HMS eWON Cosy 131 User manual

Ewon Cosy 131
USER MANUAL
UM-0004-00 1.1 en-US ENGLISH

Important User Information
Disclaimer
The information in this document is for informational purposes only. Please inform HMS Networks of any
inaccuracies or omissions found in this document. HMS Networks disclaims any responsibility or liability for any
errors that may appear in this document.
HMS Networks reserves the right to modify its products in line with its policy of continuous product development.
The information in this document shall therefore not be construed as a commitment on the part of HMS Networks
and is subject to change without notice. HMS Networks makes no commitment to update or keep current the
information in this document.
The data, examples and illustrations found in this document are included for illustrative purposes and are only
intended to help improve understanding of the functionality and handling of the product. In view of the wide range
of possible applications of the product, and because of the many variables and requirements associated with any
particular implementation, HMS Networks cannot assume responsibility or liability for actual use based on the data,
examples or illustrations included in this document nor for any damages incurred during installation of the product.
Those responsible for the use of the product must acquire sufficient knowledge in order to ensure that the product
is used correctly in their specific application and that the application meets all performance and safety requirements
including any applicable laws, regulations, codes and standards. Further, HMS Networks will under no circumstances
assume liability or responsibility for any problems that may arise as a result from the use of undocumented features
or functional side effects found outside the documented scope of the product. The effects caused by any direct or
indirect use of such aspects of the product are undefined and may include e.g. compatibility issues and stability
issues.
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US
Table of Contents Page
1 Preface ................................................................................................................................. 3
1.1 About This Document .......................................................................................................3
1.2 Document history ............................................................................................................3
1.3 Related Documents ..........................................................................................................3
1.4 Trademark Information.....................................................................................................3
2 Requirements ...................................................................................................................... 4
2.1 Hardware .......................................................................................................................4
2.2 Software.........................................................................................................................4
3 Access to the Ewon Cosy 131 ............................................................................................. 5
3.1 Assign an IP Address.........................................................................................................5
3.2 Talk2M Account Configuration ...........................................................................................5
3.3 Access the Web Configuration Interface...............................................................................7
4 Quick Launch Wizard........................................................................................................... 8
4.1 System Wizard.................................................................................................................8
4.2 Internet Wizard ............................................................................................................. 10
4.3 Talk2M Wizard .............................................................................................................. 17
5 Home Section .................................................................................................................... 19
6 Ready to establish the remote connection to your eWON............................................. 21
7 DI Config Wizard................................................................................................................ 22
7.1 Remote Access Control ................................................................................................... 22
7.2 DI Alarm Notification ...................................................................................................... 23
8 Wan fallback...................................................................................................................... 25
9 Diagnostic and Setup ........................................................................................................ 27

