Hitachi SJ-DN User manual

INSTRUCTION MANUAL
Thank you for purchase of “HITACHI INVERTER”. This manual
explains about treatment of “SJ-DN (DeviceNet Option)”
. By reading this
manual and an instruction manual of inverter use practically for
installation, maintenance, and inspection. After reading this manual,
keep it handy for future reference.
Make sure to reach this manual to the end user.
Table of Contents
Chapter1 Introduction
1
Chapter2 Installation method of printed board 4
Chapter3 Wiring, Connecting 5
Chapter4 Setting 7
Chapter5 Operation 9
Chapter6 DeviceNet Communication Function 11
Chapter7 Countermeasure for abnormality 21
Appendix Parameter Object Lists 23
SJ300/L300P SERIES
SJ-DN
(DeviceNet Option)
NB618X
Hitachi Inverter
After reading this manual, keep it at handy for future reference.

- Request -
Thank you for purchase of “SJ-DN (DeviceNet Option)”.
This instruction manual explains about treatment and maintenance of “SJ-DN”. Before using the product,
carefully read this manual with the instruction manual of inverter, and keeps it handy for quick reference of
operator and maintenance inspector. Before installing, operating, maintenance and inspection read this
manual carefully and follow the instructions exactly.
Always keep various kinds of specification mentioned in this manual and use exactly. And make sure to
prevent trouble by correct inspection and maintenance. Make sure to reach this manual to the end user.
- About treatment of this manual -
(1)Please consent that mentioned items of this manual may be change without permission.
(2)Keep this manual carefully not to lose because it can not be reissued
(3)All right reserved.
(4)Contents in this manual is written to make assurance doubly sure but, but please contact if you have
some doubts about spelling mistakes, omitted word etc.
(5)Please agree that there is no responsibility for effects resulted, in spite of contents above mentioned.
- About trademark -
(1)DeviceNet is trademark of Open DeviceNet Vendor Association, Inc.
Revision History Table
No.Revision contents The date of issued Manual No.
1. Initial release of Manual NB618X Jan. 2001 NB618X
Except this table, revised only spelling mistakes omitted words, and error writings without notice.

SAFETY PRECAUTIONS
!
SAFTY PRECAUTIONS
Carefully read this manual and all of the warning labels attached to the inverter before installing, operating,
maintaining, inspecting, it. Safety precautions are classified into “Warning”and “Caution”in this manual.
：Indicates a potentially hazardous situation which, if not avoided, can result in serious
injury or death.
：Indicates a potentially hazardous situation which, if not avoided, can result in minor to
moderate injury, or serous damage to the product
The situation described in may, if not avoided, lead to serious results. Important safety
measures are described in CAUTION (as well as WARNING) so be sure observe them.
Notes are described in this manual in“(Note)”. Carefully read the contents and follow them exactly.
CAUTION
In all the illustrations in this manual, covers and safely device are occasionally removed to describe the
details. When the product is operated, make sure that the covers and safety devices are placed as they
were specified originally and operate it according to the instruction manual.
WARNING
!
CAUTION
!
CAUTION
!

SAFETY PRECAUTIONS
!
!
WARNING
Wiring:
Wiring work shall be carried out by electrical experts.
Otherwise, there is a danger of electric shock, fire and/or damage of product.
Implement wiring after checking that the power supply is off.
Otherwise, there is a danger of electric shock and/or fire.
Operating:
Be sure not to touch the surface or the terminal of option board while energizing.
Otherwise, there is a danger of electric shock and/or fire.
Be sure not to remove the DeviceNet option printed board while operating.
Otherwise, there is a danger of electric shock and/or fire.
Maintenance, Inspection and Part Replacement:
Wait at least 10 minutes after turning off the input power supply before performing maintenance and
inspection.
(Confirm the charge lamp on the inverter is off, checks direct current voltage between P-N terminals and
confirm it is less than 45V)
Otherwise, there is a danger of electric shock.
Make sure that only qualified persons will perform maintenance, inspection, and part replacement
(Before starting the work, remove metallic objects from your person (wristwatch, bracelet, etc.).
Be sure to use tools protected with insulation.)
Otherwise, there is a danger of electric shock and/or injury.
Note:
Never modify the unit.
Otherwise, there is a danger of electric shock and/or injury.
CAUTION
Installation:
Be sure not to let the foreign matter enter such as wire clippings, spatter from welding, metal shaving,
dust etc.
Otherwise, there is a danger of fire.
Be sure to fix inverter to option printed board with an attached fixed screw.
Otherwise, there is a danger of connecting error.
Be sure to fasten the screws connecting signal wire in side of option printed board. Check for any
loosening of screw.
Otherwise, there is a danger of connecting error.
Wiring:
Be sure to fasten the screws not to loose.
Otherwise, there is a danger of connecting error.
Operation:
Check rotary direction, abnormal motor noise and vibrations during operating.
Otherwise, there is a danger of injury to personnel and/or machine breakage

