Hitachi YUTAMPO TAW-190NHB User manual

YUTAMPO SERIES
TAW-(190/270)NHB
Indoor unit
INSTALLATION AND OPERATION MANUAL
MANUAL DE INSTALACIÓN Y FUNCIONAMIENTO
INSTALLATIONS- UND BETRIEBSHANDBUCH
MANUEL D’INSTALLATION ET DE FONCTIONNEMENT
MANUALE D’INSTALLAZIONE E D’USO
MANUAL DE INSTALAÇÃO E DE FUNCIONAMENTO
INSTALLATIONS- OG BETJENINGSVEJLEDNING
INSTALLATIE- EN BEDIENINGSHANDLEIDING
INSTALLATION- OCH DRIFTHANDBOK
ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ ΚΑΙ ΛΕΙΤΟΥΡΓΙΑΣ

English
Specications in this manual are subject to change without notice in order that HITACHI may bring the latest innovations
to their customers.
Whilst every effort is made to ensure that all specications are correct, printing errors are beyond HITACHI’s control;
HITACHI cannot be held responsible for these errors.
Español
Las especicaciones de este manual están sujetas a cambios sin previo aviso a n de que HITACHI pueda ofrecer las
últimas innovaciones a sus clientes.
A pesar de que se hacen todos los esfuerzos posibles para asegurarse de que las especicaciones sean correctas, los
errores de impresión están fuera del control de HITACHI, a quien no se hará responsable de ellos.
Deutsch
Bei den technischen Angaben in diesem Handbuch sind Änderungen vorbehalten, damit HITACHI seinen Kunden die
jeweils neuesten Innovationen präsentieren kann.
Sämtliche Anstrengungen wurden unternommen, um sicherzustellen, dass alle technischen Informationen ohne Fehler
veröffentlicht worden sind. Für Druckfehler kann HITACHI jedoch keine Verantwortung übernehmen, da sie außerhalb
ihrer Kontrolle liegen.
Français
Les caractéristiques publiées dans ce manuel peuvent être modiées sans préavis, HITACHI souhaitant pouvoir toujours
offrir à ses clients les dernières innovations.
Bien que tous les efforts sont faits pour assurer l’exactitude des caractéristiques, les erreurs d’impression sont hors du
contrôle de HITACHI qui ne pourrait en être tenu responsable.
Italiano
Le speciche di questo manuale sono soggette a modica senza preavviso afnché HITACHI possa offrire ai propri
clienti le ultime novità.
Sebbene sia stata posta la massima cura nel garantire la correttezza dei dati, HITACHI non è responsabile per eventuali
errori di stampa che esulano dal proprio controllo.
Português
As especicações apresentadas neste manual estão sujeitas a alterações sem aviso prévio, de modo a que a HITACHI
possa oferecer aos seus clientes, da forma mais expedita possível, as inovações mais recentes.
Apesar de serem feitos todos os esforços para assegurar que todas as especicações apresentadas são correctas,
quaisquer erros de impressão estão fora do controlo da HITACHI, que não pode ser responsabilizada por estes erros
eventuais.
Dansk
Specikationerne i denne vejledning kan ændres uden varsel, for at HITACHI kan bringe de nyeste innovationer ud til
kunderne.
På trods af alle anstrengelser for at sikre at alle specikationerne er korrekte, har HITACHI ikke kontrol over trykfejl, og
HITACHI kan ikke holdes ansvarlig herfor.
Nederlands
De specicaties in deze handleiding kunnen worden gewijzigd zonder verdere kennisgeving zodat HITACHI zijn klanten
kan voorzien van de nieuwste innovaties.
Iedere poging wordt ondernomen om te zorgen dat alle specicaties juist zijn. Voorkomende drukfouten kunnen echter
niet door HITACHI worden gecontroleerd, waardoor HITACHI niet aansprakelijk kan worden gesteld voor deze fouten.
Svenska
Specikationerna i den här handboken kan ändras utan föregående meddelande för att HITACHI ska kunna leverera de
senaste innovationerna till kunderna.
Vi på HITACHI gör allt vi kan för att se till att alla specikationer stämmer, men vi har ingen kontroll över tryckfel och kan
därför inte hållas ansvariga för den typen av fel.
Eλλhnika
Οι προδιαγραφές του εγχειριδίου μπορούν να αλλάξουν χωρίς προειδοποίηση, προκειμένου η HITACHI να παρέχει τις
τελευταίες καινοτομίες στους πελάτες της.
Αν και έχει γίνει κάθε προσπάθεια προκειμένου να εξασφαλιστεί ότι οι προδιαγραφές είναι σωστές, η HITACHI δεν
μπορεί να ελέγξει τα τυπογραφικά λάθη και, ως εκ τούτου, δεν φέρει καμία ευθύνη για αυτά τα λάθη.

