HK Instruments MM Series User manual

Copyright HK Instruments, Inc. 2017 www.hkinstrumentsinc.com Installation version 2.0 2017
INSTALLATION
INSTRUCTIONS
DIFFERENTIAL PRESSURE GAUGES
& MANOMETERS – MM Series
• READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO
INSTALL, OPERATE OR SERVICE THIS DEVICE.
• Failure to observe safety information and comply with instructions can result in
PERSONAL INJURY, DEATH AND/OR PROPERTY DAMAGE.
• To avoid electrical shock or damage to equipment, disconnect power before
installing or servicing and use only wiring with insulation rated for full device
operating voltage.
• To avoid potential fire and/or explosion do not use in potentially flammable or
explosive atmospheres.
• Retain these instructions for future reference.
• This product, when installed, will be part of an engineered system whose
specifications and performance characteristics are not designed or controlled
by HK Instruments. Review applications and national and local codes to assure
that the installation will be functional and safe. Use only experienced and
knowledgeable technicians to install this device.
Thank you for choosing an HK Instruments MM Series liquid col-
umn manometer. The MM Series is intended for use in commercial
environments for air and non-corrosive gases. The MM Series is
designed with overpressure reservoir to protect the manometer
liquid from leaking into the duct during over pressure.
The MM Series includes a field adjustable zero point calibration
and pressure limit stickers. The MM Series is available with op-
tional level bubble and NIST standard calibration certificates.
SPECIFICATIONS
Performance
Accuracy:
MM-0202 ±0.004 inWC
MM-04 ±0.004 inWC
MM-0420
-0.4–0 inWC ±0.02 inWC
0–2.0 inWC ±0.1 inWC
MM-00824
0–0.8 inWC ±0.02 inWC
0.8–2.4 inWC ±0.1 inWC
Overpressure:
Max Pressure: 800 inWC (200 kPa)
Technical Specifications
Media Compatibility:
Dry air or non-aggressive gases
Measuring units:
inWC
Measuring ranges:
-0.2–0–0.2 inWC
0–0.4 inWC
-0.4–0–2.0 inWC
0–0.8–2.4 inWC
Environment:
Operating temperature:
-40–140 °F (-40–60ºC)
Gauge fluid:
Red: s.g. 49.068 lb/ft3 (0.786 kg/dm3) (15 °C)
(Isopar M)
MM-0202 RED
MM-04 RED
MM-0420 RED
MM-00824 RED
Physical
Case:
ABS
Cover:
PMMA
Knobs:
Polycarbonate (PC)
O-ring:
Nitrile rubber (NBR)
Weight
14.82 oz (420 g)
Safety
Product equipped with integral reservoir to prevent
gauge fluid leakage during overpressure situation.
Product is tested and meets the NRTL product approval
requirements.
INTRODUCTION WARNING
AVERTISSEMENT
• LISEZ ATTENTIVEMENT CES INSTRUCTIONS AVANT DE PROCÉDER À
L’INSTALLATION, LA MISE EN SERVICE OU L’ENTRETIEN DE CET APPAREIL.
• Le non-respect des informations et instructions de sécurité peut entraîner DES
DOMMAGES CORPORELS, LA MORT ET/OU DES DÉGÂTS MATÉRIELS.
• Afin d’éviter les chocs électriques et les dommages matériels, déconnectez
l’alimentation électrique avant l’installation ou l’entretien, et utilisez uniquement du
câblage avec isolement assigné pour une tension d’alimentation optimale.
• Afin de prévenir les risques d’incendie et/ou d’explosion, n’utilisez pas l’appareil
dans des environnements potentiellement inflammables ou explosifs.
• Conservez ces instructions à titre de référence.
• Une fois installé, ce produit fera partie d’un système technique dont les
spécifications et les caractéristiques de performance ne sont ni conçues ni
contrôlées par HK Instruments. Consultez les applications et les codes nationaux
et locaux pour garantir le fonctionnement correct et sûr de l’installation. Ne faites
appel qu’à des techniciens expérimentés et compétents pour installer cet appareil.
