HK SIEVE Series User manual

WE MAKE SIFTING OPERATIONS BETTER.
HK LAB SIEVE SERIES
Operations, Installation & Maintenance
12750 Salem Warren Road
Salem, Ohio 44460
Phone: [phone]
Fax: [phone]
www.hksieve.com
[e-mail]
WE MAKE SIFTING OPERATIONS BETTER.

WE MAKE SIFTING OPERATIONS BETTER.
2
FORWARD
Thank you for choosing HK Technologies Ultrasonic Sieving Equipment!
The Ultrasonic Sieve by HK Technologies serves the industries needs in customized ultrasonic fine
mesh sifters. With years of engineering and machining practice, HK sieves are built to function
well in industrial applications while maintaining high ultrasonic sifter throughputs with minimal
maintenance and adjustment. The instruction manual you are receiving is documentation of the
equipment and should be kept with the machine.
INTRODUCTION
This manual is structured to help customers during the installation, operation and maintenance
of their new ultrasonic sieve. You may use the Table of Contents located on page 3 as a guide to
locate information needed on how to safely handle, install, set up, program, and/or maintain this
product. If you require additional assistance, please call HK Technologies Inc. at [phone].

WE MAKE SIFTING OPERATIONS BETTER.
3
TABLE OF CONTENTS
ID Information Page Number
1.1 Intended Use of the Product 4
1.2 Warranty & Damages 4
1.3 Policy Statement Regarding OSHA Compliance 5
2 Technical & Performance 6
2.1.1 Rotary Electric Vibrator 6
2.1.2 Rotary Electric Vibrator: Electrical Specifications 6
2.1.3 Rotary Electric Vibrator: Physical Specifications 6
2.2 Vibratory Screener 6
2.2.1 Vibratory Screener: Physical Specifications 6
2.2.2 Mesh Screen Sizes 7
3 Receiving, Installation & Setup 8
3.1.1 Receiving & Product Handling 8
3.1.2 Delayed Delivery Policy 8
3.1.3 Cancellation Policy 8
3.2.1 Components List 9
3.3.1 Description of Components 10
3.3.2 Ultrasonic Back Panel Connections 11
3.4.1 Assembly of Equipment 12
3.5.1 Electrical Connections Components Diagram 13
3.6.1 Variable Frequency Drive 13
4 Operation 14
4.1.1 Adjusting Mechanical Operations 15
4.2.1 Feeding & Material Flow Operations 16
4.3.1 HK Ultrasonic Operation Assistance 17
4.4.1 Operation Sequence 17
5 Maintenance & Troubleshooting 18
5.1.2 Gasket Sealer 19-20
5.1.3 Vibratory Insulated Mounts 21-23
5.1.4 Screen Element 24-25
5.1.5 Rotary Electric Vibrator Troubleshooting 26
6 Parts Replacements & Repairs 27
7 Returns 27

WE MAKE SIFTING OPERATIONS BETTER.
4
1.1 INTENDED USE OF THE PRODUCT
The HKLab Sieve Series is to be used in conjunction with the HK Ultrasonic Power Supply, and
Cleveland Vibratory Rotary Vibrators to accomplish a wide variety of vibratory screening tasks
of powdered materials. Failure to follow instructions in the manual and any alterations made to
the equipment will void warranty. Detailed instructions of the operation of the equipment are
provided in the manual do not bolt or weld any addition equipment to the vibratory screener
warranty with HK Technologies Inc. will be voided.
1.2 WARRANTY & DAMAGES
The company warrants the equipment to be free from defects in material and workmanship
under normal use, proper installation and proper operating conditions. Except of the warranties
of title, the limited warranty is expressly in lieu of and excludes all supersedes all other warranties
and representations, express or implied from the company, including any implied warranty
of merchantability or fitness for any particular use. The company’s liability under this limited
warranty shall be limited to repair or replacing any parts witch prove defective, at its factory in
Salem, OHIO. If returned to the company’s said factory with shipping charges prepaid, within a
period of six months from the date of shipment. This shall be no liability for anticipated profits,
nor consequential or incidental damages, direct or indirect, loss of use of the equipment or of any
installation into which the equipment may be put under this limited warranty. The company’s
liability for warranty of component parts included in the equipment, which the company has
purchased as a manufactured unit from a recognized manufacturer thereof, shall be no greater
than the warranty liability assumed by the supplier or manufacturer of such component parts. In
no event shall the company be liable consequential or incidental damages resulting directly from
the failure of such component parts.
It is the company policy that it is the responsibility of the employer-owner of the equipment and
not the company, to comply with the provisions and regulations under the Occupational Safety
& Health Act of 1970 (OSHA) as well as any federal, state or local standards which might exist as to
health and safety. Therefore, in no event shall the company be liable for any direct, incidental or
consequential damages, either direct or indirect, arising out of or resulting from the operation of
equipment sold by the company as such operation pertains to OSHA or any other federal, state or
local standards which might exist regarding health and safety.

