Hitachi CV-400 ECO User manual

CV-400 ECO
CONTENTS
1. PARTLIST 2
1.1 CV-400 ECO (GN)
1.2 CV-400 ECO (LB)
1.3 CV-400 ECO (OR)
1.4 CV-400 ECO (PI)
2. CONSTRUCTION DIAGRAM AND 10
CONNECTION DIAGRAM
SPECIFICATIONS
Rated oltage : AC230V, 50Hz
Rated input : IEC 800W, Max 900W
Motor : Commutator motor
Fan : Turbo type 1 stage
Maximum air flow (without attachment) : 31.67 L/s (1.9 m
3
/ min) ( 67.1 cu.ft/min)
Maximum static pressure : 2,050 mm. H
2
O ( 80.7 in H
2
O )
Safety protector : With 6.3A. Current Fuse
Power Cord : 10 M.
Dust Capacity : Max 7.5 L.
Speed : 35,500 rpm.
Weight(without attachment) : 4.0 Kg.
Dimensions : 287 mm. (W) X 342 mm.(L) X 402 mm. (H)
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
VACUUM CLEANER
JANUARY 2016 HITACHI CONSUMER PRODUCTS (THAILAND), LTD
VC No 0733E
SERVICE MANUAL
HITACHI

1. PARTLIST
1.1 CV-400 ECO (GN)
NO. PARTS NO. DESCRIPTION Q'TY PACKED REMARKS ONLY FOR USE
Q'TY AT THE WORKS
1 CV-400 001 UPPER CASE ASSY (GN) 1 1 VAZ10576 A/V
2
3
4 CV-400 005 HANDLE (GN) 1 1 1V1EE1989 4/V
5
6 CV-300 907 DUST INDICATOR COUPLING 1 1 2A4GD1563 1/V
7 CV-960BJ 906 DUST INDICATOR ASSY 1 1 3A4GE3019 G/V
PPT SCREW M4X16 2 3VPD01939 1
9
10
11 CV-400 016 FUSE ASSY 6.3A(80 8-E) 1 1 J8 E80 8 E/V
12 CV-300 909 ROCKER SWITCH 1 1 1J61A9 91 1/V
13 CV-300 910 CLAMP WITH SPRING (DG) 1 1 inc. 14-15 3A3QH2371 A/V
14 CLAMP 1 3V1YP4645 1
15 CLAMP SPRING 1 4A4T54349 1
16 CV-SH1 929 GASKET R (COMMON) 1 1 3A LM0006 1/V
17 CV-300P 907 SILENCER T15 1 1 3A PK916 1/V
1 CV-300P 90 SILENCER T20 1 1 3A PK916 2/V
19 CV-400 010 F-GASKET (900W) 1 1 3VPR10191 1/V
20
1 CV-400 009 MOTOR ASSY (TX) 900W 1 1 inc. 16,19 K55J14 3 E/V
22 CV-3160 902 BRUSH HOLDER ASS'Y 2 2 2C6ZH367 B/V
23
24 CV-SP20V 903 NOISE CAPACITOR ASS'Y (220-240V) 1 1 2J1ZH9674 B/V
25
26 CV-300 906 MOTOR SUPPORTER 1 1 inc. 30 1V1ZC6501 A/V
27 PPT SCREW M4X25 4 Use for Motor Supporter 3VPD01939 4
2
29
30 CV-300P 906 MOTOR BASE PACKING (CV300) 1 1 3B3BK 1/V
31 CV-300P 903 P-FILTER HEPA ASS'Y 1 1 inc.32-34 2V1ZG 191 A/V
32 P-HEPA GUARD 300 1 1L47C6210 1
33 P-HEPA GUARD CCOVER300 1 1L47C6211 1
34 Sales ltem P-FILTER HEPA 300 1 1 L4ZG8876 A
35 CV-300 914 BUSHING 1 1 GK435130 3/V
36 CV-300 915 FIBER PLATE 1 1 4A3P1 011 2/V
37 PPT SCREW M4X16 2 Use for Fiber Plate 3VPD01939 1
3
- 2 -