APPLICATIONS
MM series devices are commonly used in HVAC/R systems for:
• fan, blower and filter monitoring
• pressure and flow monitoring
• pressure monitoring in cleanrooms
RoHS 2
2011/65/EU
COMPANY WITH
MANAGEMENT SYSTEM
CERTIFIED BY DNV GL
= ISO 9001 = ISO 14001 =

Copyright HK Instruments, Inc. 2017 www.hkinstrumentsinc.com Installation version 2.0 2017
INSTALLATION
Figure 1 - Surface mounting
1) Mount the device horizontally in the desired location.
8.35 (212.0)
Pa
600
500
400
300
200
150
100
50
0 Pa
=0.786
FILL
MANOMETER
MM 200600
4.13 (105.0)
5.5 (139.5)
0.67 (17.0) (4.23 (107.5)
inch (mm)
DIMENSIONAL DRAWINGS
Pa
600
500
400
300
200
150
100
50
0 Pa
=0.786
FILL
MANOMETER
MM 200600
2) Unscrew the zero adjustment knob (lower one) so that it is com-
pletely open and then turn one round backwards. Open the fill plug
(upper one) and pour in the gauge fluid until it reaches the zero on
the scale. Finetune with the zero adjustment knob until the fluid is
exactly at the zero level. Screw the fill plug back to its place.
3) Connect the pressure tubes. Connect positive pressure to port
labeled “+” and negative pressure to port “-”.
NOTE! Only use gauge fluid approved by HK Instruments to guaran-
tee accuracy and functionality of the device.
HK Instruments, Inc. (HK)
(a) WARRANTY COVERAGE: HK warrants to the original end user of the Products that
the Products will, at the date of initial purchase, meet the applicable specification for
such Products (as described by HK in its product literature) and, under normal use and
service, will be free from any defects in materials or manufacture for (a) one (1) year
from date of sale to end user for electromechanical Products and (b) five (5) years from
date of manufacture for electronic Products.
(b) NO WARRANTY OF PRODUCT SUITABILITY: Neither HK nor the manufacturer of
the Products to be sold hereunder (“Manufacturer”) makes any warranty that Products
are suitable for a particular purpose, application or design. Many states and localities
have differing codes or regulations governing the installation and/or use of HK
products. HK does not guarantee compliance with such codes or regulations; the end
user is solely responsible for safe and correct installation and use of the Products and
for compliance with such codes and regulations.
(c) EXCLUSION OF IMPLIED WARRANTIES: THE WARRANTY HEREIN IS THE
ONLY WARRANTY APPLICABLE TO THE PRODUCTS AND EXCLUDES ALL OTHER
WARRANTIES, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, AND ANY IMPLIED WARRANTY ARISING FROM
COURSE OF DEALING OR USAGE OF TRADE.
(d) REMEDIES FOR NON-CONFORMITY OR BREACH OF WARRANTY: If the Product
purchased does not conform to the applicable warranty, HK will provide, at its
option, one of the following remedies: (1) repair of the non-conforming Product, (2)
replacement with a conforming Product, or (3) refund of the original purchase price.
THESE REMEDIES SHALL BE THE EXCLUSIVE AND SOLE REMEDY for any breach
of warranty. HK and Manufacturer have no other responsibility or liability for breach of
warranty or otherwise.
(e) LIMITATION OF LIABILITY: NEITHER HK NOR MANUFACTURER WILL BE LIABLE
FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES
UNDER ANY CIRCUMSTANCE, INCLUDING WITHOUT LIMITATION ANY DEFECT IN
THE PRODUCT PURCHASED.
(f) FURTHER LIMITATIONS: The warranty herein does not cover damage caused
by lightning, flood or other natural phenomenon; normal wear and tear; accident,
improper or careless handling, abnormal use, overloading, improper storage or abuse;
incorrect installation, care or reconstruction; or alteration, calibration, reconfiguration,
maintenance or installation work done by unqualified personnel. Should Manufacturer
alter the structure of any Product in the future, HK and Manufacturer shall not be
obligated to make comparable changes to Products already purchased. HK will give
a new warranty for Products being replaced or repaired within the warranty period,
however only to the expiration of the original Product’s warranty period. The warranty
includes the repair of a defective part or device, or if needed, a new part or device, but
no other costs except as otherwise stated in the HK Distributor Terms and Conditions.
The parts left over from installation should be recycled according
to your local instructions. Decommissioned devices should be
disposed of as mixed waste according to your local instructions.
RECYCLING/DISPOSAL
WARRANTY POLICY
