HNP Mikrosysteme mzr-2509 Ex User manual

Operating manual for micro annular gear pump
mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
HNP Mikrosysteme GmbH
Bleicherufer 25
D-19053 Schwerin (Germany)
Telephone: [phone]
Telefax: +49 385/52190-333
E-mail: [e-mail]
http://www.hnp-mikrosysteme.de
Last update: October 2016

Impressum
Original instructions
Copyright
HNP Mikrosysteme GmbH
Bleicherufer 25
D-19053 Schwerin
All rights, including translation, reserved.
Without prior explicit written permission of HNP Mikrosysteme GmbH no part
of this manual may be, copied, reproduced or processed.
This manual has been prepared with care. HNP Mikrosysteme does assume no
liability for any errors in this manual and resulting consequences. Likewise, no
liability is assumed direct or subsequent damages arising from an incorrect use
of the devices.
While using micro annular gear pumps, the relevant standards regarding the
specifications of this manual have to be followed.
Subject to change without notice.

Contents Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technical data subject to change without prior notice! i
Contents
1General Information 1
1.1 Use 1
1.2 Pump model designation 2
1.3 Technical data of the micro annular gear pumps 3
1.4 Measurements and flow charts of the mzr-2509 Ex
pump 5
1.5 Measurements and flow charts of the mzr-2909 Ex
pump 6
1.6 Measurements and flow charts of the mzr-4609 Ex
pump 7
1.7 Measurements and flow charts of the mzr-7209 Ex
pump 8
1.8 Technical data of the Ex-motor 9
1.9 Technical data of the altenativ brushless DC Ex-motor
(X2 version) 12
2Safety instructions 16
2.1 Labeling of instructions in the operation manual 16
2.2 Staff qualification and training 16
2.3 Safety conscious work 17
2.4 Safety instructions for the operator 17
2.5 Safety instructions for maintenance, inspection and
assembly 18
2.6 Unauthorized modification and original spare parts 18
2.7 Improper mode of operation 18
2.8 General safety instructions 19
3Transport and storage 20
3.1 Shipping pumps and protection measures 20
3.2 Transport damage 20
3.3 Interim storage 20
3.4 Conservation for storage after operation 20
4Description of the pump 21
4.1 Principle of the micro annular gear pumps 21
4.2 Construction 23
4.3 Materials and liquids 23
4.4 Fluidic connectors 24
5Modular system 25
5.1 Fluidic seal module 25
5.2 Heat insulation modul 28
5.3 Fluidic heating- and cooling module 29
5.3.1 Construction materials of heating- and cooling
module 31
5.4 Gas-tight seal module 31

Contents Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
ii Technical data subject to change without prior notice! Last update: October 2016
6Mounting / Installation 32
6.1 Check before installation 32
6.2 Details place of operation 32
6.3 Mounting of the micro annular gear pump 32
6.4 Electrical Connections 33
6.5 Assembly instruction for tubing and accessories 33
6.6 Filter selection and use 35
6.7 Requirements for motor controller 36
6.8 Operation with motion controller S-HD-KL 37
6.9 Connection of the micro annular gear pump with S-
G05 40
6.9.1 Startup with potentiometer 42
6.9.2 Startup with external 0-10 V signal 43
6.9.3 Startup with an external 0(4)-20 mA current signal 44
6.9.4 Startup with external potentiometer 46
6.9.5 Startup with the RS-232 interface 47
6.10 Installation of the software »Motion Manager« 48
7Start up / Shut down 49
7.1 Prepare for start up 49
7.2 First start of a mzr-pump 49
7.3 Re-start after dry run 49
7.4 Operation of the micro annular gear pumps in
different temperature ranges 50
7.5 Monitoring of operation in the temperature range
T5, T6 51
7.6 Flushing procedure after use 51
7.7 Shutdown of the micro annular gear pump 54
7.7.1 Conservation 56
7.7.2 Dismantling of the system 57
7.8 Trouble shooting 58
7.9 Return of the micro annular gear pump to the
manufacturer 58
8Maintenance and service 59
8.1 Micro annular gear pumps 59
8.2 Metal bellow-type coupling 59
8.3 Ex-Motor 59
9Problems and their removal 60
10 Software »Motion Manager« 63
10.1 Command mode 63
10.2 Programming of motion controller 65
10.3 Transfer of mcl-files to motor controller 65
11 Accessories 83
12 Non-warranty 83

