activated
The port casing is electrically connected to the front panel.
The pin assignment corresponds to MDI-X.
Note: The twisted pair ports 1 ... 4 support full duplex only.
See “Front view” on page 17.