WE MAKE SIFTING OPERATIONS BETTER.
5
1.3 POLICY STATEMENT REGARDING OSHA COMPLIANCE
The Occupational Safety and Health Act 1970 (OSHA) placed the responsibly upon each employer
for their employees a place in witch to work free from recognized hazards to safety and health.
The Cleveland Vibrator Company & HK Technologies attempts to follow good safety practices in
the design of its equipment and to comply with the purpose and the standards of OSHA.
However, all purchasers must be aware that the OSHA regulations were issued to control usage of
equipment in the hands of employers rather than to regulate the manufacturer of the equipment.
Full compliance with OSHA thus involves the installation and the use of the equipment in the
hands of the employer-owner. The Cleveland Vibrator Company & HK Technologies cannot
therefore represent, or certify that their equipment conforms in all respects with OSHA
regulations.
In no event shall The Cleveland Vibrator Company & HK Technologies be liable for any direct
incidental or consequential damages arising out of or resulting from operation from operation of
our equipment as it pertains to OSHA
The policy also applies to any federal, state or local standards, which might exist.

WE MAKE SIFTING OPERATIONS BETTER.
6
2. TECHNICAL & PERFORMANCE
In this chapter, you will gain insight into the technical specifications and performance of your
unit.
2.1.1 ROTARY ELECTRIC VIBRATOR
This section describes the physical and technical specifications of the rotary electric vibrator. You
will learn about the power output and the a brief overall physical description of the rotary electric
vibrator.
2.1.2 Electrical Specifications: Power & Ratings
Sieve Model Electric Motor Model Power Current Rating Max Force
HK-8 RE 1-2 1/10 HP 0.41 AMP @ 230 Volts 220 lbs.
HK-12 RE 1-2 1/10 HP 0.41 AMP @ 230 Volts 220 lbs.
HK-17 RE 6-4 1/3 HP 1.2 AMP @ 230 Volts 1,320 lbs.
2.1.3 Electric Motor Physical Description: Dimensions & Weight
Electric Motor Model Length Width Height Weight
RE 1-2 8-5/64” 5-23/32” 5-15/16” 16.6 lbs.
2.2 VIBRATORY SIEVE
This section describes the physical and technical specifications of the vibratory screener learning
about with the inlet dimensions, inner rim size and a brief overall physical description of the
vibratory screener, frame and mesh sizes that can be fitted to the rim.
2.2.1 Sieve Model Physical Description: Dimensions & Weight
Sieve Model Length Width Height Inlet Dia. Outlet Dia. Rim Inner
Dia.
Weight
HK-8 18.875” 11” 15” 8” 1.25” 8” 65 lbs.
HK-12 22.5” 14.125” 17.5” 11.75” 2” 11.75” 75 lbs.
HK-17 28.5” 22.125” 20.125” 16.5” 3” 16.5” 150 lbs.

WE MAKE SIFTING OPERATIONS BETTER.
7
2.2.2 MESH SCREEN SIZES
The mesh size determined by the buyer and Sales Manager, it effects flow rate through the sieve
as well as the fineness of material required by the customer. Selection of the correct mesh is
important, review the following table to make certain the mesh size you have acquired what will
work to the required specifications.
MESH WIRE DIAMETER MESH OPENING OPEN AREA
/INCH INCH INCH MICRON PERCENT
20.063 0.437 11,112 76.4
30.054 0.279 7078 70.1
40.0475 0.2023 5660 65.9
40.063 0.187 4760 56
50.041 0.159 4000 63.2
60.0348 0.1318 3360 62.7
70.035 0.108 2830 57.2
80.0286 0.0964 2380 60.2
10 0.0258 0.0742 2000 56.3
11 0.018 0.073 1854 64.5
12 0.023 0.0603 1680 51.8
14 0.0204 0.0510 1410 51
16 0.0181 0.0445 1190 5.7
18 0.0173 0.0386 1000 48.3
20 0.0162 0.0340 841 46.2
24 0.014 0.0277 707 44.2
30 0.0128 0.0203 541 37.1
35 0.0118 0.0176 437 37.9
40 0.0104 0.0150 389 36
50 0.009 0.011 282 30.3
60 0.0075 0.0092 231 30.5
80 0.0055 0.0070 177 31.4
100 0.0045 0.0055 149 30.3
120 0.0037 0.0046 125 30.5
150 0.0026 0.0041 105 37.9
180 0.0023 0.0033 88 34.7
200 0.0021 0.0029 74 33.6
250 0.0016 0.0024 63 36
270 0.0016 0.0021 53 32.2
325 0.0014 0.0017 44 30.5
400 0.0010 0.0015 37 36
500 0.0010 0.0010 25 25
625 0.0008 0.0008 20 25