Contents Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technical data subject to change without prior notice! iii
13 EC Directive 84
13.1 Electromagnetic Compatibility (EMC) 85
1.1.1 EMC Directive and Standards 85
1.1.2 Information on use as intended 86
14 Declarations of conformity 88
15 Contact persons 104
16 Legal information 105
17 Safety information for the return of already
employed micro annular gear pumps and
components 106
17.1 General information 106
17.2 Declaration of liquids in contact with the micro
annular gear pump 106
17.3 Shipment 106
18 Declaration of media in contact with the micro
annular gear pump and its components 107
19 Appendix 108

1General Information Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technische Änderungen ohne Vorankündigung vorbehalten. 1
1General Information
Please read the »manual for micro annular gear pump« carefully before initial
operation of the pump. The manuals for motor and control have to be seen as
part of the pump manual. For missing manuals please call your distributor or
HNP Mikrosysteme directly. Manuals are also available to download at
www.hnp-mikrosysteme.de.
In case assistance is needed, please indicate the pump type visible on the
housing.
1.1 Use
The micro annular gear pumps described in this manual are suitable for
continuous delivery and discrete dosage of water, watery solutions, solvents,
methanol, oils, lubricating liquids, paints and varnishes as well as many other
liquids.
!
If you intend to treat any aggressive, poisonous, or radioactive liquids, you
must conform to safety measures as according to the regulations in force. Any
project concerning handling of corrosive liquids should be previously discussed
with the pump manufacturer.
!
The micro annular gear pumps must not be used for invasive medical
applications, in which the liquid having had contact with the pump is re-
introduced to the body.
!
Micro annular gear pumps exclusively are provided for use in the industrial
area. A private use is excluded.
!
The micro annular gear pumps must not be used in aircrafts and spacecrafts or
other vehicles without prior consent of the manufacturer.
!
Data concerning resistance of the pumps to the manipulated liquids have been
elaborated according to the best of HNPM's knowledge. However, operating
parameters varying from one application case to another, no warranty for this
information can be given.
!
Information given in this manual does not release the customer from the
personal obligation to check the integrity, correct choice and suitability of the
pump for the intended use. The use of the micro annular gear pumps should
be conform with technical norms and regulations in force.
If you wish to receive more information than comprised in this manual please
contact directly HNP Mikrosysteme.

1General Information Operation manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
2Technische Änderungen ohne Vorankündigung vorbehalten Last update: October 2016
1.2 Pump model designation
This manual is valid for the micro annular gear pump mzr-2509 Ex,
mzr-2909 Ex, mzr-4609 Ex and mzr-7209 Ex manufactured by HNP
Mikrosysteme GmbH, Bleicherufer 25, D-19053 Schwerin, Germany.
The bottom line of this manual shows issue and date of issue of the manual.
The micro annular gear pumps described in the operation manual are conform
to the applicable EC standards and are permitted to bear the CE mark.