!CAUTION
This product shall not be mixed with general house waste at the end of its life and it shall be retired according to the
appropriated local or national regulations in a environmentally correct way.
Due to the refrigerant, oil and other components contained in heat pump, its dismantling must be done by a
professional installer according to the applicable regulations. Contact to the corresponding authorities for more
information.
!PRECAUCIÓN
Este producto no se debe eliminar con la basura doméstica al nal de su vida útil y se debe desechar de manera respetuosa con el
medio ambiente de acuerdo con los reglamentos locales o nacionales aplicables.
Debido al refrigerante, el aceite y otros componentes contenidos en la bomba de calor, su desmontaje debe realizarlo un instalador
profesional de acuerdo con la normativa aplicable. Para obtener más información, póngase en contacto con las autoridades competentes.
!VORSICHT
Dass Ihr Produkt am Ende seiner Betriebsdauer nicht in den allgemeinen Hausmüll geworfen werden darf, sondern entsprechend den
geltenden örtlichen und nationalen Bestimmungen auf umweltfreundliche Weise entsorgt werden muss.
Aufgrund des Kältemittels, Öls und anderer Komponenten in der Wärmepumpe muss ihr Ausbau von einem professionellen
Installateur entsprechend der anwendbaren Vorschriften durchgeführt werden. Für weitere Informationen setzen Sie sich bitte mit den
entsprechenden Behörden in Verbindung.
!ADVERTISSEMENT
Ne doit pas être mélangé aux ordures ménagères ordinaires à la n de sa vie utile et qu’il doit être éliminé conformément à la
réglementation locale ou nationale, dans le plus strict respect de l’environnement.
En raison du frigorigène, de l’huile et des autres composants que contient la pompe à chaleur, son démontage doit être effectué par un
installateur professionnel conformément aux règlementations en vigueur.
!AVVERTENZE
Indicazioni per il corretto smaltimento del prodotto ai sensi della Direttiva Europea 2002/96/EC e Dlgs 25 luglio 2005 n.151
Il simbolo del cassonetto barrato riportato sull’ apparecchiatura indica che il prodotto alla ne della propria vita utile deve essere raccolto
separatamente dagli altri riuti.
L’utente dovrà, pertanto, conferire l’apparecchiatura giunta a ne vita agli idonei centri di raccolta differenziata dei riuti elettronici ed
elettrotecnici, oppure riconsegnarla al rivenditore al momento dell’ acquisto di una nuova apparecchiatura di tipo equivalente.
L’adeguata raccolta differenziata delle apparecchiature dismesse, per il loro avvio al riciclaggio, al trattamento ed allo smaltimento
ambientalmente compatibile, contribuisce ad evitare possibili effetti negativi sull’ ambiente e sulla salute e favorisce il riciclo dei materiali
di cui è composta l’ apparecchiatura.
Non tentate di smontare il sistema o l’unità da soli poichè ciò potrebbe causare effetti dannosi sulla vostra salute o sull’ ambiente.
Vogliate contattare l’ installatore, il rivenditore, o le autorità locali per ulteriori informazioni.
Lo smaltimento abusivo del prodotto da parte dell’utente può comportare l’applicazione delle sanzioni amministrative di cui all’articolo 50
e seguenti del D.Lgs. n. 22/1997.
!CUIDADO
O seu produto não deve ser misturado com os desperdícios domésticos de carácter geral no nal da sua duração e que deve ser
eliminado de acordo com os regulamentos locais ou nacionais adequados de uma forma correcta para o meio ambiente.
Por causa do refrigerante, do óleo e de outros componentes na bomba de calor, o desmantelamento deve ser realizado por um instalador
prossional em conformidade com os regulamentos aplicáveis. Contacte as autoridades correspondentes para obter mais informações.
!ADVASEL!
At produktet ikke må smides ud sammen med almindeligt husholdningsaffald, men skal bortskaffes i overensstemmelse med de
gældende lokale eller nationale regler på en miljømæssig korrekt måde.
Da varmepumpen indeholder kølemiddel, olie samt andre komponenter, skal afmontering foretages af en fagmand i overensstemmelse
med de gældende bestemmelser. Kontakt de pågældende myndigheder for at få yderligere oplysninger.
!VOORZICHTIG
Dit houdt in dat uw product niet wordt gemengd met gewoon huisvuil wanneer u het weg doet en dat het wordt gescheiden op een
milieuvriendelijke manier volgens de geldige plaatselijke en landelijke reguleringen.
Wegens de aanwezigheid van koelmiddel, olie en andere componenten in de warmtepomp moet het apparaat volgens de toepasselijke
regelgeving door een professionele installateur worden gedemonteerd. Neem contact op met de betreffende overheidsdienst voor meer
informatie.
!FÖRSIKTIGHET
Det innebär att produkten inte ska slängas tillsammans med vanligt hushållsavfall utan kasseras på ett miljövänligt sätt i enlighet med
gällande lokal eller nationell lagstiftning.
Eftersom värmepumpen innehåller kylmedel, oljor och andra komponenter, måste den demonteras av en behörig installatör i enlighet
med gällande föreskrifter. Ta kontakt med ansvarig myndighet om du vill ha mer information.
!ΠΡΟΣΟΧΗ
Σημαίνει ότι το προϊόν δεν θα πρέπει να αναμιχθεί με τα διάφορα οικιακά απορρίμματα στο τέλος του κύκλου ζωής του και θα πρέπει να
αποσυρθεί σύμφωνα με τους κατάλληλους τοπικούς ή εθνικούς κανονισμούς και με τρόπο φιλικό προς το περιβάλλον.
Λόγω του ψυκτικού, του λαδιού και άλλων εξαρτημάτων που περιλαμβάνονται στην αντλία θέρμανσης, η αποσυναρμολόγησή του
πρέπει να γίνει από εξουσιοδοτημένο επαγγελματία τεχνικό, σύμφωνα με τους ισχύοντες κανονισμούς. Για περισσότερες λεπτομέρειες,
επικοινωνήστε με τις αντίστοιχες αρχές.

MODELS CODIFICATION Important note: Please, check, according to the model name, which is your heat
pump type, how it is abbreviated and referred to in this Instruction Manual. This
Instruction Manual is only related to Indoor Units TAW-(190/270)NHB combined
with Outdoor Units RAW-35NHB or RAM-90NYP5B.
CODIFICACIÓN DE LOS MODELOS Nota importante: compruebe, de acuerdo con el nombre del modelo, el tipo
de bomba de calor, su abreviatura y su referencia en el presente manual de
instrucciones. Este Manual de instalación y funcionamiento sólo está relacionado
con unidades interiores TAW-(190/270)NHB combinadas con unidades exteriores
RAW-35NHB o RAM-90NYP5B.
MODELLCODES Wichtiger Hinweis: Bitte stellen Sie anhand der Modellbezeichnung den Typ
der Wärmepumpe und das entsprechende, in diesem Technischen Handbuch
verwendete Kürzel fest. Dieses Installations- und Betriebshandbuch bezieht sich
nur auf TAW-(190/270)NHB Innengeräte kombiniert mit den Außengeräten
RAW-35NHB oder RAM-90NYP5B.
CODIFICATION DES MODÈLES Remarque importante : veuillez déterminer, d’après le nom du modèle, quel
est votre type de pompe à chaleur et quelle est son abréviation et référence
dans ce manuel d’instruction. Ces manuels d’installation et de fonctionnement
ne concernent que les unités intérieures TAW-(190/270)NHB combinées à des
groupes extérieurs RAW-35NHB ou RAM-90NYP5B.
CODICI DEI MODELLI Nota importante: controllare in base al modello il tipo di pompa di calore, la
descrizione e il tipo di abbreviazione utilizzati nel manuale di istruzioni. Questo
manuale di installazione e d’uso fa riferimento alla sola combinazione di unità
interne TAW-(190/270)NHB e unità esterne RAW-35NHB o RAM-90NYP5B.
CODIFICAÇÃO DE MODELOS Nota importante: de acordo com o nome do modelo, verique o tipo da sua
bomba de calor e a respetiva abreviatura e menção neste manual de instruções.
Este manual de instalação e de funcionamento só está relacionado com as
unidades interiores TAW-(190/270)NHB combinadas com as unidades exteriores
RAW-35NHB ou RAM-90NYP5B.
MODELKODIFICERING Vigtig information: Kontrollér venligst din varmepumpetype i henhold til
modelnavnet, hvordan den forkortes, og hvilken reference den har i denne
vejledning. Denne monterings og driftsmanual vedrører kun indendørsenhederne
TAW-190/270)NHB kombineret med udendørsenhederne RAW-35NHB eller
RAM-90NYP5B.
CODERING VAN DE MODELLEN Belangrijke opmerking: Controleer aan de hand van de modelnaam welk type
warmtepomp u heeft, hoe de naam wordt afgekort en hoe ernaar wordt verwezen
in deze instructiehandleiding. Deze Installatie- en bedieningshandleiding
heeft alleen betrekking op binnenunits TAW-(190/270)NHB in combinatie met
buitenunits RAW-35NHB RAW-35NHB of RAM-90NYP5B.
MODELLER Viktigt! Kontrollera med modellnamnet vilken typ av värmepump du har, hur den
förkortas och hur den anges i den här handboken. Denna handbok för installation
och användning gäller endast för inomhusenheterna TAW-(190/270)NHB
kombinerad med utomhusenhet RAW-35NHB eller RAM-90NYP5B.
ΚΩ∆ΙΚΟΠΟΙΗΣΗ ΜΟΝΤΕΛΩΝ Σηµαντική σηµείωση: Ελέγξτε, σύμφωνα με το όνομα μοντέλου, τον τύπο της
δικής σας αντλίας θέρμανσης και με ποια σύντμηση δηλώνεται και αναφέρεται σε
αυτό το εγχειρίδιο. Αυτό το εγχειρίδιο εγκατάστασης και λειτουργίας αφορά μόνο
τις εσωτερικές μονάδες TAW-(190/270)NHB συνδυασμός με εξωτερικές μονάδες
RAW-35NHB ή RAM-90NYP5B.
EN English Original version
ES Español Versión traducida
DE Deutsch Übersetzte Version
FR Français Version traduite
IT Italiano Versione tradotta
PT Português Versão traduzidal
DA Dansk Oversat version
NL Nederlands Vertaalde versie
SV Svenska Översatt version
EL Ελληνικα Μεταφρασμένη έκδοση

