Hitachi UX2 Series Installation and operating manual

l
HITACHI Printer
Model UX2
Safety Guide
●Before using the printer, thoroughly read this safety guide for
optimum printer use.
●After reading, properly keep it for future reference.

To export the product, check the export control-related
regulations, such as the Foreign Exchange and Foreign Trade
Law and the Export Administration Regulations, and follow
the necessary procedures.
If you have any questions, contact your Hitachi sales
representative.
(First edition)
● No part of this documentation may be copied or reproduced without
permission.
● The contents of this documentation are subject to change without notice
for improvement.

S１
Important Notes
■Precautions before using the product
●Be sure to read the Instruction manual and related documents mentioned in the manual
thoroughly before using this product. Follow the instructions, such as product description,
safety information and precautions, and operation and handling methods, for proper use.
- Make sure that you always use the product within the specification range mentioned in
Instruction manual.
- Perform proper inspection and maintenance to prevent failures.
●After reading the Instruction manual, keep it in an easily accessible place for future
reference.
■Restrictions on Export
●User herby agrees not be export or re-export this product to any end-user who the user
has reason to suspect may utilize the product for the design, development or reproduction
or nuclear, chemical or biochemical weapons.
The product or system including the product cannot be used in countries or areas other
than those which have concluded a sales contract.
■Disclaimer
●Do not perform operation not in accordance with Instruction manual, such as using
replacement parts other than ones supplied by Hitachi or modifying parts. Doing so may
cause machine failure or personal injury. Hitachi will not bear any responsibilities for damage
resulting from these actions.
For the details on the product warranty and agreement terms, see the separate written
agreement.
●The warranty does not cover any production loss due to downtime or physical loss (damage
to a printed object and related equipment) due to a failure or malfunction of the delivered
product. Should any failure occur, Hitachi will send a technician as soon as possible to try to
minimize the downtime.
- It is recommended that you check the printing state periodically in a process even during
production.
- When starting the IJ printer, check if the printing state and print description are correct.
■Contact
If you have any questions about this manual or need consultation or after-sales services,
contact your dealer or nearest local distributor.

S２
Safety Precautions
●You should observe the precautions set forth below in order to use the product properly and
avoid endangering you or other persons or damaging property. For the purpose of clarifying
the severity of injury or damage and likelihood of occurrence, the precautions are classified
into three categories, WARNING, CAUTION, and NOTE, all of which describe hazardous
situations that may arise if you ignore the precautions and perform an incorrect handling or
operating procedure. These precautions are all important and must therefore be observed
without fail.
WARNING
Indicates the presence of a hazard which may cause severe
personal injury or death unless avoided.
CAUTION
Indicates the presence of a hazard which may cause moderate
or minor personal injury unless avoided.
NOTE
Indicates the presence of a hazard which may cause non-
personal damage unless avoided.
The △symbols are used to indicate precautions (including those
related to potential warnings) to be observed. Detailed information is
furnished by a picture within the symbol outline (a shock hazard is
indicated by the example shown at left).
The symbols are used to describe prohibited actions. The details of a
prohibited action are given by a picture within or near the symbol outline
(the example shown at left dictates that you must keep flames away).
The ●symbols are used to describe mandatory actions. Detailed
instructions are given by a picture within the symbol outline (the
example shown at left dictates that a ground connection must be made).
Pictograph examples

S３
Safety Precautions (Continued)
WARNING
●Ensure that no flame- or arc-generating devices are installed around the product.
- Fire: (Examples) Matches, lighters, cigarettes, heaters, stoves, gas burners,
welders, grinders, static electricity, etc.
- Flammable: (Examples) Ink, makeup
- Arc-generating device: (Examples) Open-type relays, open-type switches, brush
motors, etc.
Before handling ink and makeup, remove static electricity from your body, peripheral
equipment, and so on.
In the interest of safety, place a dry-chemical fire extinguisher near the product.
●Install the product in an adequately ventilated location.
●Do not install the product in an enclosed space.
●Connect the product to exhaust equipment to prevent it from being filled with organic
solvent vapor.
●Secure adequate space for the ink/makeup handling area and product installation site.
At least 200 m3must be provided per print head. Ensure that adequate ventilation is
provided.
* If ink or makeup contains any organic solvents or specified chemical substances, it
must be managed under the Industrial Safety and Health Act.
NOTE
●If extraneous noise enters the product, it may malfunction or break down.
For maximum noise immunity, observe the following installation and wiring
precautions.
- Ensure that 100 or 200 VAC power cables are not bundled with other power supply
cables.
- Insulate the product main body and print head so that they do not come into direct
contact with the conveyor or other devices.
- If the employed print target detector is housed in a metal case, use a plastic
mounting brace to insulate the detector from the conveyor and other devices.
- Ensure that the print target detector wiring is not bundled together with other
power supply cables.
Installation environment

