HJC i30 User manual

00

※
2
• Advanced Polycarbonate Composite Shell: Lightweight; superior fit and comfort
using CAD technology.
• Urban Daily Helmet for Commuting
• "ACS" Advanced Channeling Ventilation System: 1 top vent and 1 rear vent;
Full front-to-back airflow flushes heat and humidity up and out
• Pinlock Pin Prepared HJ-34 Shield: Provides 95% UV protection; Vision Plus(+10mm)
Wide Shield enhanced visibility
• RapidFire™ Shield Replacement System: Simple and secure shield ratchet system
provides ultra-quick, tool-less shield replacement
• Aerodynamic 3D Shield Design: helps avoid wind being blown in
• Integrated Sunshield: Black Dark Smoke sunshield deploys quickly and easily;
Better peripheral vision; Anti-Scratch coated
• New Easy-To-Use Sunshield Lever: Located on the lower left side for easily use
• MultiCool Interior with Advanced Antibacterial Fabric: provides enhanced
moisture-wicking and quick-dry functions; odor free
• Crown and Cheek pads: Removable and washable
• Cheek pads: interchangeable throughout all shell sizes
• Retention: Double D-ring
• Glasses Grooves: Accommodates riders who wear eyeglasses and sunglasses
• Speaker Pockets: For bluetooth communication
• Ready for SMART HJC Bluetooth (Bluetooth sold separately)
10
10
10
10
6-10

Size Chart
Although your HJC helmet is designed to reduce or prevent some injuries when worn, no helmet can
protect you from all possible or foreseeable impacts. For example, your helmet cannot protect you from
spinal or neck injuries. In addition, there is no guarantee that your helmet will PREVENT injuries to the
area of your head that is covered. A low speed accident may even result in serious injury or death.
The size chart is only for reference.
Always try the helmet on and follow
this manual's instructions for a proper
fit.
If helmet comes off or shifts over your eyes, try another size or another model or brand.
You must be able to see the edge in your upper field of vision.
1. Outer Shell
2. Top Front Vent
3. Rear Venturi Exhausts
4. Impact Absorbent Liner
5. Comfort Liner
6. Rubber Edge Trim
7. Bluetooth Cover
8. Sunshield Lever
9. Chin Strap
10. Chin Strap Snap
11. Double "D" Ring
12. Tool-less Shield
13. Sunshield
14. Eyeport Gasket
15. Shield Ratchet
72
SMART HJC
CLOSE
CLOSE
OPEN
OPEN
54-55
6 3/4 - 6 7/8
21 1/4 - 21 5/8
58-59
7 1/4 - 7 3/8
22 7/8 - 23 1/4
55-56
6 7/8 - 7
21 5/8 - 22
57-58
7 1/8 - 7 1/4
22 1/2 - 22 7/8
60-61
7 1/2 - 7 5/8
23 5/8 - 24
62-63
7 3/4 - 7 7/8
24 3/8 - 24 3/4

