Yamato CA300 User manual

Cold Trap
Model
CA300/800
Instruction Manual
- First Edition -
Yamato Scientific Co. LTD.
zThank you for purchasing "Cold Trap, CA Series"
of Yamato Scientific Co., Ltd.
zTo use this unit properly, read this "Instruction
Manual" thoroughly before using this unit.
Keep this instruction manual around this unit for
referring at anytime.
WARNING!:
Carefully read and thoroughly understand the
important warning items described in this manual
before using this unit.

Contents
Cautions in Using with Safety................................................................1
•Explanation....................................................................................................................1
•Table of Illustrated Symbols ..........................................................................................2
•Fundamental Matters of “WARNING!” and “CAUTION!”...............................................3
Before Using this unit.............................................................................5
•Requirements for Installation.........................................................................................5
Description and Function of Each Part.................................................8
•Main Unit and Control panel..........................................................................................8
Installation Method..................................................................................9
Operation Method .................................................................................10
•Procedure of Operation...............................................................................................10
•Cooling Curve (Reference Data)................................................................................. 11
Handling Precautions ...........................................................................13
Maintenance Method.............................................................................14
•Daily Inspection and Maintenance ..............................................................................14
Long storage and disposal...................................................................15
•When not using this unit for long term / When disposing............................................15
In the Event of Failure….......................................................................16
After Service and Warranty ..................................................................17
Specification..........................................................................................18
Wiring Diagram......................................................................................19
Replacement Parts Table......................................................................21
Reference...............................................................................................22
•List of Dangerous Substances ....................................................................................22

1
Cautions in Using with Safety
Explanation
MEANING OF ILLUSTRATED SYMBOLS
Various symbols are used in this safety manual in order to use the unit without
danger of injury and damage of the unit. A list of problems caused by ignoring
the warnings and improper handling is divided as shown below.Be sure that you
understand the warnings and cautions in this manual before operating the unit.
WARNING! If the warning is ignored, there is the danger of a problem that
may cause a serious accident or even fatality.
CAUTION! If the caution is ignored, there is the danger of a problem that may
cause injury/damage to property or the unit itself.
Meaning of Symbols
This symbol indicates items that urge the warning (including the caution).
A detailed warning message is shown adjacent to the symbol.
This symbol indicates items that are strictly prohibited.
A detailed message is shown adjacent to the symbol with specific actions not to
perform.
This symbol indicates items that should be always performed.
A detailed message with instructions is shown adjacent to the symbol.
Illustrated Symbols