1General Information Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technische Änderungen ohne Vorankündigung vorbehalten. 3
1.3 Technical data of the micro annular gear pumps
mzr-2509 Ex,
mzr-2509X2 Ex
mzr-2909 Ex,
mzr-2909X2 Ex
mzr-4609 Ex,
mzr-4609X2 Ex
mzr-7209 Ex,
mzr-7209X2 Ex
Unit
[UOM
Explosion-protection
Ex-certification CE II 2G c IIC
T5 X
CE II 2G c IIC
T5 X
CE II 2G c IIC
T5 X
CE II 2G c IIC
T4 X
Temperature class T5 T5 T5 T4
Ambient temperature 0 … +40 0 … +40 0 … +40 0 … +40 °C
Installation place
Ex-area zone 1, 2
Ex-area zone 1, 2
Ex-area zone 1, 2
Ex-area zone 1, 2
Protection categories
c, d (Ex-motor) c, d (Ex-motor) c, d (Ex-motor) c, d (Ex-motor)
Measurements and weight
Pump head diameter 23 23 23 35 mm
Length (without fluid
connector)
approx. 278 approx. 278 approx. 281 approx. 294 mm
Width
75
75
75
75
mm
Height 85 85 85 85 mm
Weight approx. 2500 approx. 2500 approx. 2500 approx. 2700 g
Weight (X2 version)
approx. 2700
approx. 2700
approx. 2700
approx. 2900
g
Specification
Flow rate (by 0 bar) 0,0015 – 7 0,003 – 14 0,012 - 56 0,048 – 225 ml/min
Flow rate (by 0 bar)
X2 Version
0,0015 – 6 0,003 – 12 0,012 - 48 0,048 – 192 ml/min
Smallest dosage volume 0,25 0,5 2 5 µl
Displacement volume 1,5 3 12 48 µl
Internal volume 84 85 109 525 µl
Operating pressure range
by Viskosity 1 mPas
2 4 8 30 bar
Operating pressure range
by Viskosity 16mPas
5 5 10 30 bar
Max. inlet pressure 5 5 5 5 bar
Speed range 1 – 4.700 1 – 4.700 1 – 4.700 1 – 4.700 * U/min
Speed range
X2 version
1 – 4.000 1 – 4.000 1 – 4.000 1 – 4.000 * U/min
viscosity range of pumpable
liquids
0,3 – 5 000
(10 000 mPas **)
0,3 – 5 000
(10 000 mPas **)
0,3 – 5 000
(10 000 mPas **)
0,3 – 5 000
(10 000 mPas **)
mPas
Pulsation
< 6
< 6
< 6
< 6
%
Liquid temperature -5 … +40
(-20 … +130 **)
-5 … +40
(-20 … +130 **)
-5 … +40
(-20 … +130 **)
-5 … +40
(-20 … +130 **)
°C
Ambient temperature 0 … +40 0 … +40 0 … +40 0 … +40 °C
Storage temperature 0 … +40 0 … +40 0 … +40 0 … +40 °C
*) Values are specified for water with viscosity 1 mPas. Differing specifications on request
**) Differing specifications on request
Table 1 Technical data micro annular gear pumps mzr-2509 Ex / mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Warning The material properties of a liquid (e.g. viscosity, lubricating property, particle
content, corrosiveness) impacts the technical data and the lifetime of pumps.
Under appropriate conditions the characteristic values may be increased or
decreased.

1General Information Operation manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
4Technische Änderungen ohne Vorankündigung vorbehalten Last update: October 2016
Warning If you intend to operate the pump out of the range of the above given
specification, please consult the manufacturer. Modifications may be necessary
to ensure successful operation. Otherwise the pump or the system may be
damaged seriously.

1General Information Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technische Änderungen ohne Vorankündigung vorbehalten. 5
1.4 Measurements and flow charts of the mzr-2509 Ex pump
Figure 1 Measures of the micro annular gear pump mzr-2509 Ex
Liquid water Liquid methanol
0
2
4
6
8
10
012345
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 1 mPas
Liquid water
0
2
4
6
8
10
0 1 2 3 4 5
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 0,58 mPas
Liquid methanol
Liquid oil, 16 mPas Liquid oil, 100 mPas
0
2
4
6
8
10
010 20 30
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 16 mPas
Liquid oil
0
2
4
6
8
10
010 20 30
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 100 mPas
Liquid oil
figure 2 Flow charts of the micro annular gear pump mzr-2909 Ex

1General Information Operation manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
6Technische Änderungen ohne Vorankündigung vorbehalten Last update: October 2016
1.5 Measurements and flow charts of the mzr-2909 Ex pump
Figure 3 Measures of the micro annular gear pump mzr-2909 Ex
Liquid water Liquid methanol
0
5
10
15
20
012345
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 1 mPas
Liquid water
0
5
10
15
20
012345
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 0,58 mPas
Liquid methanol
Liquid oil, 16 mPas Liquid oil, 100 mPas
0
5
10
15
20
010 20 30
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 16 mPas
Liquid oil
0
5
10
15
20
010 20 30
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 100 mPas
Liquid oil
figure 4 Flow charts of the micro annular gear pump mzr-2909 Ex

1General Information Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technische Änderungen ohne Vorankündigung vorbehalten. 7
1.6 Measurements and flow charts of the mzr-4609 Ex pump
Figure 5 Measures of the micro annular gear pump mzr-4609 Ex (UOM: mm)
Liquid water Liquid methanol
0
10
20
30
40
50
60
70
80
0 2 4 6 8 10
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
609
Speed [rpm]
Viscosity 1 mPas
Liquid water
0
10
20
30
40
50
60
70
80
02 4 6 8 10
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
609
Speed [rpm]
Viscosity 0,58 mPas
Liquid methanol
Liquid oil, 16 mPas Liquid oil, 100 mPas
0
10
20
30
40
50
60
70
80
010 20 30 40 50
Differenzdruck p [bar]
Volumenstrom Q [ml/min]
4700
4000
3000
2000
1000
Drehzahl n [U/min]
Viskosität 16 mPas
Medium Öl
0
10
20
30
40
50
60
70
80
010 20 30 40 50
Differenzdruck p [bar]
Volumenstrom Q [ml/min]
4700
4000
3000
2000
1000
Drehzahl n [U/min]
Viskosität 100 mPas
Medium Öl
figure 6 Flow charts of the micro annular gear pump mzr-4609 Ex