CHAPTER 1 INTRODUCTION
1
1.1 INSPECTION UPON UNPACKING
Make sure to treat the product carefully not to give shock and vibration while unpacking. Check that the
product is the one you ordered, no defect, and that there is no damage during transportation.
(Contents of packing)
(1) SJ-DN(DeviceNet option printed board):1
(2) Instruction manual:1
(3) DeviceNet connector:1
(4) Screws fixed printed board (M3 times 8 mm):2
If you discover any problems, contact your sales agent immediately.
1.2 INQUIRY OF THE PRODUCT AND WARRANTY FOR THE PRODUCT
1.2.1 REQUIRE WHILE INQUIRING
If inquiry of breakage, question, damage etc. is needed, please tell the following information to the supplier
you ordered or the nearest Hitachi Distributor.
(1) Type(SJ-DN)
(2) Manufacturing number (Item of label, that labeled surface of printed board. SJ-DN XXX )
(3) Date of purchasing
(4) Contents of inquiry
・Damage parts and its condition etc.
・Question parts and their contents etc.
In order to shorten impossible working time, standing spare unit is recommended.
1.2.2 WARRANTY OF THE PRODUCT
This product is guaranteed to last for one year after purchase. But, the next case is toll repair, even if within
warranty period.
(1) In case caused by operating mistake, and incorrect repair and modification.
(2) Trouble caused by reasons except the shipped product.
(3) In case of using in range over the value of specification.
(4) In case caused by natural calamity, disaster, and secondary disaster.
Warranty mentioned here means warranty for shipped product itself. Damage caused by trouble of shipped
product is not guaranteed.
[Toll repair]
Any explanation and repair after the warranty period (one-year) shall be charged to the purchaser. And also
any explanation and repair out of warranty mentioned above, even within warranty period, shall be charged
to the purchaser. If you require the toll repair, please contact your Hitachi distributor.

CHAPTER 1 INTRODUCTION
2
1.3 Outline of product
SJ-DN is DeviceNet communication board for SJ300/L300P series inverter.
SJ-DN conforms to open field Network DeviceNet and it activates as slave function (Group 2 only server).
SJ-DN is also conforms ODVA’s certification.
(SJ-DN has been tested by ODVA's authorized Independent Test Lab and found to comply with ODVA
Conformance Test Software Version A-13.)
The following functions are available via DeviceNet communication function by installing SJ-DN to
SJ300/L300P series.
Polled Input/Output message connection
This command can exchange the master’s I/O data for the slave (Inverter)’s I/O data.
Output data (from master to SJ-DN):
Run/Stop, reference frequency, Acceleration time, Deceleration time, Fault reset etc.
Input data (from SJ-DN to master):
Inverter status, output frequency, output current, trip history etc.
Explicit message connection
This function can reads and writes (configuration) the inverter’s parameter data, when it is necessary.
SJ-DN can use inverter below:
SJ300-004LF to 550LF, 007HF to 550HF, L300P-110LFR to 750LFR, 110HFR to 750HFR
(Note) RS485 communication function is disabled by installing SJ-DN to the inverter.
1.4 Appearance and Names of Parts
Figure 1-1 indicates the appearance of SJ-DN.
Connector for connecting to SJ300/L300P (Rear of unit)
DeviceNet connector (open type)
Phoenix Contact Co, Ltd. (MSTB2.5/5-ST-5.08AU) etc
Network status LED (NET)
Module status LED (MOD)
DIP SW (SW) for setting MAC ID and Baud rate
Figure 1-1 Appearance of SJ-DN