INDEX
1 GENERAL INFORMATION ....................................................1
2 SAFETY .................................................................................1
3 NAME OF PARTS AND DIMENSIONAL DATA ......................3
4 SERVICE SPACE ..................................................................3
5 UNIT INSTALLATION ............................................................4
6 ELECTRICAL AND CONTROL SETTINGS ...........................8
7 COMMISSIONING .................................................................11
8 OPERATION ..........................................................................11
9 UNIT CONTROLLER .............................................................12
10 TIMER OPERATION ............................................................21
11 MAINTENANCE ...................................................................22
12 TROUBLESHOOTING .........................................................24
13 GENERAL DATA .................................................................. 25
ÍNDICE
1 INFORMACIÓN GENERAL ...................................................27
2 SEGURIDAD .........................................................................27
3 NOMBRE DE LOS COMPONENTES Y DATOS
DIMENSIONALES ..................................................................... 29
4 ESPACIO PARA MANTENIMIENTO......................................29
5 INSTALACIÓN DE LA UNIDAD .............................................30
6 AJUSTES ELÉCTRICOS Y DE CONTROL ........................... 34
7 PUESTA EN MARCHA ..........................................................37
8 OPERACIÓN ......................................................................... 37
9 CONTROLADOR DE LA UNIDAD ......................................... 38
10 FUNCIONAMIENTO DEL TEMPORIZADOR ......................47
11 MANTENIMIENTO ...............................................................48
12 RESOLUCIÓN DE PROBLEMAS........................................50
13 DATOS GENERALES ..........................................................51
INHALT
1 ALLGEMEINE INFORMATIONEN ......................................... 53
2 SICHERHEIT ......................................................................... 53
3 NAME DER TEILE UND ANGABEN DER ABMESSUNG ..... 55
4 WARTUNGSBEREICH ..........................................................55
5 GERÄTEINSTALLATION ....................................................... 56
6 ELEKTRISCHE UND STEUERUNGS-EINSTELLUNGEN .... 60
7 INBETRIEBNAHME ...............................................................63
8 BETRIEB ...............................................................................63
9 GERÄTESTEUERUNG .........................................................64
10 TIMER-BETRIEB ................................................................. 73
11 WARTUNG ...........................................................................74
12 FEHLERBEHEBUNG ..........................................................76
13 ALLGEMEINE DATEN ......................................................... 77
INDEX
1 INFORMATIONS GÉNÉRALES ............................................79
2 SÉCURITÉ.............................................................................79
3 NOMENCLATURE DES PIÈCES ET DIMENSIONS ............. 81
4 ESPACE DE MAINTENANCE ...............................................81
5 INSTALLATION DES UNITÉS ............................................... 82
6 RÉGLAGES DE COMMANDE ET ÉLECTRIQUES ...............86
7 MISE EN SERVICE ............................................................... 89
8 FONCTIONNEMENT .............................................................89
9 CONTRÔLEUR D’UNITÉ ......................................................90
10 FONCTIONNEMENT DU PROGRAMMATEUR .................. 99
11 ENTRETIEN .........................................................................100
12 DÉPANNAGE ......................................................................102
13 SPÉCIFICATIONS GÉNÉRALES ........................................ 103
INDICE
1 INFORMAZIONI GENERALI .................................................105
2 SICUREZZA...........................................................................105
3 NOME DEI COMPONENTI E DIMENSIONI .......................... 107
4 SPAZIO DI SERVIZIO ...........................................................107
5 INSTALLAZIONE DELL’UNITÀ ..............................................108
6 IMPOSTAZIONI ELETTRICHE E DI CONTROLLO ..............112
7 MESSA IN ESERCIZIO ......................................................... 115
8 FUNZIONAMENTO ...............................................................115
9 DISPOSITIVO DI CONTROLLO DELL'UNITÀ ...................... 116
10 FUNZIONAMENTO DEL TIMER ......................................... 125
11 MANUTENZIONE ................................................................ 126
12 RISOLUZIONE DEI PROBLEMI ..........................................128
13 SPECIFICHE GENERALI .................................................... 129
ÍNDICE
1 INFORMAÇÃO GERAL ......................................................... 131
2 SEGURANÇA ........................................................................131
3 NOME DAS PEÇAS E DADOS DIMENSIONAIS .................. 133
4 ZONA DE MANUTENÇÃO .................................................... 133
5 INSTALAÇÃO DE UNIDADE ................................................. 134
6 AJUSTES DE CONTROLO E ELÉTRICOS...........................138
7 COLOCAÇÃO EM FUNCIONAMENTO .................................141
8 FUNCIONAMENTO ............................................................... 141
9 CONTROLADOR DA UNIDADE ............................................ 142
10 FUNCIONAMENTO DO TEMPORIZADOR ......................... 151
11 MANUTENÇÃO ...................................................................152
12 RESOLUÇÃO DE PROBLEMAS .........................................154
13 DADOS GERAIS .................................................................155
INDHOLDSFORTEGNELSE
1 GENEREL INFORMATION ....................................................157
2 SIKKERHED .......................................................................... 157
3 NAVNE PÅ DELE OG TEGNING MED MÅL ......................... 159
4 PLADS TIL SERVICE ............................................................159
5 INSTALLATION AF ENHED ...................................................160
6 ELEKTRISKE OG KONTROLINDSTILLINGER ....................164
7 IDRIFTSÆTTELSE ................................................................167
8 DRIFT .................................................................................... 167
9 STYREENHED ...................................................................... 168
10 TIDSINDSTILLET DRIFT ..................................................... 177
11 VEDLIGEHOLDELSE .......................................................... 178
12 FEJLFINDING......................................................................180
13 GENERELLE DATA ............................................................. 181
INHOUDSOPGAVE
1 ALGEMENE INFORMATIE .................................................... 183
2 VEILIGHEID...........................................................................183
3 NAAM EN AFMETINGEN VAN ONDERDELEN ....................185
4 ONDERHOUDSRUIMTE ....................................................... 185
5 INSTALLATIE VAN DE UNIT .................................................186
6 ELEKTRISCHE EN BESTURINGSINSTELLINGEN ............. 190
7 INBEDRIJFSTELLING ...........................................................193
8 WERKING ..............................................................................193
9 BESTURING VAN UNIT ........................................................194
10 INSTELLEN VAN TIMERFUNCTIE .....................................203
11 ONDERHOUD .....................................................................204
12 PROBLEMEN OPLOSSEN .................................................206
13 ALGEMENE GEGEVENS ....................................................207
INNEHÅLLSFÖRTECKNING
1 ALLMÄN INFORMATION .......................................................209
2 SÄKERHET ...........................................................................209
3 NAMN PÅ DELAR OCH MÅTT ..............................................211
4 SERVICEUTRYMME .............................................................211
5 INSTALLATION AV ENHET ................................................... 212
6 EL- OCH STYRINNSTÄLLNINGAR ......................................216
7 DRIFTSÄTTNING .................................................................. 219
8 DRIFT .................................................................................... 219
9 ENHETENS STYRMODUL .................................................... 220
10 TIMER ..................................................................................229
11 UNDERHÅLL ....................................................................... 230
12 FELSÖKNING......................................................................232
13 ALLMÄN INFORMATION .....................................................233
ΕΥΡΕΤΉΡΙΟ
1 ΓΕΝΙΚΕΣ ΠΛΗΡΟΦΟΡΙΕΣ ....................................................235
2 ΑΣΦΑΛΕΙΑ .............................................................................235
3 ΟΝΟΜΑΤΑ ΕΞΑΡΤΗΜΑΤΩΝ ΚΑΙ ΣΤΟΙΧΕΙΑ ΔΙΑΣΤΑΣΕΩΝ .. 237
4 ΧΩΡΟΣ ΣΥΝΤΗΡΗΣΗΣ ......................................................... 237
5 ΕΓΚΑΤΑΣΤΑΣΗ ΜΟΝΑΔΑΣ ...................................................238
6 ΡΥΘΜΙΣΕΙΣ ΗΛΕΚΤΡΙΚΕΣ ΚΑΙ ΕΛΕΓΧΟΥ ............................ 242
7 ΕΝΑΡΞΗ ΛΕΙΤΟΥΡΓΙΑΣ ........................................................ 245
8 ΛΕΙΤΟΥΡΓΙΑ ..........................................................................245
9 ΧΕΙΡΙΣΤΗΡΙΟ ΜΟΝΑΔΑΣ .....................................................246
10 ΛΕΙΤΟΥΡΓΙΑ ΧΡΟΝΟΔΙΑΚΟΠΤΗ ........................................255
11 ΣΥΝΤΗΡΗΣΗ .......................................................................256
12 ΑΝΤΙΜΕΤΩΠΙΣΗ ΠΡΟΒΛΗΜΑΤΩΝ .....................................258
13 ΓΕΝΙΚΑ ΣΤΟΙΧΕΙΑ ...............................................................259