WE MAKE SIFTING OPERATIONS BETTER.
8
3. RECEIVING, INSTALLATION & SETUP
This chapter is for the user when identify parts for assembly of the unit upon receiving. For further
information and concerns about received parts, please contact HK Technologies at
[phone].
3.1.1 RECEIVING & PRODUCT HANDLING
When receiving please know that all components have been thoroughly inspected and tested
before leaving our factory. Your unit will arrive in supplier packaging wrap, please inspect for
damage upon arrival looking for damage internally or externally from shipping.
1. Cut open box
2. Remove box
3. Inspect for damage
4. Remove shrink wrap from outside
5. Cut all metal shipping straps
6. Lift unit off shipping lugs and place on floor
3.1.2 DELAYED DELIVERY POLICY
The shipping dates given are approximate, and the company will use its best efforts to meet such
dates. If equipment is requested to be delayed by request of the buyer it may be placed in storage
by the company until the agreed upon time is met for shipping. The company will choose the
shipping method unless the buyer issues specific shipping instructions.
3.1.3 CANCELLATION
An order may be cancelled though with agreements and approval of the office. The buyer may
pay the company reasonable costs for expenses in manufacturing, work in progress, engineering
and cancellation charges.

WE MAKE SIFTING OPERATIONS BETTER.
9
3.2.1 COMPONENTS LIST
Upon arrival use this list to identify each part the unit should be competed with.
Item Part Number Part Identification QTY.
HK-8 HK-12 HK-17
1. 113300000 123300000 133300000 Ultrasonic Screen Frame Buyer’s Request
2. 92000 92000 92000 Ultrasonic Booster 1
3. 21110F 22110F 23110F Product Delivery Funnel 1
4. 11100F 12100F 13100F Housing 1
5. 41309 41309 43109 Mount Spacer 3
6. 51120 52120 53120 Clamp Band 1
7. 17270000 17270000 17600000 Mount 3
8. 232100012 232100012 234100064 Rotary Electric Motor 1
9. 41100 42100 43100 Base Plate 1
10. 41337 41337 - Rubber Foot Spacer 3
11. 17250000 17250000 17210010 Leveling Foot 3
12. 31100 32100 33100 Gasket 1
13. 91000 91000 91000 Ultrasonic Transducer 1
Item Optional Components (Not included) QTY.
14. Chute for Oversize Buyers
Request
14

WE MAKE SIFTING OPERATIONS BETTER.
10
3.3.1 DESCRIPTION OF COMPONENTS
The unit will be custom made and preassembled. Please follow the diagrams in this chapter to
help identify parts for assembly.

WE MAKE SIFTING OPERATIONS BETTER.
11
1
2
3
4
5
6
3.3.2 ULTRASONIC BACK PANEL CONNECTIONS
Back Panel of Power Supply
3.3.2 Connections of the Power Supply
Item Name Function
1 Power Switch Turns the unit on/off
2 IEC/C14 Power
Connector
To connect the power supply to a grounded electrical power source
using the provided detachable line cord
3 Fuse Holder Provides access to replaceable protective fuse
4 User I/O J2 Connector Connects the power supply to a PLC controller for remote control
5 Ground Detect Ter-
minal
Factory installed option used to detect contact between the forn and
an anvul which has been isolated from ground
6 3 Pin RF Controller Connects the power supply to the ultrasonic converter