NO. PARTS NO. DESCRIPTION Q'TY PACKED REMARKS ONLY FOR USE
Q'TY AT THE WORKS
39 CV-300 916 CORD ASSY (VDE) 1 1 2B1XK6342 4/V
40 CV-300 917 FILTER ASSY 1 1 2V1Z35150 F/V
41
42
43 CV-400 011 LOWER CASE (GN) 1 1 0VPP03499 1/V
44 CV-300 91 SUCTION INLET (DG) 1 1 2V1YL5946 1/V
45 CV-300 919 INLET PACKING 1 1 3L44 6549 1/V
46 PPT SCREW M4X25 2 Use for Suction Inlet 3VPD01939 4
47 CV-100 939 CASTER SUPPORTER (DG) 2 1 2V1YK9097 1/V
4 CV-300 921 CASTER ASSY 2 1 inc.49,50 3L9ZA653 F/V
49 PPT SCREW M4X16 3VPD01939 1
50 CV-300 922 CASTER WASHER 2 1 4M 719499 1
51
52 CV-300 924 WHEEL SUPPORTER ASSY (DG) 1 1 inc. 53 3L1Z95039 D/V
53 CV-300 925 WHEEL (100) DG 2 1 2L9333324 P/V
54 CV-300 926 HOSE ASSY 1 1 inc. 55-59 1A1ZA3203 U/V
55 SEAL RING 2 3A2RC7604 1
56 CD HOSE 3.0M 1 2VAZ10 3 3
57 STOPPER RING 2 3A2QC7605 4
5 CV-300 927 CURVED PIPE ASSY 1 1 2A1ZK9 40 A/V
59 CV-300 92 HOSE CONNECTOR (B) ASSY 1 1 2A1ZK9 41 A/V
60
61 CV-400 015 R&F TOOL ASSY D3 1-ECO 1 1 1VZZ0450 A/V
62
63 CV-300 930 EXTENSION PIPE (S) 3 1 1A1NA99 6 2/V
64 CV-300 931 DUSTING BRUSH ASSY 1 1 2V2ZC 940 B/V
65 CV-300 932 CREVICE NOZZLE C120 (DGR) 1 1 2V2EF2319 1/V
66
67
6
69
70
71
72
73
74
75
76
77
7
79
- 3 -

1.2 CV-400 ECO (LB)
NO. PARTS NO. DESCRIPTION Q'TY PACKED REMARKS ONLY FOR USE
Q'TY AT THE ORKS
1 CV-400 002 UPPER CASE ASSY (LB) 1 1 2VAZ10576 B/V
2
3
4 CV-400 006 HANDLE (LB) 1 1 1V1EE1989 5/V
5
6 CV-300 907 DUST INDICATOR COUPLING 1 1 2A4GD1563 1/V
7 CV-960BJ 906 DUST INDICATOR ASSY 1 1 3A4GE3019 G/V
PPT SCREW M4X16 2 3VPD01939 1
9
10
11 CV-400 016 FUSE ASSY 6.3A(8028-E) 1 1 2J82E8028 E/V
12 CV-300 909 ROCKER SWITCH 1 1 1J61A9 91 1/V
13 CV-300 910 CLAMP WITH SPRING (DG) 1 1 inc. 14-15 3A3QH2371 A/V
14 CLAMP 1 3V1YP4645 1
15 CLAMP SPRING 1 4A4T54349 1
16 CV-SH1 929 GASKET R (COMMON) 1 1 3A LM0006 1/V
17 CV-300P 907 SILENCER T15 1 1 3A PK916 1/V
1 CV-300P 90 SILENCER T20 1 1 3A PK916 2/V
19 CV-400 010 F-GASKET (900 ) 1 1 3VPR10191 1/V
20
21 CV-400 009 MOTOR ASSY (TX) 900 1 1 inc. 16,19 2K55J1423 E/V
22 CV-3160 902 BRUSH HOLDER ASS'Y 2 2 2C6ZH367 B/V
23
24 CV-SP20V 903 NOISE CAPACITOR ASS'Y (220-240V) 1 1 2J1ZH9674 B/V
25
26 CV-300 906 MOTOR SUPPORTER 1 1 inc. 30 1V1ZC6501 A/V
27 PPT SCREW M4X25 4 Use for Motor Supporter 3VPD01939 4
2
29
30 CV-300P 906 MOTOR BASE PACKING (CV300) 1 1 3B3BK 1/V
31 CV-300P 903 P-FILTER HEPA ASS'Y 1 1 inc.32-34 2V1ZG 191 A/V
32 P-HEPA GUARD 300 1 1L47C6210 1
33 P-HEPA GUARD CCOVER300 1 1L47C6211 1
34 Sales ltem P-FILTER HEPA 300 1 1 2L4ZG8876 A
35 CV-300 914 BUSHING 1 1 GK435130 3/V
36 CV-300 915 FIBER PLATE 1 1 4A3P1 011 2/V
37 PPT SCREW M4X16 2 Use for Fiber Plate 3VPD01939 1
3
- 4 -