1General Information Operation manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
8Technische Änderungen ohne Vorankündigung vorbehalten Last update: October 2016
1.7 Measurements and flow charts of the mzr-7209 Ex pump
Figure 7 Measures of the micro annular gear pump mzr-7209 Ex
Liquid water Liquid methanol
0
50
100
150
200
250
300
010 20 30 40
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
09
Speed [rpm]
Viscosity 1 mPas
Liquid water
0
50
100
150
200
250
300
010 20 30 40
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
09
Speed [rpm]
Viscosity 0,58 mPas
Liquid methanol
Liquid oil, 16 mPas Liquid oil, 100 mPas
0
50
100
150
200
250
300
010 20 30 40
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 16 mPas
Liquid oil
0
50
100
150
200
250
300
010 20 30 40
Differential pressure [bar]
Flow rate [ml/min]
4700
4000
3000
2000
1000
Speed [rpm]
Viscosity 100 mPas
Liquid oil
figure 8 Flow charts of the micro annular gear pump mzr-7209 Ex

1General Information Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technische Änderungen ohne Vorankündigung vorbehalten. 9
1.8 Technical data of the Ex-motor
The micro annular gear pumps mzr-2509 Ex, mzr-2909 Ex, mzr-4609 Ex,
mzr-7209 Ex are equipped with an explosion-proof DC-motor. The parameters
of the motor are described in Table 2. The speed of the motor can be
controlled with the optional motion controller S-HD-KL. One of the motor’s
features is a highly dynamic behavior. For operation it is recommended to use a
power source of 24 V (with a power rating of 5 A).
The motor of the pumps is corresponding to the applicable EC standards. The
confirmations according to EC 94/9/EG as well as of EC conformity are given.
Measurements
Diameter of motor casing 70 mm
Length of motor casing
210 mm
Weight approx. 1,8 kg
General data
Type
EXR-1.24HEDL-L10
Manufacturer Edelweiss Actuators Srl,
Via Padergnone 21
I-24050 Zanika BG
Italy
Distribution / Service Mattke Antriebstechnik
Leinenweberstraße 12
D-79108 Freiburg
Germany
Test body 0948
Number of certificate
TÜV-A 11ATEX0006X
Certification EN60079-0, EN60079-1, EU-
Richtlinie 94/9/EG, Anhang III
Ex-certification II 2G Ex d IIC T5 Gb
Installation place Ex-area zone 1, 2
Specification
Nominal voltage 24 V DC
Max. continuos current by
Temperature range T6
2 A
Max. continuos torque 75 mNm
Max. power
53 W
Max. dissipation 11 W
No load speed by 24 V 4700 rpm
Speed range
1 – 4700 rpm
Length of the cable 10 m
External compensation of potential wires:
4 mm² flexible
6 mm² single-wire
Protective class according EN60529 IP54
Operation temperature range -20 … +45 °C
Table 2 Technical data Ex-motor

1General Information Operation manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
10 Technische Änderungen ohne Vorankündigung vorbehalten Last update: October 2016
Parameter
mzr-2509 Ex
mzr-2909 Ex
mzr-4609 Ex
mzr-7209 Ex
Max. Peak current 800 mA 800 mA 900 mA 2000 mA
Max. Continuos current 600 mA 600 mA 700 mA 1800 mA
max. Acceleration
550 U/s²
550 U/s²
550 U/s²
550 U/s²
Table 3 Programming current parameters for mzr-2509 Ex, mzr-2909 Ex, mzr-4609 Ex and mzr-7209 Ex
Wire
Function
brown motor +
blue motor -
yellow/green screening / PE
red Vcc (5 VDC)
blue SGND
pink channel A neg.
grey channel A
yellow
channel B neg.
green channel B
brown channel O neg. (index)
white
channel O (index)
table 4 Pin configuration motor cable (10 Lead of cable) valid as of September 2012
Wire
Function
white motor +
brown motor -
yellow/green
screening / PE
red Vcc (5 VDC)
blue SGND
pink
channel A neg.
grey channel A
violet channel B neg.
black channel B
rot/blue channel I neg. (index)
pink/grey channel I (index)
Table 5 Pin configuration motor cable (10 Lead of cable) valid until September 2012

