Hitachi RCI-1.0FSN3E User manual
RPI-(8.0-10.0)FSN3E
INSTALLATION AND OPERATION MANUAL
MANUAL DE INSTALACIÓN Y FUNCIONAMIENTO
INSTALLATIONS- UND BETRIEBSHANDBUCH
MANUEL D’INSTALLATION ET DE FUNCTIONNEMENT
MANUALE D’INSTALLAZIONE E D’USO
MANUAL DE INSTALAÇÃO E DE FUNCIONAMENTO
BRUGER- OG MONTERINGSVEJLEDNING
INSTALLATIE- EN BEDIENINGSHANDLEIDING
HANDBOK FÖR INSTALLATION OCH ANVÄNDING
ΕΓΧΕΙΡΙΔΙΟΕΓΚΑΤΑΣΤΑΣΗΣΚΑΙΛΕΙΤΟΥΡΓΙΑΣ
INDOOR UNITS SYSTEM FREE
RCI-(1.0-6.0)FSN3E / P-N23NA
PMML0231A rev. 0 - 02/2011 Printed in Spain
PMML0231A rev. 0 - 02/2011 INDOOR UNITS SYSTEM FREE - RCI-(1.0-6.0)FSN3E
4 - way cassette
Check, depending on the name of the model, the type of air condi-
tioning system tted, the abbreviated code and reference in this in-
struction manual. This Installation and Operating Manual only refers
to RCI-(1.0-6.0)FSN3E units.
The text following this symbol contains information and instruc-
tions relating directly to your safety and physical wellbeing.
Not taking these instructions into account could lead to serious,
very serious or even fatal injuries to you and others in the prox-
imities of the unit.
The text following this symbol contains information and instruc-
tions relating directly to your safety and physical wellbeing.
Not taking these instructions into account could lead to minor
injuries to you and others in the proximities of the unit.
Not taking these instructions into account could lead to unit
damage.
The text following this symbol contains information or instruc-
tions that may be of use or that require a more thorough expla-
nation.
Instructions regarding inspections to be made on unit parts or
systems may also be included.
HITACHI is not able to foresee all the circumstances which may
result in a potential danger.
Do not pour water in the indoor or outdoor unit. These products
are tted with electric components. If water comes into contact
with electric components, this will cause a serious electric shock.
Do not handle or adjust the safety devices inside the indoor and
outdoor units. The handling or adjustment of these devices may
result in serious accident.
Do not open the service cover or access panel of the indoor and
outdoor units without disconnecting the main supply.
In the event of re, switch off the mains, put out the re immedi-
ately and contact your service supplier.
Check that the earth cable is correctly connected.
Connect the unit to a circuit breaker of the specied capacity.
Refrigerant leaks may hinder respiration as the gas displaces the
air in the room.
Fit the indoor unit, the outdoor unit, the remote control and the
cable at a minimum of 3 metres away from sources of strong ra-
diation from electromagnetic waves, such as medical equipment.
Do not use sprays, such as insecticides, varnishes or enamels or
any other inammable gas within a metre of the system.
If the circuit breaker or supply fuse of the unit comes on frequent-
ly, stop the system and contact the service suppler.
Do not carry out maintenance or inspection work yourself. This
work must be carried out by qualied service personnel with suit-
able tools and resources for the work.
Do not place any foreign material (branches, sticks, etc.) in the air
inlet or outlet of the unit. These units are tted with high speed
fans and contact with any object is dangerous.
This appliance must be used only by adult and capable people,
having received the technical information or instructions to han-
dle this appliance properly and safely.
Children should be supervised to ensure that they do not play
with the appliance.
The air in the room should be renewed and the room ventilated
every 3 or 4 hours.
The system tter and specialist shall provide anti-leak safety in
accordance with local regulations.
• Check to ensure that the accessories are packed with the indoor unit.
• Do not install the indoor units outdoors. If installed outdoors, an
electric hazard or electric leakage will occur.