NO. PARTS NO. DESCRIPTION Q'TY PACKED REMARKS ONLY FOR USE
Q'TY AT THE ORKS
39 CV-300 916 CORD ASSY (VDE) 1 1 2B1XK6342 4/V
40 CV-300 917 FILTER ASSY 1 1 2V1Z35150 F/V
41
42
43 CV-400 012 LO ER CASE (LB) 1 1 0VPP03499 2/V
44 CV-300 91 SUCTION INLET (DG) 1 1 2V1YL5946 1/V
45 CV-300 919 INLET PACKING 1 1 3L44 6549 1/V
46 PPT SCREW M4X25 2 Use for Suction Inlet 3VPD01939 4
47 CV-100 939 CASTER SUPPORTER (DG) 2 1 2V1YK9097 1/V
4 CV-300 921 CASTER ASSY 2 1 inc.49,50 3L9ZA653 F/V
49 PPT SCREW M4X16 3VPD01939 1
50 CV-300 922 CASTER WASHER 2 1 4M 719499 1
51
52 CV-300 924 WHEEL SUPPORTER ASSY (DG) 1 1 inc. 53 3L1Z95039 D/V
53 CV-300 925 WHEEL (100) DG 2 1 2L9333324 P/V
54 CV-300 926 HOSE ASSY 1 1 inc. 55-59 1A1ZA3203 U/V
55 SEAL RING 2 3A2RC7604 1
56 CD HOSE 3.0M 1 2VAZ10 3 3
57 STOPPER RING 2 3A2QC7605 4
5 CV-300 927 CURVED PIPE ASSY 1 1 2A1ZK9 40 A/V
59 CV-300 92 HOSE CONNECTOR (B) ASSY 1 1 2A1ZK9 41 A/V
60
61 CV-400 015 R&F TOOL ASSY D321-ECO 1 1 1VZZ04502 A/V
62
63 CV-300 930 EXTENSION PIPE (S) 3 1 1A1NA99 6 2/V
64 CV-300 931 DUSTING BRUSH ASSY 1 1 2V2ZC 940 B/V
65 CV-300 932 CREVICE NOZZLE C120 (DGR) 1 1 2V2EF2319 1/V
66
67
6
69
70
71
72
73
74
75
76
77
7
79
- 5 -

1.3 CV-400 ECO (OR)
NO. PARTS NO. DESCRIPTION Q'TY PACKED REMARKS ONLY FOR USE
Q'TY AT THE WORKS
1 CV-400 003 UPPER CASE ASSY (OR) 1 1 VAZ10576 C/V
2
3
4 CV-400 007 HANDLE (OR) 1 1 1V1EE1989 6/V
5
6 CV-300 907 DUST INDICATOR COUPLING 1 1 2A4GD1563 1/V
7 CV-960BJ 906 DUST INDICATOR ASSY 1 1 3A4GE3019 G/V
PPT SCREW M4X16 2 3VPD01939 1
9
10
11 CV-400 016 FUSE ASSY 6.3A(80 8-E) 1 1 J8 E80 8 E/V
12 CV-300 909 ROCKER SWITCH 1 1 1J61A9 91 1/V
13 CV-300 910 CLAMP WITH SPRING (DG) 1 1 inc. 14-15 3A3QH2371 A/V
14 CLAMP 1 3V1YP4645 1
15 CLAMP SPRING 1 4A4T54349 1
16 CV-SH1 929 GASKET R (COMMON) 1 1 3A LM0006 1/V
17 CV-300P 907 SILENCER T15 1 1 3A PK916 1/V
1 CV-300P 90 SILENCER T20 1 1 3A PK916 2/V
19 CV-400 010 F-GASKET (900W) 1 1 3VPR10191 1/V
20
1 CV-400 009 MOTOR ASSY (TX) 900W 1 1 inc. 16,19 K55J14 3 E/V
22 CV-3160 902 BRUSH HOLDER ASS'Y 2 2 2C6ZH367 B/V
23
24 CV-SP20V 903 NOISE CAPACITOR ASS'Y (220-240V) 1 1 2J1ZH9674 B/V
25
26 CV-300 906 MOTOR SUPPORTER 1 1 inc. 30 1V1ZC6501 A/V
27 PPT SCREW M4X25 4 Use for Motor Supporter 3VPD01939 4
2
29
30 CV-300P 906 MOTOR BASE PACKING (CV300) 1 1 3B3BK 1/V
31 CV-300P 903 P-FILTER HEPA ASS'Y 1 1 inc.32-34 2V1ZG 191 A/V
32 P-HEPA GUARD 300 1 1L47C6210 1
33 P-HEPA GUARD CCOVER300 1 1L47C6211 1
34 Sales ltem P-FILTER HEPA 300 1 1 L4ZG8876 A
35 CV-300 914 BUSHING 1 1 GK435130 3/V
36 CV-300 915 FIBER PLATE 1 1 4A3P1 011 2/V
37 PPT SCREW M4X16 2 Use for Fiber Plate 3VPD01939 1
3
- 6 -