Only use approved methods to clean the helmet. Using other unapproved chemicals or
methods may damage the helmet shell or lining. A damaged helmet may increase your
risk of serious injury or death in an accident.
Glossy Finish. HJC recommends cleaning your helmet with products designed for automotive cleaning
and polishing. All HJC helmets are finished with an automotive type base coat/clear coat finish. Rubbing
compounds can be used for deep cleaning to remove many scratches and scuffs. Follow the product’s
instructions diligently. Over polishing with rubbing compounds can cause light abrasions which may dull
the finish of your helmet. Stickers and decals will leave adhesive residue when removed. To remove the
adhesive residue, use alcohol swabs. Be certain to immediately wipe away the excess liquid and clean
the area with soap and water once the adhesive residue is removed. Do not use excessive pressure while
rubbing when attempting to remove the adhesive residue, instead use multiple light treatments.
Non-Glossy Finish. For our flat finish (non-glossy) helmets, we recommend using warm water and mild
soap. Use multiple treatments for heavier dirt. Do not use excessive pressure or rubbing compounds
while cleaning the surface as a “glossy” effect could be created, running the flat finish appearance.
Shell Cleaning
1. Please clean helmets from dust, bugs or grass within one day.
Cleaning progress
1) Clean the helmet with warm water and cloth.
2) If there are any remains left, dry the helmet and remove any remaining contamination with rubber eraser.
※ Do not use any alcohol or thinner to clean the helmet because they may damage the paint.
2. Avoid oil contamination as it is extremely difficult to clean once exposed.
■
Interior Cleaning
Vent Cleaning
Dirt and debris can find its way into venting of your HJC helmet. Compressed air cans used for cleaning
computer keyboards may be used to blow the debris from the ventilation system. It is recommended that
you remove any removable pads before doing this process.
Although we recommend changing a helmet every 3 to 5 years, the accumulation of sweat, humidity and
dirt can deteriorate the fabric and stitching and this may cause odor. To wash HJC removable pads, hand
washing is recommended. If you use a washing machine, please use on “Delicate” setting and air dry. HJC
do not recommend using spin-dryer for the interior pads as it may damage the material. For non-removable
interiors, HJC recommends using anti-bacteria and mildew eliminating products such as “Helmet Fresh.”
or other similar product.
Shield Cleaning
The helmet shield is made of polycarbonate materials with a polyurethane abrasion resistance coating.
It should be cleaned using mild soap and warm water. Never use hot water, salt water, benzene, thinner,
gasoline or any other harsh agents. Additionally the use of commercial shield cleaners is not recommended
because they may affect the quality of the shield material. Treat carefully when cleaning the shield to
preserve the abrasion resistant coating. When deep scratches are visible, it is highly recommended that
the helmet shield be replaced. Tinted shield are for “Day time use only” and are not suitable for use at night
or in conditions of poor visibility.
10
10
10

1. Pull the shield forward slightly then lift all the way up.
2. Move the handle-locker to the open position.
3. The shield will be automatically released out of the base ratchet mechanism.
1
2
OPEN
OPEN
OPEN
OPEN
Handle-locker
Handle-locker
1. Grasp the crown pad fabric as close as possible to its plastic base and pull/pry away from the helmet.
Notice how the crown pad plastic section aligns with the shell plastic sleeve. This will help orient you
with the reinstallation.
2. Repeat same at rear.
1. Install the front section first by aligning the plastic shell base and the crown pad plastic sleeve, ensuring
that the center and side holes are properly aligned. Press the crown pad plastic sleeve (center portion)
into the center of the channel which is built into the plasticshell base, working your way outward to each
side.
2. Align and snap the two rear snaps into place.

When helmets left out in the sun for extended periods of time, it may fade overtime.
When using the sunshield, please always also use the shield in its correct lowered position.
Try not to operate the sunshield while riding as this may impair your vision and may lead to an accident.
DO NOT pull on the sunshield when it is already down. The sunshield may be ejected and this will
increase the risk of serious injury or death in the event of an accident.
DO NOT attempt to adjust the sunshield itself with your hands. Always use the sunshield lever.
DO NOT use sunshield at night time. The sunshield is only for day time use. The sunshield does not
provide eye protection. When you use the sunshield be sure that the clear shield is also in closed position.
Above illustration shows raised
sunshield position.
Above illustration shows lowered
sunshield position.
1. While sunshield is in lower position, gently pull it until you see the top of the sunshield.
2. Gently pull one side of the sunshield as arrow indicates (repeat same for other side).
1. Insert sunshield tab 'A' into 'B' position.(Repeat same on opposite side)
※When installing the sunshield, be sure to have
it slided behind the tap ‘B’ holder.
LeverLever
B
B
A

11
HJC hereby extends a limited warranty to the purchaser of a HJC helmet that the helmet is free of defects
in materials and workmanship.
Coverage
This warranty is applicable to manufacturer's defects only and the warranty period varies between HJC
models. The RPHA Series warrants up to 5 years from the date of purchase or 7 years from date of
manufacture, while all other models warrant up to 3 years from the date of purchase or 5 years from date
of manufacture (whichever comes first). This warranty does not apply to any problems that arise from
wearer’s misuse, negligence, modifications, accidents, etc. A change of fluorescent color is not subject
to warranty as this is a typical characteristic of fluorescent color; it may fade or degrade depending on the
user’s environment.
Disclaimer
Any warranty of merchantability and any implied warranty are hereby expressly disclaimed. In addition HJC
shall not be liable for any consequential damages.
Procedure
In order to receive warranty, please take your helmet, your receipt showing the date of purchase, and a
brief memo that includes a description of the problem, your name, and phone number to the authorized
HJC dealer from which you purchased your helmet.