This page intentionally left blank

Preface 3 (28)
1 Preface
1.1 About This Document
This document presents the features of the Ewon Cosy 131 and explains briefly the steps to take
to get a functional Cosy 131.
For additional related documentation and file downloads, please visit www.ewon.biz/support.
1.2 Document history
Version Date Description
1.0 2018-05-03 First release
1.1 2018-08-29 Added: NTP Client / Server
Added: Anybus Bolt Configuration
Added: Easy APN
1.3 Related Documents
Document Author Document ID
eBuddy HMS AUG-0063-00
Talk2M HMS AUG-0028-00
eCather Mobile HMS AUG-0072-00
M2Web HMS AUG-0058-00
Wan Fallback HMS KB-0286-00
1.4 Trademark Information
Ewon®is a registered trademark of HMS Industrial Networks SA. All other trademarks mentioned
in this document are the property of their respective holders.
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Requirements 4 (28)
2 Requirements
2.1 Hardware
This guide presents the features of the Cosy 131 which is used for remote access your devices.
2.2 Software
The Cosy 131 is configured through its web interface which is accessible with any modern web
browser. The recommended platforms are:
• Firefox 15 and higher.
• Chrome 16 and higher.
• Safari 11 and higher.
• Edge 13 and higher.
eBuddy
The eBuddy application assists with initial IP address configuration for the Ewon Cosy 131 as well
as maintenance tasks such as upgrading firmware, creating/restoring backups...
Download eBuddy.
eCatcher
The companion tool eCatcher is required if you wish to connect the Ewon Cosy 131 to the
Talk2M infrastructure. It also allows to create and set up a Talk2M account.
To install eCatcher, you will need the administrator rights on the computer.
Download eCatcher.
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Access to the Ewon Cosy 131 5 (28)
3 Access to the Ewon Cosy 131
In this section, we will explain the following actions:
1. Assign an IP address to your Ewon Cosy 131, different than the default IP address.
2. Register your Ewon Cosy 131 to a Talk2M account.
3. Access the web interface of the Ewon Cosy 131 to begin its configuration.
3.1 Assign an IP Address
You can establish the first communication with the Ewon Cosy 131 using the eBuddy application
(check Software, p. 4 for more details about eBuddy).
By default, the IP address of the Ewon Cosy 131 is set to 10.0.0.53 which in some circumstances
might need to be changed.
To change the IP address of the Ewon Cosy 131, proceed as follows:
1. Connect the port labeled as LAN (port #1) of the Ewon Cosy 131.
This can be done either point-to-point (computer <> Ewon Cosy 131) or through a network
if the default IP of the Cosy 131 will not conflict with another connected device.
2. Start the eBuddy application.
The application scans through the Ethernet adapter network, identifies the connected Ewon
devices and display their IP address, subnet mask and serial number.
eBuddy also allows the modification of the default IP address without necessarily being in
the same network range.
3. Optional: Highlight the row representing the device to be modified.
4. Click on the button Set IP from the top bar menu.
5. Indicate the serial number of the Ewon Cosy 131 that you want to modify.
►If you went through step #3, the serial number is provided automatically.
6. Click Next.
7. Enter the <new IP address> and its <subnet mask>.
→ By clicking Next, eBuddy sends the commands to the Ewon Cosy 131 to change its IP
address and to reboot.
8. Once the reboot completes, you can access the Ewon Cosy 131 using its new LAN IP address.
3.2 Talk2M Account Configuration
Talk2M offers a secured and easy way to set up a remote connection over the Internet.
To allow the remote access, you need to link the Ewon Cosy 131 to the Talk2M infrastructure,
more specifically to a Talk2M account.
To configure the Talk2M account:
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Access to the Ewon Cosy 131 6 (28)
1. Launch eCatcher and log into your Talk2M account.
►To download and install eCatcher, please refer to eCatcher, p. 4
►In case you do not have a Talk2M account yet, click on Create a Free+ Account and
follow the prompts on the screen. Once you’ve created the Talk2M account, an email
will be sent with the activation link and instructions.
2. Click on the icon +Add to add the Ewon Cosy 131 to your Talk2M account.
3. Follow the screen prompts.
►Be aware that some options require the full telephone number, county code included
4. Copy the <Activation Key> to the clipboard in the last step of the wizard. You will need it
later during the Talk2M wizard of the Ewon Cosy 131 configuration.
The Ewon Cosy 131 is now successfully listed in the <Ewon list> of eCatcher.
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Access to the Ewon Cosy 131 7 (28)
3.3 Access the Web Configuration Interface
The configuration of the Ewon Cosy 131 can be done using its embedded web interface.
As your computer is connected to a LAN port of the Ewon Cosy 131, open an Internet browser
and enter the LAN IP address of the Cosy 131 in to the address field.
If the computer is not in the same network address range as the Ewon Cosy 131, its web pages
can be reached using the EZ DHCP feature of the eBuddy utility. For more information, refer to.
eBuddy from the Related Documents, p. 3
Before beginning the configuration of the Ewon Cosy 131, authentication is required. The default
login and password are both adm.
For security reasons, you are required to change the default password. The password can
be changed through the System Wizard described below.
At first boot or after a reset level 2 of the Ewon Cosy 131, and after successfully logging in, a
prompt will appear to set the interface language.
After you have selected the interface language, the Ewon Cosy 131 will propose a configuration
wizard which leads to a quick configuration of the system and communication settings. On later
connections, the configuration wizard is accessible through the Wizards button in the upper right
corner.
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 8 (28)
4 Quick Launch Wizard
Fig. 1 Quick Launch Wizard Button
The Quick launch wizard will guide you through the different setup wizards to configure your
Ewon Cosy 131 for remote connection trough Talk2M:
• The System Wizard configures basic system settings such as the date & time and the default
username & password.
• The Internet Wizard configures the WAN communication settings.
• The Talk2M Wizard establish a VPN between the Ewon Cosy 131 and the Talk2M
infrastructure.
4.1 System Wizard
The System Wizard configures basic system settings.
On the first screen of the System Wizard, enter the Ewon name.
Fig. 2 System Wizard User Setup
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 9 (28)