CHAPTER 1 INTRODUCTION
3
1.5 DeviceNet Support Version
SJ-DN can use following Production number(MFG No) of SJ300/L300P series.
After MFG No. : XX8KXXXXXXXXXXXX
(Note) Production number (MFG No) is written in specifications label on main body of
SJ300/L300Pseries. Refer to figure 1-2, figure 1-3.
(Figure1-2,1-3 are the example of SJ300 series. L300P series are the same manner as
SJ300 series.)
Specifications label
Figure 1-2 Position of specifications label
Figure 1-3 Contents of specifications label
Inverter model
Maximum applicable
motor
Input ratings
Output ratings
Production number

CHAPTER 2 INSTALLATION METHOD OF PRINTED BOARD
4
2.1 Mounting method of option board
Figure 2-1 describes how to mount the option board to the option port 1 or 2.
There are four holes on the option board, match the two of them with the screw holes on the option port 1 or 2.
and mount the other two holes with the guide posts which are located on the option port 1 and 2. To avoid
connection failure, secure the option board with screws after connection.
Option board
Guide posts for mounting the
option board.
Option port 1
Option port 2
Screw holes for secure option board.
(M3 Screws)
Figure 2-1 Installation of option board

CHAPTER 3 WIRING, CONNECTING
5
3.1 Connection for DeviceNet connector
SJ-DN has a Pluggable open connector (Male contacts), and a Network connector (Female contacts)
attached. The inverter and attach connector have a seal which is color coordinated to correspond to the
DeviceNet cable. Ensure the cable and contact are wired in the same color cable.
Cable side connector (attached connector)
Maker Type
Phoenix contact co, Ltd. MSTB 2.5/5ST-5.08 AU
Figure 3-1 Connector specification
3.2 Communication cable for DeviceNet
Use the connector which conforms to DeviceNet specification or five conductor cable and also make sure
that cable, connector and Network distance conform to DeviceNet specification.
Drop line
Baud rate(kbps) Maximum Trunk line length(m)
(Or Maximum system length(m)) Maximum length(m) Maximum total length(m)
125 500 156
250 250 78
500 100 639
8.3
18.2
15
Dimension
20.32
2.54
White
Black
Color label
Blue
Red
25.4
5.0
Wiring ofDeviceNet
Communication connector
No.
Signal
mark Type of signal Cable color
1V- - (Minus) side of power supply Black
2CAN_L Communication data (Low) Blue
3Shield Shield Bare
4
CAN_H
Communication data (High) White
5V+ + (Plus) side of power supply Red
Dimension in mm

CHAPTER 3 WIRING, CONNECTING
6
3.3 Wiring note
1.Installing / removing the cable or connector must be done after checking the power supply off.
2.Wiring should not have bare cables exposed between connector contacts.
3.Network cables should be fixed without tension. Cables fixed under tension have potential of causing a
communication fault by to be removed a connector.
4.Provide a communication power source (DC24V).
5.A terminating resistor is not built-in the unit. Please provide it.
6.Ensure external emergency stop measures are taken to stop the inverter, in the event of a network fault.
(a) Remove the Power supply of the Inverter when the network master detects a communication fault.
(b) When the master detects a communication fault, turn on the intelligent input terminal which would be
allocated (FRS), (RS) and/or (EXT) function.
(c) Setting command P045 to except “02”.
In this setting, the inverter is tripped, deceleration or free run stop when it detects a communication
fault itself. (Factory initialization of command P045 is trip after deceleration stop (code: 01).)
See “4.2 Setting of the Inverter”and “4.3 Explanation of additional parameters”about explanation of
P045 (Inverter action when communication error).
7.Basic components for construction of DeviceNet application are shown bellow.
Refer to the master’s description manuals when DeviceNet Network system comes into operation.
HITACHI
SJ300/L300P SJ300/L300P
Terminating
resistor（121Ω）
Terminating
resistor
(121Ω)
Multi port Tap
Other slave units
Power
Supply
DC24V
DeviceNet Master UNIT
(PLC)
Trunk line Trunk line
Drop
line
Multiple Node branching drop line.
Figure 3-2 Example of components for construction of DeviceNet application
Configurater (PC)
HITACHI