NO. PARTS NO. DESCRIPTION Q'TY PACKED REMARKS ONLY FOR USE
Q'TY AT THE WORKS
39 CV-300 916 CORD ASSY (VDE) 1 1 2B1XK6342 4/V
40 CV-300 917 FILTER ASSY 1 1 2V1Z35150 F/V
41
42
43 CV-400 013 LOWER CASE (OR) 1 1 0VPP03499 3/V
44 CV-300 91 SUCTION INLET (DG) 1 1 2V1YL5946 1/V
45 CV-300 919 INLET PACKING 1 1 3L44 6549 1/V
46 PPT SCREW M4X25 2 Use for Suction Inlet 3VPD01939 4
47 CV-100 939 CASTER SUPPORTER (DG) 2 1 2V1YK9097 1/V
4 CV-300 921 CASTER ASSY 2 1 inc.49,50 3L9ZA653 F/V
49 PPT SCREW M4X16 3VPD01939 1
50 CV-300 922 CASTER WASHER 2 1 4M 719499 1
51
52 CV-300 924 WHEEL SUPPORTER ASSY (DG) 1 1 inc. 53 3L1Z95039 D/V
53 CV-300 925 WHEEL (100) DG 2 1 2L9333324 P/V
54 CV-300 926 HOSE ASSY 1 1 inc. 55-59 1A1ZA3203 U/V
55 SEAL RING 2 3A2RC7604 1
56 CD HOSE 3.0M 1 2VAZ10 3 3
57 STOPPER RING 2 3A2QC7605 4
5 CV-300 927 CURVED PIPE ASSY 1 1 2A1ZK9 40 A/V
59 CV-300 92 HOSE CONNECTOR (B) ASSY 1 1 2A1ZK9 41 A/V
60
61 CV-400 015 R&F TOOL ASSY D3 1-ECO 1 1 1VZZ0450 A/V
62
63 CV-300 930 EXTENSION PIPE (S) 3 1 1A1NA99 6 2/V
64 CV-300 931 DUSTING BRUSH ASSY 1 1 2V2ZC 940 B/V
65 CV-300 932 CREVICE NOZZLE C120 (DGR) 1 1 2V2EF2319 1/V
66
67
6
69
70
71
72
73
74
75
76
77
7
79
- 7 -

