Hisense 55A6BG User manual

English
ES-A214414-1
QUICK SETUP GUIDE
Before using the TV, please read this guide thoroughly and
retain it for future reference.

A
Declaration
Declaration
Any content and service accessed through this device, while only intended for
individual non-commercial use, shall be the property of the applicable third party and
subject to protection by regulations and laws on copyright, patent, trademark and
other intellectual property rights. No part of such content and service may be modified,
duplicated, published, uploaded, distributed, translated, marketed, or used to make and
distribute products derived from it without the prior permission of the content owner or
service provider.
You acknowledge and agree explicitly that you will solely bear the risk associated with
the use of this device, and further you will solely bear any risk related to satisfactory
quality, performance and accuracy for any content and service accessed through
this device. To the maximum extent permitted by applicable law, this device and any
third party’s content and service is provided as it is without any guarantee, express or
implied.
Manufacturer hereby declare explicitly that Manufacturer shall not be held liable for any
guarantee and conditions, express or implied, related to this device and any content
and service, including but not limited to warranty on marketability, satisfactory quality,
fitness for a particular purpose, accuracy, quiet use and non-violation of any third
party’s rights; to the maximum extent permitted by applicable law, Manufacturer gives
no guarantee on the accuracy, validity, timeliness, legitimacy and completeness of any
content or service provided through this device, or the fitness of such device, content
or service for your particular requirement, or the protection from interruption and error
during operation of such device, content or service; to the maximum extent permitted
by applicable law, in any case, including fault or neglect, Manufacturer shall not be held
liable for legal actions or indemnity obligation arising from any consequence as a result
of or related to any information loaded in this device or use of such device, content or
service by you or any third party.
Any content and service provided as it is together with this device shall be the property
of the applicable third party, therefore Manufacturer gives no declaration or warranty
on modification, suspension, cancellation, termination or abortion thereof, and shall not
be held liable for legal actions or indemnity obligation arising thereof.
Manufacturer reserves the rights to restrict the use or access of certain content or
service. As the content and service are transmitted through third party’s network and
transmission facilities, Manufacturer undertakes no customer service thereof or the
obligation for such customer service.

B
Important Safety Precautions
This symbol alerts user about the
presence of a dangerous voltage not
isolated inside the product which can
be sufficiently powerful to constitute a
risk of electrocution.
This symbol alerts user about the
presence of important operating
instructions and maintenance in the
document enclosed in the package.
Disposal of Used Electrical & Electronic Equipment
ATTENTION
RISK OF SHOCK
ELECTRIC
Packaging and electrical goods should be recycled appropriately, and
not treated as household waste. Please dispose of this equipment at
your applicable collection point for the recycling of electrical & electronic
equipment waste. By ensuring the correct disposal of this product,
you will help prevent potentially hazardous to the environment and to
human health, which could otherwise be caused by unsuitable waste
handling of this product. The recycling of materials will help conserve
natural resources. Please do not therefore dispose of your old electrical
and electronic equipment with your household waste. For more detailed
information about recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you
purchased the product.
Do not open the back cover.
In no case the user is allowed to operate
inside the TV set. Only a qualified
technician is entitled to operate.
Class II product: This symbol indicates that it does not require a safety
connection of protective earthing (ground).
AC voltage: This symbol indicates that the rated voltage marked with the
symbol is AC voltage.

C
Important Safety Precautions
Warning
Never place a television set in an unstable location. A television set may fall, causing
serious personal injury or death. Many injuries, particularly to children, can be avoided
by taking simple precautions such as:
Using stands recommended by the manufacturer of the television set.
Only using furniture that can safely support the television set.
Ensuring the television set is not overhanging the edge of the supporting furniture.
Not placing the television set on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the television set to a suitable
support.
Not placing the television set on cloth or other materials that may be located
between the television set and supporting furniture.
Educating children about the dangers of climbing on furniture to reach the television
set or its controls.
If your existing television set is being retained or relocated, the same considerations
as above should be applied.