CHAPTER 4 SETTING
7
4.1 Setting methods of Baud rate and MAC ID
Follow the procedure below to set Baud rate in DeviceNet and MAC ID, reset the power supply after
changing the setting (setting will be reflected after resetting power supply.). Initial Baud rate: 125kbps, Initial
MAC ID: 0.
4.1.1 Setting method of Baud rate
The table below is the setting method of Baud rate (Front view of the option board.).
(↑，↓ indicate direction for switch of Dip switch )
Baud rate 125kbps 250kbps 500kbps
Dip switch
Setting
(Note) Do not switch on DR1 and DR0 at the same time.
4.1.2 Setting method of MAC ID
The table below is the setting method of MAC ID (Front view of the option board).
MAC ID Dip switch setting
Figure left describes the direction of Dip switches. See below.
Bottom: 0 Upper: 1
Bit increases from right to left switches.
Therefore, figure left becomes formula below.
1･2 +0･2 +1･2 +0･2 +0･2 +1･2 =29(Hex)=41(dec)
4.2 Setting of the Inverter
Following table describes setting items which relate SJ300 / L300P series Inverters with SJ-DN.
To set appropriate settings refer to inverter instruction manual “chapter 3 Operation”, “chapter 4 Explanation
of function”and this manual.
Code Function Range of data Initial
data Setting on run Change
mode on
run Setting
P044
Timer setting of
communication
timeout Whilst
running
0.00 to 99.99(sec)
setting resolution 10nsec
Case of set to 0.00, thisfunc. Is disable. 1.00 impossible impossible
P045
Inverter action When
communication
error.
00(trip)/01(trip after deceleration stop)
/02(ignore)/03(free run)
/04(deceleration stop) 01 impossible impossible
P046
Polled I/O OUTPUT
Instance number 20，21，100 21 impossible impossible
P047 Polled I/O INPUT
Instance number 70，71，101 71 impossible impossible
P048 Inverter action when
Idle mode detected. 00(trip)/01(trip after deceleration stop)
/02(ignore)/03(free run)
/04(deceleration stop) 01 impossible impossible
P049 Motor poles setting
for revolutions per
minute
0 to 38
Only even number is possible to set.
set to 0:setting and monitoring by [Hz]
except 0:setting and monitoring by [min
-1
]
0impossible impossible
Set data
when it
is need.
NA32 NA16 NA8 NA4 NA2 NA1
543210
ON
OFF
↓
↓
DR1
DRO
DR
ON
OFF
↑
↓
DR1
DRO
DR
ON
OFF
↓
↑
DR1
DRO
DR
NA32 NA16 NA8 NA4 NA2 NA1
1
0
MAC ID

CHAPTER 4 SETTING
8
4.3 Explanation of additional parameters
Following information provide explanation of additional parameters which are necessary to use SJ-DN.
4.3.1 P044 (Timer setting of communication timeout whilst running)
Set the allowable time that is an interval of polled I/O from DeviceNet master when the inverter is running.
When the timeout occurs, the inverter’s behavior is as set in command P045.
4.3.2 P045 (Inverter action when communication error)
This command decides what action occurs when a communication fault is detected on the network or P044
timeout occurs at the inverter while controlled from DeviceNet.
When set to 0.00, this function is disable.
4.3.3 P046 (Polled I/O OUTPUT Instance number)
This command is instance number of assembly object Polled I/O output. Set the parameter to comply with
table below. (Combination table for P046, P047).
4.3.4 P047 (Polled I/O INPUT Instance number)
This command is instance number of assembly object Polled I/O input. Set the parameter to comply with
table below. (Combination table for P046, P047).
4.3.5 P048 (Inverter action when Idle mode detected)
This command decides what action occurs when on Idle mode is detected on the network. Inverter can start
to operate after behavior below.
At the time of set to 00, 01:After Idle mode released and fault reset, inputs stop command and run command.
At the time of set to 02 :After Idle mode released.
At the time of set to 03, 04:After Idle mode released, inputs stop command and run command.
4.3.6 P049 (Motor poles setting for revolutions per minute)
Set the Motor poles for AC Drive device profile.
0 to 38 (even number value only)
Set to 0 when frequency setting (Hz).
Set to 2 to 38 when revolution speed setting (min-1).
(Combination table for P046 and P047) P047
70 71 101
20 ○ − −
21 − ○ −P046
100 − − ○
○：combine.
−：Do not combine.
(Note) Do not combine P046 with P047 except for combination table above, otherwise data may not be set
correctly or may not be displayed correctly.