ENGLISH
1 GENERAL INFORMATION
No part of this publication may be reproduced, copied, led
or transmitted in any shape or form without the permission of
Johnson Controls-Hitachi Air Conditioning Spain, S.A.U.
Within the policy of continuous improvement of its products,
Johnson Controls-Hitachi Air Conditioning Spain, S.A.U. reserves
the right to make changes at any time without prior notication
and without being compelled to introduce them into products
subsequently sold. This document may therefore have been
subject to amendments during the life of the product.
HITACHI makes every effort to offer correct, up-to-date
documentation. Despite this, printing errors cannot be controlled
by HITACHI and are not its responsibility.
As a result, some of the images or data used to illustrate this
document may not refer to specic models. No claims will be
accepted based on the data, illustrations and descriptions
included in this manual.
2 SAFETY
2.1 APPLIED SYMBOLS
During normal heat pump system design work or unit installation,
greater attention must be paid in certain situations requiring
particular care in order to avoid injuries and damage to the unit,
the installation or the building or property.
Situations that jeopardise the safety of those in the surrounding
area or that put the unit itself in risk are clearly indicated in this
manual.
A series of special symbols are used to clearly identify these
situations.
Pay close attention to these symbols and to the messages
following them, as your safety and that of others depends on it.
!DANGER
• The text following this symbol contains information and
instructions relating directly to your safety and physical integrity.
• Not taking these instructions into account could lead to serious,
very serious or even fatal injuries to you and others in the
proximities of the unit.
In the text following the danger symbol you can also nd
information on safe procedures during unit installation.
!CAUTION
• The text following this symbol contains information and instructions
relating directly to your safety and physical integrity.
• Not taking these instructions into account could lead to minor injuries
to you and others in the proximities of the unit.
• Not taking these instructions into account could lead to unit damage.
In the text following the caution symbol you can also nd
information on safe procedures during unit installation.
?NOTE
• The text following this symbol contains information or instructions that
may be of use or that require a more thorough explanation.
• Instructions regarding inspections to be made on unit parts or systems
may also be included.
2.2 ADDITIONAL INFORMATION ABOUT SAFETY
!DANGER
• DO NOT CONNECT THE POWER SUPPLY TO THE INDOOR UNIT
PRIOR TO FILLING DHW CIRCUITS WITH WATER AND CHECKING
WATER PRESSURE AND THE TOTAL ABSENCE OF ANY WATER
LEAKAGE.
• Do not pour water over the indoor unit electrical parts. A serious
electrical shock may occur if the electrical components enter in
contact with water.
• Do not touch or adjust the safety devices inside the sanitary hot
water heat pump. Touching or adjusting these devices may cause
a serious accident.
• Do not open the service cover or access the sanitary hot water
heat pump without disconnecting the main power supply.
• In case of re, turn the main switch off immediately, put out the
re at once and contact your service contractor.
• It must be made sure that the sanitary hot water heat pump
cannot operate accidentally either without water in the hydraulic
system or with air inside it.
!CAUTION
• Do not use any sprays such as insecticide, lacquer, hair spray or other
ammable gases within approximately one meter from the system.
• If the circuit breaker in the installation or the fuse in the unit are
triggered often, stop the system and contact your service contractor.
• Do not make service or inspections tasks by yourself. This work must
be performed by a qualied service person.
• This appliance must be used only by adult and capable people,
having received the technical information or instructions to handle the
appliance properly and safely.
• Children should be supervised to ensure that they do not play with the
appliance.
• Do not let any foreign body into the water inlet and outlet piping of the
sanitary hot water heat pump.
GENERAL INFORMATION
PMML0451 rev.2 - 03/2018
1