S４
Safety Precautions (Continued)
WARNING
●Ensure that all electrical wiring, connections, and grounding comply with applicable
cords. Properly connect the product to its dedicated ground.
Complete the above procedure to avoid electrical shock hazards.
●When welding, keep enough space between the product and the welding work area to
prevent the arc from starting a fire. Also, insulate the print head and product frame to
keep the welding current from flowing to the control section of the product, and make
a separate ground connection for the product.
●If you need to receive ink particles in a beaker, a printing test for example, use an
electrically conductive beaker and connect the beaker securely to the ground.
Do not let the tip of the printing head enter the beaker.
Ink particles used for printing are electrically charged. An ungrounded beaker has a
gradually rising charge, possibly catching on or causing a fire.
WARNING
●Use an AC power cable within the following range:
- When using an inlet: 100 to 200 VAC
- When using a power-receiving terminal block: 100 to 200 VAC/200 to 240 VAC
- Frequency: 50 or 60 Hz
If the above requirements are not met, the electric parts may overheat and burn,
causing a fire or electric shock.
●The power cable connected by default is for 100 VAC only.
Do not modify it to a power plug for 200 VAC.
●When the power cable outlet is not used, ensure that it is connected to the input port
inside the product.
- If it is connected to an incorrect input port, the electric parts may break down,
overheat, or burn, causing a fire or electric shock.
- The supplied cable with a three-pole plug is for 100 VAC only.
Grounding
Power cable handling

S５
Safety Precautions (Continued)
WARNING
●When handling ink or makeup, such as replenishment or replacement, take enough
care not to spill ink or makeup.
If you spill any ink or makeup by mistake, wipe it off neatly and promptly with wiping
paper or something similar. Do not close the maintenance cover until you make sure
that the portion you have just wiped is completely dry.
You must pay particular attention when you have spilled ink or makeup inside the
printer and it is not completely dry. This is because vapors of ink or makeup will stay
inside the product and may catch on or cause a fire.
If you find it hard to wipe the printer with the power on, stop it with the maintenance
cover open. Power it down and then wipe it off again.
●If you need to clean the casing of the product with wiping paper soaked with makeup,
be sure to do so when the power is off.
Attempting to clean it with the power on will cause makeup or vapors of makeup to
enter the product, possibly catching on or causing a fire.
When the cleaning is finished, open the maintenance cover and make sure that no
makeup has entered and no vapors remain inside.
●Should you find a leak of ink or makeup inside the product while the product is
running or being maintained, wipe it off promptly with wiping paper or something
similar. Then, with the maintenance cover open, stop the product, power it down,
and repair the leak. Otherwise, contact your nearest local distributor.
Continuing operation with a leak of ink or makeup will cause an anomaly, resulting in
abnormal printing. Ink and makeup are flammable. They may therefore catch on or
cause a fire.
●Ink and makeup, their waste solution, used wiping paper and empty containers are
flammable.
Make sure that these waste disposals are kept away from a flame or arc.
Ink and makeup handling

S６
Safety Precautions (Continued)
CAUTION
●When cleaning the product or replenishing ink or makeup, wear protective gloves and
safety goggles to avoid direct skin contact. If the ink or makeup comes into contact
with skin, wash thoroughly with soap and warm or cold water.
●When transferring the ink or makeup to or from a bottle, exercise caution to prevent
it from coming into contact with the product or surrounding articles. If there is any
spillage, immediately wipe it to clean using a cloth moistened with makeup.
Ink and makeup handling (continued)

S７
Safety Precautions (Continued)
WARNING
●Do not insert tweezers, a screwdriver, or any other metal article into the ink ejection
hole at the end of the print head.
When the product is ready to print, a high voltage (approximately 6 kV) is applied to
the deflection electrode section in the print head.
Exercise caution to avoid electric shock, injury, and fire.
●Do not remove covers and/or screws not specified in this manual.
A high voltage is applied to some sections of the product.
Exercise caution to avoid electric shock and injury.
●Exercise caution to avoid inadvertently disconnecting, forcibly pulling, or bending
piping tubes.
Since the ink and makeup in some portions of piping tubes are pressurized, they may
splash into your eyes or mouth or onto your hands or clothing.
If any ink or makeup enters your eyes or mouth, immediately flush with warm or cold
water and consult a physician.
●While the product is operating, do not look into the ink ejection hole at the end of the
print head.
Ink or makeup may enter your eyes or mouth or soil your hands or clothing. If any
ink or makeup enters your eyes or mouth, immediately flush with warm or cold water
and consult a physician.
●Make sure that there is no one in the ink ejection direction before starting the
product.
Operate with the end of the print head inserted in a beaker, etc.
●Before servicing the product, be sure to stop the ink ejection.
This is because ink or makeup may splash into your eyes or mouth or onto your
hands or clothing.
If any ink or makeup enters your eyes or mouth, immediately flush with warm or cold
water and consult a physician.
●If an earthquake, fire, or other emergency occurs while the printer is engaged in
printing or just turned on, press the main power switch to turn off the power.
Do not perform this operation in any other situation than emergency.
Main body handling

