Hitachi SJ700 Series Software User manual

Powerful Inverter
Hitachi Industrial Equipment Systems Co.,Ltd.


Over-current suppress ON
Over-current suppress OFF
OC-Trip
Frequency
Motor current
Suppress current and continues running
Impact load
Motor current
Voltage of the
main circuit DC
Output frequency
High starting Torque,
Powerful Drive and easy setting
High starting Torque
200% at 0.3Hz
Trip avoidance function
Over current &
voltage suppress function
Improvement of [Sensorless Vector Control], [Auto
Tuning] realize High starting torque 200% and more at
0.3Hz.
Easy adjusting of Motor constant
The best for applications, which need high torque, such
as cranes, extruders and lifts.
Higher internal calculation speed* improve current control
performance Over-current suppress and Over-voltage
suppress function avoid inverter trip during acceleration and
deceleration period.
Hitachi original 0Hz Domain
sensorless vector control
Keep 150% * torque at 0Hz speed
signal
Crane applications require high
torque at starting
*150%torque in case 1 frame big inverter
capacity of motor
Position Control Function
With combination of the SJ700 and a motor with an
encoder, position control is possible by adding SJ-FB
feedback option card to the inverter.
When position control is necessary with conveyor
application, the system can be built with lower cost.
According to four parameters (position command, speed
command, acceleration time and deceleration time), the
SJ700 will move an object from original position A to target
position B. After the movement, the inverter keeps servo
lock status.
DC Bus AVR Function
During Deceleration
The SJ700 controls deceleration time for DC bus voltage
not to exceed over-voltage trip level. This realizes trip-less
operation during deceleration.
E.g..Motor Torque and Speed
Torque [%]
Speed (min-1)
200
100
0
-100
-200
300 600 900 1200 1500 1800
0.3Hz
Starting point A
Starting point B
1
High performance with Many useful


130
120
110
100
90
80
70
60
50
40
30
20
10
0
150k200k 500k 1M 2M 5M 7M 10M 20M 30M
PB1
RY1
PB2
PB2
RYB
T2
PB1
T1
RY2
PB1
CM1
PB2
2
RYA
T1
T2
RY1
RY2
1
RYA FW
CM1
8
RYB
EN61800-3 2nd Envinment
［ C3 ］ QP Limit Level
2
Functions and User Friendly.
Inverter control by Built-in
Programming function
Simple sequence operation is realized by downloading to an
inverter the program created by programming soft EzSQ.
It is also possible to automatic speed control according to a load
situation like a swift lift function for crane or a conveyor, and to
operate.
Since an external circuit can be simplified, a control board is
made small and a cost cut can be aimed at.
Password function is added to prevent program information
leaks. This is also useful for unexpected data rewriting or
deletion by operation mistake.
Built-in EMC Filter
Cost and space reduction compared with external EMC Filter.
Reduces electromagnetic noise.
EN61800-3 2nd-Environment
Brake circuit up to 22kW
Cost and Space reduction compared with external Braking
Controller.
Internal Option
Programming [EzSQ: Easy Sequence] function
Example (110HFEF2)
Frequency [Hz]
Level [db]
[The example of a use] Example for Rely sequence
Current INV SJ700
Current INV SJ700
Operation
circuit
Programming window
EzSQ
Programming
Item Description
Language SpecI/O functionReserved word
Language type BASIC Like
Supported Device Windows(DOS/V)OS:Windows98SE,Windows2000,WindowsXP)
Programming
environment
Editor(Windows),Display(Windows)
Programmable flow control <Loop,Unconditional jump, conditional jump,
Time control, Sub routine, Others>
Operation command <+,-,,*, /, substitution, mod, abs>
I/O control(Bit input, Word input, Bit output, Word output)
Timer control <on delay, off delay>
Inverter parameter setting
User U(00)
- U(31)/32 point
Timer UL(00)
- UL(03)/4 point
Set frequency SET-Freq
Acceleration time ACCEL
Deceleration time DECEL
Monitor
Output frequency, Output current, Rotative direction,
PID feedback, Converted frequency, Output torque,
Output voltage, Power, Cumulative RUN time,
Cumulative power-on time, trip
General-purpose
input contact X(00)
- X(07)/8 point
General-purpose
output contact Y(00)
- Y(05)/6 point(1 point is relay output)
UB(00)
- UB(07)/8 pointInternal user
TD(0)
- TD(7)/8 point
Internal timer
contact
In a remote operator display code.
Inverter input
and output
Grammar check(Windows)
Program download/upload, All clear
Interpreter 2.0ms/command (Sub routine supported. 8 nested)
Memory area
Executable format
External input
External output
Command
Variable
1,024 steps or 6k byte
(Smaller of these)Program is stored in internal of inverter.
External digital
contact input
External analog
input
General-purpose
output terminal
Contact signal/Open collector signal input
(Internal DC24V power supply available)
Program RUN
command FW terminal is reserved
General-purpose
input Maximum of 8 point(X(00)
- X(07))
XA(0) : 0
- 10V (O terminal)
XA(1) : 4
- 20mA (OI terminal)
XA(2) : 0
- 10V (O2 terminal)
External analog
output
YA(0) : Setup for FM terminal is possible.
YA(1) : Setup for AM terminal is possible.
YA(2) : Setup for AMI terminal is possible.
Maximum of 8 point(Y(00)
- Y(05))
Download
QP: Quasi Peak
*Windows¨is a registered trademark of Microsoft Corporation.U.S.A and other countries.

Ease of Maintenance Easy Operation
Field replacement of cooling fan(s) and DC bus capacitor
can be accomplished in a fraction of the time.
Using Logic terminal move to SJ700 without wiring change.
Read SJ300 Parameter by SRW remote operator and write
them in to SJ700
Allows display of only parameters changed from default.
The port corresponding to RS-485 Modbus-RTU is
equipped as standard.
SJ700 can communicate with DeviceNet PROFIBUS-DP
LonWorks with communication options.
-DeviceNet is a trade mark of Open DeviceNet Vender Association, Inc.
-LonWorks is a registered trade mark of Echelon Corporation
-PROFIBUS-DP is a registered trade mark of PROFIBUS Nutzer
Organization
Long life time components &
Life time warning function
Long life time components
Design lifetime 10 Years or more Dc bus capacitor & Cooling
Fan.
Cooling Fan ON/OFF control lead more longer life time.
*Ambient temperature: Average 40 deg C (no corrosive gasses oil mist or
dust)
Design lifetime is calculation and out of guaranty.
Life time warning function
Avoid trouble before the malfunction by lifetime Warning
signal.
The monitor of the temperature rise of a Dc bus capacitor,
cooling fan degradation degree, a cooling fin, and a motor
can be carried out.
Replace the components before the malfunction.
Easy-removable
Dc bus Capacitor
(more than 15kW)
Easy-removable
Cooling Fan
SJ300series SJ700series
Network compatibility
Parameter
read write
Removable Control circuit terminals
(Move to SJ700 without rewiring)
Data comparison function
-The direct input of function code selection is also attained
other than a scroll type allowing for a shorter set up time.
-Continuously pushing the function key for 3 seconds,
causes the display to jump to output frequency monitor
(d001) mode from every key.
Other Functions
Basic display mode for commonly used parameters.
Basic mode (default)
Display of up to 12 User Defined Parameters U001 to U012.
User selected function
Basic
mode
Chose Basic
Parameter
Indication only
Basic Parameter
Easy-removable construction
for maintenance User selection of Parameter functions
Simple & Low cost wiring Ease of installation and replacement
3

EC97J1095
Conformity to global standards
CE, UL, c-UL, C-Tick approvals.
Micro Surge Voltage suppress
function (Patent registered in
Japan,USA & Korea)
Wide Input power voltage range
Input voltage 240V for 200V class and 480V for 400V class
as standard.
Logic input & output Terminal
apply sink & source logic
Environmental Friendliness
Global standards
Motor terminal voltage
E=650V, cable=100m
EU RoHS compliant
EU RoHS compliant by restricting to use hazardous
substances.
(except solder in power module)
Improvement of environment
Varnish coating of internal PC board & plating of main circuit
copper bus bar as standard.
Versatile Functions
Instantaneous Power Failure Disregard
Function
The SJ700 ignores instantaneous power failure when power
fluctuation happens frequently as long as DC bus voltage
keeps higher than under-voltage level.
Emergency stop
Shut down INV output by electric circuit without CPU realize
high quality emergency stop.
Intelligent input terminal and output
terminal delay time function
Simplification of an external circuit is possible.
Active frequency matching function
Restart by motor frequency search restart function without
motor remaining voltage.
Controlled deceleration and stop on
power loss
Analog Input Disconnection Detecting
Function
The SJ700 outputs disconnection signal when frequency
command through analog input is lost.
Acceleration/Deceleration curve
functions
The pattern (5 kinds) which can be chosen according to a
usage is carried.
Analog Command Holding Function
(AHD)
Output frequency can be changed with UP/DOWN Function
with analog signal as reference value. The frequency at
power shutdown can be saved, too.
Pulse train input function
Pulse train input for Frequency reference or PID feed back
signal with SJ-FB(speed feed back card:option).
Integrated Input Electric Power
monitor
Input electric power(kW) and Integrated input electric power
for monitoring energy saving.
Automatic Carrier Frequency Adjustment
Function
The SJ700 detects motor current and automatically reduces
carrier frequency according to the current.
The resolution of a monitor (voltage,
current) output is improved to 10 bits.
Hitachi original PWM control suppressing Motor terminal
Voltage less than 2 times of INV DC voltage E.
Lower than Hitachi motor Max. insulation voltage (1,250V)
(during regenerating operation increase the DC bus voltage may over
motor max. insulation voltage)
1,250V
4

STANDARD SPECIFICATIONS
3-phase 200V class
5
Model SJ700-
Braking
Enclosure (*1) IP20
Built-in
Built-in
150%,60sec., 200%,3sec.
3-phase (3-wire) 200 to 240V (corresponding to input voltage)
3-phase 200 to 240V+10%, -15%, 50/60Hz±5%
Applicable motor (4-pole, kW(HP)) (*2)
Output Ratings
Rated capacity
(KVA)
Rated capacity
(KVA)
Rated output current (A)
Overload capacity(output current)
Rated output voltage (*3)
Rated input voltage (V)
Dynamic braking (Short-time) (*4)
Minimum value of resistor (½)
Input Rating
Vibration (*5)
Integrated EMC filter
Zero-phase Reactor
Weight (lbs.)
US Version
200V
240V
550LFUF2450LFUF2370LFUF2300LFUF2220LFUF2185LFUF2150LFUF2110LFUF2075LFUF2055LFUF2
43(94.6)30(66)30(66)22(48.4)14(30.8)14(30.8)14(30.8)6(13.2)6(13.2)6(13.2)
57.57.5101016
55(75)
76.2
91.4
220
45(60)
63.0
75.6
182
37(50)
50.2
60.2
145
30(40)
41.9
50.2
121
22(30)
32.9
39.4
95
18.5(25)
26.3
31.5
76
15(20)
22.1
26.6
64
11(15)
15.9
19.1
46
7.5(10)
11.0
13.3
32
5.5(7.5)
8.3
9.9
24
Built-in BRD circuit (optional resistor) External dynamic braking unit (option)
5.9m/s2(0.6G), 10-55Hz 2.9m/s2(0.3G), 10-55Hz
-
3-phase 400V class
Model SJ700-
Braking
Enclosure (*1) IP20
Built-in
Built-in
150%,60sec., 200%,3sec.
3-phase (3-wire) 380 to 480V (corresponding to input voltage)
3-phase 380 to 480V +10%, -15%, 50/60Hz±5%
Applicable motor (4-pole, kW(HP)) (*2)
Output Ratings Rated output current (A)
Overload capacity(output current)
Rated output voltage (*3)
Rated input voltage (V)
Dynamic braking (Short-time) (*4)
Minimum value of resistor (½)
Input Rating
Vibration (*5)
Integrated EMC filter
Zero-phase Reactor
Weight (lbs.)
European Version
US Version
400V
480V
550HFEF2
550HFUF2
450HFEF2
450HFUF2
370HFEF2
370HFUF2
300HFEF2
300HFUF2
220HFEF2
220HFUF2
185HFEF2
185HFUF2
150HFEF2
150HFUF2
110HFEF2
110HFUF2
075HFEF2
075HFUF2
055HFEF2
055HFUF2
30(66)30(66)30(66)22(48.4)14(30.8)14(30.8)14(30.8)6(13.2)6(13.2)6(13.2)
202424353570
55(75)
77.6
93.1
112
45(60)
63.0
75.6
91
37(50)
51.9
62.3
75
30(40)
40.1
48.2
58
22(30)
33.2
39.9
48
18.5(25)
26.3
31.5
38
15(20)
22.1
26.6
32
11(15)
17.3
20.7
25
7.5(10)
13.1
15.8
19
5.5(7.5)
9.7
11.6
14
Built-in BRD circuit (optional resistor) External dynamic braking unit (option)
5.9m/s2(0.6G), 10-55Hz 2.9m/s2(0.3G), 10-55Hz
-
SJ700-055 HFEF2
Series Name
Applicable Motor
Capacity
004: 0.4kW(1/2HP)
|
4000: 400kW(500HP)
Power Source
L : 3-phase 200V class
H : 3-phase 400V class
F : With keypad
U : US version
E : European version
F : Integrated EMC filter
Version
Model Name Indication Model Configuration
Applicable
Motor
kW (HP)
0.4(1/2)
3-phase 200V 3-phase 400V
LFUF2 HFEF2 HFUF2
0.75(1)
1.5(2)
2.2(3)
3.7(5)
4.0(5)
7.5(7.5)
11(15)
15(20)
18.5(25)
22(30)
5.5(7.5)
Applicable
Motor
kW (HP)
30(40)
3-phase 200V 3-phase 400V
LFUF2 HFEF2 HFUF2
37(50)
46(60)
55(75)
75(100)
90(125)
132(175)
185(250)
315(400)
400(500)
110(150)
Available Plan model