2.3 IMPORTANT NOTICE
• PLEASE READ THE MANUAL CAREFULLY BEFORE
STARTING TO WORK ON THE INSTALLATION OF THE
SANITARY HOT WATER HEAT PUMP SYSTEM. Failure to
observe the instructions for installation, use and operation
described in this documentation may result in operating
failure including potentially serious faults, or even the
destruction of the sanitary hot water heat pump system.
• This sanitary hot water heat pump has been designed for
the production of sanitary hot water for human consumption.
Do not use it for other purposes such as for drying clothes,
heating foods or for any other heating process.
• Refer to the codication of models to conrm the main
characteristics of your system.
• Check and make sure that the explanations of each part of
this manual apply to your specic model of sanitary hot water
heat pump.
• Verify that all the information required for the correct
installation of the system is correct according to the manuals
bundled with outdoor and indoor units. Contact your
distributor if it is not the case.
• Signal words (NOTE, DANGER and CAUTION) are used
to identify levels of hazard seriousness. Denitions for
identifying hazard levels are provided in the rst pages of this
document.
• This manual should be considered as an integral part of the
sanitary hot water heat pump, and must be kept for future
reference.
• Both the indoor and outdoor unit must be installed at a
location, structure or support prepared to withstand a heavy
weight. Otherwise, noise and vibration may increase, and the
units may collapse and cause damage to property or physical
injuries, particularly in case of an earthquake or a similar
phenomenon.
• Keep the water temperature of the system above the freezing
temperature (above 5 ºC).
• Please install a thermostat-type mixer tap in each hot water
supply spot to prevent scald accidents, and a drain trap in the
drainage piping.
• Please use dielectric joints to prevent the electrolysis
phenomenon.
• Piping parts around the tank such as the pressure-relief valve
and the drain valve must be easily accessed for maintenance
and inspection.
• Be sure to use the specied piping set for R410A. Otherwise,
this may result in damage to copper pipes and operational
failure.
• Make sure that nothing but the specied refrigerant (R410A)
is inside the refrigerant cycle when installing or removing the
sanitary hot water heat pump. If air or moisture remain in the
refrigeration cycle, pressure may become abnormally high
and cause rupture.
• Ventilate the room if any refrigerant has leaked out during the
installation work. The refrigerant produces a poisonous gas if
exposed to re.
• The drainage gas ows backward if there is no drain trap,
which may increase the corrosion of the hot water pump
considerably, leading to breakdown.
• Be sure to use a dedicated power circuit. Never use a power
circuit shared with another appliance.
• For wiring, use a cable long enough to cover the entire
distance with no intermediate connections. The power circuit
must be a dedicated one, without additional loads on the
power supply. Failure to do so may result in abnormal heat,
electrical shock, or re.
• Be sure to connect both outdoor and indoor units to ground.
An improperly made or incomplete ground connection may
cause damage or short-circuits that could result in electrical
shock and re. A high surge current from lightning or other
sources may cause damage to the outdoor unit. Ground
connections must not be made to utility pipes, gas pipes,
water pipes, surge absorb, lightning rods or telephone ground
connections.
• Be sure to install an earth leakage and a circuit breaker
according to local regulations. Failure to do so may result in
electrical shock.
• The operation modes of these units are controlled by the unit
controller.
• HITACHI pursues a policy of continuous improvement in
product design and performance. The right is therefore
reserved to vary specications without notice. No part of this
manual may be reproduced without written permission.
• HITACHI cannot anticipate every possible circumstance that
might involve a potential hazard. If you have any questions,
contact your service contractor of HITACHI.
SAFETY
PMML0451 rev.2 - 03/2018
2

ENGLISH
3 NAME OF PARTS AND DIMENSIONAL DATA
3.1 TANK UNIT
a b Ø c
TAW-190NHB 594 9º 520
TAW-270NHB 674 8º 600
aa
bº
bº
c
160
630
830
Units in: mm
Front view
Top view
Side view
XEKS1796
Nº Name Remarks
1 LCD controller
2 Electrical box
3 Cold water inlet G 3/4" (blue)
4Hot water outlet G 3/4" (red)
5Liquid refrigerant
connection
1/4" Ø6.35 mm
(black)
6Gas refrigerant
connection
3/8" Ø9.52 mm
(black)
7 Mg anode (black)
8 Heater 1.4 kW / 220 V
9 Thermistor
10 Mounting foot ×4
4 SERVICE SPACE
TAW-190NHB TAW-270NHB
NAME OF PARTS AND DIMENSIONAL DATA
PMML0451 rev.2 - 03/2018
3

5 UNIT INSTALLATION
5.1 GENERAL NOTES
5.1.1 Delivered components
Indoor unit
?NOTE
Please refer to the Installation and Operation Manual of the outdoor unit for
information on the installation of the outdoor unit.
5.1.2 Selection of the installation location
The YUTAMPO tank of the split system with sanitary hot water
heat pump must be installed satisfying these basic requirements:
• The YUTAMPO tank is intended to be installed in an indoor
environment with an ambient temperature range of 5~30 °C.
The ambient temperature around the indoor unit must be
>5°C to prevent water from freezing.
• The indoor unit is designed to be oor mounted. The oor of
the place chosen for installation must be at, with the surface
made of a non-burnable material, and must be strong enough
to withstand the weight of the indoor unit as well as the weight
of the DHW tank when it is completely full of water.
• The oor at the place of installation must be waterproof and
have a proper drainage, in order to limit the extent of damage
in case of water leakage.
• The recommended servicing space must be kept to allow
servicing as well as a sufcient circulation of air around the
unit.
• Enough space must be reserved for the installation of a
required pressure and temperature relief valve at the DHW
inlet connection of the tank (as close as possible to the tank).
A shut-down valve (eld supplied) must be also installed at
the DHW outlet connection.
• It is the responsibility of the installer to ensure that installation
and draining works are compliant with regulations.
• The indoor unit must be protected against the intrusion of
small animals (like rodents) which could damage the wiring,
drain pipes or electrical parts, causing a re in the worst case.
• The installation environment shall be free of frost and
excessive humidity.
• The unit shall not be installed in locations where it is exposed
to oil, smoke, dust or particles, such as kitchens or factories.
• The unit shall not be installed in locations where it is exposed
to large voltage uctuations or electromagnetic interference,
such as hospitals or workshops.
• If the unit is to be installed in a coastal area where it is
exposed to salty air, in a hot spring area or other areas where
special environmental conditions prevail, consult your dealer
before installing the unit.
• Do not install the indoor unit where electromagnetic waves
are directly radiated to the electrical box.
• Install the YUTAMPO system at a distance of 1 m or more
from TV sets, radios, radio antennas or similar devices. In
areas with poor reception, increase the distance so that units
do not interfere with reception.
• The unit must be installed in a place where no damage can
be produced as a result of water leakage.
• A noise lter must be installed when the power supply emits
harmful noise.
• To avoid re or explosion, do not install the unit in a
ammable environment.
• The sanitary hot water heat pump must be installed by a
service technician. The installation must comply with local
and European regulations.
• Do not put any objects or tools on top of the indoor unit.
5.1.3 Unpacking
All units are supplied with a wooden base, packed inside a
cardboard box and covered with a plastic bag.
For unpacking, rst place the unit on the assembly area, as close
as possible to its nal installation location, to avoid damages
during transport. Two persons are required.
1 Cut the strapping bands and remove the adhesive tapes.
2 Remove the cardboard cap and then the plastic bag around
the unit. Afterwards, remove the rest of cardboard parts.
3 Lift the YUTAMPO unit from the wooden base and place it
carefully on the oor, as near as possible to its nal location.
!CAUTION
• Two or more persons are required when lifting because of the heavy
weight of the unit (50 or 56 kg, depending of the model)
• Be specially careful with the mounting foot once the unit is on the oor.
Avoid harsh handling of the unit, as it could cause damage to the foot.
UNIT INSTALLATION
PMML0451 rev.2 - 03/2018
4

ENGLISH
5.2 REMOVING THE COVERS
Please follow these operations if access to the indoor unit components is required:
• Unscrew the 2 screws in A and remove the unit controller frame.
• Unscrew the 1 screw in B and remove the service cover: Lean the cover towards yourself. Push it down. Detach the
cover from the unit.
• Pull the electrical box cover for access to the electrical box.
Electrical box cover
Service cover
Unit controller frame
Mg Anode
Unit controller
Heater
Electrical box
Hot water outlet
Cold water inlet
B
A
Gas refrigerant
connection
(3/8” Ø9.52 mm)
Liquid refrigerant
connection
(1/4” Ø6.35 mm)
Handle x 2
Adjustable feet x 4



