HJC IS-5 User manual

HJC VINA LIMITED COMPANY
Made In Vietnam
IS-5

SuperCool Interior: Moisture-wicking and odor-free interior. Crown and cheek pads are
removable and washable.
3-snap Visor.
※
Visor Removal
Visor Installation
4-5
4-5
5-8
5
5
5
5
5
6
6
6
6
7
7
7
8
8
8
8
8
4
IS-5
Advanced Polycarbonate Composite Shell: Lightweight, superior fit and comfort using
advanced CAD technology.
DOT Approved
SIZES: XS-2XL

Important Safety Information
Selecting the Right Helmet
The instructions in this manual are designed to help you select the right helmet, wear it properly, take care of it, and know when
to replace it. Failure to follow these instruction may increase your risk of serious injury or death in an accident.
In order to get the most protection possible from your helmet, you should always do the following:
• Wear your helmet when you ride;
• Handle your helmet carefully to avoid accidental damage; and
• Ride safely – do not take risks because you are wearing a helmet.
Although your HJC helmet is designed to reduce or prevent some injuries when worn, no helmet can protect you from all possible or
foreseeable impacts. For example, your helmet cannot protect you from spinal or neck injuries. In addition, there is no guarantee that your
helmet will PREVENT injuries to the area of your head that is covered. A low speed accident may even result in serious injury or death.
Never buy a used helmet or borrow someone else’s helmet. Over time the protective foam in helmets will adjust
to the contours of a user’s head. A used or borrowed helmet may not offer as much protection as a new helmet.
This helmet does not provide as much coverge or protection as a full face helmet. You can get more protection
by purchasing a helmet with greater head coverage.
Wearing the wrong size helmet can increase your risk of serious injury or death in an accident. A helmet that is
too large for your head may be dislodged or knocked off in an accident. To select the right size helmet for your
head, follow these instruction :
The size chart is only for reference. Always
try the helmet on and follow this manual's
instructions for a proper fit.
Always make sure you can see well enough to safely operate your motorcycle.
If helmet comes off or shifts over your eyes, try another size or another model or brand. You must be able
to see the edge in your upper field of vision.
Size Chart
1. Measure your head. Wrap a tape measure around your head about one inch (2.5cm) above your eyebrows.
2. Use the sizing chart to select the helmet size that corresponds most closely to your head measurement. If your head
size falls between two helmet sizes, try on the larger helmet first and then the smaller size.
6.
Test the helmet fit by placing your hands on each side of the helmet. While holding your head as motionless
as possible, try rotating your helmet from left to right then up and down. If you can feel the helmet padding
sliding on your head, it is too big, try a size smaller. You should feel the helmet move the skin on your
head and face as you try to move the helmet.
7. F asten the retention system (chin strap) as tight as possible under your jaw without causing pain. There must be no slack
in the strap, and the strap must be tight up against your jaw. See page 4-5.
3. Try on the helmet by grasping both chin straps to pull the helmet completely onto your head, ensuring that the top of your head
is in contact with the top of the helmet interior.
4.
Check for a proper fit. To make sure your helmet is the right size, check that :
• The helmet inner lining fits snugly around your head.
• The top pad presses firmly on your head.
• The cheek pads contact your cheeks.
• There is no space around your brow under the inner lining. Test this by trying to insert your fingers.
If the helmet does not fit snugly, try on a smaller size.
5.
Check your field of vision when trying on a helmet. Some helmets may obstruct or block your vision when looking left, right, up, or down.
8. Test the retention system (chin strap)
• Put your hands on the back of the helmet and try to push the helmet off by rotating it forward.
• Put your hands on the front of the helmet above your forehead (or on the chin guard) and try to push
the helmet off by rotating backward.
Repeat steps 3 throught 8 until you find a helmet that fits your head snugly and securely.
Specifications
Using Your Helmet Correctly
Inspect your helmet
To ensure that your helmet is in the best condition to maximize your protection, always inspect your helmet for damage
before riding :
• C heck for helmet damage. If your helmet is damaged or cracked, stop using it immediately. See “Helmet Replacement” (p. 6)
section for further information. If your helmet has been dropped, you may not be able to see the damage.
• C heck for worn or damaged parts. Plastic components may wear out over time. If you find worn or damaged parts, replace them
or purchase a new helmet. See “Replacement Parts” (p. 6) for information on parts replacement.
Check Your Face Shield
If your face shield is scratched or damaged it may reduce the visibility-replace if necessary.
Always make sure you can see well enough to safely operate your motorcycle.
Fasten the Retention System
Fasten the retention system (chin strap) as tight as possible under your jaw without causing pain. There must be no slack in the
strap, and the strap must be snug up against your jaw. If the retention system is not tight, your helmet may become dislodged or
knocked off in an accident.
To reduce the risk of serious injury or death, always use your helmet correctly.
If parts fall off while riding, your vision may be blocked which could cause an accident.
• Check the retention system (chin strap) for damage. If it is frayed or ripped, replace the helmet.
• Check that all pads are in place. Both of the cheek pads and the crown pads must be in place.
1. Outer shell
2. Impact absorbent liner
3. Comfort liner
4. Rubber edge trim
5. Chin strap
6. Double "D" ring
7. Sun shield
To reduce the risk of serious injury or death and to help prevent damage to your helmet :
• Never adjust your helmet accessories while riding – Only make helmet adjustments when stopped.
• Never drop your helmet – Dropping your helmet may crack the shell or damage the protective foam. The damage may
not be visible. Your helmet is only designed for ONE impact. Refer to “Helmet Replacement” (p. 6) for more information
on what to do after helmet has been dropped.
• Never wear anything between your head and your helmet – this may reduce the effectiveness of your helmet.
• Never hang or hook your helmet on anything including mirror stalks or sissy bars - Doing so may cause damage
to the helmet protective foam or liner.
• Never use insect repellent on or around your helmet – insect repellant may damage your helmet’s sun shield, shell,
protective foam, or other components.
• Never expose helmet to gasoline or gasoline fumes – Gasoline may damage your helmet’s sun shield, shell,
protective foam, or other components.
• Never use a dark or tinted face shield at night or in low visibility conditions.
- If you have any questions on what other substances may damage your helmet, please contact us.
• Always
be alert for sounds – Your helmet may impair your hearing. However, your helmet is not a form of hearing protection.
• Always store your helmet in its helmet bag when not in use to help reduce accidental surface damage.