SPECIFICATIONS
General Specifications
6
Items
Control
Inputsignal
Outputsignal
Monitoring on display
Other functions
Frequency
setting
Operator
External signal
External port
Forward /reverse
Start /stop
Operator
External signal
External port Setting via RS485 communication
Terminals
Intelligent 
input terminals
8 terminals, NO/NC switchable, sink logic/source logic switchable
Functions
1 terminal (PTC characteristics)Thermistor input
Control method
Output frequency range (*6)
Frequency accuracy
Frequency resolution
V/f characteristics
Speed fluctuation
Acceleration/deceleration time
Starting Torque
Carrier frequency range
DC braking
Line to line sine wave pulse-width modulation (PWM) control
0.1-400.0Hz
Digital: ±0.01% of the maximum frequency, Analog: ±0.2%(25±10ûC)
Digital setting: 0.01Hz, Analog setting: (Maximum frequency)/4,000 (O terminal: 12bit 0-10V, O2 terminal: 12bit -10-+10V)
V/f optionally variable (30-400Hz of base frequency), V/f control (constant torque, reduced torque), Sensorless vector control
±0.5% (sensorless vector control)
0.01-3,600sec. (Linear/curve, accel./decel. selection), Two-stage accel./decel.
200% at 0.3Hz (Sensorless vector control), 150% at around 0Hz (Sensorless vector control, 0Hz domain with motor one frame size down)
0.5-15.0kHz
Performs at start: under set frequency at deceleration, via an external input (braking force, time, and operating frequency).
Up and Down keys
DC 0-10V, -10-+10V (input impedance 10k½), 4-20mA (input impedance 100½)
Setting via RS485 communication
Start/stop commands (forward/reverse switching by parameter setting)
General Specifications
Forward-operation start/stop commands (reverse-operation start/stop possible when relevant commands are assigned to intelligent input terminals)3-wire
input possible (when relevant commands are assigned to control circuit terminals)
Reverse operation (RV), Multi-speed 1 setting (CF1), Multi-speed 2 setting (CF2), Multi-speed 3 setting (CF3), Multi-speed 4 setting (CF4), Jogging (JG),
external DC braking (DB), 2nd motor control (SET), 2-stage acceleration/deceleration (2CH), free-run stop (FRS), external trip (EXT), unattended start
protection (USP), commercial power supply switching (CS), software lock (SFT), analog input switching (AT), 3rd motor control (SET3), reset (RS), starting
by 3-wire input (STA), stopping by 3-wire input (STP), forward/reverse switching by 3-wire input (F/R), PID disable (PID), PID integration reset (PIDC),
control gain switching (CAS), acceleration by remote control (UP), deceleration by remote control (DWN), data clearance by remote control (UDC), forcible
operation (OPE), Multi-speed bit 1 (SF1), Multi-speed bit 2 (SF2), Multi-speed bit 3 (SF3), Multi-speed bit 4 (SF4), Multi-speed bit 5 (SF5), Multi-speed bit 6
(SF6), Multi-speed bit 7 (SF7), overload restriction selection (OLR), torque limit selection (enabling/disabling) (TL), torque limit 1 (TRQ1), torque limit 2
(TRQ2), P/PI switching (PPI), braking confirmation (BOK), orientation (ORT), LAD cancellation (LAC), clearance of position deviation (PCLR), permission
of 90ûshift phase (STAT), trigger for frequency addition (A145) (ADD), forcible-terminal operation (F-TM), permission of torque command input (ATR),
cumulative power clearance (KHC), servo-on (SON), pre-excitation (FOC), general-purpose input 1 (MI1), general-purpose input 2 (MI2), general-purpose
input 3 (MI3), general-purpose input 4 (MI4), general-purpose input 5 (MI5), general-purpose input 6 (MI6), general-purpose input 7 (MI7), general-purpose
input 8 (MI8), analog command holding (AHD), no assignment (no)
Running (RUN), constant-speed reached (FA1), set frequency overreached (FA2), overload notice advance signal (1) (OL), output deviation for PID control
(OD), alarm signal (AL), set frequency reached (FA3), over-torque (OTQ), instantaneous power failure (IP), undervoltage (UV), torque limited (TRQ),
operation time over (RNT), plug-in time over (ONT), thermal alarm signal (THM), brake release (BRK), braking error (BER), 0 Hz detection signal (ZS),
speed deviation maximum (DSE), positioning completed (POK), set frequency overreached 2 (FA4), set frequency reached 2 (FA5), overload notice
advance signal (2) (OL2), PID feedback comparison (FBV), communication line disconnection (NDc), logical operation result 1 (LOG1), logical operation
result 2 (LOG2), logical operation result 3 (LOG3), logical operation result 4 (LOG4), logical operation result 5 (LOG5), logical operation result 6 (LOG6),
capacitor life warning (WAC), cooling-fan speed drop (WAF), starting contact signal (FR), heat sink overheat warning (OHF), low-current indication signal
(LOC), general-purpose output 1 (M01), general-purpose output 2 (M02), general-purpose output 3 (M03), general-purpose output 4 (M04), general-
purpose output 5 (M05), general-purpose output 6 (M06), inverter ready (IRDY), forward rotation (FWR), reverse rotation (RVR), major failure (MJA), alarm
code 0 to 3 (AC0 to AC3)
Free V/f setting (7 breakpoints), frequency upper/lower limit, jump (center) frequency, acceleration/deceleration according to characteristic curve, manual
torque boost level/breakpoint, energy-saving operation, analog meter adjustment, start frequency setting, carrier frequency adjustment, electronic thermal
function (available also for free setting), external start/end frequency/frequency rate, analog input selection, retry after trip, restart after instantaneous power
failure, output of various signals, starting with reduced voltage, overload restriction, initial-value setting, automatic deceleration at power failure, AVR
function, fuzzy acceleration/deceleration, online/offline auto-tuning, high-torque multi-motor operation (sensorless vector control of two motors by one
inverter)
Protective functions
Environmental
conditions
Options
*1: The protection method conforms to JEM 1030.
*2: The applicable motor refers to Hitachi standard 3-phase motor (4-pole).
To use other motors, be sure to prevent the rated motor current (50Hz) from exceeding the rated output current of the inverter.
*3: The output voltage decreases as the main power supply voltage decreases except for the use of AVR function.
*4: Braking resistor is not integrated in the inverter. Please install optional braking resistor or dynamic braking unit when large braking torque is required.
*5: Conforms to the test method specified in JIS C0040(1999).
*6: To operate the motor beyond 50/60Hz, please consult with the motor manufacturer about the maximum allowable rotation speed.
*7: Storage temperature refers to the temperature in transportation.
Ambient operating/storage 
temperature(*7)/ humidity
Overcurrent protection, overvoltage protection, undervoltage protection, electronic thermal protection, temperature error protection, instantaneous power
failure protection, phase loss input protection, braking-resistor overload protection, ground-fault current detection at power-on, USP error, external trip,
emergency stop trip, CT error, communication error, option board error, and others
Terminals
Intelligent 
output terminals Functions
Analog voltage output, analog current output, pulse-string output (e.g., A-F, D-F [n-fold, pulse output only], A, T, V, P)
-10-50ûC / -20-65ûC / 20-90%RH (No condensation)
Location Altitude 1,000m or less, indoors (no corrosive gases or dust)
Digital input expansion card SJ-DG (4digits BCD, 16bits binary)
Feedback expansion card SJ-FB (vector control loop speed sensor)
Network interface card SJ-DN(DeviceNetTM), SJ-PBT(PROFIBUSR), SJ-LW(LONWORKSR)
Others EMI filters, input/output reactors, radio noize filters, braking resistors, braking units, LCR filter, communication cables
Output frequency, output current, output torque, frequency conversion data, trip history, input/output terminal status, electric power, and others
Monitor output 
terminals
5 open-collector output terminals, NO/NC switchable, sink logic/source logic switchable 1 relay (1c-contact) output terminal: NO/NC switchable

7
SJ700-055-110 LFUF2/HFEF2, HFUF2 SJ700-150-220 LFUF2/HFEF2, HFUF2
SJ700-300 LFUF2/HFEF2, HFUF2 SJ700-370-450 LFUF2/370-550HFEF2, HFUF2
SJ700-550 LFUF2
[Unit : mm(inch)]
Inches for reference only.
[Unit : mm(inch)]
Inches for reference only.
Digital Operator
189 (7.44)
210 (8.27)
24.5 (0.97) 80 (3.15)
79 (3.11)169 (6.69)
246 (9.69) 260 (10.274)
189 (7.44)
7 (0.28)
203 (7.99)
82 (3.23)
170 (6.69)
13.6 (0.28)
Wall
Exhaust
Air intake
244 (9.61)
229 (9.02)
273.4 (10.75)
376 (14.80) 390 (15.35)
24.5 (0.97) 80 (3.15)
229 (9.02)
250 (9.84)
79 (3.11)
7 (0.28)
9.5 (0.37)
83 (3.27)
190 (7.48)
5- 25 ( 0.98)
Wiring Hole
3-33X28 (1.30X1.10)
Wiring hole 3-42X42.5 (1.65X1.67)
Wiring hole
Wiring Hole
Digital Operator
Air intake
Exhaust
Wall
Digital Operator
79 (3.11)277 (10.91)
390 (15.35)
250 (9.84)
12 (0.47) 300 (11.81)
520 (20.47) 550 (21.65)
Air intake
Exhaust
Wall
368 (14.49)
510 (20.08) 540 (21.26)
195 (7.68)
79 (3.11)
45 (1.77) 80 (3.15) 32.5 (1.28) 80 (3.15)
10 (0.39)
265 (10.43)
310 (12.20)
Digital Operator
Air intake
Exhaust
Wall
700 (27.56) 670 (26.38)
480 (18.90)
380 (14.96)
2-12 (0.47)
250 (9.84)
Wall
Air intake
Exhaust
79 (3.11)
352 (13.87)
Digital Operator
125 (4.92)80 (3.15)
DIMENSIONS
2- 7 ( 0.28)
2- 7 ( 0.28)
2- 12 ( 0.47)
5- 41 ( 1.61)
2- 10 ( 0.39)
2- 12 ( 0.47)
6- 41 ( 1.61)
Wiring hole

OPERATION and PROGRAMMING
8
The contents of a basic mode display.(default)
Setting the output frequency
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Display code
d001 to d104
F001
F002
F003
F004
A001
A002
A003
A004
A005
A020
A021
A022
A023
A044
A045
A085
b001
b002
b008
b011
b037
b083
b084
b130
b131
C021
C022
C036
Item
Monitor display
Output frequency setting
Acceleration (1) time setting
Deceleration (1) time setting
Operation direction setting
Frequency source setting
Run command source setting
Base frequency setting
Maximum frequency setting
[AT] selection
Multi-speed frequency setting
Multi-speed 1 setting
Multi-speed 2 setting
Multi-speed 3 setting
1st control method
V/f gain setting
Operation mode selection
Selection of restart mode
Allowable under-voltage power failure time
Retry-after-trip selection
Retry wait time after trip
Function code display restriction
Carrier frequency setting
Initialization mode selection
Selection of overvoltage suppression function
Setting of overvoltage suppression level
Setting of intelligent output terminal 11
Setting of intelligent output terminal 12
Alarm relay active state
SJ700 Series can be easily operated with the digital operator provided as standard. The digital operator can also be detached and
can be used for remote-control. Multilingual (English, French, German, Italian , Spanish and Portuguese) operator with copy
function (SRW-0EX) and digital operator with potentiometer are also available as options.
Shows drive status.
Press to run the motor.
Press to stop the drive or
reset an alarm.
Lights when the power input
to the drive is ON.
Indicates the unit associated
with the parameter display.
Press to write the new value
to the EEPROM.
Press up or down to sequence
through parameters and func-
tions shown on the display, and
increment/decrement values.
Press to set or monitor a
parameter value.
Parameter Display Power LED
Display Unit LEDs
Lights to indicate that the
inverter has tripped.
ALARM LED
Store Key
Up/Down Keys
Monitor LEDs
Lights up when the inverter
is ready to respond to the
RUN key.
RUN key enable LED
RUN Key
STOP/RESET Key
Function Key
Displays frequency, motor current,
rotational speed of the motor, and
an alarm code.
If a desired parameter is not displayed, check the
setting of function "b037" (function code display
restriction). To display all parameters, specify "00" for
"b037".
Press
until appears.
（ 1 ）  or the value previously
monitored is displayed.
（ 2 ） Function code appears.
（ 3 ） appears.
Hz
V
A
%
POWER
ALARM
RUN
PRG
kW
Hz
V
A
%
POWER
ALARM
RUN
PRG
kW
Power on
Press key.
Press key.
FUNC FUNC
FUNC
Hz
V
A
%
POWER
ALARM
RUN
PRG
kW
機能
FUNC
記憶
STR
機能
FUNC
記憶
STR
機能
FUNC
記憶
STR
（ 4 ） Preset value is displayed.
（ 5 ） Newly set value is displayed.
（ 6 ） Returns to and
the setting is complete.
Hz
V
A
%
POWER
ALARM
RUN
PRG
kW
Hz
V
A
%
POWER
ALARM
RUN
PRG
kW
Hz
V
A
%
POWER
ALARM
RUN
PRG
kW
Press
to set desired value.
Press key
to store the value.
* To run the motor, go back to mon-
itor mode or basic setting mode.
STR
機能
FUNC
記憶
STR
機能
FUNC
記憶
STR
機能
FUNC
記憶
STR