For security reasons, you are required to change the default password for the adm user.
On the second screen of the System Wizard:
• Configure the accurate <date and time> settings. For Talk2M communication, it is
imperative that the date of the Ewon Cosy 131 is correct.
• Configure the <Timezone> settings:
►click either on the arrow or the map icon.
• Set the URL of the remote <NTP server>. By default, ntp.talk2m.com is set. This field is
shown only if Update clock via NTP is selected.
• The <time interval> used to update the clock. This field is shown only if Update clock via
NTP is selected.
Click Next to proceed to the next screen.
Fig. 3 System Wizard Date and Time
The third screen of the System Wizard shows the standard attribution of the four ports Ethernet
switch.
The ports #1, #2, #3, will be dedicated to LAN — localaccess — network and port #4 will be
dedicated to WAN — Internet access — network.
The attribution of a port can be easily recognized by its LED color:
• Orange for a WAN port.
• Green for a LAN port.
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 10 (28)
Fig. 4 System Wizard LAN/WAN Configuration
Click Next to finish the System Wizard settings.
Fig. 5 System Wizard Diagnosis
4.2 Internet Wizard
The Internet Wizard configures the Internet settings for the Ewon Cosy 131. The <Interface> field
allows the selection of the WAN interface used for the Internet connection:
•Ethernet WAN connection
•Cellular Modem
•Wi-Fi Connection
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 11 (28)
4.2.1 Ethernet WAN Configuration
1. Select the Ethernet Internet connection.
Fig. 6 Internet Wizard Connection Setup
2. Click Next to continue the WAN interface configuration.
3. Select the appropriate method how the Ewon Cosy 131 is supposed to receive its IP address,
according to the LAN network configuration: Static,BootP or DHCP.
Select DHCP from the dropdown to receive an IP automatically from the LAN network.
Fig. 7 Internet Wizard Ethernet WAN Connection Setup
4. Click Next to proceed to the next screen.
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 12 (28)
5. The Internet connection test is enabled by default, it allows the Ewon Cosy 131 to verify the
Internet connection.
Uncheck this option if this network uses a proxy server or if port 80 is closed for outbound
connections.
Fig. 8 Internet Wizard Validation
6. Click Next to apply the configuration changes.
→ Once the wizard completes successfully, the Ewon Cosy 131 is connected to the
primary WAN network.
Fig. 9 Internet Wizard Test
4.2.2 Cellular Network Configuration
1. Select Modem Connection if your Ewon Cosy 131 embeds a cellular modem.
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 13 (28)
2. Select the type of trigger: to keep the Cosy 131 connected to Internet permanently or select
Send SMS to activate to activate the remote access only after receiving an SMS.
►Maintain connection: the Ewon Cosy 131 is permanently connected to Internet.
►Send SMS to activate: the Ewon Cosy 131 connects to the Internet only after you sent
a “wake-up” sms.
Fig. 10 Internet Wizard Connection Setup
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 14 (28)
3. Configure the settings of the SIM card:
–<PIN code>
–<Country> where the Ewon Cosy 131 will be located, the operator
–<Operator>
–<APN list>, the address of the operator.
The Ewon Cosy 131 will automatically propose an APN based on the value of the
<Country> and <Operator> fields.
If the APN is not automatically proposed, you will need to set a Custom APN and type
the desired APN.
Be aware that some operators have different APN for the same local area.
– If required, enter the APN <Username> and <Password>, otherwise leave this field
empty.
►Double check with your operator to enter the correct information
►In case of specific connection settings such as network type or preferred provider;
check the <Show advanced options> box.
Fig. 11 Internet Wizard GSM Modem
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 15 (28)
4. Click Next to apply the configuration changes.
→ Once the wizard completes successfully, the Ewon Cosy 131 is connected to Internet
through its cellular WAN network.
Fig. 12 Internet Wizard Test
4.2.3 Wi-Fi Network Configuration
1. Select the connectivity conditions accordingly, in this case : WiFi INTERNET connection.
Fig. 13 Internet Wizard Connection Setup
2. Click Next to proceed to the next screen.
3. Provide all information related to Wi-Fi connection configuration:Select the Wi-Fi network
to connect and enter the password.
4. Keep the DHCP default settings for the Wifi WAN Connection and DNS, unless otherwise
required by the local IT department.
5. In case of specific proxy connection settings; check the Connect to Talk2M through proxy
checkbox
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 16 (28)
Click Next to apply the configuration changes.
Fig. 14 Internet Wizard Wifi Setup
Click Next to proceed to the next screen.
• The Internet connection test is enabled by default, it allows the Cosy 131 to verify the
Internet connection. If this network uses a proxy server or if port 80 is closed for outbound
connections, uncheck this option.
Click Next to apply the configuration changes.
Fig. 15 Internet Wizard Wifi Validation
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 17 (28)
4.3 Talk2M Wizard
The Talk2M Wizard, configures the VPN connection between the Cosy 131 and your Talk2M
account on the Talk2M server..
• On the first screen of the Talk2M Wizard, select Register with Activation Key option
• Paste the Activation Key .
Click Next to move forward to the next screen.
Fig. 16 Talk2M Wizard Activation Key
Alternately, it is possible to register with the eWON Name option:
• Click on Register with eWON Name
• Enter the Talk2M name of the Cosy 131, and a valid Talk2M account user credentials.
Click Next to move forward to the following screen.
Fig. 17 Talk2M Wizard Registration Name
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US

Quick Launch Wizard 18 (28)
If the network used for Internet access apply a proxy server:
• Check the Enable checkbox in the Connect via HTTP Proxy settings
• Enter the appropriate information for the proxy server
Click Next to move forward to the next screen.
Fig. 18 Talk2M Wizard Proxy Configuration
This Wizard connects to the Talk2M server and retrieve the VPN settings for the Cosy 131 linked
to your account. The Wizard also check UDP and TCP connection to find the best suitable option
for this eWON. If the wizard completes successfully, the Cosy 131 is now configured for Remote
Access through Talk2M. If the wizard fails, the Diagnostic and Setup, p. 27 section will give
additional troubleshooting information.
Fig. 19 Talk2M Wizard Validation
Ewon Cosy 131 User Manual UM-0004-00 1.1 en-US