D
Important Safety Precautions
Safeguards
Please read the following safeguards for your TV and retain for future reference.
Always follow all warnings and instructions marked on the television.
1. A note about safety and operating instructions
Read and follow all safety and operating instructions, and retain them safely for future
reference.
2. Heed Warnings
Adhere to all warnings on the appliance and in the operating instructions.
3. Cleaning
Unplug the TV from the wall outlet before cleaning. Do not use liquid, abrasive, or
aerosol cleaners. Cleaners can permanently damage the cabinet and screen. Use a
lightly dampened cloth for cleaning.
4. Wall Mount Bracket
Wall mount bracket is only available for some models. If wall mount bracket is not
supplied with this product, you can buy it at the local market.
Please refer to the installing the wall mount bracket page of Quick Setup Guide for
dimensions.
5. Water and Moisture
Avoid dripping or splashing of liquids onto the product. Objects filled with liquids, such
as vases, should not be placed on the product.
6. Setting
Do not place this TV on an unstable cart, stand or table. Placing the TV on an unstable
base can cause the TV to fall, resulting in serious personal injuries as well as damage
to the TV. Use only a cart, stand, bracket or table recommended by the manufacturer
or salesperson.
7. Ventilation
Slots and openings in the cabinet are provided for ventilation, to ensure reliable
operation of the TV and to protect it from overheating. Do not cover the ventilation
openings in the cabinet and never place the set in a confined space such as built-in
cabinet unless proper ventilation is provided. Leave a minimum 10cm gap all around
the unit, the rear of the TV should be 6cm away from the wall.
8. Power Source
This TV should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supplied to your home, consult
your appliance dealer or local power company.

E
Important Safety Precautions
9. Power-Cord Protection
Power- supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at
plug, wall outlets, and the point where they exit from the TV. MAIN plug is used as the
disconnect device, the disconnect device shall remain readily operable.
10. Lightning
For added protection for this TV during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the TV due to lightning or power-
line surge.
11. Power Lines
An outside antenna system should not be located in the vicinity of overhead power
lines or other electric light or power circuits, or where it can fall into such power lines or
circuits. While installing an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them might be fatal.
12. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or
electric shock.
13. Object and Liquid Entry
Never push objects of any kind into this TV through openings as they may touch
dangerous voltage points or short-out parts that could result in fire or electric shock.
Never spill liquid of any kind on or into the TV.
14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the TV, be sure the antenna or
cable system is grounded so as to provide some protection against voltage surges and
built-up static charges.
15. Servicing
Do not attempt to service this TV yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service
personnel.
16. Damage Requiring Service
Unplug the TV from the wall outlet and refer servicing to qualified service personnel
under the following conditions:
(a) When the power - supply cord or plug is damaged.
(b) If liquid has been spilled, or objects have fallen into the TV.
(c) If the TV has been exposed to rain or water.

F
Important Safety Precautions
To fully disconnect the TV, remove power plug from wall socket. Be sure
to have the wall socket and power plug readily accessible.
Do not mix and use new batteries with old batteries, or batteries with
different types. Do not expose batteries to heat such as direct sunlight or
fire. Make sure the batteries' positive and negative ends are facing the
correct direction.
The device should not be exposed to dripping and spraying and it cannot
be placed under objects filled with liquids.
(d) If the TV does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive
work by a qualified technician to restore the TV to its normal operation.
(e) If the TV has been dropped or the cabinet has been damaged.
(f) When the TV exhibits a distinct change in performance - this indicates a need for
service.
17. Replacement Parts
When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as
the original part. Unauthorised substitutions may result in fire, electric shock or other
hazards.
18. Safety Check
Upon completion of any service or repair to the TV, ask the service technician to
perform safety checks to determine that the TV is in safe operating condition.
19. Heat
The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that produce heat.
20. Fire
The product should be situated away from naked flame sources such as lighted candle.
21. Off-gassing
The TV smells of plastic is normal and will dissipate over time.

1
Contents
Contents
Accessories List
The following accessories are included with TV:
Figures and illustrations in this manual are provided for reference only and
may di󰀨er from actual product appearance.
Parts of the software function changes with the system upgrade.
Accessories List..............................................................................................................1
Installing the Stand or Wall mount bracket .....................................................................2
TV Front..........................................................................................................................5
TV Rear ..........................................................................................................................6
Making Connections.......................................................................................................8
Remote Control ............................................................................................................11
Turning the TV on for the First Time.............................................................................16
Specifications ...............................................................................................................17
Other Information..........................................................................................................20
Quick Setup Guide × 1 Screw × 4 Base Stand × 2
AAA Battery × 2 Remote Control × 1 Power Cord × 1
RCA jack to AV Cable × 1 (65")
NOTE
The accessories may be di󰀨erent from the list above due to di󰀨erent models, countries /
regions. Please refer to the actual accessory bag.