1General Information Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technische Änderungen ohne Vorankündigung vorbehalten. 11
4 x M8, 8 mm deep
PUR - Drag chain cable
Type S200-Length 5...10 m
Figure 9 Measurements of the motor (standard cable length 10 m)
The motor is delivered with a digital encoder type HEDL5540 with line
driver and 500 counts per revolution.
Encoder
Max. voltage Vcc 5 VDC ± 10 %
Number of channels
3 (A, B, O)
Counts per revolution and channel 500
Output signal at Vcc = 5 VDC EIA standard RS422
used driver: DS26LS31
Output current max. 20 mA
Phase shift Φ(nominal) 90°
Operating temperature range
0 ... +40°C
Table 6 Technical data encoder

1General Information Operation manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
12 Technische Änderungen ohne Vorankündigung vorbehalten Last update: October 2016
1.9 Technical data of the altenativ brushless DC Ex-motor (X2 version)
The micro annular gear pumps mzr-6359X2 Ex and mzr-7259X2 Ex are
equipped with a alternativ explosion-proof brushless DC-motor. The parameters
of the motor are described in Table 2. The speed of the motor can be
controlled with the internal motion controller. One of the motor’s features is a
highly dynamic behavior. For operation it is recommended to use a power
source of 24 V (with a power rating of 5 A).
The motor of the pumps is corresponding to the applicable EC standards. The
confirmations according to EC 94/9/EG as well as of EC conformity are given.
Measurements
Diameter of motor casing 70 mm
Length of motor casing
285 mm
Weight approx. 2,3 kg (without cable)
General data
Type
EXR-32.24-MC3-L10
Manufacturer Edelweiss Actuators Srl,
Via Padergnone 21
I-24050 Zanika BG
Italy
Distribution / Service Mattke Antriebstechnik
Leinenweberstraße 12
D-79108 Freiburg
Germany
Test body 0948
Number of certificate
TÜV-A 11ATEX0006X
Certification EN60079-0, EN60079-1, EU-
Richtlinie 94/9/EG, Anhang III
Ex-certification II 2G Ex d IIC T5 Gb
Installation place Ex-area zone 1, 2
Specification
Nominal voltage
24 V DC
Max. continuos current by
Temperature range T5
2 A
Max. continuos torque 85 mNm
Max. power
53 W
Max. dissipation 11 W
No load speed by 24 V 4200 rpm
Speed range
1 – 4000 rpm
Length of the cable 10 m
External compensation of potential wires:
4 mm² flexible
6 mm² single-wire
Protective class according EN60529 IP54
Operation temperature range -20 … +40 °C
table 7 Technical data Ex-motor for mzr-2509X2 Ex, mzr-2909X2 Ex, mzr-4609X2 Ex und mzr-7209X2 Ex

1General Information Operating manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
Last update: October 2016 Technische Änderungen ohne Vorankündigung vorbehalten. 13
Parameter
mzr-2509X2 Ex
mzr-2909X2 Ex
mzr-4609X2 Ex
mzr-7209X2 Ex
Max. Peak current 700 mA 700 mA 800 mA 1700 mA
Max. Continuos current 550 mA 550 mA 650 mA 1500 mA
max. Acceleration
500 U/s²
500 U/s²
500 U/s²
500 U/s²
Tabelle 1 Programming current parameters for mzr-2509X2 Ex, mzr-2909X2 Ex, mzr-4609X2 Ex und mzr-7209X2 Ex
Wire
Function
Cable cross-section
brown 24 VDC 0,5 mm²
blue GND 0,5 mm²
yellow/green screening / PE 0,5 mm²
red 3 IN 0,14 mm²
blue n.c. 0,14 mm²
white Fault out 0,14 mm²
pink n.c. 0,14 mm²
grey
AGND
0,14 mm²
yellow RxD / IN CAN_L 0,14 mm²
green TxD / IN CAN_H 0,14 mm²
brown
ANIN
0,14 mm²
table 8 Pin configuration motor cable (12 Lead of cable)

1General Information Operation manual mzr-2509 Ex/ mzr-2909 Ex / mzr-4609 Ex / mzr-7209 Ex
14 Technische Änderungen ohne Vorankündigung vorbehalten Last update: October 2016
Figure 10 Measurements of the motor (standard cable length 10 m)