• Consider the air distribution from each indoor unit to the space of
the room, and select a suitable location so that uniform air tem-
perature in the room can be obtained. It is recommended that the
indoor units be installed 2.3 to 3 meters from the oor level. If the
unit is installed higher than 3 meters, it is also recommended that
a fan be utilised to obtain uniform air temperature in the room.
• Avoid obstacles which may hamper the air intake or the air dis-
charge ow.
• Pay attention to the following points when the indoor units are
installed in a hospital or other places where there are electronic
waves from medical equipment, etc.
• Do not install the indoor units where electromagnetic wave is directly
radiated to the electrical box, remote control cable or remote control
switch.
• Prepare a steel box and install the remote control switch in it. Pre-
pare a steel conduit tube and wire the remote control cable in it.
Then connect the ground wire with the box and tube.
• Install a noise lter when the power supply emits harmful noises..
• This unit is exclusive non electrical heater type indoor unit. It is
prohibited to install a electrical heater in the eld.
• Mount suspension bolts using M10 (W3/8) as size, as shown below:
• Do not put any foreign material into the indoor unit and check to ensure that none exist in the indoor unit before the installation and test
running. Otherwise a re or failure, etc., may occur.
• Do not install the indoor units in a ammable environment to avoid
a re or an explosion.
• Check to ensure that the ceiling slab is strong enough. If not
strong enough, the indoor unit may fall down on you.
• Do not install the indoor units, outdoor unit, remote control switch
and cable within approximately 3 meters of strong electromag-
netic wave radiators such as medical equipment.
• Do not install the indoor units in a machinery shop or kitchen where
vapor from oil or mist ows to the indoor units. The oil will deposit
on the heat exchanger, thereby reducing the indoor unit performance,
and may deform. In the worst case, the oil damages the plastic parts
of the indoor unit.
• To avoid any corrosive action to the heat exchangers, do not in-
stall the indoor units in an acid or alkaline environment.
• When lifting or moving the indoor unit, use appropriate slings to
avoid damage and be careful not to damage the insulation material
on units surface.
-
-
-
-
-
-
-
-
• If a false ceiling has already been installed, complete all piping and
wiring work inside the ceiling before hooking-up the indoor unit.
• Secure the indoor unit using the nuts, at washers and spring
washers. (These nuts and washers are supplied, 4 pieces each)
-
-
• Do not create an upper-slope or rise for the drain piping, since
drain water will ow back to the unit and leakage to the room will
occur when the unit operation is stopped.
• Do not connect the drain pipe with sanitary or sewage piping or
any other drainage piping.
• When the common drain piping is connected with other indoor
units, the connected position of each indoor unit must be higher
than the common piping. The pipe size of the common drain pipe
must be large enough according to the unit size and number of unit.
• Drain piping will require insulating if the drain is installed in a loca-
tion where condensation forming on the outside of drain pipe may
drop and cause damage. The insulation for the drain pipe must be
selected to insure vapor sealing and prevent condensation form-
ing.
• Drain trap should be installed next to indoor unit. This trap must be
designed to good practice and be checked with water (charged)
and tested for correct ow. Do not tie or clamp the drain pipe and
refrigerant pipe together.
Install drainage in accordance with national and local codes.
-
-
-
-
Pay attention to the thickness of the insulation when the left side
piping is performed. If it is too thick, piping can not be installed in
the unit.
• Turn off the main power switch to the indoor unit and the outdoor
unit before electrical wiring work or a periodical check is per-
formed.
• Check to ensure that the indoor fan and the outdoor fan have
stopped before electrical wiring work or a periodical check is per-
formed.
• Protect the wires, drain pipe, electrical parts, etc. from rats or oth-
er small animals. If not protected, rats may gnaw at unprotected
parts and at the worst, a re will occur.
• Use twisted shielded pair cable or shield pair cable for transmis-
sion wires between the indoor and the outdoor units, and connect
the shielded part to the earth screw in the electrical box of the
indoor unit as shown below.