Double "D" Ring
Snap(Male)
D-Ring
Chin Strap
Snap(Female)
Do not rely on the snap to secure the helmet. The snap is provided only to prevent
the strap from flapping in the air. Fasten the retention system only in the following manner:
Shell Cleaning
Interior Cleaning
Only use approved methods to clean the helmet. Using other unapproved chemicals or methods may damage the helmet shell
or lining. A damaged helmet may increase your risk of serious injury or death in an accident.
Glossy Finish. HJC recommends cleaning your helmet with products designed for automotive cleaning and polishing. All HJC
helmets are finished with an automotive type base coat/clear coat finish. Rubbing compounds can be used for deep cleaning to
remove many scratches and scuffs. Follow the product’s instructions diligently. Over polishing with rubbing compounds can cause
light abrasions which may dull the finish of your helmet. Stickers and decals will leave adhesive residue when removed. To remove
the adhesive residue, use alcohol swabs. Be certain to immediately wipe away the excess liquid and clean the area with soap and
water once the adhesive residue is removed. Do not use excessive pressure while rubbing when attempting to remove the adhesive
residue, instead use multiple light treatments.
Non-Glossy Finish. For our flat finish (non-glossy) helmets, we recommend using warm water and mild soap. Use multiple
treatments for heavier dirt. Do not use excessive pressure or rubbing compounds while cleaning the surface as a “glossy” effect
could be created, running the flat finish appearance.
Although we recommend changing a helmet every 3 to 5 years, the accumulation of sweat, humidity and dirt can deteriorate the
fabric and stitching and this may cause odor. To wash HJC removable pads, HJC recommends regular machine washing and air
drying. For non-removable interiors, HJC recommends using bacteria and mildew eliminating products such as “Helmet Fresh.”
Vent Cleaning
Dirt and debris can find its way into venting of your HJC helmet. Compressed air cans used for cleaning computer keyboards may
be used to blow the debris from the ventilation system. It is recommended that you remove any removable pads before doing this
process.
Shield Cleaning
The helmet shield is made of polycarbonate materials with a polyurethane abrasion resistance coating. It should be cleaned using
a weak solution of mild soap and warm water. Never use hot water, salt water, benzene, thinner, gasoline or any other harsh agents.
Treat carefully when cleaning to preserve the abrasion resistant coating. When deep scratches are visible, it is highly recommended
that the helmet shield be replaced. Tinted shield are for “Day time use only” and are not suitable for use at night or in conditions
of poor visibility.
Maintaining Your Helmet Correctly
Cheek Pad Removal
Always check to make sure helmet pads are installed before using the helmet. A helmet with missing or improperly installed
pads may increase your risk of serious injury or death in an accident.
There are 3 snaps holding the cheek pad in place.
1. Detach the cheek pad from velcro palens.
2. Gently pry the check pad away from the interior,
releasing the snaps.
Cheek Pad Installation
1. Feed the chin strap through the opening in the cheek pad.
2. Clip the cheek pad’s 3 small male snaps to the 3 female snaps fixed on the shell interior.
3. Attach the velcro palens.
Velcro
palens
Crown Pad Removal
1. To properly remove the crown pad plastic sleeves, slightly lift the plastic shell base in the order
of A,B,C and gently pull the crown pad fabric.
2. Simply pull the crown pad fabric in the rear and it will be released.
1.
Align and insert crown pad plastic sleeves under the slot located on the crown pad’s plastic base.
Press the snap into place.
2. Align and snap the two rear snaps into place.
Crown Pad Installation
1. Firmly grasp the visor directly around one of the side visor snaps.
Firmly pry the snap free while using your palm against the shell
as leverage. This keeps you from over pulling when the snap
does release. Repeat on other side and center snap using
the same technique.
Visor Removal

