ELECTRIC TOOL PARTS LIST
LIST NO. G820
CORDLESS IMPACT WRENCH
Model WR 9DMR
2005
•
4
•
1
(E1)
Hitachi Power Tools
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26 27
28
29
30
31
32
33
31
38
39
40
41
42
43
44
45
501 502
502
34
35
36
37

*ALTERNATIVE PARTS--- 2 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
4 -- 05
WR 9DMR
1322-727 FRONT CAP (B) 1
2322-728 PROTECTOR (C) 1
3319-917
TAPPING SCREW (W/SP. WASHER) D4X25 (BLACK) 4
4322-172 HAMMER CASE 1
5322-732 ANVIL (U) 1
6959-154 STEEL BALL D5.556 (10 PCS.) 2
7322-730 HAMMER (F) 1
8959-148 STEEL BALL D3.175 (10 PCS.) 28
9315-978 WASHER (J) 1
10 320-407 HAMMER SPRING (A) 1
11 316-172 WASHER (S) 1
12 316-171 STOPPER 1
13 321-666 SPINDLE (D) 1
14 321-667 IDLE GEAR SET (2 PCS.) 2
15 319-914 NEEDLE ROLLER 2
16 320-877 RING GEAR (C) 1
17 319-911 WASHER (E) 1
18 690-1VV BALL BEARING 6901VVCMPS2L 1
19 319-909 DAMPER 2
20 321-664 INNER COVER (A) 1
21 360-702
ARMATURE ASS’Y (W/BALL BEARING) DC 9.6V 1
22 322-719 SIDE YOKE 1
23 322-723 MAGNET (E) 1
24 322-720 DUST GUARD FIN (B) 1
25 321-662 BRUSH BLOCK 1
26 999-054 CARBON BRUSH 5X6X11.5 (1 PAIR) 2
27 319-918 BRUSH CAP 2
28 302-086 TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 7
29 NAME PLATE 1
30 324-287 HOUSING (A). (B) SET 1
31 994-532 MACHINE SCREW (W/SP. WASHER) M3X5 2
32 319-906 DC-SPEED CONTROL SWITCH 1
33 321-661 PUSHING BUTTON (A) 1
34 324-285 HITACHI PLATE 1
*35 CAUTION PLATE (A) 1 FOR USA, CAN
36 321-918 HOOK ASS’Y (W/LIGHT) 1 INCLUD. 37, 38
37 321-672 TAPPING SCREW D2X6 2
38 320-288 V-LOCK NUT M5 1
39 949-565 LOCK NUT M4 (10 PCS.) 1
40 306-952 STRAP (BLACK) 1
41 322-718 SLEEVE (A) 1
42 324-278
MACHINE SCREW (W/WASHERS) M4X25 (BLACK) 1
43 319-926 HOOK SPRING 1
44 319-927 SPECIAL SCREW M5 1
*45 318-368 BATTERY EB 930H (W/ENGLISH N.P.) 2
*45 323-225 BATTERY EB 926H (W/ENGLISH N.P.) 2
*45 310-377 BATTERY EB 9B (W/ENGLISH N.P.) 2
*45 310-451 BATTERY EB 9B (W/ENGLISH N.P.) 2 FOR USA, CAN
*45 324-288 BATTERY EB 9B (W/ENGLISH N.P.) 2 FOR TPE

OPTIONAL ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
*ALTERNATIVE PARTS --- 3 ---4 -- 05
STANDARD ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
WR 9DMR
*501 322-070 CASE 1 EXCEPT FOR THA
*502 CHARGER (MODEL UC 14YFA) 1
*502 CHARGER (MODEL UC 18YG) 1
601 996-125 HEX. SOCKET ASS’Y 8MMX33L 1 INCLUD. 602, 603
602 996-124 SOCKET PIN (A) 1
603 873-095 O-RING (P-16) 1
604 996-126 HEX. SOCKET ASS’Y 10MMX33L 1 INCLUD. 602, 603
605 996-127 HEX. SOCKET ASS’Y 12MMX33L 1 INCLUD. 602, 603
606 996-128 HEX. SOCKET ASS’Y 13MMX33L 1 INCLUD. 607, 608
607 996-123 SOCKET PIN (B) 1
608 873-570 O-RING (P-18) 1
609 996-129 HEX. SOCKET ASS’Y 14MMX33L 1 INCLUD. 607, 608
610 996-130 HEX. SOCKET ASS’Y 16MMX33L 1 INCLUD. 607, 608
611 996-131 HEX. SOCKET ASS’Y 17MMX33L 1 INCLUD. 607, 608
612 996-132 HEX. SOCKET ASS’Y 18MMX33L 1 INCLUD. 607, 608
613 996-133 HEX. SOCKET ASS’Y 19MMX33L 1 INCLUD. 607, 608
614 996-134 HEX. SOCKET ASS’Y (LONG) 8MMX60L 1 INCLUD. 602, 603
615 996-135 HEX. SOCKET ASS’Y (LONG) 10MMX60L 1 INCLUD. 602, 603
616 996-136 HEX. SOCKET ASS’Y (LONG) 12MMX60L 1 INCLUD. 602, 603
617 996-137 HEX. SOCKET ASS’Y (LONG) 13MMX60L 1 INCLUD. 607, 608
618 996-138 HEX. SOCKET ASS’Y (LONG) 14MMX60L 1 INCLUD. 607, 608
619 996-139 HEX. SOCKET ASS’Y (LONG) 16MMX60L 1 INCLUD. 607, 608
620 996-140 HEX. SOCKET ASS’Y (LONG) 17MMX60L 1 INCLUD. 607, 608
621 996-141 HEX. SOCKET ASS’Y (LONG) 18MMX60L 1 INCLUD. 607, 608
622 996-142 HEX. SOCKET ASS’Y (LONG) 19MMX60L 1 INCLUD. 607, 608
623 996-143 EXTENSION BAR ASS’Y 1 INCLUD. 602, 603
624 996-144 BIT ADAPTER ASS’Y 1 INCLUD. 602, 603
625 996-145 ADAPTER ASS’Y 12.7MM 1 INCLUD. 607, 608
626 996-147 UNIVERSAL JOINT ASS’Y 1 INCLUD. 607, 608, 627
627 996-163 UNIVERSAL JOINT PIN 1
628 309-922 GREASE FOR IMPACT DRIVER (500G) 1

--- 4 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
4 -- 05
WR 9DMR
Printed in Japan
(050401N)