2
Installing the Stand or Wall mount bracket
1. Carefully place your TV face-down on a soft, flat surface to prevent damage to the
TV or scratching to the screen.
2. Take out the 2 stands from the accessory bag and then insert the stands into the
bottom slots of the TV.
3. Secure the stands to the TV with the 4 screws in accessory tightly.
Installing the stand
CAUTION
Be sure to disconnect the AC power cord before installing a stand or wall mount
brackets.
The display on your TV is fragile. Make sure the TV screen is not scratched or
damaged by hard objects or from pressure.
After the installation is completed, make sure the TV is steady on a table or firmly
attached to a wall mount, before removing all protective film, if any.
Follow the illustrations and textual instructions below to complete the installation steps:
Follow the illustrations and textual instructions below to complete the installation steps:
Screws:
M4×16 (43")
M4×12 (50"/55")
Base Stand
1. Carefully place your TV face-up on a soft, flat surface to prevent damage to the TV
or scratching to the screen.
2. Take out the 2 stands from the accessory bag and then insert the stands into the
bottom slots of the TV.
3. Secure the stands to the TV with the 4 screws in accessory tightly.
43"/50"/55"
58"

3
Installing the Stand or Wall mount bracket
1. Carefully place your TV face-down on a soft, flat surface to prevent damage to the
TV or scratching to the screen.
2. Take out the 2 stands from the accessory bag and then insert the stands into the
bottom slots of the TV.
3. Secure the stands to the TV with the 4 screws in accessory tightly.
Follow the illustrations and textual instructions below to complete the installation steps:
Base Stand Screws: M4×12
65"
Note: If your table is long enough to place the TV on top of, then insert the base stands into
the screw holes ‘A’ that are shown in the illustration. If your table is NOT long enough, then
insert the base stand into the screw holes ‘B’ that are shown in the illustration. Note that
these two installation methods types cannot be mixed.
Screws:
M5×12
Base Stand
A
A
Base Stand
B
B
Screws:
M5×12

4
Installing the Stand or Wall mount bracket
8.0 -10.0 mm (43"/50"/55"/58")
9.5 - 11.5 mm (65")
Wall mount hole pattern (mm) 200 × 300 (43"/50"/55"/58")
400 × 300 (65")
Wall mount screw size M6
Wall Mount Bracket
Wall Mount Screw
Wall Mount Spacer
Rear cover of the TV
Installing the wall mount bracket
CAUTION
When mounting the TV on a wall, follow instructions provided with the wall mount bracket. If
it is not correctly mounted, the TV may fall and cause property damage or personal injury.
NOTES
The diameter and length of the screws differ depending on the wall mount bracket
model.
Wall mount bracket is optional. Your TV may not have wall mount bracket. Please
refer to the actual accessories.
Before mounting the TV, remove the TV stand if you have already attached it, and make
sure the wall mount bracket supports the weight of your TV.
Place spacers between the TV and bracket.
Standard dimensions are shown below.
We do not recommend hanging the TV on a slanted wall, and
when wall mounting make sure your television remains parallel to
the wall and does not lean forward. TV
screen
Vertical
surface

5
TV Front
TV Front
NOTES
The Picture is Only for Reference.
Powering on the TV requires several seconds to load programmes. Do not rapidly
turn the TV off as it may cause the TV work abnormally.
Remote sensor/Power indicator/Single button (Standby/Source)
Item Description
Remote sensor
Receive remote signals from the remote control.
Do not put anything near the sensor, as its function may be
affected.
Power indicator The light is red in standby mode.
Standby / Source
Press the single button when in standby mode, and the TV will
be turned on.
Press the single button to call up the menu. When the focus is
on "Power Off", wait for 3 seconds, and then the TV will go into
standby mode automatically.
Press the single button to call up the menu, and then select
among the different input signal sources.