CHAPTER 5 OPERATION
9
5.1 Operate with Frequency command〔Hz〕
Following information indicate the explanation of the inverter control data at P046: 100 and P047: 101.
See Chapter 6 about explanation of Polled I/O message.
Explanation on each data frame
[Output data frame]
(1) Stop command. Set frequency: 50Hz (1388hex), Acceleration: 10sec.(0064hex) and Deceleration: 10sec.
(0064hex). Both Frequency source and Run command source set from DeviceNet.
(2) Forward running command.
(3) Change frequency setting: 10Hz(03E8hex).
(4) Stop command
(5) Reverse running command. Set Frequency: 50Hz(1388hex), Acceleration: 20sec.(00C8hex) and
Deceleration: 20sec.(00C8hex).
(6) Stop command
[Input data frame]
(7) Stop condition
(8) While the inverter is in the forward run condition and accelerating, “XX”represents frequency and current.
(9) Constant speed condition. Frequency arrives at 50Hz.
(10) Deceleration condition.
(11) Constant speed condition. Frequency arrives at 10Hz.
(12) Deceleration condition.
(13) Stop condition.
(14) The inverter is in the reverse run condition and accelerating.
(15) Constant speed condition. Frequency arrives at 50Hz.
(16) Deceleration condition.
(17) Stop condition.
(8)(7) (17)(16)(15)(14)(13)(12)(11)(10)(9)
ACC,DEC=20sec.
ACC,DEC=10sec.
50Hz
60
00
88
13
C8
00
C8
00
62
00
88
13
C8
00
C8
00
60
00
E8
03
64
00
64
00
61
00
E8
03
64
00
64
00
00
00
00
00
00
00
00
C0
02
01
xx
xx
xx
xx
00
C0
12
01
88
13
xx
xx
00
C0
02
01
xx
xx
xx
xx
00
C0
00
00
00
00
00
00
00
C0
01
01
xx
xx
xx
xx
00
C0
11
01
E8
03
xx
xx
00
C0
01
01
xx
xx
xx
xx
00
C0
11
01
88
13
xx
xx
00
C0
01
01
xx
xx
xx
xx
00
C0
61
00
88
13
64
00
64
00
00
00
00
00
00
00
00
C0
60
00
88
13
64
00
64
00
10Hz
50Hz
IN
(6)(5)(4)(3)(2)(1)
7Byte
0Byte
OUT
Reverse
running
Forward
running
7Byte
0Byte

CHAPTER 5 OPERATION
10
5.2 Operate with Rotational speed command〔min-1〕
Following information indicate the example of the inverter control data at P046: 21, P047: 71 and P049: 4.
See Chapter 6 about explanation of Polled I/O message.
Explanation on each data frame.
[Output frame]
(1) Stop command. Set rotational speed:1800min-1(0708hex). Acceleration / Deceleration command are
dependant on the inverter setting. Both rotational speed and run command set from DeviceNet.
(2) Forward running command.
(3) Change rotational speed command: 600min-1 (0258hex).
(4) Stop command.
(5) Reverse running command. Set rotational speed:1800min-1 (0708hex).
(6) Stop command.
[Input frame]
(7) Stop condition
(8) While the inverter is forward run condition and accelerating, “XX”represents rotational speed.
(9) Constant speed condition. Revolutions arrive at 1800min-1 .
(10) Deceleration condition.
(11) Constant speed run condition. Revolutions arrive at 600min-1 .
(12) Deceleration condition.
(13) Stop condition.
(14) The inverter is in the reverse run condition and accelerating.
(15) Constant speed condition. Revolutions arrive at 1800min-1 .
(16) Deceleration condition.
(17) Stop condition.
(8)(7) (17)(16)(15)(14)(13)(12)(11)(10)(9)
1800min-1
60
00
08
07
62
00
08
07
60
00
58
02
61
00
58
02
70
03
00
00
78
05
xx
xx
F8
04
08
07
78
04
xx
xx
70
03
00
00
74
05
xx
xx
F4
04
58
02
74
05
xx
xx
F4
04
08
07
74
04
xx
xx
61
00
08
07
70
03
00
00
60
00
08
07
600min-1
1800
min
-1
IN
(6)(5)(4)(3)(2)(1)
3Byte
0Byte
OUT
Reverse
running
Forward
running
3Byte
0Byte