◯
◯
◯
◯
◯
◯
◯
◯
◯

◯
◯
◯
◯
◯
◯
◯




◯
◯
［◯ ］
［◯ ］
TERMINALS
Terminal Description
Symbol
Name Explanation of Terminals Ratings
Maximum capacity of relays
AL1-AL0:
AC 250V, 2A(R load)/0.2A(L load)
DC 30V, 8A(R load)/0.6A(L load)
AL2-AL0:
AC 250V, 1A(R load)/0.2A(L load)
DC 30V, 1A(R load)/0.2A(L load)
Minimum capacity of relays
AL1-AL0, AL2-AL0:
AC100V, 10mA DC5V, 100mA
Power Supply
Frequency Setting
Monitor Output
Monitor Output
Power Supply
Contact
Input
Open
Collector
Output
Analog
Input
Relay
Output
Run
Command
Functions
Common
Terminal
State
Sensor
State/
Alarm
Common Terminal for Analog
Power Source
Power Source for Frequency
Setting
Frequency Command Terminal
Frequency Command Extra
Terminal
Frequency Command Terminal
Analog Output Monitor (Voltage)
Analog Output Monitor (Current)
Digital Monitor (Voltage)
Power Terminal for Interface
Allowable input voltage range
AnalogDigitalAnalogDigital
In default setting, an alarm is activated when inverter output is turned off by a protective
function.
Common terminal for H, O, O2, OI, AM, and AMI. Do not ground.
-
Input impedance: 10k½, Allowable
input voltage range: DC -0.3-+12V
DC 10V, 20mA max.
Input impedance:10k½, Allowable
input voltage range: DC 0-±12V
Maximum frequency is attained at DC 10V in DC 0-10V range. Set the voltage at A014 to
command maximum frequency below DC 10V.
O2 signal is added to the frequency command of O or OI in DC 0-±10V range. By
changing configuration, frequency command can be input also at O2 terminal.
Maximum frequency is attained at DC 20mA in DC 4-20mA range.
When the intelligent terminal configured as AT is on, OI signal is enabled.
Selection of one function from:
Output frequency, output current, torque, output voltage, input power, electronic thermal
load ratio, and LAD frequency.
[DC0-10V output (PWM output)] Selection of one function from: Output frequency, output
current, torque, output voltage, input power, electronic thermal load ratio, and LAD fre-
quency.
[Digital pulse output (Pulse voltage DC 0/10V)] Outputs the value of output frequency as
digital pulse (duty 50%)
Internal power supply for input terminals. In the case of source type logic, common termi-
nal for contact input terminals.
Common Terminal for Interface Common terminal for P24, TH, and FM. In the case of sink type logic, common terminal for
contact input terminals. Do not ground.
Select sink or source logic with the short-circuit bar on the control terminals.
Sink logic: Short P24 to PLC / Source logic: Short CM1 to PLC.
When applying external power source, remove the short-circuit bar and connect PLC ter-
minal to the external device.
Assign 5 functions to open collector outputs.
When the alarm code is selected at C062, terminal 11-13 or 11-14 are reserved for error
codes of inverter trip.
(Refer to the standard specifications for the functions.)
Both sink and source logic are always applicable between each terminal and CM1.
The inverter trips when the external thermistor detects abnormal temperature. Common
terminal is CM1.
[Recommended thermistor characteristics]
Allowable rated power: 100mW or over.
Impedance in the case of abnormal temperature: 3k½
Note: Thermal protection level can be set between 0 and 9999½.
Forward Command Input
Intelligent Input Terminals
Common Terminal for
Intelligent Input Terminals,
Common Terminal for
External Power Supply for
PLCs, etc.
Intelligent Output Terminals
Common Terminal for
Intelligent Output Terminals
Thermistor Input Terminals
Alarm Output Terminals
Power supply for frequency command input
Input impedance: 100½, Allowable
input voltage range: DC 0-24mA
DC 0-10V, 2mA max.
DC 4-20mA, 250½ max.
Digital output frequency
range: 0-3.6kHz, 1.2mA max.
DC 24V, 100mA max.
The motor runs forward when FW terminal is ON,
and stops when FW is OFF. [Input ON condition]
Voltage between each terminal
and PLC: DC 18V min.
[Input OFF condition]
Voltage between each terminal
and PLC: DC 3V max.
Input impedance between each
terminal and PLC: 4.7½
Allowable maximum voltage
between each terminal and
PLC: DC 27V
Decrease in voltage between
each terminal and CM2:
4V max. during ON
Allowable maximum voltage: DC 27V
Allowable maximum current: 50mA
Common terminal for intelligent output terminal 11-15.
11
12
13
14
15
AL0
AL1
AL2
1
2
3
4
5
6
7
8
O2
OI
AM
AMI
FM
TH
L
H
-
P24
CM1
FW
PLC
CM2
O
Assign 8 functions to terminals.
(Refer to the standard specifications for the functions.)
CONTROL CIRCUIT TERMINALS
Terminal Arrangement
MAIN CIRCUIT TERMINALS
Terminal Description
R(L1),S
(L2),T (L3)
U(T1),V
(T2),W (T3)
PD(+1),P
(+)
P(+),RB
(RB)
P(+),N
(
-
)
(G)
R
0
(R
0
),T
0
(T
0
)
Terminal Symbol Terminal Name
Main power supply input terminals
Inverter output terminals
DC reactor connection terminals
External braking resistor connection terminals
External braking unit connection terminals
Ground connection terminal
Control power supply input terminals
Terminal Arrangement
055
-
220LFUF2/HFEF2,
HFUF2
450
-
550LFUF2
Screw diameter:M3 Terminal Width:6.4mm
Screw Diameter and
Terminal Width
Model Screw diameter Terminal width
（ mm ）
055,075LFUF2/HFEF2, HFUF2
110LFUF2/HFEF2, HFUF2
150,185LFUF2/150-300HFEF2, HFUF2
220,300LFUF2
370,450LFUF2/370-550HFEF2, HFUF2
550LFUF2
R
0 T 0 terminals (All models)
M5
M6
M6
M8
M8
M10
M4
18
18
23
23
29
40
9
*1 Ground Screw diameter is M6
*2 Ground Screw diameter is M8
*1
*2
9
300
-
370LFUF2
300
-
550HFEF2, HFUF2
DC0
-
8V
DC8V
10k½
1k½
[Input Circuit]
Thermistor
TH
CM1
R
(L1) S (L2) T (L3) PD (+1) P (+) N ( - )U (T1) V (T2) W (T3)
RB
(RB )
R0
(R0)T0 (T0)
(G) (G)
(G) (G)
(G) (G)
R
(L1) S (L2) T (L3) PD (+1) P (+) N ( - )U (T1) V (T2) W (T3)
R0
(R0)T0 (T0)
R
(L1) S (L2) T (L3) PD (+1) P (+) N ( - )U (T1) V (T2) W (T3)
R0
(R0)T0 (T0)
H
LO2 OAM OI FM AM1 TH P24 FW PLC 8 CM1 CM1 75 63 41 214 15 13 CM2 11 12 AL1 AL0 AL2
W
W:Terminal width

A001
A002
A003
A203
A303
A004
A204
A304
A005
A006
A011
A012
● MONITORING FUNCTIONS and MAIN PROFILE PARAMETERS
Basic settings
Analog input and others
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Monitored data or setting
● A GROUP: STANDARD FUNCTIONS
PROTECTIVE FUNCTIONS
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
d001
d002
d003
d004
d005
d006
d007
d008
d009
d010
d012
d013
d014
d015
d016
d017
d018
d019
d022
d023
d024
d025
d026
d027
d028
d029
d030
d080
d090
d102
d103
d104
F001
F002
F202
F302
F003
F203
F303
F004
A---
b---
C---
H---
P---
U---
Output frequency monitor
Output current monitor
Rotation direction minitoring
Process variable (PV), PID feedback monitor
Intelligent input terminal status
Intelligent output terminal status
Scaled output frequency monitoring
Actual-frequency monitoring
Torque command monitoring
Torque bias monitoring
Torque monitoring
Output voltage monitoring
Power monitoring
Cumulative power monitoring
Cumulative operation RUN time monitoring
Cumulative power-on time monitoring
Heat sink temperature monitoring
Motor temperature monitoring
Life-check monitoring
Program counter
Program number monitoring
User monitor 0
User monitor 1
User monitor 2
Pulse counter
Position setting monitor
Position feedback monitor
Trip Counter
Trip monitoring 1-6
Programming error monitoring
DC voltage monitoring
BRD load factor monitoring
Electronic thermal overload monitoring
Output frequency setting
Acceleration (1) time setting
Acceleration (1) time setting, 2nd motor
Acceleration (1) time setting, 3rd motor
Deceleration (1) time setting
Deceleration time setting, 2nd motor
Deceleration time setting, 3rd motor
Keypad Run key routing
A Group: Standard functions
b Group: Fine tuning functions
C Group: Intelligent terminal functions
H Group: Motor constants functions
P Group: Expansion card functions
U Group: User-selectable menu functions
Monitor Mode
-
-
-
-

-


-

-
-
-

-
-
-
-
-
-
-
-
-

-
-
-
-
-
-
-
-
-

-
-
-
-
-

0.00Hz
30.00s
30.00s
30.00s
30.00s
30.00s
30.00s
00
-
-
-
-

-


-

-
-
-
-
-
-
-
-
-
-
-
-
-

-
-
-
-
-
-
-
-
-

-
-
-
-
-

0.00Hz
30.00s
30.00s
30.00s
30.00s
30.00s
30.00s
00
-
-
-
-

-


-

-
-
-
-
-
-
-
-
-
-
-
-
-

-
-
-
-
-
-
-
-
-

-
-
-
-
-

◯
◯
◯
◯◯
◯
◯
◯
×
◯
-
-
-

-


-

◯
-
-
-
-
-
-
-
-
-
-
-
-

-
-
-
-
-
-
-
-
-

-
-
-
-
-

◯
◯
◯
◯◯
◯
◯
◯
×
Setting Mode
Expanded Function
(Example) FW, 7, 2,1:ON
8, 6, 5, 4, 3 : OFF
(Example) 12, 11 : ON
AL, 15, 14, 13 :OFF
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.0 to 999.9, 1000 to 9999 (A)
F (forward rotation), o (stopped), r (reverse rotation)
0.00 to 99.99, 100.0 to 999.9, 1000. to 9999. 1000 to 9999 (10000 to 99990), 「 100 to 「 999 (10000 to 999000)
0.00 to 99.99, 100.0 to 999.9, 1000. to 9999., 1000 to 3996 (10000 to 39960)
-400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz)
-200. to +200. (%)
-200. to +200. (%)
-200. to +200. (%)
0.0 to 600.0 (V)
0.0 to 999.9 (kW)
0.0 to 999.9, 1000. to 9999. , 1000 to 9999 (10000 to 99990), 「 100 to 「 999 (100000 to 999000)
0. to 9999., 1000 to 9999 (10000 to 99990), 「 100 to 「 999 (10000 to 999000) (hr)
0. to 9999., 1000 to 9999 (10000 to 99990),
「 100 to 「 999 (10000 to 999000) (hr)
-020. to 200.0 ( ℃ )
-020. to 200.0 ( ℃ )
0to512
0000 to 9999
-2147483647 to 2147483647 (upper 4 digits including Ò-Ò)
-2147483647 to 2147483647 (upper 4 digits including Ò-Ò)
-2147483647 to 2147483647 (upper 4 digits including Ò-Ò)
0 to 2147483647 (upper 4 digits)
-1073741823 to 1073741823 (upper 4 digits including Ò-Ò)
-1073741823 to 1073741823 (upper 4 digits including Ò-Ò)
0. to 9999., 1000 to 6553 (10000 to 65530) (times)
Factor, frequency (Hz), current (A), voltage across P-N (V),
running time (hours), power-on time (hours)
Warning code
0.0 to 999.9 (V)
0.0 to 100.0 (%)
0.0 to 100.0 (%)
0.0, "start frequency" to "maximum frequency" (or maximum frequency, 2nd/3rd motors) (Hz)
0.0 to 100.0 (when PID function is enabled)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
00 (forward rotation), 01 (reverse rotation)
Frequency source setting
Run command source setting
Base frequency setting
Base frequency setting, 2nd motor
Base frequency setting, 3rd motor
Maximum frequency setting
Maximum frequency setting, 2nd motor
Maximum frequency setting, 3rd motor
[AT] selection
[O2] selection
O-L input active range start frequency
O-L input active range end frequency

01

01
50.
50.
50.
50.
50.
50.