5.3 INSTALLATION OF INDOOR UNIT
?NOTE
Please, try to perform the entire procedure following all the steps in the
exact order in which they are presented below.
Installation procedure
1 DHW pipe connection
2 Drain pipe connection
3 Refrigerant piping connection
4 Power and transmission wiring connection
5 Levelling procedure
6 Test and check
5.3.1 General notes before performing piping
work
• Arrange locally-supplied copper pipes.
• Select pipes of the appropriate material, with sufcient
thickness to withstand pressure.
• Select clean copper pipes. Make sure that there is no dust
or moisture inside the pipes. Blow the inside of the pipes
with oxygen-free nitrogen to remove any dust and foreign
materials before connecting them.
?NOTE
A refrigerant system with no moisture or oil contamination will yield
maximum performance and life cycle, whereas a poorly prepared system
will not. Take particular care to ensure that all copper piping is clean and
dry internally.
• Cap the end of the pipe when it is to be inserted through a
wall hole.
• Do not put pipes on the ground directly without a cap or vinyl
tape at the end of the pipe.
• If piping installation is not completed until the following day or
over a longer period of time, braze off the ends of the piping
and charge with oxygen-free nitrogen through a Schrader
valve type access tting to prevent moisture and particle
contamination.
• It is advisable to insulate the water pipes, joints and
connections in order to avoid heat loss and dew condensation
on the surface of the pipes or accidental injuries due to
excessive heat on piping surfaces.
UNIT INSTALLATION
PMML0451 rev.2 - 03/2018
5

• Do not use insulation material that contains NH3, as it can
damage copper pipe material and become a source of future
leakage.
• It is recommended to use exible joints for the inlet and outlet
of water piping, in order to avoid the transmission of vibration.
• The refrigerant and water circuits must be installed and
inspected by a licensed technician and must comply with all
the relevant European and national regulations.
• It is recommended to perform a thorough water pipe
inspection after completion of piping work to make sure that
there is no water leakage in the space heating circuit.
5.3.2 DHW pipe connection
The connection between the DHW installation and the DHW tank
must be done taking the following considerations into account:
1 A pressure and temperature relief valve must be installed at
the DHW inlet connection (as close as possible to the tank) to
provide the following functions:
• Pressure protection
• No-return function
• Shut-down valve
• Filling
• Draining
If not, a specic device for each function should be installed.
2 A shut-down valve (eld supplied) must also be installed in
the DHW system.
!DANGER
Do not connect the power supply to the indoor unit prior to lling the
DHW circuit with water and checking water pressure and the total
absence of any water leakage.
Illustrative example:
Hot water supply line Mixed tap
Purge valve
Drainpipe
Tank unit
Hot water
outlet
Cold water inlet
Drain valve
Pressure-relief valve
Drain pipe
Water check valve
Pressure
reduction valve
Water valve
Cold water
supply line
Hopper
?NOTE
The discharge pipe should always be open to the atmosphere, free of frost
and obstruction, and in continuous descending slope in order to let water
out in case that a leakage occurs.
5.3.3 Requirements and recommendations for
the hydraulic circuit
• When the unit is stopped during shutdown periods and the
ambient temperature is very low, the water inside the pipes
may freeze, thus damaging the pipes. In these cases, the
installer shall ensure that the water temperature inside the
pipes does not fall below the freezing point.
• Fresh water must circulate inside the water circuit of the
DHW tank at least once every day during the rst days
after the installation has been performed. Additionally, it is
advised to ush the system with fresh water when there is no
consumption of DHW during long periods of time.
• A pressure with a nominal value of 7 bar must be tted in
case that the pressure of domestic cold water inlet is higher
than the design pressure of the equipment (6 bar).
• The installation must satisfy the requirements of applicable
legislation in terms of piping connection and materials,
hygienic measures and testing, as well as the possible
requirements for the use of some specic components such
as thermostatic mixing valves, differential pressure overow
valves, etc.
5.3.4 Filling the DWH tank with water
Follow the steps below when starting up the unit for the rst time
or when it has not been used for an extended period of time
1 Open the outlet water taps of the DHW, to expel all the air
from inside the tank.
2 Turn on all the connected mixer taps (hot water side).
3 Open the inlet valve of the DHW tank in order to ll the tank.
If there is a shut-down valve installed in the DHW tank outlet,
open it to allow circulation through the DHW installation.
4 When water begins to ow from the outlet water taps of the
DHW installation, close all these taps.
5 Turn off all the connected mixer taps.
6 Inspection
-1 After lling the tank, check all pipe, heater and anode
joints and the tank for leakage.
-2 Check operation of the pressure relief valve.
-3 After heating water for the rst time, check water
leakage from the pipe, heater and anode joints and the
tank once more.
!CAUTION
• Check carefully for leaks in the water circuit, connections and circuit
elements.
• Check that the water pressure in the circuit is lower than 7 bars.
• Fill the circuit with tap water. Water that conforms to the drinking
water regulation in each country must be used. Do not use water from
sources not subject to sanitary control like wells, rivers or lakes, since
it may have a high content of impurities, salinity, lime, etc.
• Please install the a water softening device when the hardness of water
is high. (Maximum hardness French degree 25 °F or equivalent rules)
UNIT INSTALLATION
PMML0451 rev.2 - 03/2018
6

ENGLISH
• The recommended standard water quality for the DHW circuit is shown
in the table below.
Item
DHW space Tendency (1)
Water
supply (2) Corrosion Deposit of scales
Electrical conductivity (mS/m)
(25 °C) 100~2000
Chlorine Ion (mg CI¯/I) max 250
Sulphate (mg/l) max 250
Combination of chloride and
sulphate (mg/l) max 300
Total Hardness (mg CaCO3/I) 60~150
?NOTE
• (1): The “ ” mark in the table indicates that the concerned item is a
factor increasing the tendency of each of the phenomena.
• (2): Water quality must comply with EU directive 98/83 EC.
5.3.5 Refrigerant piping connection
The connection of refrigerant pipes must be done respecting the
considerations indicated in the Installation Manual of the outdoor
unit. Flare nuts are used for the connection of refrigerant piping.
Follow the instruction “1) Preparation of Pipe” as indicated in the
Installation Manual of the outdoor unit.
1 Use the are nuts supplied in the accessory bag.
2 Please be careful when bending the copper pipe.
3 Place the are nuts manually to avoid misalignment. Once
the are nuts have been screwed in, use a torque wrench to
tighten the connection.
Fix wrench
Screw
wrench
Outer
diameter
of pipe
(Ø)
Torque
N.m
(kgf.cm)
Small
diameter
side
6.35 (1/4”) 13.7-18.6
(140-190)
Large
diameter
side
9.52 (3/8”) 34.3-44.1
(350-450)
?NOTE
Do not perform connection work with only one wrench. Always use two
wrenches (keeping one of them xed, while using the other to tighten the
connection). Refrigerant leakage may occur if the screwing procedure is
performed with only one wrench.
4 After having performed the connection of refrigerant piping,
seal the open space between the knock-out hole and
refrigerant pipes with insulation material.
5 Follow the instruction “3) Remove air from the Pipe and gas
leakage inspection” as indicated in the installation manual of
the outdoor units.
!CAUTION
• Check for refrigerant leakage in detail. If a large refrigerant leakage
occurred, it would cause difculty with breathing. Also, harmful gases
would be generated if there was a re in the room.
• If the are nut is tightened too hard, it may crack over time and cause
refrigerant leakage.
Maximum permitted concentration of HFCs
The R410A refrigerant (charged in the outdoor unit) is a non-
ammable, non-toxic gas. However, if leakage occurs and the
room becomes lled with gas, it may cause suffocation. The
maximum permissible concentration of HFC gas according to
EN378-1 is 0.44 kg/m3, and the volume of the installation room
must be greater than 3.2 m3in order to avoid suffocation in case
of leakage.
The formula used for the calculation of the maximum refrigerant
concentration allowed in case of refrigerant leakage is the
following:
R
— = C
V
R: Total quantity of refrigerant charged (kg)
V: Volume of the room (m³)
C: Refrigerant concentration
If the volume of the room does not meet this minimum value,
some effective measures must be carried out after installation to
prevent suffocation in case of leakage.
UNIT INSTALLATION
PMML0451 rev.2 - 03/2018
7