CHAPTER 6 DEVICENET COMMUNICATION FUNCTION
11
6.1 Feature of DeviceNet communication function
SJ-DN conforms to open field Network DeviceNet and it activates as slave function (Group 2 only server).
There are two ways to communicate with the master, one is polled I/O message communication and the other
one is explicit message communication. Also SJ-DN corresponds to the AC Drive profile.
6.2 Basic DeviceNet specification
The table below describes basic DeviceNet specification of this product.
Items Specification
Protocol DeviceNet Volume I -Release2.0
DeviceNet Volume II-Release2.0
Support communication speed 125kbps(500m)/250kbps(250m)/500kbps(100m)
Maximum number of connection
Node 64 Nodes (Maximum number of Node for slaves are 63 Nodes)
Support connection Explicit Message
Polled Input/Output Message
Explicit Message (Each of Data has different length which are
dependant on data.)
Data length Polled Input/Output Message 4Bytes / 8 Bytes
Type of device Group2 Only Server
(Predefined Master/Slave Connection Set)
Device profile AC Drive
List of object for mounting is shown below.
Name of objects Class ID Instance ID Contents
Identity 01 1Information for distinguishing Device type, Serial
number and Vender ID etc.
Message Router 02 1This Router gives Explicit message to appropriate
object.
DeviceNet 03 1It controls Physical connection for DeviceNet
20,21,100 It controls Polled I/O Output Message.Assembly 04 70,71,101 It controls Polled I/O Input Message.
Connection 05 1,2 It controls Connection.
Motor Data 40 1It controls the motor connected to the inverter.
Control Supervisor 41 1It controls control information of the inverter.
AC/DC Drive 42 1It controls operational information of the inverter.
Inverter parameter 100〜109 1,2,3 It controls inverter parameter.
See Appendix about details of Inverter parameter.

CHAPTER6 DEVICENET COMMUNICATION FUNCTION
12
6.3 Details of Polled I/O communication
6.3.1 Basic I/O instance
This I/O instance is standard I/O instance, which is defined by AC drive profile in DeviceNet.
Master to SJ-DN: Instance20 (P046: 20)
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
0-----Fault
Reset -Run Fwd
1-
2Speed Reference (Low Byte)
3Speed Reference (High Byte)
Data Contents
Run Fwd The inverter is running forward. 0:Stop 1:Run
Fault Reset When the bit is set to “1”, the trip states can be cancelled
0:- 1:Fault reset
Speed Reference
It indicates speed command of the inverter.
[P049:Except for 0]
Rotational speed setting: Speed Reference(min-1) / 2 SS: Speed scale
Range of setting:0〜24000(min-1) (Resolution: 1min-1) Magnification: 1 time
e.g.) When the order of speed setting is 1800 min-1, (Speed scale:0)
Speed Reference=1800/2 =1800=0708(Hex)
[P049:0]
Operational frequency setting (Resolution: 0.01Hz).
Range of setting:0.00 to 400.00(Hz) Magnification: 100 time
SJ-DN to Master: Instance70 (P047: 70)
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
0-----Running
1-Faulted
1-
2Speed Actual (Low Byte)
3Speed Actual (High Byte)
Data Contents
Faulted It indicates the inverter is in a fault detecting state.
0:Normal 1:During detecting fault state
Running 1 It indicates inverter’s running state.
0:Stop/During Reverse run 1:During Forward Run
Speed Actual
It indicates inverter speed.
[P049:Except for 0]
Rotational speed monitor: Speed Actual(min-1) / 2 SS: Speed scale
Range of monitor:0〜24000(min-1) (Resolution: 1min-1) Magnification: 1 time
e.g.) When Speed Actual is 03E8(Hex) (Speed scale:0)
Speed Actual=03E8(Hex)/2 =1000/2 =1000(min-1)
[P049:0]
Current frequency display (Resolution: 0.01Hz).
Range of monitor:0.00 to 400.00(Hz) Magnification: 100 time
O
SS
SS
OO