00


03
0.00
0.00


01

01
60.
60.
60.
60.
60.
60.

00


03
0.00
0.00


×

×
×
×
×
×
×
×

×


×
×
×


×

×
×
×
×
×
×
×

×


×
◯
◯

01 (control circuit terminal block), 02 (digital operator), 03 (RS485), 04 (option 1), 05 (option 2)
30. to "maximum frequency " (Hz)
30. to "maximum frequency, 2nd motor" (Hz)
30. to "maximum frequency, 3rd motor" (Hz)
30. to 400. (Hz)
30. to 400. (Hz)
30. to 400. (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
Setting
during operation
(allowed or not)
FW
5487 2361
ON
OFF
AL 1213 1115 14
ON
OFF
1: Capacitor on main circuit board
2: Cooling-fan speed drop
ON
OFF
21
-
d081
d086
PROTECTIVE FUNCTIONS
［◯ = Allowed × = Not permitted ］
［◯ = Allowed
× = Not permitted ］
00 (switching between O and OI terminals), 01 (switching between O and O2 terminals),
02 (switching between O terminal and keypad potentiometer) (*1), 03 (switching between OI terminal
and keypad potentiometer) (*1), 04 (switching between O2 and keypad potentiometer) (*1)
00 (keypad potentiometer) (*1), 01 (control circuit terminal block),
02 (digital operator), 03 (RS485), 04 (option 1), 05 (option 2),
06 (pulse-string input), 07 (easy sequence), 10 (operation function result)
00 (single), 01 (auxiliary frequency input via O and OI terminals) (nonreversible),
02 (auxiliary frequency input via O and OI terminals) (reversible), 03 (disabling O2 terminal)
*1 This setting is valid only when the OPE-SR is connected.
10

O-L input active range start voltabe
O-L input active range end voltabe
O-L input active range start frequency selection
External frequency filter time constant
Easy sequence function selection
Multispeed operation selection
Multispeed frequency setting
Multispeed frequency setting, 2nd motor
Multispeed frequency setting, 3rd motor
Multispeed 1-15 setting
Jog frequency setting
Jog stop mode
Torque boost method selection
Torque boost method selection, 2nd motor
Manual torque boost value
Manual torque boost value, 2nd motor
Manual torque boost value, 3rd motor
Manual torque boost frequency adjustment
Manual torque boost frequency adjustment, 2nd motor
Manual torque boost frequency adjustment, 3rd motor
V/F characteristic curve selection, 1st motor
V/F characteristic curve selection, 2nd motor
V/F characteristic curve selection, 3rd motor
V/f gain setting
Voltage compensation gain setting for automatic torque boost. 1st motor
Voltage compensation gain setting for automatic torque boost, 2nd motor
Slippage compensation gain setting for automatic torque boost, 1st motor
Slippage compensation gain setting for automatic torque boost, 2nd motor
DC braking enable
DC braking frequency setting
DC braking wait time
DC braking force during deceleration
DC braking time for deceleration
DC braking/edge or level detection for [DB] input
DC braking force for starting
DC braking time for starting
DC braking carrier frequency setting
Frequency upper limit setting
Frequency upper limit setting, 2nd motor
Frequency lower limit setting
Frequency lower limit setting, 2nd motor
Jump (center) frequency setting 1
Jump (hysteresis) frequency width setting 1
Jump (center) frequency setting 2
Jump (hysteresis) frequency width setting 2
Jump (center) frequency setting 3
Jump (hysteresis) frequency width setting 3
Acceleration stop time frequency setting
Acceleration stop time frequency setting
PID function enable
PID proportional gain
PID integral time constant
PID derivative gain
PV scale conversion
PV source setting
Output of inverted PID deviation
PID variation range
AVR function select
AVR voltage select
Operation mode selection
Energy saving mode tuning
Acceleration (2) time setting
Acceleration (2) time setting, 2nd motor
Acceleration (2) time setting, 3rd motor
Deceleration (2) time setting
Deceleration (2) time setting, 2nd motor
Deceleration (2) time setting, 3rd motor
Select method to switch to Acc2/Dec2 profile
Select method to switch to Acc2/Dec2, 2nd motor
Acc1 to Acc2 frequency transition point
Acc1 to Acc2 frequency transition point, 2nd motor
Dec1 to Dec2 frequency transition point
Dec1 to Dec2 frequency transition point, 2nd motor
Acceleration curve selection
Deceleration curve selection
OI-L input active range start frequency
OI-L input active range end frequency
OI-L input active range start current
OI-L input active range end current
Multispeed operation and Jogging
V/f CharacteristicDC BrakingPID ControlAVR
External frequency
adjustment
Operation Mode and acceleration/deceleration function
Frequency Upper/Lower Limit and Jump Frequency
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
A013
A014
A015
A016
A017
A019
A020
A220
A320
A038
A039
A041
A241
A042
A242
A342
A043
A243
A343
A044
A244
A344
A045
A046
A246
A047
A247
A051
A052
A053
A054
A055
A056
A057
A058
A059
A061
A261
A062
A262
A063
A064
A065
A066
A067
A068
A069
A070
A071
A072
A073
A074
A075
A076
A077
A078
A081
A082
A085
A086
A092
A292
A392
A093
A293
A393
A094
A294
A095
A295
A096
A296
A097
A098
A101
A102
A103
A104
0. to "[O]-[L] input active range end voltage" (%)
"[O]-[L] input active range start voltage" to 100. (%)
00 (external start frequency), 01 (0 Hz)
1. to 30. or 31. (500 ms filter ±0.1 Hz with hysteresis)
00 (disabling), 01 (enabling)
00 (binary: 16 speeds selectable with 4 terminals), 01 (bit: 8 speeds selectable with 7 terminals)
0.0 or Òstart frequencyÓ to Òmaximum frequencyÓ (Hz)
0.0 or Òstart frequencyÓ to Òmaximum frequency, 2nd motorÓ (Hz)
0.0 or Òstart frequencyÓ to Òmaximum frequency, 3rd motorÓ (Hz)
0.0 or Òstart frequencyÓ to Òn-th maximum frequencyÓ (Hz)
"Start frequency" to 9.99 (Hz)
00(Manual torque boost) / 01(Automatic torque boost)
00(Manual torque boost) / 01(Automatic torque boost)
0.0 to 20.0 (%)
0.0 to 20.0 (%)
0.0 to 20.0 (%)
0.0 to 50.0 (%)
0.0 to 50.0 (%)
0.0 to 50.0 (%)
00 (VC), 01 (VP), 02 (free V/f), 03 (sensorless vector control), 04 (0Hz-range sensorless vector), 05 (vector with sensor)
00 (VC), 01 (VP), 02 (free V/f), 03 (sensorless vector control), 04 (0Hz-range sensorless vector)
00(VC), 01(VP)
20. to 100. (%)
0. to 255.
0. to 255.
0. to 255.
0. to 255.
00 (disabling), 01 (enabling), 02 (set frequency only)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.0 to 5.0 (s)
0. to 100. (%)
0.0 to 60.0 (s)
00 (edge operation), 01 (level operation)
0. to 100.(%)
0.0 to 60.0(s)
0.5 to 15.0(kHz)
0.00 or "1st minimum frequency limit" to "maximum frequency" (Hz)
0.00 or "2nd minimum frequency limit" to "maximum frequency, 2nd motor" (Hz)
0.00 or "start frequency" to "maximum frequency limit" (Hz)
0.00 or "start frequency" to "maximum frequency, 2nd motor limit" (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 10.00 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 10.00 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 10.00 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.0 to 60.0 (s)
00 (disabling), 01 (enabling), 02 (enabling inverted-data output)
0.2 to 5.0
0.0 to 999.9, 1000. to 3600.0 (s)
0.00 to 99.99, 100.0 (s)
0.01 to 99.99
00(OFF), 01 (ON)
0.0 to 100.0 (%)
00 (always on), 01 (always off), 02 (off during deceleration)
200 V class: 200, 215, 220, 230, 240 (V) 400 V class: 380, 400, 415, 440, 460, 480 (V)
00(Normal operation)/ 01(Energy-saving operation)/ 02(Fuzzy operation)
0.1 to 100.0
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
00 (switching by 2CH terminal), 01 (switching by setting), 02 (switching only when rotation is reversed)
00 (switching by 2CH terminal), 01 (switching by setting), 02 (switching only when rotation is reversed)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
00 (linear), 01 (S curve), 02 (U curve), 03 (inverted-U curve), 04 (EL-S curve)
00 (linear), 01 (S curve), 02 (U curve), 03 (inverted-U curve), 04 (EL-S curve)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0. to "[OI]-[L] input active range end current" (%)
"[OI]-[L] input active range start current" to 100. (%)
00 (free-running after jogging stops [disabled during operation]), 01 (deceleration and stop after jogging
stops [disabled during operation]), 02 (DC braking after jogging stops [disabled during operation]),
03 (free-running after jogging stops [enabled during operation]), 04 (deceleration and stop after jogging
stops [enabled during operation]), 05 (DC braking after jogging stops [enabled during operation])
［◯ = Allowed × = Not permitted ］ ［◯ ］
［◯ ］
A021
I
A035
0.
100.
01
31.
00
00
0.00
0.00
0.00

0.00
1.00

00

00
00
1.0
1.0
1.0
5.0
5.0
5.0
00
00
00
100.
100.
100.
100.
100.
00
0.50
0.0
0
0.0
01
0.
0.0
5.0
0.00
0.00
0.00
0.00
0.00
0.50
0.00
0.50
0.00
0.50
0.00
0.0
00
1.0
1.0
0.0
1.00

00
00
0.00
00
230/400
00
50.0
15.00
15.00
15.00
15.00
15.00
15.00
00
00
0.00
0.00
0.00
0.00
00
00
0.00
0.00
20.
100.

0.
100.
01
31.
00
00
0.00
0.00
0.00

0.00
1.00

00

00
00
1.0
1.0
1.0
5.0
5.0
5.0
00
00
00
100.
100.
100.
100.
100.
00
0.50
0.0
0
0.0
01
0.
0.0
5.0
0.00
0.00
0.00
0.00
0.00
0.50
0.00
0.50
0.00
0.50
0.00
0.0
00
1.0
1.0
0.0
1.00

00
00
0.00
00
230/460
00
50.0
15.00
15.00
15.00
15.00
15.00
15.00
00
00
0.00
0.00
0.00
0.00
00
00
0.00
0.00
20.
100.

×
×
×
×
×
×
○
○
○

○
○

×

×
×
○
○
○
○
○
○
×
×
×
○
○
○
○
○
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
○
○
○
×

×
×
×
×
×
×
○
○
○
○
○
○
○
×
×
×
×
×
×
×
×
×
×
×
×

◯
◯
◯
◯
×
×
○
○
○

○
○

○

×
×
○
○
○
○
○
○
×
×
×
○
○
○
○
○
○
○
○
○
○
○
○
○
×
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○

○
○
○
×
×
×
○
○
○
○
○
○
○
×
×
×
×
×
×
×
×
×
○
○
○

00 (input via OI), 01 (input via O), 02 (external communication),
03 (pulse-string frequency input), 10 (operation result output)
Analog input
and others
11

Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
OI-L input start frequency enable
O2-L input active range start frequency
O2-L input active range end frequency
O2-L input active range start voltage
O2-L input active range end voltage
Acceleration curve constants setting
Deceleration curve constants setting
Operation-target frequency selection 1
Operation-target frequency selection 2
Operator selection
Frequency to be added
Sign of the frequency to be added
EL-S-curve acceleration ratio 1
EL-S-curve acceleration ratio 2
EL-S-curve deceleration ratio 1
EL-S-curve deceleration ratio 2
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
A105
A111
A112
A113
A114
A131
A132
A141
A142
A143
A145
A146
A150
A151
A152
A153
00 (external start frequency), 1 (0 Hz)
-400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz)
-400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz)
-100. to 02 end-frequency rate (%)
"02 start-frequency rate" to 100. (%)
01 (smallest swelling) to 10 (largest swelling)
01 (smallest swelling) to 10 (largest swelling)
00 (digital operator), 01 (keypad potentiometer), 02 (input via O), 03 (input via OI),
04 (external communication), 05 (option 1), 06 (option 2), 07 (pulse-string frequency input)
00 (digital operator), 01 (keypad potentiometer), 02 (input via O), 03 (input via OI),
04 (external communication), 05 (option 1), 06 (option 2), 07 (pulse-string frequency input)
00 (addition: A141 + A142), 01 (subtraction: A141 - A142), 02 (multiplication: A141 x A142)
0.00 to 99.99, 100.0 to 400.0 (Hz)
00 (frequency command + A145), 01 (frequency command - A145)
0. to 50. (%)
0. to 50. (%)
0. to 50. (%)
0. to 50. (%)
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
Selection of restart mode
Allowable under-voltage power failure time
Retry wait time before motor restart
Instantaneous power failure/under-voltage trip alarm enable
Number of restarts on power failure/under-voltage trip events
Phase loss detection enable
Restart frequency threshold
Selection of retry after tripping
Selection of retry after undervoltage
Selection of retry count after overvoltage or overcurrent
Retry wait time after tripping
Electronic thermal setting (calculated within the inverter from current output)
Electronic thermal setting (calculated within the inverter from current output), 2nd motor
Electronic thermal setting (calculated within the inverter from current output), 3rd motor
Electronic thermal characteristic
Electronic thermal characteristic, 2nd motor
Electronic thermal characteristic, 3rd motor
Free-setting electronic thermal frequency (1)
Free-setting electronic thermal current (1)
Free-setting electronic thermal frequency (2)
Free-setting electronic thermal current (2)
Free-setting electronic thermal frequency (3)
Free-setting electronic thermal current (3)
Overload restriction operation mode
Overload restriction setting
Deceleration rate at overload restriction
Overload restriction operation mode (2)
Overload restriction setting (2)
Deceleration rate at overload restriction (2)
Overcurrent suppression enable
Active frequency matching, scan start frequency
Active frequency matching, scan-time constant
Active frequency matching, restart frequency select
Software lock mode selection
RUN/ power-on warning time
Rotational direction restriction
Reduced voltage start selection
Function code display restriction
Initial-screen selection
Automatic user-parameter setting function enable
Torque limit selection
Torque limit(1) (Forward-driving in 4-quadrant mode)
Torque limit(2) (Reverse-regenerating in 4-quadrant mode)
Torque limit(3) (Reverse-driving in 4-quadrant mode)
Torque limit(4) (Forward-regenerating in 4-quadrant mode)
Torque limit LADSTOP enable
Reverse RUN protection enable
Controlled deceleration and stop on power loss
DC bus voltage trigger level during power loss
Over-voltage threshold during power loss
Deceleration time setting during power loss
Initial output frequency decrease during power loss
Proportional gain setting for nonstop operation at power loss
Restart after instantaneous power failure or tripping
Electronic thermal function
Overload restriction and overcurrent restraint
Others
Torque limitation
Non-stop operation at
momentary power failure software
lock
Operation-target frequency Acceleration
and
deceleration
Acceleration
and deceleration
b001
b002
b003
b004
b005
b006
b007
b008
b009
b010
b011
b012
b212
b312
b013
b213
b313
b015
b016
b017
b018
b019
b020
b021
b022
b023
b024
b025
b026
b027
b028
b029
b030
b031
b034
b035
b036
b037
b038
b039
b040
b041
b042
b043
b044
b045
b046
b050
b051
b052
b053
b054
b055
00 (tripping), 01 (starting with 0 Hz), 02 (starting with matching frequency), 03 (tripping after
deceleration and stopping with matching frequency), 04 (restarting with active matching frequency)
0.3 to 25.0 (s)
0.3 to 100.0 (s)
00 (disabling), 01 (enabling), 02 (disabling during stopping and decelerating to stop)
00 (16 times), 01 (unlimited)
00 (disabling), 01 (enabling)
0.00 to 99.99, 100.0 to 400.0 (Hz)
00 (tripping), 01 (starting with 0 Hz), 02 (starting with matching frequency), 03 (tripping after
deceleration and stopping with matching frequency), 04 (restarting with active matching frequency)
00 (16 times), 01 (unlimited)
1 to 3 (times)
0.3 to 100.0 (s)
0.20 x "rated current" to 1.00 x "rated current" (A)
0.20 x "rated current" to 1.00 x "rated current" (A)
0.20 x "rated current" to 1.00 x "rated current" (A)
00 (reduced-torque characteristic), 01 (constant-torque characteristic), 02 (free setting)
00 (reduced-torque characteristic), 01 (constant-torque characteristic), 02 (free setting)
00 (reduced-torque characteristic), 01 (constant-torque characteristic), 02 (free setting)
0. to 400. (Hz)
0.00 to rated current (A)
0. to 400. (Hz)
0.00 to rated current (A)
0. to 400. (Hz)
0.00 to rated current (A)
00 (disabling), 01 (enabling during acceleration and deceleration), 02 (enabling during constant
speed), 03 (enabling during acceleration and deceleration (increasing the speed during regeneration))
0.20 x "rated current" to 1.00 x "rated current" (A)
0.10 to 30.00 (s)
00 (disabling), 01 (enabling during acceleration and deceleration), 02 (enabling during constant speed),
03 (enabling during acceleration and deceleration (increasing the speed during regeneration))
0.20 x "rated current" to 2.00 x "rated current" (A)
0.10 to 30.00 (s)
00 (disabling), 01 (enabling)
0.20 x "rated current" to 2.00 x "rated current" (A)
0.10 to 30.00 (s)
00 (frequency at the last shutoff), 01 (maximum frequency), 02 (set frequency)
0. to 9999. (0 to 99990), 1000 to 6553 (10000 to 655300) (hr)
00 (enabling both forward and reverse rotations), 01 (enabling only forward rotation), 02 (enabling only reverse rotation)
0 (minimum reduced voltage start time) to 255 (maximum reduced voltage start time)
00 (full display), 01 (function-specific display), 02 (user setting), 03 (data comparison display), 04 (basic display)
00 (screen displayed when the STR key was pressed last), 01 (d001), 02 (d002), 03 (d003), 04 (d007), 05 (F001)
00 (disabling), 01 (enabling)
00 (quadrant-specific setting), 01 (switching by terminal), 02 (analog input), 03 (option 1), 04 (option 2)
0. to 200. (%), no (disabling torque limitation)
0. to 200. (%), no (disabling torque limitation)
0. to 200. (%), no (disabling torque limitation)
0. to 200. (%), no (disabling torque limitation)
00 (disabling), 01 (enabling)
00 (disabling), 01 (enabling)
00 (disabling), 01 (enabling)
0.0 to 999.9, 1000. (V)
0.0 to 999.9, 1000. (V)
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
0.00 to 10.00 (Hz)
0.00 to 2.55
● B GROUP: FINE TUNING FUNCTIONS
00 (disabling change of data other than "b031" when SFT is on), 01 (disabling change
of data other than "b031" and frequency settings when SFT is on), 02 (disabling change
of data other than "b031"), 03 (disabling change of data other than "b031" and
frequency settings), 10 (enabling data changes during operation)
［◯ ］ ［◯ = Allowed × = Not permitted ］
［◯ = Allowed
× = Not permitted ］
Rated current of
inverterx 1..0
Rated current x 1.50
Rated current x 1.50
Rated current of inverterx 1..0
◯
◯
◯
◯
00
0.00
0.00
-100.
100.
02
02

02

03
00
0.00
00
25.
25.
25.
25.
00
0.00
0.00
-100.
100.
02
02

02

03
00
0.00
00
25.
25.
25.
25.
×
×
×
×
×
×
×

×

×
×
×
×
×
×
×
×
○
○
○
○
○
○
○

○

○
○
○
○
×
×
×
×
00
1.0
1.0
00
00
00
0.00

00
00
3
1.0



01
01
01
0.
0.0
0.
0.0
0.
0.0

01

1.00

01

1.00
01

0.50
00

01

0.
00
06
04
01
00
00
150.
150.
150.
150.
00
00
00
0.0
0.0
1.00
0.00
0.20

00
1.0
1.0
00
00
00
0.00

00
00
3
1.0



01
01
01
0.
0.0
0.
0.0
0.
0.0

01

1.00

01

1.00
01

0.50
00

01

0.
00
06
04
01
00
00
150.
150.
150.
150.
00
00
00
0.0
0.0
1.00
0.00
0.20

×
×
×
×
×
×
×

×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×

×
×
×

×
×
×
×
×
×
×

×

×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
○

○
○
○
○
○
○
○

○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○

○
○
○

○
○
○
○
○
○
○

○

○
×
○
○
○
○
○
○
○
○
○
○
○
×
×
×
×
×
○

External frequency
adjustment
12

Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Integral time setting for nonstop operation at power loss
Maximum-limit level of window comparators O
Minimum-limit level of window comparators O
Hysteresis width of window comparators O
Maximum-limit level of window comparators OI
Minimum-limit level of window comparators OI
Hysteresis width of window comparators OI
Maximum-limit level of window comparators OI
Minimum-limit level of window comparators O/OI/O2
Hysteresis width of window comparators O/OI/O2
Operation level at O disconnection
Operation level at OI disconnection
Operation level at O2 disconnection
Cumulative input power data clearance
Cumulative input power display gain setting
Start frequency adjustment
Carrier frequency setting
Initialization mode (parameters or trip history)
Country code for initialization
Frequency scaling conversion factor
STOP key enable
Restart mode after FRS
Automatic carrier frequency reduction
Dynamic braking usage ratio
Stop mode selection
Cooling fan control
Dynamic braking control
Dynamic braking activation level
Thermistor for thermal protection control
Thermal protection level setting
Free-setting V/f frequency (1)
Free-setting V/f voltage (1)
Free-setting V/f frequency (2)
Free-setting V/f voltage (2)
Free-setting V/f frequency (3)
Free-setting V/f voltage (3)
Free-setting V/f frequency (4)
Free-setting V/f voltage (4)
Free-setting V/f frequency (5)
Free-setting V/f voltage (5)
Free-setting V/f frequency (6)
Free-setting V/f voltage (6)
Free-setting V/f frequency (7)
Free-setting V/f voltage (7)
Brake control enable
Brake wait time for release
Brake wait time for acceleration
Brake wait time for stopping
Brake wait time for confirmation
Brake release frequency setting
Brake release current setting
Braking frequency
Overvoltage suppression enable
Overvoltage suppression level
Acceleration and deceleration rate at overvoltage suppression
Overvoltage suppression propotional gain
Overvoltage suppression Integral time
Window comparatorOthersFree setting of V/f characteristicOthers
Code Function Name Monitored data or setting
b056
b060
b061
b062
b063
b064
b065
b066
b067
b068
b070
b071
b072
b078
b079
b082
b083
b084
b085
b086
b087
b088
b089
b090
b091
b092
b095
b096
b098
b099
b100
b101
b102
b103
b104
b105
b106
b107
b108
b109
b110
b111
b112
b113
b120
b121
b122
b123
b124
b125
b126
b127
b130
b131
b132
b133
b134
0.0 to 9.999 /10.00 to 65.55
0. to 100. (lower limit : b061 + b062 / 2) (%)
0. to 100. (lower limit : b060 - b062 / 2) (%)
0. to 10. (lower limit : b061 - b062 / 2) (%)
0. to 100. (lower limit : b064 + b066 / 2) (%)
0. to 100. (lower limit : b063 - b066 / 2) (%)
0. to 10. (lower limit : b063 - b064 / 2) (%)
-100. to 100. (lower limit : b067 + b068 / 2) (%)
-100. to 100. (lower limit : b066 - b068 / 2) (%)
0. to 10. (lower limit : b066 - b067 / 2) (%)
0 to 100 (%) or "no" (ignore)
0 to 100 (%) or "no" (ignore)
0 to 100 (%) or "no" (ignore)
Clearance by setting "01" and pressing the STR key
1. to 1000.
0.10 to 9.99 (Hz)
0.5 to 15.0 (kHz) (subject to derating)
00 (clearing the trip history), 01 (initializing the data), 02 (clearing the trip history and initializing the data)
00 (Japan), 01 (EU), 02 (U.S.A.)
0.1 to 99.0
00 (enabling), 01 (disabling), 02 (disabling only the function to stop)
00 (starting with 0 Hz), 01 (starting with matching frequency), 02 (starting with active matching frequency)
00: invalid, 01: valid
0.0 to 100.0 (%)
00 (deceleration until stop), 01 (free-run stop)
00 (always operating the fan), 01 (operating the fan only during inverter operation
[including 5 minutes after power-on and power-off])
00 (disabling), 01 (enabling [disabling while the motor is topped]), 02 (enabling [enabling also while the motor is topped])
330 to 380, 660 to 760(V)
00 (disabling the thermistor), 01 (enabling the thermistor with PTC), 02 (enabling the thermistor with NTC)
0. to 9999. ( Ω )
0. to "free-setting V/f frequency (2)" (Hz)
0.0 to 800.0 (V)
0. to "free-setting V/f frequency (3)" (Hz)
0.0 to 800.0 (V)
0. to "free-setting V/f frequency (4)" (Hz)
0.0 to 800.0 (V)
0. to "free-setting V/f frequency (5)" (Hz)
0.0 to 800.0 (V)
0. to "free-setting V/f frequency (6)" (Hz)
0.0 to 800.0 (V)
0. to "free-setting V/f frequency (7)" (Hz)
0.0 to 800.0 (V)
0. to "free-setting V/f frequency (8)" (Hz)
0.0 to 800.0 (V)
00 (disabling), 01 (enabling)
0.00 to 5.00 (s)
0.00 to 5.00 (s)
0.00 to 5.00 (s)
0.00 to 5.00 (s)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.0 to 2.00 x "rated current"
0.00 to 99.99, 100.0 to 400.0 (Hz)
00 (disabling the restraint), 01 (decelerating and stagnating), 02 (enabling acceleration)
330 to 390 (V) (200 V class model), 660 to 780 (V) (400 V class model)
0.10 to 30.00 (s)
0.00 to 2.55
0.000 to 9.999 / 10.00 to 63.53 (s)
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
Intelligent input terminals
Code
● C GROUP: INTELLIGENT TERMINAL FUNCTIONS
01 (RV: Reverse RUN), 02 (CF1: Multispeed 1 setting), 03 (CF2: Multispeed 2 setting),
04 (CF3: Multispeed 3 setting), 05 (CF4: Multispeed 4 setting), 06 (JG: Jogging), 07 (DB:
external DC braking), 08 (SET: Set 2nd motor data), 09 (2CH: 2-stage
acceleration/deceleration), 11 (FRS: free-run stop), 12 (EXT: external trip), 13 (USP:
unattended start protection), 14: (CS: commercial power source enable), 15 (SFT: software
lock), 16 (AT: analog input voltage/current select), 17 (SET3: 3rd motor control), 18 (RS: reset),
20 (STA: starting by 3-wire input), 21 (STP: stopping by 3-wire input), 22 (F/R: forward/reverse
switching by 3-wire input), 23 (PID: PID disable), 24 (PIDC: PID reset), 26 (CAS: control gain
setting), 27 (UP: remote control UP function), 28 (DWN: remote control DOWN function), 29
(DWN: remote control data clearing), 31 (OPE: forcible operation), 32 (SF1: multispeed bit 1),
33 (SF2: multispeed bit 2), 34 (SF3: multispeed bit 3), 35 (SF4: multispeed bit 4), 36 (SF5:
multispeed bit 5), 37 (SF6: multispeed bit 6), 38 (SF7: multispeed bit 7), 39 (OLR: overload
restriction selection), 40 (TL: torque limit enable), 41 (TRQ1: torque limit selection bit 1), 42
(TRQ2: torque limit selection bit 2), 43 (PPI: P/PI mode selection), 44 (BOK: braking
confirmation), 45 (ORT: orientation), 46 (LAC: LAD cancellation), 47 (PCLR: clearance of
position deviation), 48 (STAT: pulse train position command input enable), 50 (ADD: trigger for
frequency addition [A145]), 51 (F-TM: forcible-terminal operation), 52 (ATR: permission of
torque command input), 53 (KHC: cumulative power clearance), 54 (SON: servo-on), 55 (FOC:
pre-excitation), 56 (MI1: general-purpose input 1), 57 (MI2: general-purpose input 2), 58 (MI3:
general-purpose input 3), 59 (MI4: general-purpose input 4), 60 (MI5: general-purpose input 5),
61 (MI6: general-purpose input 6), 62 (MI7: general-purpose input 7), 63 (MI8: general-purpose
input 8), 65 (AHD: analog command holding), 66 (CP1: multistage position settings selection 1
), 67 (CP2: multistage position settings selection 2), 68 (CP3: multistage position settings
selection 3), 69 (ORL: Zero-return limit function), 70 (ORG: Zero-return trigger function), 71
(FOT: forward drive stop), 72 (ROT: reverse drive stop), 73 (SPD: speed / position switching),
74 (PCNT: pulse counter), 75 (PCC: pulse counter clear), no (NO: no assignment)
［◯ = Allowed × = Not permitted ］ ［◯ ］
［◯ = Allowed × = Not permitted ］
Rated current of inverterx 1..0
0.100
100
0
0
100
0
0
100
-100
0
255(no)
255(no)
127(no)
00
1.
0.50
5.0
00
01
1.0
00
00
00
0.0
00