WE MAKE SIFTING OPERATIONS BETTER.
12
3.4.1 ASSEMBLY OF EQUIPMENT IF NECESSARY
Complete list of assembly instructions listed below.
3.4.1 Assembly of Equipment
Steps Action
1 Disconnect all power to the unit before trying to adjust parts
2 Notice the housing of this unit is prefabricated. Make sure the unit is placed in a clear desig-
nated area after assembly
3 Notice the lock nuts and vibration mounts are to be screwed into the base plate before bolt-
ing to the housing, jam nuts will be tightened and fixed accordingly after installation
4 Start by threading bolt and washer into the feet and base plate, torque bolts after threading.
Set the feet with base plate onto flat surface
5 Thread lock nuts onto each side of the dampeners before threading assembled parts into
base plate
6 Thread the three rods onto the assembled dampeners
7 Thread studs into the ends of the rods
8 Notice on the inside of the housing is a welded plate. The RES-1-2 Rotary Electric Vibrator
must be aligned with the bolt holes. Orient the rotary electric vibrator length wise direction,
vertically, before torquing the vibrator mount fastener and nut assembly to the motor plate.
Make sure the cord is leading out of the hole in the housing before securing the knurled
piece to the housing
9 Now that the vibrator is installed, align the holes of the housing with the studs. Place studs
into the housing holes before tightening the nuts
10 The product delivery funnel should sit on the housing with the spout pointing out of the
hole in the side of the housing and downwards
11 The ultrasonic rim should seat within the funnels out lip with the screen down onto the base
assembly with gaskets around outside edges. The band clamp will be placed around the rim,
funnel lip and housing groove. See section 5.1.2 to find the workings of the clamp and how to
attach and un-attach it
12 Please check that the contact surfaces of the booster to rim and horn to booster are clean of
dirt, dry and polish before connecting
13 An M8 stud should come with the unit, it will be threaded halfway into the hole on the outer
edge of the rim. After threading the stud attach the ultrasonic booster to rim and with a
spanner wrench torque to 180 inch pounds
14 A ½” stud should come with the unit, it will be threaded halfway into the hole at the back of
the booster. After threading the stud attach the ultrasonic horn to the booster and torque to
180 inch pounds
15 The rotary motor switch box will be preassembled and found within the preassembled unit
or it can be found attached to the metal from
16 Connect cord to power before starting

WE MAKE SIFTING OPERATIONS BETTER.
13
3.5.1 ELECTRICAL CONNECTION COMPONENTS DIAGRAM
3.6.1 VARIABLE FREQUENCY DRIVE
Operational Instructions:
• Green Button - Turns machine on
• Red Button - Turns machine off
• Up/Down Arrows - Adjusts operating frequency of the sieve while running (up to 60 Hz)
• Important Note: The VFD come pre-programmed
Additional information can be found in the VFD manual. Contact HK Technologies for more
information.

WE MAKE SIFTING OPERATIONS BETTER.
14
WARNING - Before adjusting eccentric weights, turn off and lock out/tag out energy source
to vibrator.
CAUTION - Do not operate vibrator with end caps removed. Dust accumulation around
vibrator shaft could cause unit to fail.
CAUTION - Adjust both sets of eccentric weights to same setting number mirror images, or
force output will be uneven and damaged vibrator.
WARNING - Vibrator may produce loud noise during operation. See OSHA 1910.95 for
guidelines and required, wear ear protection to avoid impairment or loss of hearing.
CAUTION - Do not allow motor to exceed nameplate rating. If vibrator operates
continuously at above rating damage may occur.
4. OPERATION
The following chapter addresses the operation, mechanical adjustments and material flow of the system.
The system uses several variables that allow the sifter to perform at optimal throughputs such as the
rotary motor and vibration dampeners. Vibratory sifters operate by rotary motors which use counter
weights rotating at high RPM to produce the vibratory force required to move material across the wire
mesh. Paired with the vibration dampening rubber mounts the system works in unison together, while
the rotary motors deliver the centrifugal force outwards the vibration dampeners give the elasticity
that allows the housing to vibrate at the right force frequency. The weights within the motors can be
adjusted to change the force frequency and speed the material travels across the screen. For instructions
on adjusting the force frequency, please refer to section 4.1.1. and for any other questions contact HK
Technologies at [phone].
The following are notices to safety requirements that the reader should take note of before operating and
maintaining the equipment. The reader should know these general warnings:
• Warning - indicates a hazardous situation that if avoided can result in serious death or
injury.
• Caution - indicates a hazardous situation that if avoided can result in minor of moderate
injury.