• Wrap the eld supplied insulation around the wires, and plug the
wiring connection hole with the seal material to protect the prod-
uct from any condensate water or insects.
• Tightly secure the wires with the cord clamp inside the indoor unit.
• Lead the wires through the knockout hole in the side cover when
using conduit.
• Secure the cable of the remote control switch using the cord
clamp inside the electrical box.
1N~ 230V 50Hz
T B1
L1
L2
N
R
S
MP
DSW8
Before setting dips switches, rstly turn off power source and set the
position of the dips switches. If the switches are set without turning
off the power source, the contents of the setting are invalid.
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
The mark n indicates position of dips switches. Figures show set-
ting before shipment or after selection.
• In case that the both indications of the ADDS. (Address) and RN.
(Refrigerant Cycle Number) show AA, the same setting is per-
formed to all the indoor units.
• The indoor units not connected are not indicated.
The Label for checking the contents of the setting is attached to the
holding bracket. Write down the contents of the setting on the label.
When the air panel is unpacked, place it on insulation material, etc.
to protect the sealing insulation from scratches
b
a
cd
• If tighten long screws insufcient, may cause something wrong
as below.
• If any gap has even though tighten long screws sufcient, readjust
the height of indoor unit.
• It’s able to adjust the indoor unit height by using wrench from the
corner pocket.
• Too considerable adjustment of height cause dewing from drain-
pain.
• Do not turn the air louver by hand. If moved, the louver mechanism
would be damaged.
When the corner cover is to be removed after installing the air panel:
Insert a coin or a at-tipped screwdriver into the groove -1- and turn
it gently downwards. Perform the same operation in grooves -2- and
-3-. Lift the corner cover and, once the securing tabs (3 positions)
have been removed, remove it.
Do not use hot water higher than approximately 40ªC
This manual suits for next models
5
Table of contents
Languages:
Other Hitachi Air Conditioner manuals
Hitachi
Hitachi CH Series User manual
Hitachi
Hitachi RAD-50DH7A User manual
Hitachi
Hitachi air core 600 Instruction Manual
Hitachi
Hitachi air Home 600 User manual
Hitachi
Hitachi RAK-18QXA User manual
Hitachi
Hitachi RAS-18GH5 User manual
Hitachi
Hitachi RA-08MF Specification sheet
Hitachi
Hitachi RAS-E18CY(J) User manual
Hitachi
Hitachi RAS-X10CBK User manual
Hitachi
Hitachi RAC-50FPA User manual
Hitachi
Hitachi P-N23NA2 User manual
Hitachi
Hitachi RAK-15QPE User manual
Hitachi
Hitachi RAS-80YH5A User manual
Hitachi
Hitachi RA-20HV User manual
Hitachi
Hitachi RAK-35RPC User manual
Hitachi
Hitachi YUTAKI Series Manual
Hitachi
Hitachi airHome 600 RAK-VH18PHASV User manual
Hitachi
Hitachi RAS-E10CBT User manual
Hitachi
Hitachi RAD-18RPA User manual
Hitachi
Hitachi RAS-60YHA2 User manual
Popular Air Conditioner manuals by other brands
Mitsubishi Electric
Mitsubishi Electric MSZ-DM25VA operating instructions
Cooler Master
Cooler Master Silent Pro Gold 450W user manual
MegaLife
MegaLife NEBULA GREEN R32 Use and Installation Instructions
AirStage
AirStage ASUA7RLAV installation manual
Daikin
Daikin J Series Service manual
Frigidaire
Frigidaire LRA257ST216 installation instructions
Shinco
Shinco SPF1-10C owner's manual
Technibel
Technibel MCAV77C5VAB Technical data & service manual
DeLonghi
DeLonghi EX Series Instructions for use
LG
LG E1823P owner's manual
Trane
Trane Packaged TerminalAir Conditioners & Heat... Installation operation & maintenance
Midea
Midea BREEZELESS Technical manual