00
00
360/720
00
3000.
0.
0.0
0.
0.0
0.
0.0
0.
0.0
0.
0.0
0.
0.0
0.
0.0
00
0.00
0.00
0.00
0.00
0.00

0.00
00
380/760
1.00
0.50
0.060
0.100
100
0
0
100
0
0
100
-100
0
255(no)
255(no)
127(no)
00
1.
0.50
5.0
00
01
1.0
00
00
00
0.0
00

00
00
360/720
00
3000.
0.
0.0
0.
0.0
0.
0.0
0.
0.0
0.
0.0
0.
0.0
0.
0.0
00
0.00
0.00
0.00
0.00
0.00

0.00
00
380/760
1.00
0.50
0.060
○
○
○
○
○
○
○
○
○
○
×
×
×
○
×
×
×
×
×
○
×
×
×
×
×

×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
×
○
×
×
×
○
○
○
×
○
○

○
○
○
○
○
×
×
×
×
×
×
×
×
×
×
×
×
×
×
○
○
○
○
○
○
○
○
○
○
○
○
○
Terminal [1] function (*2)
Terminal [2] function
Terminal [3] function (*2)
Terminal [4] function
Terminal [5] function
Terminal [6] function
Terminal [7] function
Terminal [8] function
C001
C002
C003
C004
C005
C006
C007
C008
18(RS)
16(AT)
06(JG)
11(FRS)
09(2CH)
03(CF2)
02(CF1)
01(RV)

18(RS)
16(AT)
06(JG)
11(FRS)
09(2CH)
13(USP)
02(CF1)
01(RV)

×
×
×
×
×
×
×
×

○
○
○
○
○
○
○
○

*2 When the emergency stop function is enabled (SW1 = ON), "18" (RS) and "64" (EMR) are forcibly written to parameters "C001" and "C003",
respectively. (You cannot arbitrarily write "64" to "C001".) If the SW1 signal is turned off and then turned on, "no" (no assignment) is set in parameter "C003".
13

Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
Intelligent output terminalsAnalog monitoringLevels and output terminal statusCommunication functionAdjustmentOthers Intelligent
output terminals
Intelligent input terminals
Terminal (1) active state
Terminal (2) active state
Terminal (3) active state
Terminal (4) active state
Terminal (5) active state
Terminal (6) active state
Terminal (7) active state
Terminal (8) active state
Terminal FW active state
FM signal selection
AM signal selection
AMI signal selection
Digital current monitor reference value
Terminal (11) active state
Terminal (12) active state
Terminal (13) active state
Terminal (14) active state
Terminal (15) active state
Alarm relay terminal active state
Low-current indication signal output mode selection
Low-current indication signal detection level
Overload signal output mode
Overload level setting
Frequency arrival setting for accel.
Frequency arrival setting for decel.
PID deviation level setting
Frequency arrival setting for acceleration (2)
Frequency arrival setting for deceleration (2)
Maximum PID feedback data
Minimum PID feedback data
Over-torque(Forward-driving) level setting
Over-torque(Reverse-regenerating) level setting
Over-torque(Reverse-driving) level setting
Over-torque(Forward-regenerating) level setting
Electronic thermal warning level setting
Alarm code input
Zero speed detection level
Heat sink overheat warning level
Communication speed selection
Node allocation
Communication data length selection
Communication parity selection
Communication stop bit selection
Selection of the operation after communication error
Communication timeout limit before tripping
Communication wait time
Communication mode selection
O input span calibration
OI input span calibration
O2 input span calibration
Thermistor input tuning
Debug mode enable
UP/DOWN memory mode selection
Reset mode selection
Restart mode after reset
FM gain adjustment
AM gain adjustment
C011
C012
C013
C014
C015
C016
C017
C018
C019
C027
C028
C029
C030
C031
C032
C033
C034
C035
C036
C038
C039
C040
C041
C042
C043
C044
C045
C046
C052
C053
C055
C056
C057
C058
C061
C062
C063
C064
C071
C072
C073
C074
C075
C076
C077
C078
C079
C081
C082
C083
C085
C091
C101
C102
C103
C105
C106
00 (RUN: running), 01 (FA1: constant-speed reached), 02 (FA2: set frequency overreached), 03 (OL:
overload notice advance signal (1)), 04 (OD: output deviation for PID control), 05 (AL: alarm signal), 06
(FA3: set frequency reached), 07 (OTQ: over-torque), 08 (IP: instantaneous power failure), 09 (UV:
undervoltage), 10 (TRQ: torque limited), 11 (RNT: operation time over), 12 (ONT: plug-in time over), 13
(THM: thermal alarm signal), 19 (BRK: brake release), 20 (BER: braking error), 21 (ZS: 0 Hz detection
signal), 22 (DSE: speed deviation maximum), 23 (POK: positioning completed), 24 (FA4: set frequency
overreached 2), 25 (FA5: set frequency reached 2), 26 (OL2: overload notice advance signal (2)), 27 (Odc:
Analog O disconnection detection), 28 (OIDc: Analog OI disconnection detection), 29 (O2Dc: Analog O2
disconnection detection), 31 (FBV: PID feedback comparison), 32 (NDc: communication line disconnection),
33 (LOG1: logical operation result 1), 34 (LOG2: logical operation result 2), 35 (LOG3: logical operation
result 3), 36 (LOG4: logical operation result 4), 37 (LOG5: logical operation result 5), 38 (LOG6: logical
operation result 6), 39 (WAC: capacitor life warning), 40 (WAF: cooling-fan speed drop), 41 (FR: starting
contact signal), 42 (OHF: heat sink overheat warning), 43 (LOC: low-current indication signal), 44 (M01:
general-purpose output 1), 45 (M02: general-purpose output 2), 46 (M03: general-purpose output 3), 47
(M04: general-purpose output 4), 48 (M05: general-purpose output 5), 49 (M06: general-purpose output 6),
50 (IRDY: inverter ready), 51 (FWR: forward rotation), 52 (RVR: reverse rotation), 53 (MJA: major failure),
54(WCO: window comparator O), 55(WCOI: window comparator OI), 56 (WCO2: window comparator O2)
(When alarm code output is selected for "C062", functions "AC0" to "AC2" or "AC0" to "AC3" [ACn: alarm
code output] are forcibly assigned to intelligent output terminals 11 to 13 or 11 to 14, respectively.)
00 (output frequency), 01 (output current), 02 (output torque), 03 (digital output frequency), 04 (output
voltage), 05 (input power), 06 (electronic thermal overload), 07 (LAD frequency), 08 (digital current
monitoring), 09 (motor temperature), 10 (heat sink temperature), 12 (general-purpose output YA0)
00 (output frequency), 01 (output current), 02 (output torque), 04 (output voltage), 05 (input power), 06
(electronic thermal overload), 07 (LAD frequency), 09 (motor temperature), 10 (heat sink temperature), 11
(output torque [signed value]), 13 (general-purpose output YA1)
00 (output frequency), 01 (output current), 02 (output torque), 04 (output voltage), 05 (input power), 06
(electronic thermal overload), 07 (LAD frequency), 09 (motor temperature), 10 (heat sink temperature), 14
(general-purpose output YA2)
［◯ ］ ［◯ = Allowed × = Not permitted ］
［◯ ］
0.20 x "rated current" to 2.00 x "rated current" (A)
(Current with digital current monitor output at 1,440 Hz)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00 (output during acceleration/deceleration and constant-speed operation),
01 (output only during constant-speed operation)
0.0 to 2.00 x "rated current" (A)
00 (output during acceleration/deceleration and constant-speed operation),
01 (output only during constant-speed operation)
0.0 to 2.00 x "rated current" (A)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.0 to 100.0 (%)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.0 to 100.0 (%)
0.0 to 100.0 (%)
0. to 200. (%)
0. to 200. (%)
0. to 200. (%)
0. to 200. (%)
0. to 100. (%)
00(Disabled) / 01(3-bit) / 02(4-bit)
0.00 to 99.99, 100.0 (Hz)
0. to 200.0 ( ℃ )
02 (loopback test), 03 (2,400 bps), 04 (4,800 bps), 05 (9,600 bps), 06 (19,200 bps)
1. to 32.
7 (7 bits), 8 (8 bits)
00 (no parity), 01 (even parity), 02 (odd parity)
1 (1 bit), 2 (2 bits)
00 (tripping), 01 (tripping after decelerating and stopping the motor), 02 (ignoring errors),
03 (stopping the motor after free-running), 04 (decelerating and stopping the motor)
0.00 to 99.99 (s)
0. to 1000. (ms)
00(ASCII), 01(Modbus-RTU)
0. to 9999., 1000 to 6553(10000 to 65530)
0. to 9999., 1000 to 6553(10000 〜 65530)
0. to 9999., 1000 to 6553(10000 〜 65530)
0.0 to 999.9, 1000.
(Do not change this parameter, which is intended for factory adjustment.)
00 (not storing the frequency data), 01 (storing the frequency data)
00 (resetting the trip when RS is on), 01 (resetting the trip when RS is off),
02 (enabling resetting only upon tripping [resetting when RS is on])
00 (starting with 0 Hz), 01 (starting with matching frequency), 02 (restarting with active matching frequency)
50. to 200. (%)
50. to 200. (%)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00(NO) / 01(NC)
00
00
00
00
00
00
00
00
00
