CHAPTER 6 DEVICENET COMMUNICATION FUNCTION
13
6.3.2 Expansive I/O Instance
This I/O instance is standard I/O instance, which is defined by AC drive profile in DeviceNet.
Master to SJ-DN: Instance21 (P046: 21)
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
0-NetRef NetCtrl - - Fault
Reset Run Rev Run Fwd
1-
2Speed Reference (Low Byte)
3Speed Reference (High Byte)
Data Contents
Run Fwd The inverter is running forward. 0:Stop 1:Run forward
Run Rev The inverter is running reverse. 0:Stop 1:Run reverse
Fault Reset When the Bit is set to “1”, the trip states can be cancelled.
0:- 1:Fault reset
NetCtrl
It indicates method of operation command.
0:Method of operation command, which is selected at operation command
selection(A002).
1:Method of Operation command from DeviceNet is valid.
NetRef
It indicates method of frequency command.
0:Method of frequency command, which is selected at frequency command
selection(A001).
1:Method of frequency command from DeviceNet is valid.
Speed Reference
It indicates speed command of the inverter.
[P049:Except for 0]
Rotational speed setting: Speed Reference(min-1) / 2 SS: Speed scale
Range of setting:0〜24000(min-1) (Resolution: 1 min-1) Magnification: 1 time
e.g.) When the order of speed setting is 1800 min-1, (Speed scale:0)
Speed Reference=1800/2 =1800=0708(Hex)
[P049:0]
Operational frequency setting (Resolution:0.01Hz).
Range of setting:0.00 to 400.00(Hz) Magnification: 100 time
(Note) When set both Run Fwd and Run Rev to 1, the inverter executes the command, which is inputted first.
SS
O

CHAPTER6 DEVICENET COMMUNICATION FUNCTION
14
SJ-DN to Master: Instance71 (P047: 71)
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
0At
Reference Ref From Net Ctrl From Net Ready Running2 (Rev) Running1 (Fwd) Warning Faulted
1Drive Status
2Speed Actual (Low Byte)
3Speed Actual (High Byte)
Data Contents
Faulted It indicates the inverter is in a fault detecting state.
0:Normal 1:During detecting fault state
Warning It indicates the inverter is in a warning detecting state.
0:Normal
1:During detecting warning (When there is contradiction on the inverter setting.).
Running1(Fwd) It indicates inverter’s running condition.
0:Stop / During reverse run 1:During forward run
Running2(Rev) It indicates inverter’s running condition.
0:Stop / During forward run 1:During reverse run
Ready It indicates the inverter ready for drive. 0:Except Drive status: 3,4,5.
1:Complete ready to drive (Drive Status: 3,4,5).
Ctrl From Net It indicates selection state for inputting the inverter operational command 0:Operation command selection(A002) is valid to set.
1:Operation command from DeviceNet is valid.
Ref From Net It indicates selection state for inputting the inverter frequency command. 0:Frequency command selection(A001) is valid to set.
1:Frequency command from DeviceNet is valid.
At Reference It indicates arrival frequency detecting state for the inverter. 0:During stop / During accelerate or decelerate
1:Arrival frequency
Drive Status
It indicates inverter status.
1:Startup (Only R0-T0 power supply is ON)
2:Not Ready (Just after turn on power supply)
3:Ready (Able to activate the inverter）
4:Enabled (Inverter is running by run command)
5:Stopping (Inverter is decelerating by stop command)
6:Fault Stop (Inverter is decelerating because trip is detected)
7:Faulted (Trip condition)
Speed Actual
It shows inverter speed.
[P49:Except for 0]
Rotational speed monitor: Speed Actual(min-1) / 2 SS: Speed scale
Range of monitor:0〜24000(min-1) (Resolution: 1min-1) Magnification: 1 time
e.g.) When Speed Actual is 03E8(Hex) (Speed scale:0)
Speed Actual=03E8(Hex)/2 =1000/2 =1000(min-1)
[P049:0]
Current frequency display (Resolution: 0.01Hz).
Range of monitor:0.00 to 400.00(Hz) Magnification: 100 time
SS
O O