WE MAKE SIFTING OPERATIONS BETTER.
15
4.1.1 ADJUSTING MECHANICAL OPERATIONS
If mechanical adjustments are required read the following as it instructs how to set weights of the
rotary motors when fine tuning to the ultrasonic pulses. Adjusting weights in the rotary motor
control the rate at which the product moves and feeds around the screen.
Adjusting Mechanical Operations
Step Instruction
1 Disconnect all power of unit before removing motor covers.
2 Remove the motor enclosure if included.
3 Remove the four bolts on the top cover
4 The top two weights maybe loosened by the hex head nut on the outside edge.
5 Notice the weights are fixed around the shaft and can be rotated 360 degrees.
6 For product to move quickly to outside edges align the weights to 100% as shown in Fig. 4.1
7 For product to move slowly to the outside edge rotate the lower weight to 50% as shown in
Fig. 4.2
8 For product to remain at center during cycle rotate the lower weight to 0% as shown in Fig.
4.3
9 After finding the right weight balance that works for your set-up tighten the nut to specified
torque on the weights to hold in place during cycle.
10 Replace the motor cover and tighten nuts to specified torque before turning on motor.
11 Replace motor enclose and connect power to start sieve.
12 *Special Note: Ensure both weights are set to identical weight balances
FIG. 4.1 100% Weight Force FIG. 4.2 50% Weight Force FIG. 4.3 0% Weight Force

WE MAKE SIFTING OPERATIONS BETTER.
16
4.2.1 FEEDING AND MATERIAL FLOW OPERATIONS
The sifter material will be fed into the top of the machine through the inlet hole at the center of
the housing when the vibrator is on. This should be done by plastic tube (not included) over the
outer diameter allowing material to pour in at a steady rate. The screen should be covered with
1/8” deep of the material. The now in-process sifting material should move across screen while
smaller pieces pass through the mesh and large pieces remain on top see Fig. 4.4.
FIGURE 4.4 MATERIAL FLOW DIAGRAM

WE MAKE SIFTING OPERATIONS BETTER.
17
4.3.1 HK ULTRASONIC OPERATION ASSISTANCE
For detailed instructions when using your HK Ultrasonic power supply, see Sect. 6.1 for Front Panel
Controls, Sect. 6.2 for System Modes and Sect. 6.3 for Main Screen Navigation.
4.4.1 OPERATION SEQUENCE
Your HK Technologies vibratory sieve and rotary electric vibrator should work in unison with
your HK Ultrasonic power supply once assembled. For quick and easy navigation please see the
following steps.
Mode/Configuration
Key Test Key Start/Stop
Key

WE MAKE SIFTING OPERATIONS BETTER.
18
Ultrasonic Operation Sequence
Step Action
1 Switch on using power switch at the rear of the unit
2 Press Mode/Configuration Key
3 Pulse on time should flash, then press enter
4 Change on time if needed, then press enter
5 With amplitude flashing press enter
6 Change amplitude if needed, then press enter
7 With Off-Time flashing press enter
8 Change Off-Time if needed press enter
9 Total time flashing 0.00 to run continuously press enter until RDY is displayed
10 Press test button % should read below 10 press Start/Stop the start operation
5. MAINTENANCE & TROUBLESHOOTING
This chapter will cover how to maintain and troubleshoot the unit. It will also cover how to replace
parts and return parts to HK Technologies Inc. for repair. The unit may require periodic inspection
of the screen, gasket sealers, vibratory insulted mounts, rotary motor and damage to the outer
surface. This chapter will provide detailed descriptions and illustrations to help the reader
disassemble and reassemble the unit.

WE MAKE SIFTING OPERATIONS BETTER.
19
5.1.2 GASKET SEAL
Wear to the rubber gasket placed around the unit’s outer rims maybe noticed. Do not hesitate to
replace them if:
• Tearing or wear patterns occur
• Stretched and oversized to rim
• Surface cracks appear
• Does not retain seal during operation
• Product leakage
To replace gasket:
• Make sure power is disconnected
• Remove the band clamps
• Remove the ultrasonic rim from the assembly
• Pry away the gasket away from the sealed surface around the rim, use a screwdriver if
necessary see Fig. 3.2 for gasket location.
• Peel the gasket away from rim
• Apply new gasket once all pieces of the previous gasket have been removed
• Reassemble the unit
1. Disconnect Power 2. Remove Band Clamps
1: Rotate
2: Rotate
3: Pull Apart

WE MAKE SIFTING OPERATIONS BETTER.
20
4. Pry Away the Gasket
5. Peel Away the Gasket
3. Remove Ultrasonic Rim
6. Apply New Gasket to Shown Surfaces