6
TV Rear
TV Rear
NOTES
For 43", ANT2 Jack supports power supply for satellite antenna
(13/18V, 420mA max.)
For 50"/55"/58", ANT2 Jack supports power supply for satellite
antenna (13/18V, 0.5A max.)
Check the jacks for position and type before making any
connections. Loose connections can result in image or colour
problems. Make sure that all connections are tight and secure.
Not all A/V devices have the ability to connect to a TV, please
refer to the user’s manual of your A/V device for compatibility
and connections procedure.
Before connecting external equipment, remove the mains plug
from the wall socket. Otherwise, it may cause electric shock.
Service jack is not available for you to connect an external
device. It can only be used by our factory for testing purposes.
AC INPUT
420mA
50"/55"/58"
43"
43"/50"/55"/58"

7
TV Rear
TV Rear
NOTES
ANT2 Jack supports power supply for satellite antenna (13/18V,
0.5A max.)
Check the jacks for position and type before making any
connections. Loose connections can result in image or color
problems. Make sure that all connections are tight and secure.
Not all A/V devices have the ability to connect to a TV, please
refer to the user’s manual of your A/V device for compatibility
and connections procedure.
Before connecting external equipment, remove the mains plug
from the wall socket. Otherwise, it may cause electric shock.
Service jack is not available for you to connect an external
device. It can only be used by our factory for testing purposes.
65"
AC INPUT

8
Making Connections
Wireless router with DHCP
LAN Cable
Wireless LAN Adapter
built-in TV set
TV JACK
Modem Cable
LAN CableLAN Cable
External Modem
(ADSL / VDSL / Cable TV)
IP Sharer (Router)
(with DHCP server)
NOTES
You must use the built-in Wireless LAN Adapter to use a wireless network because
the set doesn’t support external USB network adapters.
If the wireless router supports DHCP, your TV can connect more easily to the wireless
network.
If you apply a security system other than the systems listed below, it will not work with
the TV.
Security system: WPA, WEP, WPA2.
In order to guarantee smooth network, the distance between router and TV should be
less than 10 metres.
Wireless setup
To connect your TV to your network wirelessly, you need a wireless router or
modem. See the illustration below.
·The built-in Wireless LAN Adapter supports the IEEE 802.11b/g/n (43"/50"/58")
/ IEEE 802.11a/b/g/n/ac (55"/65") communication protocols. It is recommended
to use IEEE 802.11n router. Low transfer rates for b/g may have the influence
on the quality of streamed videos and other media.
LAN (Wired setup)
Connect your TV to your network by connecting the LAN port on the back of your
TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the
illustration below.
·It is recommended to use a modem or router that supports Dynamic Host
Configuration Protocol (DHCP). Modems and routers that support DHCP
automatically provide the IP address, subnet mask, gateway, and DNS, so you
don’t have to enter them manually. Most home networks already have DHCP.

9
Making Connections
Outdoor
Antenna
Antenna Cable (75Ω)
or ANT OUT
Cable
VHF/UHF Antenna
Satellite antenna
ANT 1
DVB-T/T2/C
ANT 2
DVB-S/S2
DIGITAL AUDIO cable (not included)
Audio Amplier/Speaker
ANT
AV IN
DIGITAL
AUDIO OUT
HDMI
HDMI
(ARC)
HDMI
HDMI cable (not included)
HDMI cable (not included)
HDMI
Audio Amplier/Speaker
HDMI
DVD/Blu-Ray/AV receiver/
Set-top Box
(not included)
(not included)
DIGITAL
AUDIO OUT
HDMI (ARC)
HDMI
White(L)
Red(R)
Yellow(Video)
VCR/DVD Player/
Recorder/Set-top box/
Satellite Receiver/
Video Camera
Video L
A/V OUT
R
(not included)
(not included)
(not included)
White(L)
Red(R)
Yellow(Video)
VCR/DVD Player/
Recorder/Set-top box/
Satellite Receiver/
Video Camera
Video L
A/V OUT
R
AV IN
(not included)
(not included)
(not included)
43"/50"/55"/58"
65"