CHAPTER 6 DEVICENET COMMUNICATION FUNCTION
15
6.3.3 Hitachi inverter I/O Instance
This I/O instance is able to control the operation control, which is necessary to Hitachi inverters.
Master to SJ-DN: Instance100 （ P046: 100 ）
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
0−NetRef NetCtrl −Free run
stop Fault Reset Run Rev Run Fwd
1−
2Speed Reference (Low Byte)
3Speed Reference (High Byte)
4Acceleration time (Low Byte)
5Acceleration time (High Byte)
6Deceleration time (Low Byte)
7Deceleration time (High Byte)
Data Contents
Run Fwd The inverter is running forward run. 0:Stop 1:Run forward
Run Rev The inverter is running reverse run. 0:Stop 1:Run reverse
Fault Reset
When the Bit is set to “1”, the trip states can be cancelled.
0:- 1:Fault reset
Case of the inverter is not in trip condition, when the Bit is set to “1”, the inverter
will stop the motor.
Free run stop When the Bit is set to “1”, the inverter stops output and the motor enters the free
run mode.
0:- 1:Free run stop
NetCtrl
It indicates setting for method of operational command.
0:Method of operation command, which is selected at operation command
selection (A002).
1:Method of Operation command from DeviceNet is valid.
NetRef
It indicates setting for method of frequency command.
0:Method of Frequency command, which is selected at frequency command
selection(A001) and setting at Acc / Dec time(F002, F003).
1:Method of frequency and Acc / Dec time command from DeviceNet is valid.
Speed Reference It indicates setting for output frequency of the inverter. Range of setting:0.00 to 400.00(Hz), Resolution:0.01(Hz), Magnification:100
times, Transmit data:0 to 9C4O(Hex)
Acceleration time /
Deceleration time
It indicates setting for Acc/Dec time of the inverter.
Range of setting:0.1 to 3600.0(sec), Resolution:0.1(sec), Magnification:10 times
Transmit data:1 to 8CA0(Hex)
If Acceleration / Deceleration time has not been set by DeviceNet, the inverter will
use the settings in command F002 / F003.
(Note) When set both Run Fwd and Run Rev to 1, the inverter executes as stop command.

CHAPTER6 DEVICENET COMMUNICATION FUNCTION
16
SJ-DN to Master: Instance101 (P047: 101)
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
0Input
Terminal
3 State
Input
Terminal
2 State
Input
Terminal
1 State
At
Reference −Faulted Running2 (Rev) Running1 (Fwd)
1Drive Status
2Speed Actual (Low Byte)
3Speed Actual (High Byte)
4Output current (Low Byte)
5Output current (High Byte)
6Trip cause
7Ref From
Net Ctrl From Net
Forward
Terminal
state
Input
Terminal
8 State
Input
Terminal
7 State
Input
Terminal
6 State
Input
Terminal
5 State
Input
Terminal
4 State
Data Contents
Running1(Fwd) It indicates inverter’s running condition.
0:Stop / During reverse run 1:During forward run
Running2(Rev) It indicates inverter’s running condition.
0:Stop / During forward run 1:During reverse run
Faulted It indicates the inverter is in a fault detecting state.
0:Normal 1:During detecting fault state
At Reference It indicates arrival frequency detecting state for the inverter. 0:During stop / During accelerate or decelerate
1:Arrival frequency
Input Terminal 1 State 0: (opened) 1: Input terminal 1 and common are closed.
Input Terminal 2 State 0: (opened) 1: Input terminal 2 and common are closed.
Input Terminal 3 State 0: (opened) 1: Input terminal 3 and common are closed.
Input Terminal 4 State 0: (opened) 1: Input terminal 4 and common are closed.
Input Terminal 5 State 0: (opened) 1: Input terminal 5 and common are closed.
Input Terminal 6 State 0: (opened) 1: Input terminal 6 and common are closed.
Input Terminal 7 State 0: (opened) 1: Input terminal 7 and common are closed.
Input Terminal 8 State 0: (opened) 1: Input terminal 8 and common are closed.
Forward Terminal State 0: (opened) 1: Forward terminal (FW) and common are closed.
Drive Status
It indicates the inverter condition.
00:The inverter is stopping.
01:The inverter is running.
02:The inverter is in jogging mode.
03:The inverter’s output is stopped and the motor is free running (coasting).
04:The inverter is executing DC braking.
This includes the DC braking wait time.
05:The inverter is trying to restart with frequency matching.
Command b001 is set to ”3”.
06:Stop output at instantaneous power failure.
07:The inverter is trying to restart with frequency matching.
Command b001 is set to “2”.
08:The inverter is waiting before it runs on motor again to restart with
frequency matching (by setting b001, b088, C103).
This waiting time is as setting value command b003.
10:The inverter is in a trip condition.
11:The inverter is in under-voltage condition.
Speed Actual It indicates the inverter’s output frequency monitor. Monitor range:0.00 to 400.00(Hz), Resolution:0.01(Hz), Magnification:100
times, Receiving data:0 to 9C4O(Hex)