00


00


00



00
00
00
00
00
01

01


01

0.00
0.00
3.0
0.00
0.00
100.0
0.0
100.
100.
100.
100.
80.
00
0,00
120.
04
1.
7
00
1

02
0.00
0.
00




00
00

00

100.
100.
00
00
00
00
00
01
00
00
00
















00


00


00



00
00
00
00
00
01

01


01

0.00
0.00
3.0
0.00
0.00
100.0
0.0
100.
100.
100.
100.
80.
00
0,00
120.
04
1.
7
00
1

02
0.00
0.
00




00
00

00

100.
100.
×
×
×
×
×
×
×
×
×
















×


×


×


○
×
×
×
×
×
×

×
×

×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×

×
×
×
×
×
×
×
×
×
×

○
×
○
○
○
○
○
○
○
○
○
○
○
















○


○


○


○
○
○
○
○
○
○

○
○

○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○

○
○
○
○
○
○
○
○
×
○

○
○
○
○
Rated current of
inverterx 1..0
Rated current of inverterx 1..0
Rated current of inverterx 1..0
Rated current of inverterx 1..0
Factory set
Terminal (11) function
Terminal (12) function
Terminal (13) function
Terminal (14) function
Terminal (15) function
Alarm relay terminal function
C021
C022
C023
C024
C025
C026
01(FA1)
00(RUN)
03(OL)
07(OTO)
40(WAF)
05(AL)



01(FA1)
00(RUN)
03(OL)
07(OTO)
40(WAF)
05(AL)




×
×
×
×
×
×


○
○
○
○
○
○





Meter
adjustment
14

［◯ ］
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
AMI gain adjustment
AM bias adjustment
AMI bias adjustment
Overload setting (2)
O input zero calibration
OI input zero calibration
O2 input zero calibration
Output 11 on-delay time
Output 11 off-delay time
Output 12 on-delay time
Output 12 off-delay time
Output 13 on-delay time
Output 13 off-delay time
Output 14 on-delay time
Output 14 off-delay time
Output 15 on-delay time
Output 15 off-delay time
Output RY on-delay time
Output RY off-delay time
Logical output signal 1 selection 1
Logical output signal 1 selection 2
Logical output signal 1 operator selection
Logical output signal 2 selection 1
Logical output signal 2 selection 2
Logical output signal 2 operator selection
Logical output signal 3 selection 1
Logical output signal 3 selection 2
Logical output signal 3 operator selection
Logical output signal 4 selection 1
Logical output signal 4 selection 2
Logical output signal 4 operator selection
Logical output signal 5 selection 1
Logical output signal 5 selection 2
Logical output signal 5 operator selection
Logical output signal 6 selection 1
Logical output signal 6 selection 2
Logical output signal 6 operator selection
Input terminal response time setting 1
Input terminal response time setting 2
Input terminal response time setting 3
Input terminal response time setting 4
Input terminal response time setting 5
Input terminal response time setting 6
Input terminal response time setting 7
Input terminal response time setting 8
Input terminal response time setting FW
Multistage speed/position determination time
50. to 200. (%)
0. to 100. (%)
0. to 100. (%)
0.0 to 2.00 x "rated current" (A)
0. to 9999., 1000 to 6553 (10000 to 65530)
0. to 9999., 1000 to 6553 (10000 to 65530)
0. to 9999., 1000 to 6553 (10000 to 65530)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
0.0 to 100.0 (s)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
00 (AND), 01 (OR), 02 (XOR)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
00 (AND), 01 (OR), 02 (XOR)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
00 (AND), 01 (OR), 02 (XOR)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
00 (AND), 01 (OR), 02 (XOR)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
00 (AND), 01 (OR), 02 (XOR)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
Same as the settings of C021 to C026 (except those of LOG1 to LOG6)
00 (AND), 01 (OR), 02 (XOR)
0. to 200. ( × 2ms)
0. to 200. ( × 2ms)
0. to 200. ( × 2ms)
0. to 200. ( × 2ms)
0. to 200. ( × 2ms)
0. to 200. ( × 2ms)
0. to 200. ( × 2ms)
0. to 200. ( × 2ms)
0. to 200. ( × 2ms)
0. to 200. ( × 10ms)
Terminal
other
C107
C109
C110
C111
C121
C122
C123
C130
C131
C132
C133
C134
C135
C136
C137
C138
C139
C140
C141
C142
C143
C144
C145
C146
C147
C148
C149
C150
C151
C152
C153
C154
C155
C156
C157
C158
C159
C160
C161
C162
C163
C164
C165
C166
C167
C168
C169
［◯ = Allowed × = Not permitted ］
Adjustment
Output terminal operation functionInput terminal response
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
Auto-tuning Setting
Motor data selection, 1st motor
Motor data selection, 2nd motor
Motor capacity, 1st motor
Motor capacity, 2nd motor
Motor poles setting, 1st motor
Motor poles setting, 2nd motor
Motor speed constant, 1st motor
Motor speed constant, 2nd motor
Motor stabilization constant, 1st motor
Motor stabilization constant, 2nd motor
Motor stabilization constant, 3rd motor
Motor constant R1, 1st motor
Motor constant R1, 2nd motor
Motor constant R2, 1st motor
Motor constant R2, 2nd motor
Motor constant L, 1st motor
Motor constant L, 2nd motor
Motor constant Io
Motor constant Io, 2nd motor
Motor constant J
Motor constant J, 2nd motor
Auto constant R1, 1st motor
Auto constant R1, 2nd motor
Auto constant R2, 1st motor
Auto constant R2, 2nd motor
Auto constant L, 1st motor
Auto constant L, 2nd motor
Auto constant Io, 1st motor
Auto constant Io, 2nd motor
00 (disabling auto-tuning), 01 (auto-tuning without rotation), 02 (auto-tuning with rotation)
00 (Hitachi standard data), 01 (auto-tuned data), 02 (auto-tuned data [with online auto-tuning function])
00 (Hitachi standard data), 01 (auto-tuned data), 02 (auto-tuned data [with online auto-tuning function])
0.20 to 75.00 (kW)
0.20 to 75.00 (kW)
2, 4, 6, 8, 10 (poles)
2, 4, 6, 8, 10 (poles)
0.001 to 9.999, 10.00 to 80.00 (10.000 to 80.000)
0.001 to 9.999, 10.00 to 80.00 (10.000 to 80.000)
0. to 255.
0. to 255.
0. to 255.
0.001 to 9.999, 10.00 to 65.53 ( Ω )
0.001 to 9.999, 10.00 to 65.53 ( Ω )
0.001 to 9.999, 10.00 to 65.53 ( Ω )
0.001 to 9.999, 10.00 to 65.53 ( Ω )
0.01 to 99.99, 100.0 to 655.3 (mH)
0.01 to 99.99, 100.0 to 655.3 (mH)
0.01 to 99.99, 100.0 to 655.3 (A)
0.01 to 99.99, 100.0 to 655.3 (A)
0.001 to 9.999, 10.00 to 99.99, 100.0 to 999.9, 1000. to 9999.
0.001 to 9.999, 10.00 to 99.99, 100.0 to 999.9, 1000. to 9999.
0.001 to 9.999, 10.00 to 65.53 ( Ω )
0.001 to 9.999, 10.00 to 65.53 ( Ω )
0.001 to 9.999, 10.00 to 65.53 ( Ω )
0.001 to 9.999, 10.00 to 65.53 ( Ω )
0.01 to 99.99, 100.0 to 655.3 (mH)
0.01 to 99.99, 100.0 to 655.3 (mH)
0.01 to 99.99, 100.0 to 655.3 (A)
0.01 to 99.99, 100.0 to 655.3 (A)
H001
H002
H202
H003
H203
H004
H204
H005
H205
H006
H206
H306
H020
H220
H021
H221
H022
H222
H023
H223
H024
H224
H030
H230
H031
H231
H032
H232
H033
H233
［◯ = Allowed × = Not permitted ］
Control constants
［◯ ］
［◯ ］
100.
0.
20.





0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
1
1
1
1
1
1
1
1
1
0
100.
0.
20.





0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
00
1
1
1
1
1
1
1
1
1
0
○
○
○

×
○
○
○
○
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
○
○
○

○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
00
00
00


4
4
1,590
1,590
100.
100.
100.

00
00
00


4
4
1,590
1,590
100.
100.
100.

×
×
×
×
×
×
×
○
○
○
○
○
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
○
○
○
○
○
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
Rated current of
inverterx 1..0
Factory set
Factory set
Depending on
motor capacity
● H GROUP: MOTOR CONSTANTS FUNCTIONS
Meter
adjustment
15

Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
Auto constant J, 1st motor
Auto constant J, 2nd motor
PI proportional gain for 1st motor
PI proportional gain for 2nd motor
PI integral gain for 1st motor
PI integral gain for 2nd motor
P proportional gain setting for 1st motor
P proportional gain setting for 2nd motor
Zero LV lmit for 1st motor
Zero LV lmit for 2nd motor
Zero LV starting boost current for 1st motor
Zero LV starting boost current for 2nd motor
Terminal selection PI proportional gain setting
Terminal selection PI integral gain setting
Terminal selection P proportional gain setting
Gain switching time
0.001 to 9.999, 10.00 to 99.99, 100.0 to 999.9, 1000. to 9999.
0.001 to 9.999, 10.00 to 99.99, 100.0 to 999.9, 1000. to 9999.
0.0 to 999.9, 1000.
0.0 to 999.9, 1000.
0.0 to 999.9, 1000.
0.0 to 999.9, 1000.
0.01 to 10.00
0.01 to 10.00
0.0 to 100.0
0.0 to 100.0
0. to 50. (%)
0. to 50. (%)
0.0 to 999.9, 1000.
0.0 to 999.9, 1000.
0.00 to 10.00
0. to 9999. (ms)
H034
H234
H050
H250
H051
H251
H052
H252
H060
H260
H061
H261
H070
H071
H072
H073
［◯ = Allowed × = Not permitted ］［◯ ］
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
● U GROUP: USER-SELECTABLE MENU FUNCTIONS
no/d001 to P131
［◯ ］
Code Function Name Default Setting
-FE(CE) -FU(UL)
Change
during operation
(allowed or not)
Setting
during operation
(allowed or not)
Monitored data or setting
Operation mode on expansion card 1 error
Operation mode on expansion card 2 error
Encoder pulse-per-revolution (PPR) setting
Control pulse setting
Pulse input mode setting
Home search stop position setting
Home search speed setting
Home search direction setting
Home search completion range setting
Home search completion delay time setting
Electronic gear set position selection
Electronic gear ratio numerator setting
Electronic gear ratio denominator setting
Feed-forward gain setting
Position loop gain setting
Position bias setting
Temperature compensation thermistor enable
Over-speed error detection level setting
Speed deviation error detection level setting
Numerator of motor gear ratio
Denominator of motor gear ratio
Accel./decel. time input selection
Positioning command input selection
Torque command input selection
Torque command setting
Polarity selection at the torque command input via O2 terminal
Torque bias mode
Torque bias value
Torque bias polarity selection
Speed limit for torque-controlled operation (forward rotation)
Speed limit for torque-controlled operation (reverse rotation)
DeviceNet comm watchdog timer
Inverter action on DeviceNet comm error
DeviceNet polled I/O : Output instance number
DeviceNet polled I/O : input instance number
Inverter action on DeviceNet idle mode
DeviceNet motor poles setting for RPM
Pulse-string frequency scale
Time constant of pulse-string frequency filter
Pulse-string frequency bias
Pulse-string frequency limit
Multistage position setting 0-7
Zero-return mode selection
Zero-return direction selection
Low-speed zero-return frequency
High-speed zero-return frequency
Position range specification (forward)
Position range specification (reverse)
Teaching selection
Easy sequence user parameter U (00)-(31)
00 (tripping), 01 (continuing operation)
00 (tripping), 01 (continuing operation)
128. to 9999., 1000 to 6500 (10000 to 65000) (pulses)
00 (ASR), 01 (APR), 02 (APR2), 03 (HAPR)
00 (mode 0), 01 (mode 1), 02 (mode 2)
0. to 4095.
"start frequency" to "maximum frequency" (up to 120.0) (Hz)
00 (forward), 01 (reverse)
0. to 9999., 1000 (10000) (pulses)
0.00 to 9.99 (s)
00 (feedback side), 01 (commanding side)
0. to 9999.
0. to 9999.
0.00 to 99.99, 100.0 to 655.3
0.00 to 99.99, 100.0
-204 (-2048.) / -999. to 2048
00 (no compensation), 01 (compensation)
0.0 to 150.0 (%)
0.00 to 99.99, 100.0 to120.0 (Hz)
0. to 9999.
0. to 9999.
00 (digital operator), 01 (option 1), 02 (option 2), 03 (easy sequence)
00 (digital operator), 01 (option 1), 02 (option 2)
00 (O terminal), 01 (OI terminal), 02 (O2 terminal), 03 (digital operator)
0. to 200. (%)
00 (as indicated by the sign), 01 (depending on the operation direction)
00 (disabling the mode), 01 (digital operator), 02 (input via O2 terminal)
-200. to +200. (%)
00 (as indicated by the sign), 01 (depending on the operation direction)
0.00 to "maximum frequency" (Hz)
0.00 to "maximum frequency" (Hz)
0.00 to 99.99 (s)
00 (tripping), 01 (tripping after decelerating and stopping the motor), 02 (ignoring errors),
03 (stopping the motor after free-running), 04 (decelerating and stopping the motor)
20, 21, 100
70, 71, 101
00 (tripping), 01 (tripping after decelerating and stopping the motor), 02 (ignoring errors),
03 (stopping the motor after free-running), 04 (decelerating and stopping the motor)
0, 2, 4, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30, 32, 34, 36, 38 (poles)
1.0 to 50.0 (kHz)
0.01 to 2.00 (s)
-100. to +100. (%)
0. to 100. (%)
Position setting range reverse side Ð forward side
(upper 4 digits including Ò-Ò)
00(Low) / 01 (Hi1) / 00 (Hi2)
00 (FW) / 01 (RV)
0.00 Ð 10.00 (Hz)
0.00 Ð 99.99 / 100.0 Ð Maximum frequency setting, 1st motor (Hz)
0 Ð 268435455 (when P012 = 02) 0 Ð 1073741823 (When P012 = 03) (upper 4 digits)
-268435455 Ð 0 (when P012 = 02) -1073741823 - 0 (When P012 = 03) (upper 4 digits)
00 (X00) / 01 (X01) / 02 (X02) / 03 (X03) /04 (X04) / 05 (X05) / 06 (X06) / 07 (X07)
0. to 9999., 1000 to 6553 (10000 to 65535)
P001
P002
P011
P012
P013
P014
P015
P016
P017
P018
P019
P020
P021
P022
P023
P024
P025
P026
P027
P028
P029
P031
P032
P033
P034
P035
P036
P037
P038
P039
P040
P044
P045
P046
P047
P048
P049
P055
P056
P057
P058
P068
P069
P070
P071
P072
P073
P074
［◯ = Allowed × = Not permitted ］
［◯ = Allowed
× = Not permitted ］
Output terminal operation function
Absolute position control
sequence
Control constants
P100
I
P131
P060
I
P067
U001
I
P012 User selected functions 1-12
parameters
no no ○ ○
Control
constants
Depending on
motor capacity