6 ELECTRICAL AND CONTROL SETTINGS
6.1 GENERAL CHECK
• Make sure that the following conditions related to power
supply installation are satised:
-The power capacity of the electrical installation is large
enough to support the power demand of the YUTAMPO
system (outdoor unit + DHW tank).
-The power supply voltage is within ±10% of the rated
voltage.
-The impedance of the power supply line is low enough
to avoid any voltage drop of more than 15% of the rated
voltage.
• The installation must satisfy the following requirements
established by the Council Directive 2014/30/EU, relating to
electromagnetic compatibility:
-Compliance with EN61000-3-2 (Harmonics).
-Compliance with EN61000-3-3 (Voltage uctuations).
6.2 ELECTRICAL CONTROL BOX
N
12L
3
CB
CB
RB
RB
Mark Part Name
PCB Printed circuit board
DSW1
DIP Switch (factory setting)
TB1 Communication terminal board
(1-2-3 / Outdoor unit - Tank)
TB2 Power terminal board
(L-N : 1~ 230V 50Hz)
AR Relay
ITH Thermostat
CB Cord band
RB Rubber bushing
6.3 SYSTEM WIRING DIAGRAM AND TRANSMISSION WIRING BETWEEN OUTDOOR UNITS
AND INDOOR UNIT TANK
The units shall be connected according to the following electric diagrams, depending on the applicable powering scheme and
according to the local regulations:
In case of power supply through the tank
1 230V 50Hz~
Tank Unit Outdoor Unit
Power supply to Outdoor Unit
Communication (Power IU PCB)
Power supply to
Electrical Heater of
the tank and OU
Earth
CB
ELB
In the case of independent supply to the tank and to
the outdoor unit
1 230V 50Hz~ 1 230V 50Hz~
Tank Unit Outdoor Unit
Communication (Power IU PCB)
Power supply to
Electrical Heater of
the tank
Power supply to OU
Earth Earth
CB
ELB
CB
ELB
!CAUTION
This power supply is not available in case of combination with RAM-90NYP5B.
ELECTRICAL AND CONTROL SETTINGS
PMML0451 rev.2 - 03/2018
8

ENGLISH
In case of power supply through the outdoor unit
1 230V 50Hz~
Tank Unit Outdoor Unit
Communication (Power IU PCB)
Power supply to Electrical Heater
of the tank
Power supply to the
outdoor unit and the
electrical heater of
the tank.
Earth
CB
ELB
!CAUTION
• If the electrical heater is not used, the indoor unit must be wired to
earth through the outdoor unit (1-2-3 and earth).
• Make sure that the transmission wiring is not connected to any live part
by mistake, since it could damage the PCB.
• These wiring diagrams are for illustrative purposes only. The location
of the terminals in the diagrams may differ from the actual location of
the terminals in the electrical box.
!CAUTION
This power supply is not available in case of combination with RAM-90NYP5B.
6.4 WIRING SIZE AND MINIMUM REQUIREMENTS OF THE PROTECTION DEVICES
!CAUTION
• Make sure that the eld supplied electrical components (mains power switches, circuit breakers, wires, connectors and wire terminals) have been
properly selected according to the electrical data indicated in this chapter and that they comply with national and local codes. If necessary, contact
your local authority concerning standards, rules, regulations, etc.
Use wires which are not lighter than the polychloroprene sheathed exible cord with code designation 60245 IEC 57.
Type of powering
scheme
Power
supply
Applicable
voltage RNC
(A)
IPT
(kW)
MC
(A)
Max.
IPT
(kW)
CB
(A)
ELB
(n/A/mA)
Section of
the power
cable
(L-N)
Section of the
connection wires
between the tank
and the outdoor unit
(1-2-3)
U min.
(V)
U max.
(V)
Independent supply to the
indoor unit (tank) 1~ 230V 50Hz 207 253 7.1 1.64 7.5 1.64 10 2/40/30 1.5 mm20.75 mm2
Independent supply to the
outdoor unit 1~ 230V 50Hz 207 253 4.9 1.04 8.5 1.80 10 2/40/30 1.5 mm20.75 mm2
Common power supply
for the indoor (tank) and
outdoor units
(Not available in case of
combination with
RAM-90NYP5B)
1~ 230V 50Hz 207 253 11.7 2.68 16 3.44 20 2/40/30 4.0 mm20.75 mm2
!CAUTION
• Ensure specically that there is an earth leakage breaker (ELB) installed for both the outdoor and indoor unit.
• If the installation is already tted with an earth leakage breaker (ELB), ensure that its rated current is large enough to withstand the current of the
units (both outdoor and indoor).
?NOTE
• Electric fuses can be used instead of magnetic circuit breakers (CB). In that case, select fuses with rated values similar to those of the CB.
• The earth leakage breaker (ELB) mentioned in this manual is also commonly known as residual current device (RCD) or residual current circuit
breaker (RCCB).
• The circuit breakers (CB) are also known as thermal-magnetic circuit breakers or just magnetic circuit breakers (MCB).
• The “Maximum current” shown in the tables is the maximum total running current of the unit under the following condition:
- Power supply voltage: 90 % of the rated voltage.
• The power supply cables must be appropriately sized to provide this maximum current value.
• Specications in these tables are subject to change without prior notice in order to let HITACHI offer the latest innovations to its customers.
• The abbreviations used in the table stand for the following concepts:
U: Power supply
IPT: Total input power
STC: Starting current: Less than maximum current
RNC: Running current
MC: Maximum current
ELECTRICAL AND CONTROL SETTINGS
PMML0451 rev.2 - 03/2018
9

6.4.1 Power and transmission wiring connection
Safety instructions
!DANGER
• Do not connect the power supply to the indoor unit prior to lling
the space heating and DHW circuits with water and checking
water pressure and the total absence of any water leakage.
• Do not connect or adjust any wiring or connections unless the
main power switch is OFF.
• When using more than one power source, check and ensure that
all of them are turned OFF before operating the indoor unit.
• Avoid wiring installation in contact with the refrigerant pipes,
water pipes, edges of plates and electrical components inside the
unit to prevent damage, which may cause electric shock or short
circuit.
!CAUTION
Make sure that all wiring and protection devices are properly selected,
connected, identied and xed to the correspond ing terminals of the unit,
specially the protection (earth) and power wiring, taking into account
the applicable national and local regulations. Establish proper earthing;
Incomplete earthing may cause electric shock.
Connection procedure
Perform the following steps after having accessed the electrical
box:
1 Power supply of the electrical heater:
TERMINAL BOARD 2 (TB2)
N
L
Power terminals of
the electric heater
Earth terminal
2 Connect the transmission wires between outdoor and indoor
unit to the terminals 1, 2 and 3 on the terminal board 1 (TB1).
Earth screw
YUTAMPO
DHW
Terminal
board
Green & Yellow
Connecting
cord 1.5mm2
Terminal
board Earth
screw
3 Fix the cables using the cord bands located in the electrical
box. Route the cables out through the electrical wiring holes
with rubber bushing at the bottom side of the indoor unit.
Cord bands
Rubber bushing for power
and transmission wires
6.4.2 Levelling procedure
After completing the connections described above, adjust the
height of the mounting feet to align the height of the refrigerant
piping outlet with that of the connection of the installation.
?NOTE
• This procedure must be done before lling the water tank.
• Only adjust those feet in which adjustment is necessary.
• Start with all four feet screwed in as far as possible (factory supplied
position).
• The levelling procedure must be performed by two people.
ELECTRICAL AND CONTROL SETTINGS
PMML0451 rev.2 - 03/2018
10