1.4 CV-400 ECO (PI)
NO. PARTS NO. DESCRIPTION Q'TY PACKED REMARKS ONLY FOR USE
Q'TY AT THE WORKS
1 CV-400 004 UPPER CASE ASSY (PI) 1 1 2VA 10576 D/V
2
3
4 CV-400 008 HANDLE (PI) 1 1 1V1EE1989 7/V
5
6 CV-300 907 DUST INDICATOR COUPLING 1 1 2A4GD1563 1/V
7 CV-960BJ 906 DUST INDICATOR ASSY 1 1 3A4GE3019 G/V
PPT SCREW M4X16 2 3VPD01939 1
9
10
11 CV-400 016 FUSE ASSY 6.3A(8028-E) 1 1 2J82E8028 E/V
12 CV-300 909 ROCKER SWITCH 1 1 1J61A9 91 1/V
13 CV-300 910 CLAMP WITH SPRING (DG) 1 1 inc. 14-15 3A3QH2371 A/V
14 CLAMP 1 3V1YP4645 1
15 CLAMP SPRING 1 4A4T54349 1
16 CV-SH1 929 GASKET R (COMMON) 1 1 3A LM0006 1/V
17 CV-300P 907 SILENCER T15 1 1 3A PK916 1/V
1 CV-300P 90 SILENCER T20 1 1 3A PK916 2/V
19 CV-400 010 F-GASKET (900W) 1 1 3VPR10191 1/V
20
21 CV-400 009 MOTOR ASSY (TX) 900W 1 1 inc. 16,19 2K55J1423 E/V
22 CV-3160 902 BRUSH HOLDER ASS'Y 2 2 2C6ZH367 B/V
23
24 CV-SP20V 903 NOISE CAPACITOR ASS'Y (220-240V) 1 1 2J1ZH9674 B/V
25
26 CV-300 906 MOTOR SUPPORTER 1 1 inc. 30 1V1ZC6501 A/V
27 PPT SCREW M4X25 4 Use for Motor Supporter 3VPD01939 4
2
29
30 CV-300P 906 MOTOR BASE PACKING (CV300) 1 1 3B3BK 1/V
31 CV-300P 903 P-FILTER HEPA ASS'Y 1 1 inc.32-34 2V1ZG 191 A/V
32 P-HEPA GUARD 300 1 1L47C6210 1
33 P-HEPA GUARD CCOVER300 1 1L47C6211 1
34 Sales ltem P-FILTER HEPA 300 1 1 2L4 G8876 A
35 CV-300 914 BUSHING 1 1 GK435130 3/V
36 CV-300 915 FIBER PLATE 1 1 4A3P1 011 2/V
37 PPT SCREW M4X16 2 Use for Fiber Plate 3VPD01939 1
3
- -

NO. PARTS NO. DESCRIPTION Q'TY PACKED REMARKS ONLY FOR USE
Q'TY AT THE WORKS
39 CV-300 916 CORD ASSY (VDE) 1 1 2B1XK6342 4/V
40 CV-300 917 FILTER ASSY 1 1 2V1Z35150 F/V
41
42
43 CV-400 014 LOWER CASE (PI) 1 1 0VPP03499 4/V
44 CV-300 91 SUCTION INLET (DG) 1 1 2V1YL5946 1/V
45 CV-300 919 INLET PACKING 1 1 3L44 6549 1/V
46 PPT SCREW M4X25 2 Use for Suction Inlet 3VPD01939 4
47 CV-100 939 CASTER SUPPORTER (DG) 2 1 2V1YK9097 1/V
4 CV-300 921 CASTER ASSY 2 1 inc.49,50 3L9ZA653 F/V
49 PPT SCREW M4X16 3VPD01939 1
50 CV-300 922 CASTER WASHER 2 1 4M 719499 1
51
52 CV-300 924 WHEEL SUPPORTER ASSY (DG) 1 1 inc. 53 3L1Z95039 D/V
53 CV-300 925 WHEEL (100) DG 2 1 2L9333324 P/V
54 CV-300 926 HOSE ASSY 1 1 inc. 55-59 1A1ZA3203 U/V
55 SEAL RING 2 3A2RC7604 1
56 CD HOSE 3.0M 1 2VAZ10 3 3
57 STOPPER RING 2 3A2QC7605 4
5 CV-300 927 CURVED PIPE ASSY 1 1 2A1ZK9 40 A/V
59 CV-300 92 HOSE CONNECTOR (B) ASSY 1 1 2A1ZK9 41 A/V
60
61 CV-400 015 R&F TOOL ASSY D321-ECO 1 1 1V 04502 A/V
62
63 CV-300 930 EXTENSION PIPE (S) 3 1 1A1NA99 6 2/V
64 CV-300 931 DUSTING BRUSH ASSY 1 1 2V2ZC 940 B/V
65 CV-300 932 CREVICE NOZZLE C120 (DGR) 1 1 2V2EF2319 1/V
66
67
6
69
70
71
72
73
74
75
76
77
7
79
- 9 -

CV-400 ECO NO.0733E
HITACHI CONSUMER PRODUCTS(THAILAND), LTD.
HITACHI
Printed in Thailand