100.0
100.0
100.0
100.0
1.00
1.00
100.
100.
50.
50.
100.0
100.0
1.00
100.


100.0
100.0
100.0
100.0
1.00
1.00
100.
100.
50.
50.
100.0
100.0
1.00
100.
×
×
○
○
○
○
○
○
○
○
○
○
○
○
○
○
×
×
○
○
○
○
○
○
○
○
○
○
○
○
○
○
00
00
1024
00
00
0.
5.00
00
5.
0.00
0.0
0.0
1
0.00
0.50
0.
00
135.0
7.50
1.
1.
00
00
00
0.
00
00
0.
00
0.00
0.00
1.00

01
21
71

01
00
25.0
0.10
0.
100.

0
00
00
0.00
0.00


00

0.
00
00
1024
00
00
0.
5.00
00
5.
0.00
0.0
0.0
1
0.00
0.50
0.
00
135.0
7.50
1.
1.
00
00
00
0.
00
00
0.
00
0.00
0.00
1.00

01
21
71

01
00
25.0
0.10
0.
100.

0
00
00
0.00
0.00


00

0.
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
○
×
×
○
×
○
○
×

×
×
×

×
×
×
×
×
×

○
○
○
○
○
○
○
○

○
○
○
×
×
×
○
○
×
○
○
○
○
×
○
○
○
○
○
×
○
○
×
○
×
○
×
×
○
×
○
○
×

×
×
×

×
×
○
○
○
○

○
○
○
○
○
○
○
○

○
268435455
-268435455

● P GROUP: EXPANSION CARD FUNCTIONS
16

〈 How to access the details about the present fault 〉
〈 Status Display 〉
Code Description
Reset
Stop
0
1
Code Description
Deceleration
Constant Speed
2
3
Code Description
Acceleration
f0 Stop
4
5
Code Description
Starting
DB
6
7
Code Description
Overload Restriction
Forcible or servo-on
8
9
Name
Display
on digital
operator
Display on remote
operator/copy unit
Cause(s)
Over-current protection
Overload protection(*1)
Braking resistor
overload protection
Over-voltage protection
EEPROM error(*2)
Under-voltage error
CT(Current transformer) error
CPU error
External trip
USP error
Ground fault
Input over-voltage protection
Instantaneous power failure
Inverter thermal trip
Gate array error
Phase loss detection
IGBT error
Thermistor error
Braking error
Out of operation due
to under-voltage
Expansion card 1 connection error
Expansion card 2 connection error
Communication error has occurred between CPU and gate array.
One of three lines of 3-phase power supply is missing.
An error has been detected in an expansion card or at its connecting terminals.
While at constant speed
During deceleration
During acceleration
Others
When the built-in EEPROM memory has problems due to noise or excessive temperature, the inverter trips
and turns off its output.
When a signal to an intelligent input terminal configured as EXT has occurred, the inverter trips and turns
off its output.
An error occurs when power is cycled while the inverter is in RUN mode if the Unattended Start Protection
(USP) is enabled. The inverter trips and does not go into RUN mode until the error is cleared.
When the input voltage is higher than the specified value, it is detected 60 seconds after power-up and the
inverter trips and turns of its output.
When power is cut for more than 15ms, the inverter trips and turns off its output. If power failure continues,
the error will be cleared. The inverter restarts if it is in RUN mode when power is cycled.
Temperature error due to low
cooling-fan speed The inverter will display the error code shown on the right if the lowering of cooling-fan speed is detected at
the occurrence of the temperature error described below.
The inverter turns off its output when it can not detect whether the braking is ON or OFF within waiting time
set at b024 after it has released the brake. (When braking is enabled at b120)
When the DC bus voltage exceeds a threshold, due to regenerative energy from the motor, the inverter trips
and turns off its output.
When a motor overload is detected by the electronic thermal function, the inverter trips and turns off its out-
put.
The inverter output was short-circuited, or the motor shaft is locked or has a
heavy load. These conditions cause excessive current for the inverter, so the
inverter output is turned off.
Easy sequence function Error
When the regenerative braking resistor exceeds the usage time allowance or an over-voltage caused by the
stop of the BRD function is detected, the inverter trips and turns off its output.
A decrease of internal DC bus voltage below a threshold results in a control circuit fault. This condition can
also generate excessive motor heat or cause low torque. The inverter trips and turns off its output.
If a strong source of electrical interference is close to the inverter or abnormal operations occur in the
built-in CT, the inverter trips and turns off its output.
The inverter is protected by the detection of ground faults between the inverter output and the motor during
power-up tests. This feature protects the inverter only.
When the inverter internal temperature is higher than the specified value, the thermal sensor in the inverter
module detects the higher temperature of the power devices and trips, turning off the inverter output.
When an instantaneous over-current has occurred, the inverter trips and turns off its output to protect main
circuit element.
Main circuit error (*3) The inverter will trip if the gate array cannot confirm the on/off state of IGBT because of a malfunction due
to noise or damage to the main circuit element.
When the thermistor inside the motor detects temperature higher than the specified value, the inverter trips
and turns off its output.
Emergency stop (*4) If the EMR signal (on three terminals) is turned on when the slide switch (SW1) on the logic board is set to
ON, the inverter hardware will shut off the inverter output and display the error code shown on the right.
Modbus communication error
If timeout occurs because of line disconnection during the communication in Modbus-RTU mode, the inverter
will display the error code shown on the right. (The inverter will trip according to the setting of "C076".)
Low-speed overload protection
If overload occurs during the motor operation at a very low speed at 0.2 Hz or less, the electronic thermal protection
circuit in the inverter will detect the overload and shut off the inverter output. (2nd electronic thermal control)
(Note that a high frequency may be recorded as the error history data.)
Due to insufficient voltage, the inverter has turned off its output and been trying to
restart. If it fails to restart, it goes into the under-voltage error.
When a malfunction in the built-in CPU has occurred, the inverter trips and turns off its output.
Error indications by protective functions with the easy sequence function used.
*1: Reset operation is acceptable 10 seconds after the trip.
*2: Check the parameters when EEPROM error occurs.
*3: The inverter will not accept reset commands input via the RS terminal or entered by the STOP/RESET key. Therefore, turn off the inverter power.
*4: The inverter will not accept the reset command entered from the digital operator. Therefore, reset the inverter by turning on the RS terminal.
Status at trip pointError code Output frequency
at trip point Motor current at trip point Voltage between P(+) and N(
−
) at trip point Cumulative inverter RUN time at trip point Cumulative power-on time at trip point
OC.Drive
ERR1****
OC.Decel
OC.Accel
Over.C
Over.L
OL.BRD
Over.V
EEPROM
Under.V
CT
CPU
EXTERNAL
USP
GND.Flt.
OV.SRC
Inst.P-F
OH FIN
GA
PH.Fail
IGBT
TH
BRAKE
UV.WAIT
OP1-0 OP1-9
〜
OP2-0 OP2-9
〜
PRG.CMD
PRG.NST
PRG.ERR1
OH.stFAN
Main.Cir
EMR
NET.ERR
OL-LowSP
〜
〜
17
PROTECTIVE FUNCTIONS

45 46
N
P
CONNECTING DIAGRAM
Source type logic
In case of 400V class, place a transformer for operating circuit to receive 200V.
Terminal Name
Common terminal FW, 1, 2, 3, 4, 5, 6, 7, 8 FM, TH H, O, O2, OI, AM, AMI
L
P24 CM1
18
Frequency
setting device
500
-
2k½
DC0
-
10V
(12bit)
DC0
-
10V(10bit)
(G)
DC
-
10
-
+10V
(12bit)
DC4
-
20mA(12bit)
DC4
-
20mA(10bit)
DC0
-
10V
O2
OI
L
AM
AMI
10k½
10k½
100½
TH
H
O
SN
RP
SN
SP
DC10V
15
11
CM2
Thermistor
Intelligent output terminals
RS-485
Serial communication port
Expansion card 1
Expansion card 2
AM monitor output
(Analog output)
AM monitor output
(Analog output)
Option
Customer wiring
(Outside the inverter)
PLC
CM1
FW
8
7
6
1
FM
CM1
AL2
AL1
AL0
DC24V
- +
P
RB
P
RB
Short-circuit
bar
Forward command
Intelligent input
terminals (8 terminals)
FM monitor output
(PWM)
For 30kW(40HP) and over
Intelligent relay
output contacts
(Inverter)
Braking resistor(RB)
(To operating circuit)
For up to 22kW(30HP)
IM
SJ700
(T3)W
(T2)V
(T1)U
N
PRB
R1
R2
RB
(+1)PD
AL1
AL2
AL1
AL2
RB
P
RB
P
N
(+)
(
- )
DC link choke
Dynamic braking unit (BRD)
R(L1)
S(L2)
T(L3)
R
P24
T(J51)
R0
T0
200V
-
240V+10%, - 15%
50/60Hz±5%
(*2)Remove connection with J51
when RoTo power is supplied
externally
(*2)
Control power source

19
N
CONNECTING DIAGRAM
Sink type logic
Terminal Name
Common terminal FW, 1, 2, 3, 4, 5, 6, 7, 8, FM, TH
CM1
H, O, O2, OI, AM, AMI
L
In case of 400V class, place a transformer for operating circuit to receive 200V.
R(L1)
S(L2)
T(L3)
R
T(J51)
R0
T0
200V
-
240V+10%, - 15%
50/60Hz±5%
(*2)Remove connection with J51
when RoTo power is supplied
externally
(*2)
Control power source
Short-circuit bar
Frequency
setting device
500
-
2k½
DC0
-
10V
(12bit)
DC0
-
10V(10bit)
DC
-
10
-
+10V
(12bit)
DC4
-
20mA(12bit)
DC4
-
20mA(10bit)
DC0
-
10V
Forward command
Intelligent input
terminals(8 terminals)
FM monitor output
(PWM)
AM monitor output
(Analog output)
AM monitor output
(Analog output)
(G)
P24
PLC
FW
8
7
6
1
FM
O2
OI
L
AM
AMI
10k½
10k½
100½
TH
H
O
RP
DC10V
Thermistor
IM
SJ700
CM1
(T3)W
(T2)V
(T1)U
N
PRB
R1
R2
RB
(+1)PD
AL1
AL2
AL1
AL2
RB
P
RB
P
(+)
(
- )
DC link choke
Dynamic braking unit (BRD)
For 30kW(40HP) and over
(To operating circuit)
For up to 22kW(30HP)
Expansion card 1
Expansion card 2
SN
SN
SP
AL2
AL1
AL0
DC24V
15
11
CM2
N
P
P
RB
P
RB
Intelligent relay
output contacts
(Inverter)
Braking resistor(RB)
Intelligent output terminals
RS-485
Serial communication port
Option
Customer wiring
(Outside the inverter)
- +