10
Making Connections
NOTES
Before you insert/remove the CI+ module, ensure that the TV
is switched off. Then insert the CI card into the CI+ module in
accordance with the Service Provider's instructions.
Do not repeatedly insert or remove the Common Access
Module as this may damage the interface and cause a
malfunction.
You must obtain a CI+ module and card from the service
provider of the channels you want to watch.
Insert the CI+ module with the SmartCard in the direction
marked on the module and SmartCard.
CI+ is not supported in some countries and regions; check with
your authorized dealer.
COMMON
INTERFACE
USB
Headphone (not included)
NOTE
Excessive sound pressure from earphones and headphones
can cause hearing loss.
HEADPHONE
HEADPHONE
SMART CARD
CAM CARD
12
USB
DC 5V 0.5A(MAX)
NOTES
When connecting a hard disk or a USB hub, always connect
the mains adapter of the connected device to the power
supply. Exceeding a total current consumption may result in
damage. The USB 1.1 and USB 2.0 devices maximum current
consumption are 500mA.
For individual non-standard high-capacity mobile hard disk, if
its impulse current is greater than or equal 1A, it may cause
TV-rebooting or self-locking. So the TV does not support it.
The USB port supports a voltage of 5V.

11
Remote Control
NOTE: The included remote control will vary depending on model, countries/regions.
Check information according to the actual remote control in the accessory bag.
1INPUT: Select input sources
2POWER: Switch the TV on or into standby mode
3Number button: Direct channel selection or
numbers input
4GUIDE: Display the Electronic Programme Guide
(DTV mode)
5CH.LIST: Display the Channel List on the screen
6Special function buttons
7: Display the Quick setup menu
8: Media content control function buttons
9/ / < / >: Allow you to navigate the on-screen
menus and adjust the system settings to your
preference
10 OK: Confirm the selection in the on-screen menus
11 BACK: Return to previous menu
12 EXIT: Exit the menu
13 HOME: Enter the Home screen
14 VOL +/-: Adjust the volume
15 CH / : Switch channel
16 MIC: Activate the microphone
17 SUBTITLE: Activate or deactivate the subtitle
mode
18 INFO: Display the present programme information
TEXT: Turn on/off the teletext function
19 MUTE: Mute or restore the TV sound
20 APP: Quick access to the app
: Custom button to launch input or apps quickly
21 APP: Quick access buttons to apps
MEDIA: Enter the media mode
: All Apps
BROWSER: Enter into BROWSER
20
21
1
45
7
11
15
14
2
8
10
12
16
19
9
6
13
17 18
3

12
NOTE: The included remote control will vary depending on model, countries/regions.
Check information according to the actual remote control in the accessory bag.
12
3
45
6
7
89
10
11 12
13
14
1: Switch the TV on or into standby mode
2INPUT: Select input sources
3: Activate the microphone
4: Media content control function buttons
5: Enter Channels / input numbers and special
function buttons (Red/Green/Yellow/Blue)
6/ / < / >: Allow you to navigate the on-screen
menus and adjust the system settings to your
preference
7OK: Confirm the selection in the on-screen menus
8: Return to previous menu
9: Display the Quick setup menu
10 : Enter the Home screen
11 VOL / : Adjust the volume
12 CH / : Switch channel
13 : Mute and restore sound
14 APP: Quick access buttons to apps
MEDIA: Enter the media mode
Remote Control

13
Remote Control
1
4
6
7
11
14
17
20
19
3
9
2
5
8
12
15
18
13
10
16
NOTE: The included remote control will vary depending on model, countries/regions. Check
information according to the actual remote control in the accessory bag.
1POWER: Switch the TV on or into standby mode
2INPUT: Select input sources
3Number button: Direct channel selection or
numbers input
4GUIDE: Display the Electronic Programme Guide
(DTV mode)
5CH.List: Display the Channel List on the screen
6Special function buttons
7: Display the Quick setup menu
8: Media content control function buttons
9/ / < / >: Allow you to navigate the on-screen
menus and adjust the system settings to your
preference
10 OK: Confirm the selection in the on-screen menus
11 BACK: Return to previous menu
12 EXIT: Exit the menu
13 HOME: Enter the Home screen
14 VOL +/-: Adjust the volume
15 CH / : Switch channel
16 MUTE: Mute or restore the TV sound
17 TXT/TEXT: Turn on/off the teletext function
18 INFO: Display the present programme information
19 SUBTITLE: Activate or deactivate the subtitle
mode
20 APP: Quick access buttons to apps
MEDIA: Enter the media mode
/: All Apps
BROWSER: Enter into BROWSER