S８
Safety Precautions (Continued)
CAUTION
●Only people who have completed an operator training course for Hitachi can operate
and service the product.
- If the printer is operated or serviced incorrectly, it may malfunction or break down.
- There is a training school available for a deeper understanding of the product. For
details, contact Hitachi sales department.
●Do not attempt to repair the product for any other purpose than operation or
maintenance.
Otherwise, it may cause a malfunction, so if a repair is needed, contact your nearest
local distributor.
Main body handling(continued)

S９
This page is blank.

S１０
Essentials of Daily Operations
Startup procedure⇒Thoroughly read “3.1 Start operation”of instruction
Manual.
(1)Check whether or not the print head cover and the area around the nozzle are soiled by
ink.
● If the area around the nozzle are soiled by ink, clean the print head.
(refer to the “Essentials of print head cleaning” given below)
(2)Turn on the power by pressing the main power switch.
●When stopped only by the Stop switch and the main power switch was not turned off
at the previous operation, the main power switch does not have to be pressed.
(3) Press the On switch. (For about 2 seconds)
●When the main power switch of (2) is pressed, the following “Print description” screen
appears.
●Ensure that status indicator lamp is turned off when On switch is pressed.
(4)Place a piece of wiping paper,etc., against the ink injection port at the end of the print
head and press the STARTUP →Ready.
●Place a piece of wiping paper, etc., against the ink ejection port in preparation for
splashing of the ejected ink.
Loosen the screw
Pull out
Around nozzle
Print head cover
Status indicator lamp
Stop switch
On switch
Main power switch
Print head
Wiping pepar, etc.
Press STARTUP
Press Ready
1

S１１
(5) Wait until the status changes from “Starting” to “Ready”.
(6) Make test prints to verify the printing results.
(7) If the ink jets out continuously, a fault exists.
●Stop the operation by performing the "No-cleaning stop procedure” which is indicated at section
３No-cleaning stop procedure.
●Clean the print head (refer to the "Essentials of print head cleaning" given below).
●With the print head cover left removed, press the STARTUP and Eject ink keys in
sequence to initiate ink ejection and verify the ink stream position.
Essentials of print head cleaning
●With the cleaning bottle, pour the makeup over the orifice plate, charge electrode,
deflection electrodes, gutter, and mounting base to clean them.
●Thoroughly wipe the makeup away from the parts (mounting base included) surfaces
with wiping paper and allow them to dry.
The ink and makeup, their waste solution, used wiping papers and empty containers
are flammable.
Waste disposal must comply with appropriate regulations.
Consult the appropriate regulatory agency for further information.
Precautions
If you frequently perform the <Shut down> procedure, excessive makeup ink enters the
printer, thereby thinning the ink and raising the main ink tank ink level unduly high. If it is
absolutely necessary to stop an operation at frequent intervals, follow the
" 3 No-cleaning stop procedure."
Mounting base
Orifice plate
Charge electrode
Deflection electrode
Gutter
Area to be cleaned
３
1
２

S１２
Shutdown method⇒Thoroughly read “3.2 Shut down operation” of Instruction Manual.
Be sure to perform the steps indicated below to complete the ink stop process. If you turn
OFF the power without completing the ink stop process, the following conditions occur.
(1) There is a case that the operation management information (Ink operating time and print
count) and count update will not be stored into memory. If the count function is used, it is
necessary to set the count update (initial value) again at the time of power ON.
(2) Nozzle automatic cleaning will not be performed. Therefore, the nozzle may be clogged.
Method A Press the Stop switch.
(Press for about 2 seconds.)
All operations up to IJ printer power
OFF are performed automatically.
Method B Press the screen button.
2
1
２
On switch
Stop switch
Main power switch
Press SHUTDOWN
Stops ink jet.
Press the Stop switch or turn OFF
the Main power switch.
Turns OFF the power after
ink jet is stopped.

S１３
No-cleaning stop procedure (for frequently stopping an operation)
●If you perform the above procedure and allow the resultant condition to continue,
the nozzle may become stopped up with ink, causing the ink stream to bend and the
nozzle to clog.
３
２
Press No-cleaning stop
Press SHUTDOWN