Replacement Parts
Do Not Modify Your Helmet
Your HJC helmet is designed to meet DOT standard. Contact HJC America for more information about the DOT
standard. Modifying your helmet may increase your risk of serious injury or death in an accident. Do not modify your HJC
helmet. Modifications include the following :
• drilling holes;
• cutting shell, liner, or strap;
• modifying the retention system, including adding a chin cup;
• removing parts;
• painting; and
• attaching accessories that are not manufactured by HJC for this helmet.
If you have questions about modifications, please contact HJC
America , See back cover for contact information.
Always check to make sure helmet pads are installed before using the helmet. A helmet with missing or improperly installed
pads may increase your risk of serious injury or death in an accident.
Even if your helmet has not been damaged, it needs to be replaced every 3 to 5 years depending on how much you use it.
Over time, UV rays and adhesive and component aging will damage your helmet. Wearing a damaged helmet may increase
your risk of serious injury or death in an accident. If you are unsure if you need to replace your helmet, contact HJC America
before using your helmet again.
HJC hereby extends a limited warranty to the purchaser of a HJC helmet that the helmet is free of defects in materials and
workmanship.
This warranty is applicable to manufacturer’s defects only and is good up to one year from the date of purchase, It does not
apply to any problems arising out of wearer’s misuse, negligence, modifications, accidents, etc.
Helmet Disposal
Coverage
Any warranty of merchantability and any implied warranty are hereby expressly disclaimed. In addition HJC shall not be liable
for any consequential damages.
Disclaimer
In order to receive warranty, please take your helmet, your receipt showing the date of purchase, and a brief memo that
includes a description of the problem, your name, and phone number tothe authorized HJC dealer from which you purchased
your helmet.
Procedure
An improperly stored helmet can become damaged and may increase your risk of serious injury or death in
an accident. You should:
• Store helmet in a cool and dry place,
• Keep helmet away from pets and other animals,
• Keep helmet away from heat in excess of 122°F and do not set on or near hot surfaces.
• When helmets left out in the sun for extended periods of time, it may fade overtime.
Although your HJC helmet is constructed with the best materials available to offer a long-lasting product, it
will eventually need to be replaced. Immediately replace your helmet if:
• It has suffered an impact. Your helmet is only designed for ONE impact.An impact may fracture the outer
s hell or compress the impact absorbing liner. You may not be able to detect this damage. Any impact in
a crash or a drop from as low as 4 feet is enough to damage your helmet.
• T he shell, lining, or retention system is damaged. The helmet shell, the impact absorbing lining, and the
retention system must be in good condition to provide you with the most protection.
If you buy a new helmet, destroy the old one to ensure it cannot be reused. Do not sell or give away your
old helmet, even if it has not been damaged. Over time the protective foam in the helmet will adjust to the
contours of your head. If someone else uses this helmet it will not provide them with as much protection.
Helmet Replacement
Storing Your Helmet Correctly
Warranty
1. While sun shield is in lower position, gently pull it until you see the top of the sun shield.
2. Gently pull one side of the sun shield as arrow indicates (repeat same for other side).
Sun shield Removal
1. Insert sun shield tab 'A' into 'B' position.(Repeat same on opposite side)
Sun shield Installation
Visor Installation
1. Align the center snap and firmly press the snap closed.
These snaps are strong so you might need to press
the snap firmly with your palm.
※When installing the sun shield,
be sure to have it slided behind
the tap ‘B’ holder.
A
A
B
B
DO NOT operate the sun shield mechanism while riding as this may impair your vision
and may lead to an accident.
DO NOT pull on the sun shield when it is already down. The sun shield may be ejected
and this will increase the risk of serious injury or death in the event of an accident.
DO NOT use sun shield at night time.
