Hitron Ebbu User manual

Parts

QUICK INSTALLATION GUIDE

EBBU: External Battery Back-up

Read me

first!

Battery Back-up Unit Installation

Mute button (silence the buzzer)

Power port

Battery port

DC output port

Screws

0440010322N0

Install batteries into the EBBU

Unplug device

STEP

Loosen the two screws on the EBBU and set them aside.

Please do not throw the screws away.

Disconnect the power adapter from both the device and the

wall plug. IMPORTANT: Make sure the unit is not powered on

until Step 4.

STEP

Reset

Tel

USB

Ethernet

Cable

Power

Battery

Install batteries into the EBBU

pull up

Pull up the notch to open the door. Remove the door and set it aside.

Install batteries into the EBBU

Slide the batteries into the compartments separately.

Slide the door in, ensuring the latches align with the holes inside

the EBBU casing. Push the bottom corners of the door to ensure

the notch latches properly in place to keep the door closed.

Align

The buzzer will sound when battery life is less than 50%.

STEP

Connect the EBBU to the device

Safety warnings

Check LED status

STEP After powering up the device, the Status LED will be in one of the

following states.

Connect power adapter to EBBU

STEP Plug the power adapter to a wall jack and connect it to the EBBU’s

Power port.

IEC 62368-1

All equipment is to be designed to allow installation according to the National Electrical Code (NEC), ANSI/NFPA 70, the Canadian Electrical Code (CEC),

Part I, CAN/CSA C22.1, and when applicable, the National Electrical Safety Code, IEEE C2. Also, for such equipment marked or otherwise identified, installation is allowed per the Standard for the

Protection of Information Technology Equipment, ANSI/NFPA 75. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE TO DISPOSE OF USED BATTERIES ACCORDING TO INSTRUCTED

SAFETY WARNING:

Risk of electrical shock if the device is exposed to water or moisture. This unit is designed for home and office environments, do not use the device outdoors. Keep the device in an environment between 0°C-25°C (32°F-77°F). To avoid overheating,

do NOT place any object on top of the device or restrict the flow of air around the device. The manufacturer assumes no liability for damage caused by any improper use of the device. Only use the cables offered with the device.

DISCLAIMER:

The manufacturer assumes no liability with respect to the contents of the document. The manufacturer also reserves the right to revise this document or update the content thereof without any obligation to notify any person of such revisions or

amendments. Specifications subject to change without notice.

LIMITED WARRANTY:

Each EBBU and its accessories have a rated lifespan of over 3 years. The EBBU support a standby-time of at least 24 hours with 2 fully-charged batteries and 12 hours with 1 fully-charged battery during a power-outage (includes all voice ports, but

no calls during this time interval). The EBBU’s battery capacity can vary depending on storage time and temperature.

Battery Replacement:

To reduce the risk of fire or electric shock, install batteries in a temperature and humidity-controlled indoor area, free from conductive contaminants. When replacing batteries, the replacement should use the same battery pack—Getac Technology

Corp. type C4589 or contract manufacturers. Deliver spent batteries to a recycling facility in accordance with local regulations. Don’t dispose of batteries in a fire as batteries may explode if improperly disposed.

FCC

This equipment is in accordance with the procedures given in ANSI C63.4-2014 and the energy emitted by this equipment was passes FCC Part 15 Subpart B and ICES-003, Issue 6 Class B. Conducted and

radiated emissions comply with Class B limits.

Off:

Red- Steady:

Red- Blinking:

Green- Steady:

Green- Blinking:

Orange- Steady:

Flicker between orange and red:

Boot-up failed

Any battery life is less than 50%

No AC power on the power outlet

Normal operation with 100% charge