ENGLISH
7 COMMISSIONING
7.1 PRELIMINARY CHECK
Once the installation has been completed, commissioning
must be performed according to the following procedure before
handing the system over to the customer. Commissioning must
be performed methodically, checking that electrical wiring and
piping are correctly connected.
Indoor and outdoor units must be congured by the installer to
achieve optimal system performance with the most appropriate
settings.
7.1.1 Checking the unit
• Check the external appearance of the unit to look for any
damage that might have been caused during installation.
• Check that all the covers are fully closed.
• Check that the unit has been correctly installed and that the
mounting feet are correctly adjusted.
7.1.2 Electrical checking
!CAUTION
Do not operate the system until all the check points have been cleared:
• Check to ensure that the electrical resistance is more than 1 MΩ, by
measuring the resistance between ground and the electrical parts
terminal. If the measured resistance value is lower than that, do not
operate the system until the electrical leakage is found and repaired.
Do not apply voltage on the terminals for transmission and sensors .
• Check that the power supply voltage is within ±10% of the rated
voltage.
• Check that eld-supplied electrical components (main switches,
breakers, wires, conduit connectors and wire terminals) have been
properly selected according to the electrical specications given in this
document, and check that the components comply with international
and domestic standards.
• Wait for at least three minutes after having turned the main switch OFF
before touching any electrical components.
• Check to ensure that the electrical wiring of the indoor unit and the
outdoor unit are connected as shown in the chapter.
• Check to ensure that the external wiring is correctly xed, to prevent
problems such as abnormal vibration and noise, or damage to wiring
due to contact with the plates.
7.1.3 Checking the hydraulic circuit (DHW)
• Check that the circuit has been properly ushed and lled
with water and that the installation has been drained.
• The pressure of the DHW circuit in the tank has to be lower
than 7 bars.
• Check for any leakage in the water cycle. Pay special
attention to the water piping, heater and anode connections.
• Make sure that the internal water volume of the DHW tank is
correct.
• Check that the valves of the hydraulic circuit are fully open.
7.1.4 Checking the refrigerant circuit
• Check to ensure that the stop valves on the gas and liquid
lines are fully open.
• Check that the size of the piping and the refrigerant charge
comply with the applicable recommendations.
• Check the inside of the unit for refrigerant leakage. Contact
your dealer in case that there is a refrigerant leakage.
7.2 COMMISSIONING PROCEDURE
This procedure applies regardless of the options installed on the module.
• When installation is complete and all necessary settings have been performed, close the electrical box and place the cabinet as
shown in the manual.
• Start up the setup wizard from the unit controller.
• Select the “Domestic hot water temperature” settings.
• Start the unit by pressing the Run/Stop button.
8 OPERATION
The time required to reach the set water temperature depends on factors such as the temperature of water supply, the temperature
inside the tank or the outdoor air temperature.
The electric heater is automatically set to hote in case that heating up the water would take more than eight hours due to low water
and outdoor air temperatures.
COMMISSIONING
PMML0451 rev.2 - 03/2018
11

9 UNIT CONTROLLER
9.1 DEFINITION OF THE SWITCHES
OK







LCD screen
OK button
It is used to select the parameters to adjust and to conrm the
selected values.
Arrow key
It is used to navigate through the menus and screens.
Run/Stop button
Menu button
It is used to display the different conguration options of the
controller.
Return button
It is used to return to the previous screen.
Favourite button
It is used as a shortcut to execute the preset favourite action
(Timer, Night shift or DHW) directly.
9.2 DESCRIPTION OF THE ICONS
9.2.1 Common icons
Icon Name Values Explanation
State of DHW heating
operation
DHW is ready (Thermo-OFF).
DHW is being heated up (Themo ON).
DHW heating operation has been stopped by unit controller button or by timer.
Progress of DHW
heating operation
DHW heating operation is in Thermo-OFF.
DHW heating operation has reached 0~33% of the selected water outlet temperature.
DHW heating operation has reached 33~66% of the selected water outlet temperature.
DHW heating operation has reached 66~100% of the selected water outlet temperature.
88 Setting temperature Value Setting temperature of DHW heating operation
Alarm There is an alarm. The alarm code is shown next to this icon.
Timer Simple timer
Weekly timer
Derogation The current operation settings have been manually modied with respect to those of the active
timer program.
Installer mode The unit controller is in installer mode, which has special privileges.
Menu lock The menu is being blocked from a central control. This icon disappears when indoor
communication is interrupted.
Outdoor air
temperature The outdoor air temperature is indicated next to this icon.
DHW Heater The DHW Heater is in operation.
Defrost Defrost function is active.
Control mode
(Local/Full)
- Operation in local control mode when no icon is displayed
Operation in central control mode
Forced OFF This icon is displayed under each setting item turned to OFF, in case that the forced OFF input is
congured and its signal is received.
Anti-legionella
operation Anti-legionella operation is active
DHW boost operation DHW boost operation is active.
Night shift Informs about night shift operation
UNIT CONTROLLER
PMML0451 rev.2 - 03/2018
12

ENGLISH
9.3 MAIN SCREEN
9.3.1 Comprehensive view






Time and date
State of DHW heating operation (OFF, Thermo ON/OFF)
DHW control
This part of the screen is used for the indication of the setting
temperature for DHW and a throughput icon indicating the
progress of DHW heating operation. It can also show icons
indicating the operation of the auxiliary DHW electrical heater,
the activation of timer programs and the operation of DHW
boost, in case that these options are enabled.
The setting temperature can be modied using the arrow
key when in this view. The following quick actions are shown
when pressing the OK button:
-Timer: Menu for the selection and conguration of simple
timer and schedule timer
-Status: Display of information related to current operation
conditions
-DHW Boost: Activation of the auxiliary DHW heater, to
speed up DHW heating operation

Unit status icons
This part of the screen is used for the display of notication
icons related to general status and operation conditions of the
unit, including icons such as Central operation, Night shift or
Compressor.

Outdoor temperature / Alarm indication
In normal operation, the outdoor air temperature is displayed
next to the home-shaped icon.
In abnormal operation, the alarm icon is indicated together
with the corresponding alarm code.

Available buttons / Installer mode
This part of the screen is used to indicate the buttons of the
unit controller which can be used at the moment.
When the Installer mode is enabled, its icon appears at the
right end of this bar.
UNIT CONTROLLER
PMML0451 rev.2 - 03/2018
13

9.4 USER MENU
UNIT CONTROLLER
PMML0451 rev.2 - 03/2018
14
